Am I being picky ?

Maybe I,m going nutz but,I have noticed that most (nearly all) the bikes in here that have been restored with centerpull brakes (namely weinmann) put the wire grab clasp on backwards !when i was a kid ( oh here he goes) the clasp was positioned so the name could be seen which also partially hid the main brake cable behind it,doesnt it matter ? or am I loosing the plot ?
ozneddy is offline   Reply With Quote
Old 12-10-07, 01:04 AM   #2
Kommisar89
Bottecchia fan

Join Date: Aug 2003
Location: Colorado Springs, CO
Bikes: 1959 Bottecchia Professional (frame), 1966 Bottecchia Professional (in progress...), 1971 Bottecchia Professional (frame), 1973 Bottecchia Gran Turismo, 1974 Bottecchia Special (in progress...), 1977 Bottecchia Special (frame), 1974 Peugeot UO-8
Posts: 3,425
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Hmmm...I don't have any Weinmann centerpulls and I don't think my Universal or MAFAC hangers have anything written on them. I put them on with the cable going through the nut on the backside of the brake and the open side of the hanger towards the front of the brake so that it's easy to remove. Like so:

__________________
1959 Bottecchia Professional (frame), 1966 Bottecchia Professional, 1971 Bottecchia Professional (frame),
1973 Bottecchia Gran Turismo, 1974 Bottecchia Special, 1977 Bottecchia Special (frame),
1974 Peugeot UO-8, 1988 Panasonic PT-3500, 2002 Bianchi Veloce, 2004 Bianchi Pista
Kommisar89 is offline   Reply With Quote
Old 12-10-07, 01:44 AM   #3
LWaB
Senior Member

Join Date: Dec 2005
Location: Auld Blighty
Bikes: Early Cannondale tandem, '99 S&S Frezoni Audax, '65 Moulton Stowaway, '52 Claud Butler, TSR30, Brompton
Posts: 2,240
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Komissar89, the cable hangers usually are mounted the other way round with the brake cable running behind the straddle cable. It doesn't matter much in reality but still...
LWaB is offline   Reply With Quote
Old 12-10-07, 03:46 AM   #4
caterham
Senior Member

Join Date: Sep 2007
Bikes:
Posts: 680
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I side with Kommisar's setup as being the convention of the time. I never saw any factory new , fresh from the box bike with the equaliser cross-cable mounted behind the hanger on a Weinmann centrepull.
caterham is offline   Reply With Quote
Old 12-10-07, 03:50 AM   #5
LWaB
Senior Member

Join Date: Dec 2005
Location: Auld Blighty
Bikes: Early Cannondale tandem, '99 S&S Frezoni Audax, '65 Moulton Stowaway, '52 Claud Butler, TSR30, Brompton
Posts: 2,240
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Perhaps the American variation?
LWaB is offline   Reply With Quote
Old 12-10-07, 06:32 AM   #6
Bikedued
Senior Member

Bikedued's Avatar

Join Date: Jul 2004
Bikes:
Posts: 10,630
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 21 Post(s)
Dunno, but Mafac hangers I've seen have MAFAC on them in big letters. maybe only the older ones do? I like to have mine with the cable in back. Looks much cleaner.,,,,BD
Bikedued is offline   Reply With Quote
Old 12-10-07, 06:35 AM   #7
BobHufford
Keeper of the SLDB

BobHufford's Avatar

Join Date: Sep 2002
Location: Springfield, MO
Bikes: '75 Schwinn Paramount P-10, '86 Ritchey Commando, '87 Schwinn Cimarron, '91 Trek 990, '87 Schwinn High Sierra, '73 Schwinn Super Sport, '4? Schwinn New World, '76 Swing Bike.
Posts: 1,629
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by LWaB View Post
Perhaps the American variation?
Not the Schwinn way ...



Bob
BobHufford is offline   Reply With Quote
Old 12-10-07, 07:32 AM   #8
pastorbobnlnh
Freewheel Medic

pastorbobnlnh's Avatar

Join Date: Oct 2005
Location: Ascending or Descending the NH Mountains NW of Concord!
Bikes: Snazzy* Schwinns, Classy Cannondales, & a Lonely '83 Santana Tandem (* Ed.)
Posts: 10,240
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
The recent Super Sport from the dump I restored.

And the Twinn Sport I swapped sidepulls for centerpulls.

I suppose I pass the down under Bike Mechanic's quiz?
__________________
Bob
Dreaming about riding in NH's summertime!

Visit my websites:
FreeWheelSpa.com orpastorbobnlnh.com
pastorbobnlnh is offline   Reply With Quote
Old 12-10-07, 08:02 AM   #9
Grand Bois
Senior Member

Grand Bois's Avatar

Join Date: Mar 2005
Location: Pinole, CA, USA
Bikes:
Posts: 16,569
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 33 Post(s)
It doesn't matter, but I think it looks better this way:

Grand Bois is offline   Reply With Quote
Old 12-10-07, 08:17 AM   #10
LWaB
Senior Member

Join Date: Dec 2005
Location: Auld Blighty
Bikes: Early Cannondale tandem, '99 S&S Frezoni Audax, '65 Moulton Stowaway, '52 Claud Butler, TSR30, Brompton
Posts: 2,240
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by pastorbobnlnh View Post
I suppose I pass the down under Bike Mechanic's quiz?
Looks like it to me. Nice machines you have there.
LWaB is offline   Reply With Quote
Old 12-10-07, 08:21 AM   #11
T-Mar
Senior Member

Join Date: Nov 2004
Bikes:
Posts: 11,667
Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 84 Post(s)
It doesn't matter, but if you look at the literature issued by Dia-Compe, Weinmann and Mafac, they show the yoke/cable carrier with the lip facing away from the frame and the cable routed on the same side as the lip (i.e. same as the Schwinn pic posted by Bob). This method certainly provides a neater appearance, but I always did the exact opposite, simply because I found it easier. When the cable is routed on the side away from the frame there is also less chance of the cable scratching the frame if the fork flops, particularly if the cable has been bent per common practice, the end cap is missing and the cable is frayed. Admittedly, this is a minor point.

In Kossimsar89's case, the cable is routed on the opposite side of the lip. In this case the cable anchor is offeset and not located directly over the straddle cable. Theoretically, this is not the optimum set-up for smooth operation and maximum transfer of energy, though in practice the difference is almost certainly imperceptible.

Last edited by T-Mar; 12-10-07 at 08:27 AM.
T-Mar is offline   Reply With Quote
Old 12-10-07, 08:41 AM   #12
stronglight
Old Skeptic

stronglight's Avatar

Join Date: Jan 2006
Location: New Mexico, USA
Bikes: 19 road bikes & 1 Track bike
Posts: 1,044
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
The bikes in all the local shops I had seen BACK THEN were fitted with the main cable routed behind the engraved face of the straddle cable hanger. Yes, it was a more awkward fit, and it was more difficult to set up and still look good. The later straddle wire hangers had notches [butt cracks] in the back of the hanger behind the straddle wire to help center and ease the main cable as it dropped down behind the channel and this left the cables looking cleaner than the side twist of the main cable which BobHufford's Schwinn page or Dirtdrop's Carlton photo shows. But, they were still a bother. Perhaps this was why shops continued to do this against logic and reason: ... a minor detail which demonstrated the great care they took to even centering the cable attractively.

I think Kommisar89's set up is entirely more practical and intuitive [but, would you please trim that brake cable ] and I have set up some bikes this way too. It is much more sensible if you do not have a quick release hanger for the brakes [think MAFAC], because you can more easily lift off the straddle wire entirely when removing a wheel. But, for both correctness sake and well finished look, I think the cable is better concealed and with the manufacturer's logo proudly displayed out front.

So, yes, you are being picky Ozneddy, but why not.
stronglight is offline   Reply With Quote
Old 12-10-07, 09:03 AM   #13
stronglight
Old Skeptic

stronglight's Avatar

Join Date: Jan 2006
Location: New Mexico, USA
Bikes: 19 road bikes & 1 Track bike
Posts: 1,044
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Of course, you could also combine the two and just set the exposed main cable out the front, right across the Logo.



stronglight is offline   Reply With Quote
Old 12-10-07, 09:22 AM   #14
mrmw
Senior Member

Join Date: Dec 2005
Location: Atlanta
Bikes: 1982 Schwinn Super Sport S/P, 1984 Miyata 610, 1985 Panasonic LX 1000, Centurion Pro Tour 15 1983
Posts: 596
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by T-Mar View Post
It doesn't matter, but if you look at the literature issued by Dia-Compe, Weinmann and Mafac, they show the yoke/cable carrier with the lip facing away from the frame and the cable routed on the same side as the lip (i.e. same as the Schwinn pic posted by Bob). This method certainly provides a neater appearance, but I always did the exact opposite, simply because I found it easier. When the cable is routed on the side away from the frame there is also less chance of the cable scratching the frame if the fork flops, particularly if the cable has been bent per common practice, the end cap is missing and the cable is frayed. Admittedly, this is a minor point.

In Kossimsar89's case, the cable is routed on the opposite side of the lip. In this case the cable anchor is offeset and not located directly over the straddle cable. Theoretically, this is not the optimum set-up for smooth operation and maximum transfer of energy, though in practice the difference is almost certainly imperceptible.
I have learned so much from T-Mar, and alanbikehouston, it pains me to say that during my most recent round of messing with centerpulls (caliper and cantilevers) I have to side with Kommisar89's method of routing the lip facing away from the frame and the cable facing the frame. With well maintained cables and casing operation is smooth and clean. With the lip facing the headtube, its a snap to engage and disengage the straddle carrier from the straddle cable.
mrmw is offline   Reply With Quote
Old 12-10-07, 10:07 AM   #15
Kommisar89
Bottecchia fan

Join Date: Aug 2003
Location: Colorado Springs, CO
Bikes: 1959 Bottecchia Professional (frame), 1966 Bottecchia Professional (in progress...), 1971 Bottecchia Professional (frame), 1973 Bottecchia Gran Turismo, 1974 Bottecchia Special (in progress...), 1977 Bottecchia Special (frame), 1974 Peugeot UO-8
Posts: 3,425
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by stronglight View Post
but, would you please trim that brake cable
Done long ago - it's an old picture

Funny 'cause whatever the original setup was is lost in the mists of time (or I killed those brain with a night of drinking, whatever) so I just set it up the way that seemed to work the best. I got tired of the brake cable blocking the removal of the straddle cable. Now I can just pinch the calipers and pop the hanger right off the straddle cable in seconds. I'm fine with the way it works in practice, especially on the MAFACs.
__________________
1959 Bottecchia Professional (frame), 1966 Bottecchia Professional, 1971 Bottecchia Professional (frame),
1973 Bottecchia Gran Turismo, 1974 Bottecchia Special, 1977 Bottecchia Special (frame),
1974 Peugeot UO-8, 1988 Panasonic PT-3500, 2002 Bianchi Veloce, 2004 Bianchi Pista
Kommisar89 is offline   Reply With Quote
Old 12-10-07, 10:52 AM   #16
dbakl
Senior Member

Join Date: Nov 2005
Bikes: Cinelli, Paramount, Raleigh, Carlton, Zeus, Gemniani, Frejus, Legnano, Pinarello, Falcon
Posts: 5,775
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I hate centerpulls!
dbakl is offline   Reply With Quote
Old 12-10-07, 02:23 PM   #17
infinityeye
Nut

infinityeye's Avatar

Join Date: Apr 2005
Location: Tallahassle, FL
Bikes:
Posts: 697
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
wrong! centerpulls rule! this thread has been an enlightnment to me. To think all along I was jamming the brake cable and the straddle cable behind and facing the frame, now I can set it up however for ease of use! sometimes it is so like duh you fell like an even bigger turd burglar
infinityeye is offline   Reply With Quote
Old 12-10-07, 03:52 PM   #18
ozneddy
Senior Member
Thread Starter

ozneddy's Avatar

Join Date: Nov 2005
Location: Gold Coast, Australia
Bikes: Casati, ,Peugot,Mitchell,Raliegh,Nishiki
Posts: 1,485
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Just seen your pic,s Stronglight,---> Off to the Norty Corner ! lol
