    1986 giubilato, Campy equipped 100% original

    Campagnolo victory
    san marco concor
    ambrosio elite

    everything is original. Let me know if you guys want more information on her. I love this bike. have been riding her for the past year and i'm only loving her more as the days go on.

    I understand she is dirty and needs a thorough cleaning. She needs new cables, housings, chain and pads. Once I have the funds i will do a full maintenence. I also have plans to restore her in the near future. This this frame completely chrome under the paint or only at the rear stays and fork?










  2. #2
    Senior Member jebensch's Avatar
    Join Date
    Nov 2007
    Location
    Medford, MA
    My Bikes
    Gazelle Champ Mondial, Nishiki Comp II, Moto Grand Record, Peugeot UO-10, Koga-Miyata SS
    Posts
    1,225
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Beauty! Keep that sand away from your drivetrain!
    Steel-loving cheapskate

    www.jessebenjamin.blogspot.com

  3. #3
    Forum Admin lotek's Avatar
    Join Date
    Dec 2001
    Location
    n.w. superdrome
    My Bikes
    1 trek, serotta, rih, de Reus, Pogliaghi and finally a Zieleman! and got a DeRosa
    Posts
    17,606
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Giubilato was originally in Turin Italy, and marketed Sannino and Ganna frames.
    The shop was reported to have closed ( or moved to Germany) but I found a current website (I think
    it's current) http://www.giubilatocicli.com/english/home.html
    and an address: Via Gaidon, 3 - 36067 San Giuseppe di Cassola (VI) - Italy
    The bikes are all labeled either DUKE or Ganna but the company is Giubilato

    Marty

    P.S. what kind of tubing sticker is that? Columbus SL? Aelle?
    Sono pił lento di quel che sembra.
    Odio la gente, tutti.

    Are you a registered member? Why not? click here to register. Its free, and only takes 27 seconds!
    Want to upgrade your membership? Click Here.

  4. #4
    Senior Member radiocontrolhea's Avatar
    Join Date
    Sep 2008
    Posts
    196
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Lotek! thank you! I have tried to find as much inforamtion about the company as possible. I emailed Ganna for decals and some history behind the frame but did not get an answer back! Needless to say, I was dissapointed.

    The tubing is Columbus Aelle. I'm guessing it's a basic steel frame. I was also told it was an entry level road bike with entry component groupo (victory)

  5. #5
    Senior Member radiocontrolhea's Avatar
    Join Date
    Sep 2008
    Posts
    196
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    http://cgi.ebay.com/Racing-Bike-Atal...3A1%7C294%3A50

    This is the next closest thing to my bike. Same grouppo and what appears to be even the same paint color!

  6. #6
    Forum Admin lotek's Avatar
    Join Date
    Dec 2001
    Location
    n.w. superdrome
    My Bikes
    1 trek, serotta, rih, de Reus, Pogliaghi and finally a Zieleman! and got a DeRosa
    Posts
    17,606
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Ok,
    Aelle was Columbus' 'budget' tubeset. Aelle was plain guage Manganese Moly as opposed to Chrome Moly of the more expensive SL and SP butted tubes. Aelle R was a later version that was
    butted. Aelle tubing was cold drawn tubing which I believe meant it could be brazed faster
    (less temperature sensitive than the SL or SP tubing). Aelle was used on mid level bikes, including
    entry level racing frames, bikes made with aelle tubing generally were outfitted in good solid
    mid tier components (i.e. the Victory gruppo).
    It's very interesting that in the 80's Bicycle Guide ran a blind test of bikes made with 7 various
    tubesets from Reynolds and Columbus' best, down to I believe the Aelle and Reynolds 501 levels and
    not one tester could discern a significant difference in the ride of the bikes.

    Marty
    Sono pił lento di quel che sembra.
    Odio la gente, tutti.

    Are you a registered member? Why not? click here to register. Its free, and only takes 27 seconds!
    Want to upgrade your membership? Click Here.

  7. #7
    Senior Member
    Join Date
    Jul 2007
    Location
    Lancaster County, PA
    My Bikes
    '39 Hobbs, '58 Marastoni, '73 Italian custom, '75 Wizard, '76 Wilier, '78 Tom Kellogg, '79 Colnago Super, '79 Sachs, '81 Masi Prestige, '82 Cuevas, '83 Picchio Special, '84 Murray-Serotta, '85 Trek 170, '89 Bianchi, '90 Bill Holland, '94 Grandis
    Posts
    5,063
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Adds whole new meaning to the term "beach cruiser."

  8. #8
    Senior Member radiocontrolhea's Avatar
    Join Date
    Sep 2008
    Posts
    196
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    I was extremely cautious with the sand!

  9. #9
    Senior Member
    Join Date
    Nov 2004
    Posts
    9,998
    Mentioned
    3 Post(s)
    Tagged
    1 Thread(s)
    Quote Originally Posted by lotek View Post
    Ok,
    Aelle was Columbus' 'budget' tubeset. Aelle was plain guage Manganese Moly as opposed to Chrome Moly of the more expensive SL and SP butted tubes. Aelle R was a later version that was
    butted. Aelle tubing was cold drawn tubing which I believe meant it could be brazed faster
    (less temperature sensitive than the SL or SP tubing). Aelle was used on mid level bikes, including
    entry level racing frames, bikes made with aelle tubing generally were outfitted in good solid
    mid tier components (i.e. the Victory gruppo).
    It's very interesting that in the 80's Bicycle Guide ran a blind test of bikes made with 7 various
    tubesets from Reynolds and Columbus' best, down to I believe the Aelle and Reynolds 501 levels and
    not one tester could discern a significant difference in the ride of the bikes.

    Marty
    Aelle was carbon-manganese not manganese-molybdenum (MnMo). The latter is basically equivalent to chromium-molybdenum (CrMo). MnMo and CrMo require a lower and more finely controlled brazing temperature. Carbon-manganese withstands the higher temperatures of automated brazing without significant loss of strength and thus as better suited for mass production. However, in the end, it is not quite a strong as CrMo or MnMo, though it's closer to these two than it is to hi-tensile steel.

  10. #10
    Senior Member terrors's Avatar
    Join Date
    Jun 2005
    Location
    Vancouver Island B.C.
    Posts
    376
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)

    giubilato

    i have two giubilatos nice bikes. This one has Miche, campy, and modolo with Mavic gp4 tubulars (aelle tubing) OF all my bikes this one is the lightest.




    This one is one of my favourites mainly because of the pure Italian bling with the colours. Also has tubulars but the bike is all Campy Victory, the red saddle is a Concor. I do have some decals that i got from Giubilato company (yes, as someone mentioned they make Ganna bikes. I also have some Ganna stickers):



    EDIT: Both bikes are fully chromed and the red, white and green one is columbus sl.
    Last edited by terrors; 03-16-09 at 06:51 PM.
    1993 Bridgestone X0-3, 1980 apollo gran sport(fixed/SS), , 1987 (?) colnago spiral conic slx, 1988 Bianchi campione d'italia, 1985 (?) Giubilato FS, 1987 Marinoni Corsa track, , Cinelli Sentiero MTB., Miyata 1000 LT, Miyata sport 10 (now 12) mixte. 1987 Marinoni Special yellow, 1987 Marinoni Special blue and silver c-record, 2006 DE ROSA 'Merak'. 1977 Raleigh Super Course (in rebuild), 1982 Cinelli SC. , 1998 Cannondale R600 Cad 3, 1977 Holdsworth Pro, 1976 Holdsworth Sprint (track)

  11. #11
    Senior Member radiocontrolhea's Avatar
    Join Date
    Sep 2008
    Posts
    196
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    You were able to get original decals from the giubilato company?!?! Did you email the Ganna bike company for them? I would love to do this myself. Please help!

  12. #12
    Senior Member terrors's Avatar
    Join Date
    Jun 2005
    Location
    Vancouver Island B.C.
    Posts
    376
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)

    email

    email sent.
    1993 Bridgestone X0-3, 1980 apollo gran sport(fixed/SS), , 1987 (?) colnago spiral conic slx, 1988 Bianchi campione d'italia, 1985 (?) Giubilato FS, 1987 Marinoni Corsa track, , Cinelli Sentiero MTB., Miyata 1000 LT, Miyata sport 10 (now 12) mixte. 1987 Marinoni Special yellow, 1987 Marinoni Special blue and silver c-record, 2006 DE ROSA 'Merak'. 1977 Raleigh Super Course (in rebuild), 1982 Cinelli SC. , 1998 Cannondale R600 Cad 3, 1977 Holdsworth Pro, 1976 Holdsworth Sprint (track)

  13. #13
    Senior Member radiocontrolhea's Avatar
    Join Date
    Sep 2008
    Posts
    196
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Terrors. I dont' exactly know if my frame is completely chromed. What do you think? I do believe they are though judging by teh rear stays. Would companys only partially chrome a frame?


    Also, your bikes are georgous! I always wanted to know who the owner was of that italian schemed giubilato!

  14. #14
    slow as I ever was Ex Pres's Avatar
    Join Date
    Dec 2007
    Location
    an imposter living in the 35223
    My Bikes
    see signature
    Posts
    5,472
    Mentioned
    1 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by radiocontrolhea View Post
    ... Would companys only partially chrome a frame?...

    You may find that even if all chrome, they only polished to a high sheen the portions left exposed (forks & stays)
    72 special CNC ___________ 72 Frejus (ala Legnano) __73 Holdsworth Record
    78 Raleigh Professional_____ 80 Ranson_____________ 80 unknown French (SS)
    82 Peugeot PXN10_________83 Trek 600____________ 85 Gianni Motta
    85 Trek 560______________88 Guerciotti GLX
    90 Miele Gara_____________02 Casati Dardo (g/b\k)___02 Casati Dardo (y/blk)
    03 Casati Dardo___________08 BF IRO (fixed)________10 Vassago Fisticuff (IGH)

  15. #15
    Senior Member terrors's Avatar
    Join Date
    Jun 2005
    Location
    Vancouver Island B.C.
    Posts
    376
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)

    giubi

    I am only going by the scratches on my bikes, what i see underneath on the top tubes of both bikes is chrome (but as mentioned by bob barker it is not polished). Also under the scratches on the seat stays on the 'tri-colore'. Both bikes are 56cm btw. Thanks for the comments.
    1993 Bridgestone X0-3, 1980 apollo gran sport(fixed/SS), , 1987 (?) colnago spiral conic slx, 1988 Bianchi campione d'italia, 1985 (?) Giubilato FS, 1987 Marinoni Corsa track, , Cinelli Sentiero MTB., Miyata 1000 LT, Miyata sport 10 (now 12) mixte. 1987 Marinoni Special yellow, 1987 Marinoni Special blue and silver c-record, 2006 DE ROSA 'Merak'. 1977 Raleigh Super Course (in rebuild), 1982 Cinelli SC. , 1998 Cannondale R600 Cad 3, 1977 Holdsworth Pro, 1976 Holdsworth Sprint (track)

  16. #16
    Forum Admin lotek's Avatar
    Join Date
    Dec 2001
    Location
    n.w. superdrome
    My Bikes
    1 trek, serotta, rih, de Reus, Pogliaghi and finally a Zieleman! and got a DeRosa
    Posts
    17,606
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    T-Mar
    thanks for the correction. I always thought Aelle was maganese-moly.

    Marty
