Would like to see your DIY flashlight mounts

I bought a Q5 Cree flashlight the other day, and am wanting to attach it to my bike. I would like to make my own mount if at all possible. Just looking for suggestions.

Thanks in advance.
Brett92 is offline   Reply With Quote
Old 09-15-08, 06:26 PM   #2
uke
it's easy if you let it.

uke's Avatar

Join Date: Jul 2008
Location: indoors and out.
Bikes:
Posts: 4,124
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Unless you can make it for less than $1.90, I'd get one of these.
uke is offline   Reply With Quote
Old 09-15-08, 06:28 PM   #3
JPMacG
Senior Member

Join Date: Dec 2006
Location: Bucks County, PA
Bikes:
Posts: 400
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I'm using two conduit clamps bolted back to back. The one for the flashlight is size 0 and the one for the handlebar is size 1. They were about $2.35 for a 5 pack at Home Depot, so I have enough for 5 mounts for about $5. I put heat shrink tubing on them to prevent scratching the bike and light, but you could just as well use electrical tape or duct tape.

I learned about it here on BikeForums. Seach this forum for conduit clamps.
JPMacG is offline   Reply With Quote
Old 09-15-08, 07:38 PM   #4
joshandlauri
Got another new bike

Join Date: Nov 2007
Location: dundalk, md
Bikes: pacific elite 3.1 w/upgrades and street slicks, got an iron horse maverick now, cannondale sr800, gt gtr pro rival
Posts: 584
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
use 2 of these, one to the bar and one to the light and bolt together, i have mine like this and I can still move and aim them as needed, plus they don't stratch the bars.





Last edited by joshandlauri; 09-15-08 at 07:45 PM.
joshandlauri is offline   Reply With Quote
Old 09-15-08, 08:18 PM   #5
Brett92
Junior Member
Thread Starter

Join Date: Aug 2008
Bikes:
Posts: 9
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks guys for the replies.

Hey Josh, what are those called? Is that the "conduit clamps" the poster above you was referring to? How would you say that mount stands up to bumps? I'm hoping to carry my lights off road.
Brett92 is offline   Reply With Quote
Old 09-15-08, 10:57 PM   #6
bicycleflyer
747 Freight Pilot

bicycleflyer's Avatar

Join Date: Aug 2008
Location: Ohio, USA
Bikes: Rivendell, Bike-Friday Pocket-Rocket and one home made fixed gear
Posts: 458
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Hey Josh, what are those called? Is that the "conduit clamps" the poster above you was referring to?
No, those are P-Clamps. Conduit clamps are a different animal. Here is the link to the DIY mount using conduit clamps. http://nordicgroup.us/s78/flashlights.html
bicycleflyer is offline   Reply With Quote
Old 09-16-08, 02:08 AM   #7
JeffB502
Arrogant Safety Nanny

Join Date: Apr 2007
Location: Santa Maria, CA
Bikes: 2007 Trek 7.2 FX, 2008 Trek Madone 5.2
Posts: 554
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Livestrong band and Fenix P1:


Dinotte spare O-ring and DX 9-LED el cheapo flashlight:


Anything rubber and stretchy should work, with another piece of rubber (I used a small piece of a cut innertube) between the flashlight and the bar to prevent scratching and improve stability.

Others have made mounts out of old/punctured innertubes...that's the ultimate in free, heh.

Edit: And oh yeah...here's my solution for helmet mounting my Fenix P3D:

Last edited by JeffB502; 09-16-08 at 02:15 AM. Reason: Added helmet mount picture.
