3T Motus stem: what's the story?

The detachable faceplate on my 3T Motus stem cracked. I did not tighten it unduly; it is clearly a bad design. The photographic evidence:




I came across vredstein's post about his 3T Motus cracking whilst doing a search of the forum. To wit:

Quote:
Originally Posted by vredstein
I had a TTT Motus stem with a removable face plate that cracked. I replaced the plate and am currently riding it, but keeping an eye on it. I got the Motus because I like the removable face plate feature and it looks good. I see several other quill stems with the removable plate, but they look like crap. I guess I'll have to either switch to one of these and deal with a bad looking stem, or go back to to the single bolt, no face plate stems.
I received a replacement faceplate from 3T just today. I really like how the stem looks. Questions for vredstein: are you still riding yours? How's it doing?

The front insert between the faceplate and the body is a solid piece of metal, while the back insert is rubber. I wonder if I overtightened (according to 3T specs) the front bolt on the hard insert, causing it to crack, where I should have tightened the back bolt on the soft insert?

I also wonder: having received the replacement, do you think putting the rubber insert in the front and discarding the hard insert would be a good idea?

Last edited by rousseau; 05-06-09 at 11:28 PM.
rousseau is offline   Reply With Quote
Old 05-06-09, 10:10 PM   #2
genejockey
Klaatu..Verata..Necktie?

genejockey's Avatar

Join Date: May 2007
Location: SF Bay Area
Bikes: Battaglin MAX, Chorus kit; Bianchi 928 Veloce; Ritchey Road Logic, 7410 Dura Ace
Posts: 1,099
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
It happened to me, too.

What did you have to do to get the new faceplate?
genejockey is offline   Reply With Quote
Old 05-06-09, 11:27 PM   #3
rousseau
Senior Member
Thread Starter

rousseau's Avatar

Join Date: Oct 2005
Location: Southwestern Ontario
Bikes:
Posts: 2,621
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Wow, the stories just keep coming out of the woodwork. Search this forum for "3T Motus" and you'll come up with more threads, one of them mine. I first contacted 3T, who sent me to the old 3T distributor at www.gruppospa.com. I sent my story about the stem and photos to the first contact person at this page: http://www.columbustubi.com/EN/contatta.html.

I honestly wonder at this point if 3T shouldn't put out a recall. I mean, somebody could get seriously hurt.
rousseau is offline   Reply With Quote
Old 05-07-09, 01:40 AM   #4
Geordi Laforge
Large Member

Geordi Laforge's Avatar

Join Date: Nov 2008
Bikes:
Posts: 1,497
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
time to use another stem, no?
Geordi Laforge is offline   Reply With Quote
Old 05-07-09, 08:46 AM   #5
bellweatherman
Senior Member

bellweatherman's Avatar

Join Date: Aug 2005
Location: Austin
Bikes: Too many to count
Posts: 2,103
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I agree. I wouldn't trust that stem.
bellweatherman is offline   Reply With Quote
Old 05-07-09, 09:44 AM   #6
vredstein
Senior Member

vredstein's Avatar

Join Date: Aug 2008
Location: Tucson, Arizona
Bikes: '02 Lemond Buenos Aires, '98 Fuji Touring w/ Shimano Nexus premium, '06 Jamis Nova 853 cross frame set up as commuter, '03 Fuji Roubaix Pro 853 back up training bike
Posts: 704
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I got a replacement stem from the original EXCELLENT Ebay seller
http://stores.shop.ebay.com/The-New-...__W0QQ_armrsZ1.
I used this stem on a Cinelli Eubios handlebar. This handlebar is 26.0mm in diameter. The Motus stem is supposed to work with both 26.0 and 25.4. The stem's clamp radius seem to fit a 26.0 perfectly, but just like yours, the spacers don't completely fill in the space.
When I clamp this onto my handlebars, both the front triangular metal spacer and the rear rubber spacer have plenty of wiggle room. Like you, I debated on whether to clamp it so the front spacer was tight, leaving the rear rubber spacer with wiggle room, or clamp it so the rear was tight, and the front has wiggle room. I even tried making an additional spaceer cut from an old inner tube. But since it's still rubber, once you tighten the bolt, any faulty stress is still going to manifest itself.
I finally decided to clamp it even, making sure there was an equal amount of space front and rear. The spacers might as well not even be there. Hopefully, this equal clamping pressure will be the safest. Since my original post, I've been keeping any eye on it and there are no signs of cracks.
I'd be interested so see how this fits on a 25.4 bar.
I was trying to get ahold of a Salsa SUL quill stem with the removable faceplate, but that too is a problem unit and I believe it has been recalled. Weird because the SUL stand for Stiff Upper Lip. Instead of a flat mating surface or spacers, it has a lip which was specifically designed to strengthen it.
In the end, I think the smartest thing to do is just bite the bullet and get a Nitto stem and live without a detachable faceplate.
vredstein is offline   Reply With Quote
Old 05-07-09, 10:32 AM   #7
rousseau
Senior Member
Thread Starter

rousseau's Avatar

Join Date: Oct 2005
Location: Southwestern Ontario
Bikes:
Posts: 2,621
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
I have a Nitto Noodle 26.0 bar on mine. Actually, I'm currently using a nice silver ITM quill stem with "Bianchi" pantographed on it, which better suits my Bianchi both in terms of said pantographing and the fact that it's silver. But the Motus is a cool-looking mofo of a stem, though. I kinda wouldn't mind putting it on again. Shrug.

Now that I think about it, I'm quite sure mine cracked for two reasons: 1) the bad design, of course; and 2) a 10 km-section of really rough chipseal-like road that had been redone without my knowing it (and without my knowing where it would end). That damn section of road was harsh enough to loosen my headset, and I do recall hearing some creaking in the bar after that. Lesson learned: stay away from chipseal!
