Fork on backwards...

The other day, while locking my bike up, I realised the bike locked to the other side of the rack had the fork on backwards! It was what I'd describe as a BSO, but it had clearly been ridden there. Just how dangerous would it be to ride a bike like that? And how the heck does that get past inspection?
Airburst is offline   Reply With Quote
Old 02-03-12, 11:48 AM   #2
Booger1
Senior Member

Join Date: Sep 2007
Location: Gaseous Cloud around Uranus
Bikes:
Posts: 3,730
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Might be a little twitchy.......
Booger1 is offline   Reply With Quote
Old 02-03-12, 11:54 AM   #3
fietsbob
coprolite

fietsbob's Avatar

Join Date: Jun 2010
Location: NW,Oregon Coast
Bikes: 7
Posts: 20,436
Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 656 Post(s)
opposite..
In a video demonstration, MIT Professor, Author of bicycle science,
set a handle bar less
bicycle in motion down a hill, it went dead straight, with no one on it.
because the trail was large.. it more stable, but harder to change direction.
so great if no hands butt steering is the plan..
teacup and saucer in hands while on the way.

in the carton the fork is backwards,.. BSO are assembled by min. wage clerks
in the big box stores, not skilled bike mechanics..
fietsbob is offline   Reply With Quote
Old 02-03-12, 12:01 PM   #4
dbg
Si Senior

dbg's Avatar

Join Date: Nov 2004
Location: Naperville, Illinois
Bikes: Too Numerous (not)
Posts: 2,612
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Of the three bikes currently being built up in my workshop, none of them would allow a backwards fork. The front wheel would be impeded by the downtube. Must have been a MTB.
dbg is offline   Reply With Quote
Old 02-03-12, 12:01 PM   #5
bobotech
Senior Member

Join Date: Jan 2012
Location: Spokane, WA
Bikes: Specialized Sequoia Elite/Motobecane Fantom Cross Team Ti/'85 Trek 520
Posts: 2,253
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Think of casters. Casters trail behind and are much more stable when trailing behind the pivot point. Turn the casters so they are facing forward (leading) on a shopping cart and then push the cart, the cart wants to shift around while the casters try to twist so they are trailing as you initially push the cart.

Cars are the same way. If you adjust the caster angle on a cart so that you have positive caster, you will make the car feel more twitchy and responsive however it won't track as straight easily and when you let go of the steering wheel while making a turn, it won't return back to center. You adjust the caster so you have negative caster, the car won't be as responsive or twitchy when you are steering but it will feel much more stable. You will be able to let go of your steering wheel and the car should tract straight for a while.

So yeah, a backwards fork will make the bike feel much more stable but when you turn the handlebars, it won't respond as quickly as a normal positive angle fork.
bobotech is offline   Reply With Quote
Old 02-03-12, 12:11 PM   #6
jimc101
Senior Member

Join Date: Oct 2007
Location: West Yorkshire, United Kingdom
Bikes:
Posts: 4,814
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 35 Post(s)
Guess you've never shopped at Tesco when they have bikes in. Pretty common to see incorrectly assembled bikes, and the people who buy them don't seem to mind / care about it.

See here for a photo of one on an instore display http://singletrackworld.com/forum/to...cing-wrong-way
jimc101 is offline   Reply With Quote
Old 02-03-12, 12:21 PM   #7
Airburst
Senior Member
Thread Starter

Join Date: Oct 2009
Location: England, currently dividing my time between university in Guildford and home just outside Reading
Bikes: Too many to list here!
Posts: 1,921
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by jimc101 View Post
See here for a photo of one on an instore display http://singletrackworld.com/forum/to...cing-wrong-way
I don't want to live on this planet anymore......
Airburst is offline   Reply With Quote
Old 02-03-12, 01:11 PM   #8
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Bikes: Several, mostly not name brands.
Posts: 16,529
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 126 Post(s)
Stayer bike?

JohnDThompson is offline   Reply With Quote
Old 02-03-12, 03:48 PM   #9
jack002
Senior Member

jack002's Avatar

Join Date: Feb 2009
Location: Southwest MO
Bikes: (1) 1993 Cannondale R900, red
Posts: 594
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)

That's soooo wrong.
jack002 is offline   Reply With Quote
Old 02-04-12, 02:36 AM   #10
neurocop
Senior Member

Join Date: Oct 2011
Location: SF Bay Area
Bikes: 2003 Lemond Zurich; 1987 Schwinn Tempo; 1968 PX10; 1978 PX10LE, Peugeot Course; A-D Vent Noir
Posts: 428
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by JohnDThompson View Post
Stayer bike?

Interesting pic! I guess the fork "reversal" changes the front wheel "trail" and that would certainly affect handling.
neurocop is offline   Reply With Quote
Old 02-04-12, 10:10 AM   #11
prathmann
Senior Member

Join Date: Nov 2008
Location: Bay Area, Calif.
Bikes:
Posts: 6,142
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 113 Post(s)
On my first trip with my folding Bike Friday I was a bit rushed and accidentally assembled it with the fork reversed. Handling was fine but a little bit too stable. But when I had to brake hard in traffic I felt the rear wheel lift much more easily than usual. Fortunately it didn't cause me to fall and at that point I checked over the bike and discovered my assembly error.
prathmann is offline   Reply With Quote
Old 02-04-12, 10:29 AM   #12
fietsbob
coprolite

fietsbob's Avatar

Join Date: Jun 2010
Location: NW,Oregon Coast
Bikes: 7
Posts: 20,436
Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 656 Post(s)
Bike in #8 is for motorbike paced track racing.., racers sheltered
Air resistance reduced , behind the 'Clyde' on a Derny.
fietsbob is offline   Reply With Quote
Old 02-04-12, 11:07 AM   #13
Andy_K
Senior Member

Andy_K's Avatar

Join Date: Jan 2008
Location: Beaverton, OR
Bikes: 2013 Kona Jake, 2015 Kona Jake the Snake, 2008 Kona Major Jake, 2013 Kona Jake the Snake, 2006 Kona Kula, 2012 Ridley Excalibur, 2001 LeMond Buenos Aires, 1984 Pinarello Gran Turismo, 1982 Trek 614, 1978 Austro-Daimler, 1987 Pinarello Montello
Posts: 8,929
Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 219 Post(s)
At my own workplace:

__________________
My Bikes
Andy_K is offline   Reply With Quote
Old 02-04-12, 01:09 PM   #14
dabac
Senior Member

Join Date: Mar 2008
Bikes:
Posts: 5,502
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 45 Post(s)
Quote:
Originally Posted by bobotech View Post
Think of casters. Casters trail behind and are much more stable when trailing behind the pivot point.
But a shopping cart caster pivots around a vertical axle. If you lean a caster wheel until its pivot axle has the approximate angle of a bike head tube, the wheel will happily stay on the forward side, just like on a bike.

Quote:
Originally Posted by bobotech View Post
Cars are the same way.
Are they? I think not. Bike forks have rake, or offset. Never seen that discussed for cars.

Quote:
Originally Posted by bobotech View Post
So yeah, a backwards fork will make the bike feel much more stable .
No. A backwards fork will make the bike less stable.
Look at a bike with a standard oriented fork. Notice the exact height of, say the top tube/head tube junction when the wheel is pointing straight forward.
Now turn the bar, as in a sharp turn. You'll notice your chosen reference point rising a little. Let it back into a straight forward position, see how the reference point drops again.
Gravity alone will make the bike strive to continue straight forward. This is (part of) what allows us to ride no handed.

If you flip the fork around, the reference point will be at its highest point with the wheel straight forward. Turning the wheel will lower the front of the bike. A flipped fork bike will be (near) impossible to ride no handed.
But hands-on riding isn't really much affected, as long as there's no toe strike or down tube strike.
dabac is online now   Reply With Quote
Old 02-04-12, 03:27 PM   #15
prathmann
Senior Member

Join Date: Nov 2008
Location: Bay Area, Calif.
Bikes:
Posts: 6,142
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 113 Post(s)
Quote:
Originally Posted by dabac View Post
A flipped fork bike will be (near) impossible to ride no handed.
But hands-on riding isn't really much affected, as long as there's no toe strike or down tube strike.
Nope, my Bike Friday (mentioned above) is the only bike I have where the fork can be reversed without striking the down tube. It is much easier to ride straight no-handed with the fork reversed - but harder to turn.
prathmann is offline   Reply With Quote
Old 02-04-12, 03:55 PM   #16
Al1943
Senior Member

Join Date: Feb 2005
Location: Oklahoma
Bikes: Trek 5500, Colnago C-50
Posts: 9,433
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by dabac View Post
Are they? I think not. Bike forks have rake, or offset. Never seen that discussed for cars.
For cars, generally referred to as "caster", but the same principal. A car or truck's wheel spindle is angled back, similar the how a bike's head tube is angled back. My '32 Ford has 7 degrees caster built into the solid front axle. This allows me to remove my hands from the steering wheel while the car runs straight down the road.
With bicycles the term "rake" is somewhat misused. With motorcycles and most other vehicles rake is the angle of the axis of rotation expressed in degrees. This is equivalent to what we call HTA, head tube angle. What we call rake is actually the offset that the wheel axle has to the axis of fork rotation. On a bicycle increasing rake offset reduces steering trail, causing the bike to change directions more quickly. Reducing rake offset increases steering trail, causing the bike to feel more stable (at least at most riding speeds).
http://en.wikipedia.org/wiki/Bicycle...cycle_geometry
Al1943 is offline   Reply With Quote
Old 02-06-12, 11:10 AM   #17
jack002
Senior Member

jack002's Avatar

Join Date: Feb 2009
Location: Southwest MO
Bikes: (1) 1993 Cannondale R900, red
Posts: 594
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Andy_K View Post
At my own workplace:

Are we sure that seat isn't also backwards?
