Show off your DIY lights
I am currently using a DIY set up and would like to see others.
#2
Mad bike riding scientist
Join Date: Nov 2004
Location: Denver, CO
Posts: 27,335
Bikes: Some silver ones, a red one, a black and orange one, and a few titanium ones
Mentioned: 152 Post(s)
Tagged: 1 Thread(s)
Quoted: 6193 Post(s)
Liked 4,192 Times
in
2,352 Posts
Look here
__________________
Stuart Black
Plan Epsilon Around Lake Michigan in the era of Covid
Old School…When It Wasn’t Ancient bikepacking
Gold Fever Three days of dirt in Colorado
Pokin' around the Poconos A cold ride around Lake Erie
Dinosaurs in Colorado A mountain bike guide to the Purgatory Canyon dinosaur trackway
Solo Without Pie. The search for pie in the Midwest.
Picking the Scablands. Washington and Oregon, 2005. Pie and spiders on the Columbia River!
Stuart Black
Plan Epsilon Around Lake Michigan in the era of Covid
Old School…When It Wasn’t Ancient bikepacking
Gold Fever Three days of dirt in Colorado
Pokin' around the Poconos A cold ride around Lake Erie
Dinosaurs in Colorado A mountain bike guide to the Purgatory Canyon dinosaur trackway
Solo Without Pie. The search for pie in the Midwest.
Picking the Scablands. Washington and Oregon, 2005. Pie and spiders on the Columbia River!
#4
Just another bum
Thread Starter
Join Date: Nov 2007
Location: Wichita, KS
Posts: 18
Bikes: Giant FCR2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
My lights started with Optronic housings from Wal-Mart $15.00. The 12v 7ah battery came from a computer power back up, free. The wire is from work, surplus = free. The charger is Black & Decker Battery Maintainer, it carries 2 amps and is a smart charger. Tail light, small box and switches came from www.allelectronics.com $10.00. Lamps are from HD $7.00.
One of the lights is a 20 watt and the other is a 50 watt, all three lights are on thier switch.
Here are the pics.
One of the lights is a 20 watt and the other is a 50 watt, all three lights are on thier switch.
Here are the pics.
#5
Mad bike riding scientist
Join Date: Nov 2004
Location: Denver, CO
Posts: 27,335
Bikes: Some silver ones, a red one, a black and orange one, and a few titanium ones
Mentioned: 152 Post(s)
Tagged: 1 Thread(s)
Quoted: 6193 Post(s)
Liked 4,192 Times
in
2,352 Posts
No, look HERE: https://www.bikeforums.net/showthread.php?t=42629
__________________
Stuart Black
Plan Epsilon Around Lake Michigan in the era of Covid
Old School…When It Wasn’t Ancient bikepacking
Gold Fever Three days of dirt in Colorado
Pokin' around the Poconos A cold ride around Lake Erie
Dinosaurs in Colorado A mountain bike guide to the Purgatory Canyon dinosaur trackway
Solo Without Pie. The search for pie in the Midwest.
Picking the Scablands. Washington and Oregon, 2005. Pie and spiders on the Columbia River!
Stuart Black
Plan Epsilon Around Lake Michigan in the era of Covid
Old School…When It Wasn’t Ancient bikepacking
Gold Fever Three days of dirt in Colorado
Pokin' around the Poconos A cold ride around Lake Erie
Dinosaurs in Colorado A mountain bike guide to the Purgatory Canyon dinosaur trackway
Solo Without Pie. The search for pie in the Midwest.
Picking the Scablands. Washington and Oregon, 2005. Pie and spiders on the Columbia River!
#6
Just another bum
Thread Starter
Join Date: Nov 2007
Location: Wichita, KS
Posts: 18
Bikes: Giant FCR2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
#7
Senior_Member2
Join Date: Apr 2006
Location: Finlando NOT: Orlando, Fl
Posts: 1,694
Bikes: Beater + Nishiki Bigfoot X-29
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
Some one needs to compile a list, with links, of completed lights, and projects, there is a list like that at candle power forums. The total geekiness thread is more discussion than showing your lights.
#8
Scott
Join Date: Jun 2006
Posts: 2,393
Bikes: Too Many
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 1 Time
in
1 Post
Luxeon 1-watt LED with matching Fraen 10X20 lens and holder mounted in a 1" PVC pipe coupler.
I run it and an LED taillight from four Ni-MH batteries for a system voltage of 4.8-volts DC. With the dynamo engaged the system voltage is 5.2-volts at 8 MPH or faster so I may recharge my batteries as I ride. I never worry about dead batteries. I may also power and recharge USB devices like a PALM TIX, Cell Phone or GPS unit.
I run it and an LED taillight from four Ni-MH batteries for a system voltage of 4.8-volts DC. With the dynamo engaged the system voltage is 5.2-volts at 8 MPH or faster so I may recharge my batteries as I ride. I never worry about dead batteries. I may also power and recharge USB devices like a PALM TIX, Cell Phone or GPS unit.
Last edited by n4zou; 12-11-07 at 02:04 PM.
#9
Recumbent Evangelist
Join Date: Mar 2005
Location: Kitchener, Ontario
Posts: 2,991
Bikes: Rebel Cycles Trike, Trek 7500FX
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
My new tail light is complete. It's a bit shorter than the old one, since I kept smacking it on stuff. I'll have video when I get my video camera for Christmas (woohoo!) Also, I got boards and parts to make 15 more of them, so I'll be busy with my soldering iron in the next few weeks!
#11
Senior_Member2
Join Date: Apr 2006
Location: Finlando NOT: Orlando, Fl
Posts: 1,694
Bikes: Beater + Nishiki Bigfoot X-29
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
My fav thread is pics of you all lit up. Or something like that, i thought it was going to be a sticky but it died somehow.
#12
Senior Member
Join Date: Oct 2007
Location: Central Florida
Posts: 274
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
I need to get some fresh pictures of mine. It's changed so much since I did my thread I don't even want to bother posting old pics of it. I'll work on it tomorrow.
#14
Senior Member
Join Date: Apr 2007
Location: South Bay Area
Posts: 163
Bikes: trek 7.2, 7.3FX, 5200 OCLV
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
I have a 35W HID Bulb rigged up with a Harbor Freight foglight and a 50w Catz XSL Halogen Foglight. The HID is powered by a 12V 12AH battery and the Catz Foglight is powered by a 12V 7AH battery. I only use the CATZ foglight for heavy traffic area. Most of the time I just leave it off.
All these gadgets are stuffed into my trusty 05 Trek 7.2FX Hybrid. Notice real hybrid sports road bike front end parts(caliper, fork & tire) and back end remains MTB parts.....
All these gadgets are stuffed into my trusty 05 Trek 7.2FX Hybrid. Notice real hybrid sports road bike front end parts(caliper, fork & tire) and back end remains MTB parts.....
#15
Senior Member
Join Date: Oct 2007
Location: Central Florida
Posts: 274
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
Ask and you shall receive...
Time for some current pics...
First a reference flash pic of the garage door:
This is the light setup I run every morning. Note the backup lights I have on the bar that suck but are bright enough to get me home in the event of a main battery failure, and the 3 watt LED Maglight on the top tube that can add useful light but is mainly a dog beater.
And here's just the flood light (35 degree, 20 watt at 14.4V):
And the spotlight only (10 degree, 20 watt, at 14.4V):
And my new addition, a rayovac headlight modded with a self regulating Cree Xre LED pack in it:
And lastly, this is how I ride (or roll if you live in the ghetto) in the mornings with the floodlight and headlight:
Plenty of light, lot's of redundancy, options, and backup.
#16
Just another bum
Thread Starter
Join Date: Nov 2007
Location: Wichita, KS
Posts: 18
Bikes: Giant FCR2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
Overdrive, what did you make your halogen light housings from? Before I bought the Optronic driving lights I made two housings from outdoor light fixtures. They would have worked but would not looked as clean.
Your lights look good.
Here is a pic of the housings that did not make it.
Your lights look good.
Here is a pic of the housings that did not make it.
#18
Senior Member
Join Date: Oct 2007
Location: Central Florida
Posts: 274
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
Mine are 1.5" PVC inline couplers that I ground out the leading edge of just enough to let the light sit flush in. I sealed one with epoxy and the other with JB Weld. I've looked at tons of track lights and light fixtures but just haven't seen exactly what I'm looking for. Some of the track lights come close but the ones with the MR16 plug in them also seem to always come with a ac/dc converter attached to them. I'll probably end up going the optronics route. I just don't want to pay an arm and a leg for them and it seems lately everyone on fleabay wants to pay retail.
#19
Just another bum
Thread Starter
Join Date: Nov 2007
Location: Wichita, KS
Posts: 18
Bikes: Giant FCR2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
The units that I did not use are aluminum; I liked them better for this. I ground a groove inside to hold a snap ring. I also had to open the inside diameter to allow the mr-16 bulbs to set recessed inside the housing. They would have worked great at removing the heat but had casted printing on the outside, not good.
I found the Optronics at Wal-Mart for $15.00, this seemed reasonable enough. I took those to work and sandblasted off the chrome and painted them black. They get hot, after a 2 hour ride the 20 watt is not hot enough to bubble the paint but it is close. I do not run the 50 watt for long; it is used as a high beam for high speeds. My longest runs have been 2.5 hours and the battery is holding up well.
I found the Optronics at Wal-Mart for $15.00, this seemed reasonable enough. I took those to work and sandblasted off the chrome and painted them black. They get hot, after a 2 hour ride the 20 watt is not hot enough to bubble the paint but it is close. I do not run the 50 watt for long; it is used as a high beam for high speeds. My longest runs have been 2.5 hours and the battery is holding up well.
#20
I am not a car
Join Date: May 2004
Location: Decatur, GA
Posts: 747
Bikes: Giant Revel 1, Surly Ogre
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 1 Time
in
1 Post
See my current setup here: https://www.bikeforums.net/showpost.p...postcount=1739
__________________
"Bad facts make bad laws." FZ
"Bad facts make bad laws." FZ
#21
Just another bum
Thread Starter
Join Date: Nov 2007
Location: Wichita, KS
Posts: 18
Bikes: Giant FCR2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
Interesting Map tester, have you tested your leds against the mr-16 halogens. I have not found much information on newer led technology.
#22
I am not a car
Join Date: May 2004
Location: Decatur, GA
Posts: 747
Bikes: Giant Revel 1, Surly Ogre
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 1 Time
in
1 Post
I started with a 20w MR16 halogen, and my son's bike still has one. It is quite bright, probably brighter than the LEDs. I should take both of them out on the street and do a side-by-side test. The only reason I went with LEDs is to get a longer runtime without using a bigger battery. A side effect is the color of the LEDs (cool white) is very different than halogens (both car and bike), so it tends to be more noticeable.
__________________
"Bad facts make bad laws." FZ
"Bad facts make bad laws." FZ
#24
Senior Member
Join Date: Jun 2006
Location: Augusta, GA
Posts: 639
Bikes: Bottecchia CF frame and fork, Ultegra 6603 crank and FD, DuraAce RD, Easton Vista wheels, Brooks B-17 saddle, Shimano 105 brakes, Michelin Pro2 Race tires
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times
in
0 Posts
I used to have a 20W halogen mounted on the handlebar overvolted to about 15 volts, so it was pulling about 30 watts. I've recently removed it and installed a CREE mounted on the left fork, pulling about 4 watts. I've ordered another CREE for the right fork. With the 2nd CREE, I think the light will be close enough to the halogen to satisfy me. The one CREE is fine for my morning rides, but two will be a little better and give me some extra power during fast decents on unlit roads.
The color of the CREE is much whiter (bluish white) than the halogen (more reddish, yellowish white), and is more of a spot than a flood with the bulb choice I made. But the CREE still gives enough diffuse light around the spots to give some good visibility up closer to the bike while the spot is aimed about 30 to 40 feet down the road.
I was getting about 2.25 hours runtime on my halogen, so I think the same battery should drive two CREEs for about 8.5 hours or one CREE for 17 hours. That will allow me to ride all night on the longer brevets!
The color of the CREE is much whiter (bluish white) than the halogen (more reddish, yellowish white), and is more of a spot than a flood with the bulb choice I made. But the CREE still gives enough diffuse light around the spots to give some good visibility up closer to the bike while the spot is aimed about 30 to 40 feet down the road.
I was getting about 2.25 hours runtime on my halogen, so I think the same battery should drive two CREEs for about 8.5 hours or one CREE for 17 hours. That will allow me to ride all night on the longer brevets!
#25
Healthy and active
Join Date: Mar 2007
Location: Caldwell, Idaho USA
Posts: 887
Bikes: mid-60's Dunelt 10-speed, Specialized Allez Sport Tripple, Trek 7.2 FX
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Likes: 0
Liked 1 Time
in
1 Post
This headlight is made from a 3 LED module made for a 2 AA cell Maglite flashlight. It is mounted with a piece of steel wire to a battery holder from Radio Shack. I bend the wire to aim the light. The switch is a piece of plastic from a milk jug and is slipped in between a battery tip and holder terminal to shut the light "off." It is bright enough for me to see what I need to see.
