What is this British Steel?

I'm having a hard time deciding exactly what this is - a Raleigh / Carlton of some kind I think - the BB frame # of "DD 136" suggests its a 1969 going by Kurt's published codes - but that's the only code on the BB - or the frame for that matter.

It has Campy dropouts but no chroming - and no decals for id, apart from the Reynolds ones - which do incidentally look original, but I'd be more definite about the originality of the paintwork (lagoon blue possibly?). Lugwork detail is nice but not overfancy as on some of the later professionals I've seen....

Any ideas? Your advice and input will be greatly appreciated - TIA!







Attached Images
File Type: jpg 002.jpg (104.1 KB, 74 views)
File Type: jpg 005.jpg (92.1 KB, 58 views)
File Type: jpg 009.jpg (89.0 KB, 48 views)
File Type: jpg 010.jpg (105.1 KB, 53 views)
jo1010 is offline   Reply With Quote
Old 08-27-12, 05:06 AM   #2
big chainring
Senior Member

Join Date: Sep 2007
Location: Wilmette, IL
Bikes:
Posts: 5,576
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 17 Post(s)
From the details I'm seeing I'm thinking its an early to mid 80's frame. Beyond that ?????
big chainring is offline   Reply With Quote
Old 08-27-12, 09:09 AM   #3
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Bikes:
Posts: 9,195
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 15 Post(s)
that "leaf" cap on the seat stays was something favored by Bernard Carre (France) but also by Jan LeGrand who was chief mechanic for Raleigh TI and probably had some influence on the SBDU frames. Besides that little bit, I have no idea about this particular frame...looks good, though. I'm sure it wouldn't have those details (under-BB cabling, braze-ons, short dropouts) if it was built in '69.
If it was a LeGrand "Presto" (his own brand) it would have other give-away details like a diamond-section brake bridge and "XXX" marking on the BB shell, etc.

Last edited by unworthy1; 08-27-12 at 09:15 AM.
unworthy1 is offline   Reply With Quote
Old 08-27-12, 09:13 AM   #4
lostarchitect
incazzare.

lostarchitect's Avatar

Join Date: Mar 2010
Location: Brooklyn, NY
Bikes: See sig
Posts: 6,039
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
What's the seatpost size? BB threading?
__________________
1964 JRJ (Bob Jackson), 1973 Wes Mason, 1974 Raleigh Gran Sport, 1986 Schwinn High Sierra, 2000ish Colian (Colin Laing), 2011 Dick Chafe, 2013 Velo Orange Pass Hunter
lostarchitect is offline   Reply With Quote
Old 08-27-12, 10:18 AM   #5
jo1010
Junior Member
Thread Starter

Join Date: Jul 2012
Bikes:
Posts: 14
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by lostarchitect View Post
What's the seatpost size? BB threading?
Seatpost is 27.2mm and BB adjustable cup is marked up with BC 1.37 (no pitch is shown)
jo1010 is offline   Reply With Quote
Old 08-27-12, 11:31 AM   #6
Captain Blight
Senior Member

Captain Blight's Avatar

Join Date: Oct 2009
Location: Minneapolis
Bikes: -1973 Motobecane Mirage -197? Velosolex L'Etoile -'71 Raleigh Super Course
Posts: 2,473
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That actually looks a lot like my 3Rensho built Specialized Allez Comp. Seatstay cluster and fork look that way, anyhow. Decals can come from anywhere, of course. Mine doesn't have the cable guides under the BB or the stamped shell, but dang, it's close.
Captain Blight is offline   Reply With Quote
Old 08-27-12, 03:36 PM   #7
sailorbenjamin
26 tpi nut.

sailorbenjamin's Avatar

Join Date: Mar 2008
Location: Rhode Island (an obscure suburb of Connecticut)
Bikes: one of each
Posts: 5,698
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
No headbadge holes are there?
__________________
I have spoken.
sailorbenjamin is offline   Reply With Quote
Old 08-27-12, 03:48 PM   #8
nlerner
Senior Member

Join Date: Dec 2005
Bikes:
Posts: 9,901
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 41 Post(s)
I'm not seeing anything that shouts Raleigh or Carlton.
nlerner is offline   Reply With Quote
Old 08-27-12, 04:41 PM   #9
jo1010
Junior Member
Thread Starter

Join Date: Jul 2012
Bikes:
Posts: 14
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by sailorbenjamin View Post
No headbadge holes are there?
That's right - I don't think there is any evidence of headbadge fitting or filling of headbadge holes. Intriguing since I really don't think it's been repainted - looking at the numerous scratches there is only one layer of paint. Then again I haven't inspected the head tube really closely - will do so tomorrow and report back if findings are any different....
jo1010 is offline   Reply With Quote
Old 08-27-12, 04:58 PM   #10
jo1010
Junior Member
Thread Starter

Join Date: Jul 2012
Bikes:
Posts: 14
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Let me give a quick update on what I'm thinking. Definitely not 'Raleigh' - there is nothing in Raleigh catalogues that is remotely similar. However, I did find this site giving details of a Carlton Professional:
http://www.mytenspeeds.com/My_TenSpe..._2_Finding.htm

On that page about half way down is a pic of seat lug detail that seems similar to my example. Many of the other details of the bikes are different, but that's not necessarily surprising if the dating estimate of 1969 based on the stamped frame code is correct (and the date code format does seem to correspond to that used by Raleigh/Carlton). It also seems that Carlton did produce their own cycles alongside Raleigh production and also had their own catalogue - a 1970 Carlton catalogue is on Bulgier, but again this is for a year later than my case so I wouldn't expect it to correspond exactly.

However, all this is fairly loose and could quite easily be completely wrong...just my current best guess really..... until someone comes up with a better one!
jo1010 is offline   Reply With Quote
Old 08-28-12, 10:32 AM   #11
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Bikes:
Posts: 9,195
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 15 Post(s)
If I were the owner, I might bother Don Gillies to take a look at this frame...if it's anything from Raleigh or Carlton (or not), he might know.
gillies(AT)cs.ubc.ca
Since I don't know how he'd feel about a "blind email request" for his participation, I should approach him very politely.
unworthy1 is offline   Reply With Quote
Old 08-28-12, 11:01 AM   #12
jo1010
Junior Member
Thread Starter

Join Date: Jul 2012
Bikes:
Posts: 14
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks for that suggestion *unworthy1* - I will very politely enquire, and update the thread accordingly....
Joe
jo1010 is offline   Reply With Quote
Old 08-28-12, 01:03 PM   #13
bikingshearer
Crawlin' up, flyin' down

bikingshearer's Avatar

Join Date: Jan 2006
Location: Democratic Peoples' Republic of Berkeley
Bikes: 1967 Paramount, 1982-ish Ron Cooper,1986 De Rosa Professional, 1978 Eisentraut "A," 1961 BianchiCompetizione, 1994 Trek 520, 199? Burley Bossa Nova, early-1970s Cinelli Speciale Corsa
Posts: 3,328
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
I agree that both the under-BB cable routing and the style of Reynolds sticker say "probably 1980s, definitely not 1969." BTW, a 1969 Reynolds 531 frame sticker would have the "531" on a slant (at least for the butted tubes), and the fork stickers would be triangular in shape, with a flat top side.
__________________
"I'm in shape -- round is a shape." Andy Rooney
bikingshearer is offline   Reply With Quote
Old 08-28-12, 04:55 PM   #14
dbakl
Senior Member

Join Date: Nov 2005
Bikes: Cinelli, Paramount, Raleigh, Carlton, Zeus, Gemniani, Frejus, Legnano, Pinarello, Falcon
Posts: 5,775
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Doesn't say Carlton to me. I believe that Reynolds decal was for an anniversary, 1984.
dbakl is offline   Reply With Quote
Old 08-28-12, 05:42 PM   #15
jo1010
Junior Member
Thread Starter

Join Date: Jul 2012
Bikes:
Posts: 14
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks to those who have contributed so far and have nudged things (and me) in the right direction (perhaps) of the 1980s. I've collated more evidence, which doesn’t necessarily lend itself to a consistent conclusion

1) All the components are shimano – Tange headset, shimano light action shifters/mechs, biopace chainwheels, 105 cranks, Rigida rims with Maillard hubs, Weinmann 570 sidepulls, Shimnao SLR brake levers. Sounds like mid-80’s. So is this really an 80’s bike (eg a Raleigh Ritmo?) that somebody has painted in Carlton colours? Paint does not look like a factory finish, the Reynolds decals do look wrong (too new) for even an 80’s bike, and I can’t see where any headbadge placement was – so the frame must have been filled, painted, and newer Reynolds decals applied. However, if this is true somebody went to a vast amount of trouble with all the lug highlighting – which was then detracted from with the Shimano component build. Seems a little self contradictory to expend the effort, but then everybody’s different (and perhaps the original owner really wanted a Carlton but couldn't afford/obtain one).

2) However, the frame numbering is still anomalous. Later Raleighs (I thought) all had the 'Raleigh system' of numbering which is not like the AAnnn stamped on the bottom bracket of this bike. So is this really an older frame (seat clamp bolt is threaded into the frame itself unlike all 80’s Raleighs that I’ve seen) that has been updated with Shimano components – but then that also would seem a little pointless.

So the search goes on, and I’ll research more into 1980’s Raleighs to see if I can find any similarities....
