Building pit wheels with same dish as current *pics comming*

I will try to make this understandable. I have a set of GL330 Mavic wheels with Shimano 600 hubs (i did not build, got 2nd hand). The freehub body holds 9 speed with a 1mm spacer on the hub.

The axle on the rear appears to have 2 spacers on the non drive side, i had a hard time getting my calipers in there, but it looks like 3mm (one looks thicker than the other, but 3mm would get 126 to 129, seems a bit off). I have been reading about adding spacers to 126mm to make 130. Anyhow, i am going to build up a 2nd set of wheels that i can use as pit wheels and that my wife can use on her 9spd bike.

I will look for some Shimano 600's so that I can dupicate this setup, but if i were to go with tiagra or 105's, will my wheel dishing be all screwed up so that i cannot easily swap wheels back and forth?

If i were to find some stock 130mm wheels and the RD still shifted OK, would it be safe to say that i could build up some standard 130mm hubs on my next set and all will be well?

I hope this made sense

CLIFF NOTES: Shimano 600 rear hubs have 2 spacers on non-drive side, want to build up a set of pit wheels, but am worried that dish/axle spacing may be screwy for shifting/brakes

Last edited by adam_mac84; 02-22-11 at 09:35 PM.
adam_mac84 is offline   Reply With Quote
Old 02-22-11, 09:34 PM   #2
adam_mac84
Senior Member
Thread Starter

Join Date: Dec 2009
Bikes:
Posts: 614
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)


adam_mac84 is offline   Reply With Quote
Old 02-22-11, 09:34 PM   #3
adam_mac84
Senior Member
Thread Starter

Join Date: Dec 2009
Bikes:
Posts: 614
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I guess the other question is were there 130mm shimano 600's? My googling hasn't exactly turned much up
adam_mac84 is offline   Reply With Quote
Old 02-22-11, 10:07 PM   #4
mrrabbit
Senior Member

mrrabbit's Avatar

Join Date: Dec 2007
Location: San Jose, California
Bikes: 2001 Tommasini Sintesi w/ Campagnolo Daytona 10 Speed
Posts: 3,193
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
First off, you don't seem to understand what dish is. Dish is about having the rim centered between the locknut. There is no such thing as more dish or less dish - either the wheel is dished or not. All wheels properly built are dished. Dish is NOT about the difference in one side versus of the other. That's a description of offsets...

However what it appear to be that you reall want is:

1. Use one set of wheels...

2. Pop in another set WITHOUT having to make derailleur setup and shifting changes.

For freehubs that is accomplished by the following:

1. Making sure the distance from the center of the drive side flange to the end of the drive side locknut is the same. (Typical 8/9 speed is 48mm)
2. Making sure the distance from the center of the inner-most cog to the end of the drive side locknut is the same.
3. Making sure the distance from the center of the outer-most cog to the end of the drive side locknut is the same.
3. Making sure the same cogset speeds-wise is used.

=8-)
__________________
4000+ wheels built since 1984...

Disclaimer:

1. I do not claim to be an expert in bicycle mechanics despite my experience.
2. I like anyone will comment in other areas.
3. I do not own the preexisting concepts of DISH and ERD.
4. I will provide information as I always have to others that I believe will help them protect themselves from unscrupulous mechanics.
5. My all time favorite book is:

Kahane, Howard. Logic and Contemporary Rhetoric: The Use of Reason in Everyday Life
mrrabbit is offline   Reply With Quote
Old 02-23-11, 11:49 PM   #5
DannoXYZ
Senior Member

DannoXYZ's Avatar

Join Date: Jul 2005
Location: Saratoga, CA
Bikes:
Posts: 11,606
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Quote:
Originally Posted by adam_mac84 View Post
I guess the other question is were there 130mm shimano 600's? My googling hasn't exactly turned much up
Yeah, 600-Ultegra FH-6402 was 8-spd with 130mm spacing. Though, they didn't get the cool conical locknut that Dura-ace had to help spread out 126mm rear-ends to 130mm.

Don't bother with measuring non-driveside stuff. I have 126mm and 130mm 8-spd cassette rear-wheels that shift identically to another 130mm 8-spd wheel with freewheel. Also some 126mm wheels with 7-spd freewheels with 8-spd spacing that shifts cleanly as well. Here's the bottom line:

1. make sure the c-t-c spacing on your cogs are exactly the same. I have a mix of Shimano and Campy 8-spd cassettes, Sachs 8-spd, Suntour 8-spd and Dura-ace 7-spd freewheels. All the cogs have been spaced to exactly 3.0mm c-t-c by grinding spacers and/or shimming with 0.1mm stock.

2. make sure the 1st cog is exactly the same distance away from the dropout face. Easiest to measure with the wheel mounted and I use calipers to measure. On my wheels, I use 3.5mm gap between cog and dropout since that's the smallest I can go before the chain rubs the dropout (for minimal dish). I adjust this gap by juggling axle-washers between the two sides. Sometimes, I have to custom mill a washer to just the right fractional-mm thickness.

So really, it doesn't matter what your dropout spacing is on your wheels or the number of speeds. Imagine the cogs floating in between your dropouts. As long as they are in the exact same location on all your wheels, they will shift identically.

Last edited by DannoXYZ; 02-23-11 at 11:55 PM.
