24" front wheel, 700c back -- how does that ride?

Am scoping out a mid-80's Terry Symmetry which has a 24" front wheel and a 700C back. What is the purpose of the 24" front wheel? how does it affect the ride? I've never seen anything like that and I can't figure out why you would design a bike like that. Thanks for the info!
erbfarm is offline   Reply With Quote
Old 11-25-08, 06:08 PM   #2
cb400bill
Forum Moderator

cb400bill's Avatar

Join Date: Jul 2007
Location: Kalamazoo MI
Bikes: Yes
Posts: 12,218
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 162 Post(s)
The design is to allow a full size frame on a bike that would fit a smaller person.

Doesn't East Hill ride one?
cb400bill is offline   Reply With Quote
Old 11-25-08, 06:33 PM   #3
bmaxwell
Senior Member

bmaxwell's Avatar

Join Date: Sep 2008
Location: Poulsbo Washington
Bikes: Nishiki Saga, Nishiki Olympic
Posts: 729
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
There is also another thread that has a big frame set up like that, I was wondering the same question if it is not for the smaller person then why is the bike set up like that?
bmaxwell is offline   Reply With Quote
Old 11-25-08, 06:44 PM   #4
cuda2k
Unique Vintage Steel

cuda2k's Avatar

Join Date: May 2005
Location: Allen, TX
Bikes: Kirk Frameworks JKS-C, Serotta Nova, Gazelle AB-Frame, Fuji Team Issue, Schwinn Crosscut, All-City Space Horse
Posts: 11,486
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
bmaxwell is thinking of the 3Rensho that i just picked up. Probably a slightly different rig than the Terry, but I do hope to get the 3Rensho built this weekend or some time over the next week or so and give it a try. I would think that with the proper fork set up and stem it wouldn't handle much if any differently than a 700c pair.
cuda2k is offline   Reply With Quote
Old 11-25-08, 06:51 PM   #5
rhenning
Senior Member

Join Date: Apr 2006
Bikes:
Posts: 2,554
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 34 Post(s)
24" front wheel is to avoid toe over lap when you make a bike for a short person. My wife owns a Symmetry and likes it a lot. It was here favorite bike until she got a custom Seven this summer. The Seven has 24" wheels front and rear. Roger
rhenning is offline   Reply With Quote
Old 11-25-08, 07:00 PM   #6
East Hill
Lanky Lass

East Hill's Avatar

Join Date: Sep 2005
Location: Take a deep breath, and ask--What would Sheldon do?
Bikes: Nishiki Nut! International, Pro, Olympic 12, Sport mixte, and others too numerous to mention.
Posts: 21,455
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by cb400bill View Post
The design is to allow a full size frame on a bike that would fit a smaller person.

Doesn't East Hill ride one?
Yes, I have two bikes like that.

The idea is that the smaller front wheel will not get in the way of one's toes the same way a 700c wheel would. I find that the design tends to make the bike a bit 'twitchy' at first, but rapidly became accustomed to it. Now I just think of those bikes as 'nimble' .

The modern solution to tiny women on bikes:



Here's the Nishiki which now lives with bmaxwell, with 700c wheels fore and after:



The Centurion Dave Scott Ironman:



The Nishiki Prestige:



The Richard Sach, with 24 inch wheels:

__________________
___________________________________________________
TRY EMPATHY & HAVE LOVE IN YOUR HEART, PERHAPS I'LL SEE YOU ON THE ROAD...
East Hill is offline   Reply With Quote
Old 11-25-08, 07:07 PM   #7
cuda2k
Unique Vintage Steel

cuda2k's Avatar

Join Date: May 2005
Location: Allen, TX
Bikes: Kirk Frameworks JKS-C, Serotta Nova, Gazelle AB-Frame, Fuji Team Issue, Schwinn Crosscut, All-City Space Horse
Posts: 11,486
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Yeah, having spent only a little bit of time on bikes with smaller thin tires in the past, I was going to guess that it would be a little more 'twitchy' to someone coming from a 700c front wheel due to the smaller rotating radius, but not something that you wouldn't adjust to rather quickly. I feel the same way just going to a much smaller frame some times if I get on a say 53cm bike (my normal being closer to a 57cm)
cuda2k is offline   Reply With Quote
Old 11-25-08, 07:39 PM   #8
Amani576
Buh'wah?!

Amani576's Avatar

Join Date: Jul 2008
Location: Raleigh, NC
Bikes: 1972 Raleigh Twenty, mid-80's Trek
Posts: 2,130
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
East Hill, I don't mean to be rude/intrusive/something else equally offending (I hope I'm not coming off that way asking this)... But... Just how tall are you? Cause it always seems like you ride something that's equivalent to like a 46cm frame. I'm just curious, sorry if I'm being a tad out of line or anything.
-Gene-
Amani576 is offline   Reply With Quote
Old 11-25-08, 08:04 PM   #9
East Hill
Lanky Lass

East Hill's Avatar

Join Date: Sep 2005
Location: Take a deep breath, and ask--What would Sheldon do?
Bikes: Nishiki Nut! International, Pro, Olympic 12, Sport mixte, and others too numerous to mention.
Posts: 21,455
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by Amani576 View Post
East Hill, I don't mean to be rude/intrusive/something else equally offending (I hope I'm not coming off that way asking this)... But... Just how tall are you? Cause it always seems like you ride something that's equivalent to like a 46cm frame. I'm just curious, sorry if I'm being a tad out of line or anything.
-Gene-

I am 5'0" tall (that's if I haven't shrunk over the years).

My bikes are between 46-48cms.

No offense taken, it's a legitimate question!

East Hill
__________________
___________________________________________________
TRY EMPATHY & HAVE LOVE IN YOUR HEART, PERHAPS I'LL SEE YOU ON THE ROAD...
East Hill is offline   Reply With Quote
Old 11-25-08, 10:07 PM   #10
StephenH
Uber Goober

StephenH's Avatar

Join Date: Sep 2007
Location: Dallas area, Texas
Bikes:
Posts: 11,326
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
I noticed a couple of Craigslist time-trial bikes with smaller front wheel, with the claim that this was for a more aero riding position. Not being familiar with such things, I didn't know if this was some BS or something that's really done and reasonable.
__________________
"be careful this rando stuff is addictive and dan's the 'pusher'."
StephenH is offline   Reply With Quote
Old 11-25-08, 10:12 PM   #11
Exit.
No lugs? No hugs.

Exit.'s Avatar

Join Date: Aug 2007
Location: Vancouver, Canada
Bikes: '85 Miyata 310, '06 GT Performer
Posts: 1,115
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by StephenH View Post
I noticed a couple of Craigslist time-trial bikes with smaller front wheel, with the claim that this was for a more aero riding position. Not being familiar with such things, I didn't know if this was some BS or something that's really done and reasonable.
This is the post I was about to make.

Sometimes it's for short people, sometimes it's for getting low over the front of the bike for better aero, usually on TT bikes.

People often refer to them as "funny bikes" or "drag bikes".
Exit. is offline   Reply With Quote
Old 11-25-08, 10:18 PM   #12
StephenH
Uber Goober

StephenH's Avatar

Join Date: Sep 2007
Location: Dallas area, Texas
Bikes:
Posts: 11,326
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Here's two ads that show this. I was thinking I saw an ad that mentioned the aero position, but I'm not seeing it now.
http://dallas.craigslist.org/dal/bik/932866926.html
http://dallas.craigslist.org/dal/bik/932897442.html
__________________
"be careful this rando stuff is addictive and dan's the 'pusher'."
StephenH is offline   Reply With Quote
Old 11-25-08, 10:28 PM   #13
BengeBoy
Senior Member

BengeBoy's Avatar

Join Date: Jul 2007
Location: Seattle, Washington, USA
Bikes: 2014 Pivot Mach 5.7 MTB, 2009 Chris Boedeker custom, 1988 Tommasini Prestige, 2007 Bill Davidson custom; 1988 Specialized Stumpjumper
Posts: 6,941
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Amani576 View Post
East Hill, I don't mean to be rude/intrusive/something else equally offending (I hope I'm not coming off that way asking this)... But... Just how tall are you? Cause it always seems like you ride something that's equivalent to like a 46cm frame.
I've met East Hill. She's a giant - well over 7' tall. She wears one bicycle on each foot, like roller skates. And thus the legend was born...

(BTW, I have never seen a picture of your Rodriguez, is it the same size as your others?)

Last edited by BengeBoy; 11-25-08 at 10:34 PM.
BengeBoy is offline   Reply With Quote
Old 11-26-08, 12:31 AM   #14
bmaxwell
Senior Member

bmaxwell's Avatar

Join Date: Sep 2008
Location: Poulsbo Washington
Bikes: Nishiki Saga, Nishiki Olympic
Posts: 729
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Ok, here is east hills nishiki olympic 12 and how it looks now. This work was a compilation of east hills frame, my components and mtwkr's technical skills putting it all together. this is one true C&V group project and it would have qualified for the velo cheapo build off.


bmaxwell is offline   Reply With Quote
Old 11-26-08, 12:50 AM   #15
BengeBoy
Senior Member

BengeBoy's Avatar

Join Date: Jul 2007
Location: Seattle, Washington, USA
Bikes: 2014 Pivot Mach 5.7 MTB, 2009 Chris Boedeker custom, 1988 Tommasini Prestige, 2007 Bill Davidson custom; 1988 Specialized Stumpjumper
Posts: 6,941
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
One thing I've noticed about East Hill's bikes is the fork rake is s-o-o-o- long. Very stretched out, like a touring bike. Is there something about the geometry of small frames that requires the builders to put on those forks - stretches out the wheelbase to keep a small bike from being too twitchy? Moves the wheel out a bit to avoid toe overlap?
BengeBoy is offline   Reply With Quote
Old 11-26-08, 01:02 AM   #16
rodar y rodar
weirdo

Join Date: Jan 2008
Location: Reno, NV
Bikes:
Posts: 1,962
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Interresting. I knew about the Terrys and I`ve seen pics of those "funny bikes" but I never would have expected to see the Ironman or the Prestige that way. The chain rings look enormous!
rodar y rodar is offline   Reply With Quote
Old 11-26-08, 08:51 AM   #17
soderbiker
Waiting for Summer !

soderbiker's Avatar

Join Date: May 2007
Location: Sthlm , Sweden
Bikes: E.Merckx Corsa extra PK Banken,E.Merckx Corsa extra TT,E.Merckx Strada,De Visini,Olmo Gentleman,Peugeot PA-10,E.Merckx Corsa extra Team Issue,Nishiki Olympic Royale,Nishiki Olympic
Posts: 754
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by bmaxwell View Post
Ok, here is east hills nishiki olympic 12 and how it looks now. This work was a compilation of east hills frame, my components and mtwkr's technical skills putting it all together. this is one true C&V group project and it would have qualified for the velo cheapo build off.



SO sweet .
nice ride .!
Cheers
T
soderbiker is offline   Reply With Quote
Old 11-26-08, 09:18 AM   #18
USAZorro
Seņor Member

USAZorro's Avatar

Join Date: Oct 2004
Location: Florence, KY
Bikes: 1954 Hetchins M.O., 1959 Viking Severn Valley, 1970 Raleigh Pro, 1972 Fuji "The Finest", 1974 Raleigh Superbe&Comp, 1976 Raleigh Team Pro, 1996 Giant Iguana, 2000 Bob Jackson Arrowhead
Posts: 14,564
Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 67 Post(s)
Quote:
Originally Posted by StephenH View Post
I noticed a couple of Craigslist time-trial bikes with smaller front wheel, with the claim that this was for a more aero riding position. Not being familiar with such things, I didn't know if this was some BS or something that's really done and reasonable.
For TT bikes, it was a fad, and a poor idea IMO (but I'm an opinionated old cuss ). You'll note that they aren't used in competition any more. More research, and to some extent, rules modifications have rendered them a footnote in cycling history.

For smaller riders, the concept was, and remains perfectly valid.
__________________
In search of what to search for.
USAZorro is offline   Reply With Quote
Old 11-26-08, 09:52 AM   #19
RFC
Senior Member

RFC's Avatar

Join Date: Sep 2007
Location: Scottsdale, AZ
Bikes: many
Posts: 4,471
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 13 Post(s)
Quote:
Originally Posted by USAZorro View Post
For TT bikes, it was a fad, and a poor idea IMO (but I'm an opinionated old cuss ). You'll note that they aren't used in competition any more. More research, and to some extent, rules modifications have rendered them a footnote in cycling history.

For smaller riders, the concept was, and remains perfectly valid.
Basically correct. I have had two funny bikes, the Team Fuji with a 650 front wheel and a Nashbar Aero Sprint with a 24" front wheel.

I notice very little difference with the Fuji. With the Aero Sprint, however, the fact that the front wheel was rotating at a higher rpm was noticeable. Both bikes are a lot of fun to ride, particularly when you are all warmed up and get into that "speed kills" zone riding down the highway. The lower front end is fine for me because I don't suffer from back problems or old man ailments and like to ride low. Climbing, however, is more difficult.

I sold the Aero Sprint on CL to a very nice young guy, about my son's age, a graphic artist from California who shows his work in Scottsdale. He was crazy about the design aspects and had no intention to turn it into a FG/SS, but he did show me the absolutely beautiful and new Panasonic track bike he had in his jeep.



RFC is offline   Reply With Quote
Old 11-26-08, 10:42 AM   #20
cuda2k
Unique Vintage Steel

cuda2k's Avatar

Join Date: May 2005
Location: Allen, TX
Bikes: Kirk Frameworks JKS-C, Serotta Nova, Gazelle AB-Frame, Fuji Team Issue, Schwinn Crosscut, All-City Space Horse
Posts: 11,486
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
The Nashbar reminds me a lot of the Nikshiki that Steven posted from the dallas CL above. Same seller who I picked the 3Rensho up from.

cuda2k is offline   Reply With Quote
Old 11-26-08, 01:28 PM   #21
East Hill
Lanky Lass

East Hill's Avatar

Join Date: Sep 2005
Location: Take a deep breath, and ask--What would Sheldon do?
Bikes: Nishiki Nut! International, Pro, Olympic 12, Sport mixte, and others too numerous to mention.
Posts: 21,455
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by BengeBoy View Post
One thing I've noticed about East Hill's bikes is the fork rake is s-o-o-o- long. Very stretched out, like a touring bike. Is there something about the geometry of small frames that requires the builders to put on those forks - stretches out the wheelbase to keep a small bike from being too twitchy? Moves the wheel out a bit to avoid toe overlap?
I had not paid much attention until you pointed it out--but they do all have a long fork rake, don't they?

My guess would be the toe overlap problem is responsible for a lot of it, and also to prevent extreme twitchiness.

East Hill
__________________
___________________________________________________
TRY EMPATHY & HAVE LOVE IN YOUR HEART, PERHAPS I'LL SEE YOU ON THE ROAD...
East Hill is offline   Reply With Quote
Old 11-26-08, 01:41 PM   #22
bkbldr
Newbie

Join Date: Aug 2008
Bikes:
Posts: 4
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Late this summer I picked up a Nashbar areo from CL... 100$ I couldn't pass it up.
it looked like this just a little smaller and with a few different components.



Now it looks like this... blast to ride, 6 gears, 2 brakes 1 brake lever, 18.5 lbs. everything you need, nothing you don't.





bkbldr is offline   Reply With Quote
Old 11-26-08, 03:11 PM   #23
Oldpeddaller
Senior Member

Oldpeddaller's Avatar

Join Date: Apr 2008
Location: Maidstone, Kent, England
Bikes: 1970 Holdsworth Mistral, Vitus 979, Colnago Primavera, Corratec Hydracarbon, Massi MegaTeam, 1935 Claud Butler Super Velo, Carrera Virtuoso, Viner, 1953 Claud Butler Silver Jubilee, 1954 Holdsworth Typhoon, 1966 Claud Butler Olympic Road, 1982 Claud
Posts: 2,619
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by East Hill View Post
I am 5'0" tall (that's if I haven't shrunk over the years).

My bikes are between 46-48cms.

No offense taken, it's a legitimate question!

East Hill
It's true then - all the best things do come in the smallest parcels!
Oldpeddaller is offline   Reply With Quote
Old 11-26-08, 05:32 PM   #24
Amani576
Buh'wah?!

Amani576's Avatar

Join Date: Jul 2008
Location: Raleigh, NC
Bikes: 1972 Raleigh Twenty, mid-80's Trek
Posts: 2,130
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
The thing, to me atleast, about those old TT bikes is that they were more aesthetically pleasing than these new ones, and also weren't substantially taller than their counterpart road bikes. Nowadays the TT and Tri bikes you see have such high bottom brackets to count for their high seats, and what seems like an even more extreme seat->handlebar drop than they did in the 80's/90's. Sure, the frames truly ARE more aerodynamic, but, if someone was to make a frame like that again, only out of carbon, they could probably make it equally as aerodynamic, if not more with it technically being lower to the ground. Maybe I'm a young-old-fart for thinking all of this, but, I like the older TT bikes much more, and wish they were still being used competitively.
Either way, the idea of different wheels fore and aft for SMALL sizes is interesting. Though conversions to dual 700c would look quite funny. Actually, it might make it look like a modern compact frame...
-Gene-
Amani576 is offline   Reply With Quote
Old 11-26-08, 07:06 PM   #25
rhenning
Senior Member

Join Date: Apr 2006
Bikes:
Posts: 2,554
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 34 Post(s)
My wife's custom fit 24" wheeled Seven. Roger
Attached Images
File Type: jpg PICT0004.JPG (53.7 KB, 23 views)
File Type: jpg PICT0006.JPG (54.1 KB, 11 views)
rhenning is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 07:19 AM.
