How difficult is it to bend an axle?

Here's my situation. I bought some wheels from a friend a year ago. I took the old rear and hung it up in the garage. The frame is now becoming my trainer frame and the new wheels went on a new frame. I stuck the old rear on the trainer frame and discovered that the axle is bent. I don't remember this happening while I was riding the wheel, so it must have occurred while it was hanging in the garage. Granted, I've moved since then, so maybe it got banged around, but is this likely or did I just miss it being bent when I originally took the wheel off?
UnsafeAlpine is offline   Reply With Quote
Old 02-22-09, 02:02 PM   #2
bikeman715
Senior Member

bikeman715's Avatar

Join Date: Mar 2008
Location: Salinas , Ca.
Bikes: Bike Nashbar AL-1 ,Raligh M50 , Schwinn Traveler , and others
Posts: 2,402
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
axles can bent easy if you use to much torque on them or if the bike has fall over or you tighten the trainer to much to hold it in.just to name a few.
bikeman715 is offline   Reply With Quote
Old 02-22-09, 02:12 PM   #3
dabac
Senior Member

Join Date: Mar 2008
Bikes:
Posts: 5,360
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Quote:
Originally Posted by UnsafeAlpine View Post
..I stuck the old rear on the trainer frame and discovered that the axle is bent. I don't remember this happening while I was riding the wheel, so it must have occurred while it was hanging in the garage.
That is just plain impossible. The loads on a stored bike are so much smaller (for any reasonable method of storage) as compared to the riding loads. It must have happened at another occasion.
dabac is offline   Reply With Quote
Old 02-22-09, 02:27 PM   #4
UnsafeAlpine
Domestic Domestique
Thread Starter

UnsafeAlpine's Avatar

Join Date: Dec 2007
Location: Michigan
Bikes: Brand New Old Catamount! Schwinn Homegrown, Specialized FSR, Salsa Vaya, Salsa Chile Con Crosso
Posts: 1,742
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by dabac View Post
That is just plain impossible. The loads on a stored bike are so much smaller (for any reasonable method of storage) as compared to the riding loads. It must have happened at another occasion.
Would it be possible to damage it in the move? It's just weird that I didn't notice anything askew when I took the wheel off initially.
UnsafeAlpine is offline   Reply With Quote
Old 02-22-09, 02:29 PM   #5
operator
cab horn

Join Date: Jun 2004
Location: Toronto
Bikes: 1987 Bianchi Campione
Posts: 28,306
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Not possible. You bent it while riding.
operator is offline   Reply With Quote
Old 02-22-09, 02:47 PM   #6
dabac
Senior Member

Join Date: Mar 2008
Bikes:
Posts: 5,360
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Quote:
Originally Posted by UnsafeAlpine View Post
Would it be possible to damage it in the move?
Possible - yes. Probable - no. Easiest (read: least hard) way to bend an axle is by exposing it to a load similar to that it'd see while riding. Pretty much the only other option is by exposing it to an axial load, basically pinching it hard between something. And there are few structures around that'd be able to accidentally squeeze a wheel axle hard enough to bend it w/o getting visibly damaged.
dabac is offline   Reply With Quote
Old 02-22-09, 02:49 PM   #7
UnsafeAlpine
Domestic Domestique
Thread Starter

UnsafeAlpine's Avatar

Join Date: Dec 2007
Location: Michigan
Bikes: Brand New Old Catamount! Schwinn Homegrown, Specialized FSR, Salsa Vaya, Salsa Chile Con Crosso
Posts: 1,742
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Well, it sounds like I need to pay more attention.
UnsafeAlpine is offline   Reply With Quote
Old 02-22-09, 03:00 PM   #8
nahh
on your left.

Join Date: Nov 2007
Location: Blacksburg, VA
Bikes: Scott SUB 30, Backtrax MTB
Posts: 1,802
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
My dad snapped a rear axle a while back starting to move from a stop because the QR skewer was loosened/stressed.

It took forever to convince the LBS manager that it happened that way, and that the entire wheel didn't need rebuilt.
nahh is offline   Reply With Quote
Old 02-22-09, 10:39 PM   #9
conspiratemus
Senior Member

Join Date: Jun 2008
Location: Hamilton, Ontario, Canada
Bikes:
Posts: 265
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I had always read that when an axle breaks inside the hub it is usually not obviously apparent, even with the wheel off and the QR skewer removed. Sure enough, I discovered the first broken axle of my life just this weekend when I went to remove spacers from the drive side to install a narrower six-speed freewheel. Even with the non-drive end of the axle clamped in the axle vise, turning the locknut on the drive end caused the visible end of the axle to turn with it. Oops, somethings wrong... There was initially not much play on wiggling the axle but a bit of extra wiggling coaxed it out much like a child's baby tooth.

We have more hills here in Southern Ontario than a lot of people think...

So the OP's axle could have broken a long time ago, from riding absolutely.
conspiratemus is offline   Reply With Quote
Old 02-22-09, 11:01 PM   #10
nitropowered
Senior Member

Join Date: Dec 2004
Location: Athens, Ohio
Bikes: Custom Custom Custom
Posts: 5,104
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I see bent and broken axles on Freewheel hubs but rarely see a cassette hub have a broken/bent axle.
nitropowered is offline   Reply With Quote
Old 02-22-09, 11:28 PM   #11
Lenton58
Senior Member

Lenton58's Avatar

Join Date: Dec 2008
Location: Sendai, Japan
Bikes: Vitus 979, Simplon 4-Star (Romani), Woodrup Giro, Gazelle AB
Posts: 1,629
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Considering the sort of steel used in these things, I can see that axles may break on occasion due to fatigue. This can happen to highly tempered steel along faults created in the crystal structure. IMHO, this situation could be aggravated by misaligned dropouts, and constant torque could fatigue the axle. The violence needed to bend an axle? Well, I'm not going to try it, but I'd predict that if you were to take an old axle, lay it on an anvil and strike blows on it with a hammer, you be really whaling away before measuring a bend. My guess and none of my business really is that your fiend had an accident ... a real prang ... repaired the damage and yet missed the damage to the axle.

Another explanation may be that the axle was locally case-hardened in the area where the bearing race was machined and polished. The outer extremities might then be softer and more vulnerabe to distortions caused by sudden, extreme loads.

In either case, I agree with the some others above that it most likely happened on the machine. The chances of it happening due to transport, and yet without damage to the spokes or the wheel itself are really remote. My two-cents ... interesting case!
Lenton58 is offline   Reply With Quote
Old 02-23-09, 03:41 AM   #12
Metzinger
Primate

Metzinger's Avatar

Join Date: Jan 2006
Location: gone
Bikes: Concorde Columbus SL, Rocky Mountain Edge, Sparta stadfiets
Posts: 2,582
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Lenton58 View Post
The violence needed to bend an axle?
...interesting case!

Indeed.
But have you noticed, Watson, the marks in the concrete floor, here, here, and here? And the damage to the underside of the SUV here, and here? We cannot stay here a moment longer. Miss Whittington is in mortal danger!
Metzinger is offline   Reply With Quote
Old 02-23-09, 04:31 AM   #13
meb
Senior Member

meb's Avatar

Join Date: Aug 2003
Location: arlington, VA
Bikes:
Posts: 1,745
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by dabac View Post
Possible - yes. Probable - no. Easiest (read: least hard) way to bend an axle is by exposing it to a load similar to that it'd see while riding. Pretty much the only other option is by exposing it to an axial load, basically pinching it hard between something. And there are few structures around that'd be able to accidentally squeeze a wheel axle hard enough to bend it w/o getting visibly damaged.
I've seen a neighbors bent axle from something striking the axle while the wheel was off a bike. But the greater probability is it was bent from riding and not noticed. I've been riding for several months on one that is bent (5 speed freewheel quick release)-it makes aligning the wheel more dificult and it will eventially bend to the point that it will create some extra friction and eventually snap. This is my last quick release freewheel rear. As they go, I replace my destroyed quick release rear freewheels with bolt on axles for extra strength. I've never had a freehub axle fail nor a freewheel bolt on axle fail.
meb is offline   Reply With Quote
Old 02-23-09, 10:24 AM   #14
Lenton58
Senior Member

Lenton58's Avatar

Join Date: Dec 2008
Location: Sendai, Japan
Bikes: Vitus 979, Simplon 4-Star (Romani), Woodrup Giro, Gazelle AB
Posts: 1,629
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Quote:
Indeed. But have you noticed, Watson, the marks in the concrete floor, here, here, and here? And the damage to the underside of the SUV here, and here? We cannot stay here a moment longer. Miss Whittington is in mortal danger!
Lenton58 is offline   Reply With Quote
