Drop bars on a mountain bike?

Hello everyone, I am currently renovating a 16 year old Giant Iguana and i love the feel of drop bars so i was planning on making some adjustments so they could work with my bike. First off, i was planning on using 25.4 mm drop bars so i could use my current mountain bike stem. Secondly i was planning on using dia compe 287 drop bar brake levers since i have center pull cantilever brakes. I was also planning on using some old sram grip shifters i have and putting them on stem part of the handlebars if i can get them past the drops if not i could always put them on the bar ends. If anybody has any input or experience with this kind of stuff please comment i could use some help.
crnlmushroom is offline   Reply With Quote
Old 08-05-09, 04:36 PM   #2
Sixty Fiver
Bicycle Repair Man !!!

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
I skipped the whole shifter nonsense when I converted my Kuwaharas into drop bar versions... I went with a fixed drive.



Grip shifters are designed for mtb bars so there could be some compatibility issues and they won't pass the bend in the bars... bar end levers would be the way to go.
Sixty Fiver is offline   Reply With Quote
Old 08-05-09, 05:28 PM   #3
crnlmushroom
Member
Thread Starter

Join Date: Aug 2009
Bikes: Giant iguana
Posts: 28
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That is a good idea with the fixed drive but i need the gears because i live in a very hilly area. As far as the shifters go i think your right about not being able to get them past the bends but i think i can still put them on the drops. As for compatibility i think it should work since the only difference between drop bars and mountain bike bars are the diameter (as far as i know) and i got mtn bar diameter drop bars so i think that problem is resolved
crnlmushroom is offline   Reply With Quote
Old 08-05-09, 05:33 PM   #4
Sixty Fiver
Bicycle Repair Man !!!

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
That sounds like it will all work out fine.
Sixty Fiver is offline   Reply With Quote
Old 08-05-09, 05:56 PM   #5
caloso
Packfodding 3

caloso's Avatar

Join Date: Jul 2002
Location: Sacramento, California, USA
Bikes: Ridley Excalibur, Gazelle Champion Mondial, On-One Pompino, Specialized Rock Hopper
Posts: 33,626
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 59 Post(s)
I did it with an old Rock Hopper. It was a bit of a kludge -- having more to do with the 8 speed shifters on the 7 speed cassette -- than the bars themselves. My advice would be to look for some bar end shifters. In friction mode they'll work with any derailleur and they're relatively cheap on eBay.

caloso is offline   Reply With Quote
Old 08-05-09, 06:53 PM   #6
c_m_shooter
Senior Member

c_m_shooter's Avatar

Join Date: Sep 2006
Location: Paradise, TX
Bikes: Surly Cross Check, Redline Monocog 29er, Generic Track bike, Surly Pugsley, Salsa Fargo, Schwinn Klunker
Posts: 1,542
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I wouldn't go with the grip shifters. Harris Cyclery has an adaptor to mount them on the bar ends, but you can get a set of barcons for the same price.
c_m_shooter is offline   Reply With Quote
Old 08-05-09, 07:19 PM   #7
norwood
GO BIG RED

norwood's Avatar

Join Date: Nov 2008
Location: Hastings,NE
Bikes: 1996 Bianchi Veloce 1993 Bridgestone MB-3 1992 Trek 700 1992 Trek 820
Posts: 678
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Gripshifters on a Trek hybrid that originally had flat bars. I went with Gripshifters because I don't care for barcons. They work fantastic. The handlebar adapters are homemade. One problem that you may run into is that some MTB stems won't accept a drop bar, I'm not talking bar diameter, but the clamp area may be so wide that the curves of the dropbar won't fit through the clamp area. I've tried it. I didn't want to open up the clamp so far that it may damage it. I just went with a road stem. Yours may be different.


norwood is offline   Reply With Quote
Old 08-05-09, 08:54 PM   #8
bikemeister
Senior Member

Join Date: Jan 2006
Location: Tucson, AZ
Bikes:
Posts: 771
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
SRAM really knew what the heck they were doing when they invented GripShift! Nice setup!
bikemeister is offline   Reply With Quote
Old 08-05-09, 09:18 PM   #9
crnlmushroom
Member
Thread Starter

Join Date: Aug 2009
Bikes: Giant iguana
Posts: 28
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by norwood View Post
Gripshifters on a Trek hybrid that originally had flat bars. I went with Gripshifters because I don't care for barcons. They work fantastic. The handlebar adapters are homemade. One problem that you may run into is that some MTB stems won't accept a drop bar, I'm not talking bar diameter, but the clamp area may be so wide that the curves of the dropbar won't fit through the clamp area. I've tried it. I didn't want to open up the clamp so far that it may damage it. I just went with a road stem. Yours may be different.


thanks for the picture that is the basic idea i had glad to see someone else has done it succesfully. I was wondering though if i could put the grip shifters backwards and without a extender piece thing
crnlmushroom is offline   Reply With Quote
Old 08-05-09, 09:33 PM   #10
pacificaslim
Surf Bum

Join Date: Aug 2008
Location: Pacifica, CA
Bikes: Lapierre Pulsium 500 FdJ, Ritchey breakaway cyclocross, vintage trek mtb.
Posts: 2,170
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
what ever you do, match your shifters and front derailleur. i.e. if you use road shifters, use road derailleur, and if you use mountain shifters, use mountain derailleur. the amount of cable pull is different with each type so you need to match them up. (if you want good front shifting).

rear derailleur doesn't matter. mix and match as you please.
pacificaslim is offline   Reply With Quote
Old 08-06-09, 12:03 AM   #11
fuzz2050
Real Men Ride Ordinaries

fuzz2050's Avatar

Join Date: Sep 2008
Bikes:
Posts: 3,697
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by crnlmushroom View Post
. As for compatibility i think it should work since the only difference between drop bars and mountain bike bars are the diameter (as far as i know) and i got mtn bar diameter drop bars so i think that problem is resolved
Remember, there are two diameters at play, stem clamp diameter AND grip diameter. 25.4 is the stem clamp diameter, and there are plenty of drop bars available in that size. As far as grip diameter, the drop bars and the mountain bars will be different. You might be able to squeeze, and such, but I wouldn't count on it.

And I'll put in my own suggestion, Suntour Command Shifters
fuzz2050 is offline   Reply With Quote
Old 08-06-09, 05:49 AM   #12
norwood
GO BIG RED

norwood's Avatar

Join Date: Nov 2008
Location: Hastings,NE
Bikes: 1996 Bianchi Veloce 1993 Bridgestone MB-3 1992 Trek 700 1992 Trek 820
Posts: 678
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by fuzz2050 View Post
remember, there are two diameters at play, stem clamp diameter and grip diameter. 25.4 is the stem clamp diameter, and there are plenty of drop bars available in that size. As far as grip diameter, the drop bars and the mountain bars will be different. You might be able to squeeze, and such, but i wouldn't count on it.

+1


Quote:
thanks for the picture that is the basic idea i had glad to see someone else has done it succesfully. I was wondering though if i could put the grip shifters backwards and without a extender piece thing
As above, I'm betting the diameter is not the same. The Gripshifters work much better the direction that I have them. The other direction, and the cable is really out and in the way. Even if you could get them on your bars.
norwood is offline   Reply With Quote
Old 08-06-09, 06:29 AM   #13
cs1
Senior Member

cs1's Avatar

Join Date: Feb 2004
Location: Clev Oh
Bikes: Specialized, Schwinn
Posts: 6,651
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Quote:
Originally Posted by crnlmushroom View Post
That is a good idea with the fixed drive but i need the gears because i live in a very hilly area. As far as the shifters go i think your right about not being able to get them past the bends but i think i can still put them on the drops. As for compatibility i think it should work since the only difference between drop bars and mountain bike bars are the diameter (as far as i know) and i got mtn bar diameter drop bars so i think that problem is resolved

Sorry but what you're talking about is Old School road bars with a 25.4mm clamp. Which is MTB bar standard. A MTB bar has 22.2mm tubing for the rest of the bar. A road bike uses 23.5 or something similar, feel free to jump in and give the exact dia. That's why grip shifters won't even slip over the flats on a road bar. Good luck there's been some great suggestions so far.
cs1 is offline   Reply With Quote
Old 08-06-09, 08:59 AM   #14
crnlmushroom
Member
Thread Starter

Join Date: Aug 2009
Bikes: Giant iguana
Posts: 28
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
First off thanks to everyone for the input. Ok so the general idea is that the grip shifters will probably not fit on the drops of the bar, i have heard about the extenders/adapters but they do seem a bit pricey (im on a tight budget) are there any other cost effective solutions?
crnlmushroom is offline   Reply With Quote
Old 08-06-09, 09:46 AM   #15
crnlmushroom
Member
Thread Starter

Join Date: Aug 2009
Bikes: Giant iguana
Posts: 28
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by norwood View Post
Gripshifters on a Trek hybrid that originally had flat bars. I went with Gripshifters because I don't care for barcons. They work fantastic. The handlebar adapters are homemade. One problem that you may run into is that some MTB stems won't accept a drop bar, I'm not talking bar diameter, but the clamp area may be so wide that the curves of the dropbar won't fit through the clamp area. I've tried it. I didn't want to open up the clamp so far that it may damage it. I just went with a road stem. Yours may be different.



How did you make the custom handlebar adapters?
crnlmushroom is offline   Reply With Quote
Old 08-06-09, 10:39 AM   #16
crnlmushroom
Member
Thread Starter

Join Date: Aug 2009
Bikes: Giant iguana
Posts: 28
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
by the way these are the handlebars i was planning on getting http://www.ebikestop.com/nitto_classic_40cm_254mm_silver_road_bar___model_115-HB1018.php[/URL]
crnlmushroom is offline   Reply With Quote
Old 08-06-09, 01:59 PM   #17
fuzz2050
Real Men Ride Ordinaries

fuzz2050's Avatar

Join Date: Sep 2008
Bikes:
Posts: 3,697
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
yup, it would take a LOT of work, or HubBub adapters to make gripshifts fit that bar.
fuzz2050 is offline   Reply With Quote
Old 08-06-09, 03:23 PM   #18
crnlmushroom
Member
Thread Starter

Join Date: Aug 2009
Bikes: Giant iguana
Posts: 28
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by fuzz2050 View Post
yup, it would take a LOT of work, or HubBub adapters to make gripshifts fit that bar.
yeh i think your right about how much work it would take. What about the shimano ultegra 8 speed bar end shifters? I dont know if they would or would not work with my 7 speed cassette and shimano altus derailleur. any suggestions for cheap bar end shifters that would would work with my 7 speed cassette?
crnlmushroom is offline   Reply With Quote
Old 08-06-09, 03:42 PM   #19
LesterOfPuppets
cowboy, steel horse, etc

LesterOfPuppets's Avatar

Join Date: Sep 2008
Location: Rock Springs, WY
Bikes: My War
Posts: 26,493
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 65 Post(s)
Sram should bring back road gripshifts. I wonder if they'd sell today?
LesterOfPuppets is offline   Reply With Quote
Old 08-06-09, 08:45 PM   #20
norwood
GO BIG RED

norwood's Avatar

Join Date: Nov 2008
Location: Hastings,NE
Bikes: 1996 Bianchi Veloce 1993 Bridgestone MB-3 1992 Trek 700 1992 Trek 820
Posts: 678
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by crnlmushroom View Post
How did you make the custom handlebar adapters?
http://www.onlinemetals.com/merchant...195&top_cat=60
I used .875" (or 7/8" or 22.2mm) diameter aluminum rod from Online Metals and turned one end down to the I.D. of the drop bars. Make the piece as long as the shifter plus how ever far you want to extend into the handlebar. I went about two inches. I made the dia. a snug slip fit into the bar and then it's simply anchored with a small sheet metal screw. I used a tubing cutter to take off about an inch of the handlebar so that there wouldn't be so much hanging out. The Gripshifter then clamps on to the .875" dia. part. Any machine shop should be able to turn these out. I know mine cost a lot less than a Hubbub adapter.
norwood is offline   Reply With Quote
Old 08-07-09, 02:45 AM   #21
zzyzx_xyzzy
headtube.

zzyzx_xyzzy's Avatar

Join Date: Sep 2008
Bikes:
Posts: 804
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Get a 1" threadless stem and a short bit of MTB handlebar and you can run this Sheldon setup:

http://www.sheldonbrown.com/org/rale...l-nexus10.html
zzyzx_xyzzy is offline   Reply With Quote
Old 08-07-09, 09:55 AM   #22
fuzz2050
Real Men Ride Ordinaries

fuzz2050's Avatar

Join Date: Sep 2008
Bikes:
Posts: 3,697
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by crnlmushroom View Post
yeh i think your right about how much work it would take. What about the shimano ultegra 8 speed bar end shifters? I dont know if they would or would not work with my 7 speed cassette and shimano altus derailleur. any suggestions for cheap bar end shifters that would would work with my 7 speed cassette?
Almost every bar-end shifter can be turned to friction mode, allowing it to shift ANY derailer made. It's nice.
fuzz2050 is offline   Reply With Quote
Old 08-07-09, 11:28 AM   #23
mastershake916
Senior Member

Join Date: Aug 2006
Location: Nor~Cal
Bikes:
Posts: 1,691
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Grip shifters are the devil.
Get some thumb shifters.
mastershake916 is offline   Reply With Quote
Old 08-12-09, 10:28 AM   #24
cs1
Senior Member

cs1's Avatar

Join Date: Feb 2004
Location: Clev Oh
Bikes: Specialized, Schwinn
Posts: 6,651
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Quote:
Originally Posted by mastershake916 View Post
Grip shifters are the devil.
Get some thumb shifters.
I love my thumbies. Wish they made them for a road bar. It would be great to have a set on the top of a drop bar. I probably spend 90% of my time there.
cs1 is offline   Reply With Quote
Old 08-12-09, 12:00 PM   #25
norwood
GO BIG RED

norwood's Avatar

Join Date: Nov 2008
Location: Hastings,NE
Bikes: 1996 Bianchi Veloce 1993 Bridgestone MB-3 1992 Trek 700 1992 Trek 820
Posts: 678
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by cs1 View Post
I love my thumbies. Wish they made them for a road bar. It would be great to have a set on the top of a drop bar. I probably spend 90% of my time there.
For a while I had drop-bars on my B'stone MB3 and had it's 7spd Deore thumbies mounted on a peice of 7/8" aluminum tube that spanned the bars right in back of the brake hoods. They were right in thumb reach when riding on the hoods. In practice it worked well but I couldn't come up with a satisfactory way to attach the alum. tube. It had to be removeable in case I needed to remove the bars from the stem. And I ended up taking off the drop bars anyway. But with a stem with a removable face plate.......
norwood is offline   Reply With Quote
