Old 11-17-10, 03:58 PM   #76
SpartyBrutus
Newbie

Join Date: Nov 2010
Bikes:
Posts: 2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Hi, relative newbie to this forum.

I purchased a B2C hub and Alex DM18 20 rim towards building a new wheel on a (formerly single speed) Swobo Folsom. LBS did the work building the wheel and installing. Total cost ~$145 parts/labor. Kept the old wheel as a spare (reused rear cog).

The hub works pretty well so far. I think its pretty easy to shift without engaging the brake though I have to plan ahead a bit at a stoplight to restart in LO.

With my 42t/18t cogs the hub runs at about 60 and 83 gear inches for low/hi gear. The 60 gear inches is fine for gentle hills, though I might change to 20t rear cog if my knees start protesting... Certainly the high gear makes the Folsom scoot right along - its fun pushing 20mph on a fat tire oversize BMX bike!

Will keep you posted as to the hubs performance through this winter.
SpartyBrutus is offline   Reply With Quote
Old 11-18-10, 08:37 AM   #77
Uno
Member

Join Date: Nov 2010
Location: Germany, Bavaria
Bikes: Dahon mu uno; VSF T400 BA, Singlespeed bike
Posts: 29
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Hi,

i like this new Moulton TSR2

http://www.moultonbicycles.co.uk/ima.../TSR2_Zoom.jpg

It´s also available in black but i find the orange quite cool.


Uno is offline   Reply With Quote
Old 11-30-10, 10:29 AM   #78
kesroberts
Senior Member

kesroberts's Avatar

Join Date: Apr 2004
Location: Worcester, Mass.
Bikes: Several
Posts: 292
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Is everyone getting this clicking sound when braking? Does it go away with break-in? I am on mine, but haven't put many miles on it yet.



Quote:
Originally Posted by SesameCrunch View Post
I have an 18t cog with 39t ring. It works well for me.

Yeah, I get noise when I brake also. It sounds like metal straining. I'm guessing that it's the newness of the brake drum, or not enough grease there. I don't know for sure. Like you, I'm hoping it'll break in over time. If it doesn't quit in a few months, I'll take it apart and find out the cause.

I'm loving the hub otherwise, though.
kesroberts is offline   Reply With Quote
Old 12-06-10, 03:28 PM   #79
mconlonx
Nobody

mconlonx's Avatar

Join Date: Jun 2007
Bikes:
Posts: 7,148
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 612 Post(s)
Not a folder:







Da hub:


Got it with an 18t sprocket, but changed to a 21. 44/21 gearing works out to about 56/75

OK, so a front brake isn't strictly necessary with the coaster brake, but I have some experience with higher pressure, narrower tires and coaster brakes, so I wanted a front brake, was interested in the new 90mm S/A hubs, and really, really wanted to run it through the headset. Result is I could do barspins... if I knew how. Practically speaking, however, nothing on the front runs into any part of the frame:


Fun, fun bike. If you get a chance, try out a S2C bike or build one up on your own. Custom wheel like I built--S2C hub
__________________
I know next to nothing. I am frequently wrong.
mconlonx is offline   Reply With Quote
Old 02-19-11, 08:04 AM   #80
fwd-bwd
Senior Member

Join Date: Feb 2009
Bikes:
Posts: 218
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Finally picked up my Moulton TSR-2 yesterday and test-rode it for about 10 miles. I found two peculiar issues about the S2C on the bike: There was constant clicking noise in either gears when pedaling (not sure about coasting; couldn't hear anything over the freewheel clicking), and black grease kept oozing from the seam between hub shell and left cap. The grease even got on the spokes and rim due to the force of wheel rotation. After a thorough cleaning, more grease came out. Are these problems temporary and normal for a new S2C?
fwd-bwd is offline   Reply With Quote
Old 02-19-11, 11:32 AM   #81
jerrysimon
Senior Member

Join Date: Jan 2010
Bikes:
Posts: 433
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I have a TSR2 as well. Basically the S2C it is both a little stiff and oozes black grease when you first get it. However do not worry after about 100 miles things really start to free up and the grease oozing ceases.

I agree though the S2C is a little noisey. Again I suspect this will reduce as it all beds in.

I am loving my TSR2.

Regards

Jerry
jerrysimon is offline   Reply With Quote
Old 02-19-11, 07:22 PM   #82
lexm
Erudite white trash

lexm's Avatar

Join Date: Jul 2010
Location: Omaha
Bikes: Rivendell Clem Smith, Jr. Low, Rivendell SimpleOne, Schwinn Super Sport ('87), Velo Orange Campeur
Posts: 202
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by fwd-bwd View Post
Finally picked up my Moulton TSR-2 yesterday and test-rode it for about 10 miles. I found two peculiar issues about the S2C on the bike: There was constant clicking noise in either gears when pedaling (not sure about coasting; couldn't hear anything over the freewheel clicking), and black grease kept oozing from the seam between hub shell and left cap. The grease even got on the spokes and rim due to the force of wheel rotation. After a thorough cleaning, more grease came out. Are these problems temporary and normal for a new S2C?
Mine emits the same gentle clicking sound. I'm at about 80 miles since purchase (Chicago weather having precluded much riding). So, listen to Brother Jerry. All will be right soon.
lexm is offline   Reply With Quote
Old 02-20-11, 12:00 PM   #83
SesameCrunch
Eschew Obfuscation

SesameCrunch's Avatar

Join Date: Aug 2005
Location: San Francisco Bay Area
Bikes: 2005 Fuji Professional, 2002 Lemond Zurich, Folders - Strida, Merc, Dahon, Downtube, Recumbent folder
Posts: 3,850
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by fwd-bwd View Post
Finally picked up my Moulton TSR-2 yesterday and test-rode it for about 10 miles. I found two peculiar issues about the S2C on the bike: There was constant clicking noise in either gears when pedaling (not sure about coasting; couldn't hear anything over the freewheel clicking), and black grease kept oozing from the seam between hub shell and left cap. The grease even got on the spokes and rim due to the force of wheel rotation. After a thorough cleaning, more grease came out. Are these problems temporary and normal for a new S2C?
I had the same concerns when I first laced up my S2C in September of last year. Now, she is quiet and running smoothly.
__________________
SesameCrunch is offline   Reply With Quote
Old 02-21-11, 10:08 AM   #84
fwd-bwd
Senior Member

Join Date: Feb 2009
Bikes:
Posts: 218
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks everyone for sharing your experience. I guess I just need to ride more and break it in.
fwd-bwd is offline   Reply With Quote
Old 03-01-11, 02:02 PM   #85
fwd-bwd
Senior Member

Join Date: Feb 2009
Bikes:
Posts: 218
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Anyone knows where to buy the dust cap (HSL921)? I couldn't find any websites selling it. Is it wise riding without one?
fwd-bwd is offline   Reply With Quote
Old 03-01-11, 06:25 PM   #86
Dynocoaster
Senior Member

Join Date: May 2004
Location: Pacific Northwest
Bikes: Too many....................
Posts: 3,075
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Get hold of Sturmey Archer in California and they will let you know what parts are available.
Dynocoaster is offline   Reply With Quote
Old 03-10-11, 02:40 PM   #87
Johnnnyc
Junior Member

Join Date: Feb 2009
Bikes:
Posts: 17
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Wanted to pop in on grease boilout issues;

We've built about 25 sets with the S2C recently, and stuff is going pretty well.

Couple folks complained about this. All but one of the hubs seems to have settled down with extended (100+ mile riding)

Excited to see how these hubs hold up to their original duomatic fame!

-Johnny

Attached Images
File Type: jpg 38departurebicycle.jpg (44.1 KB, 28 views)
Johnnnyc is offline   Reply With Quote
Old 03-10-11, 02:55 PM   #88
SesameCrunch
Eschew Obfuscation

SesameCrunch's Avatar

Join Date: Aug 2005
Location: San Francisco Bay Area
Bikes: 2005 Fuji Professional, 2002 Lemond Zurich, Folders - Strida, Merc, Dahon, Downtube, Recumbent folder
Posts: 3,850
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Johnnnyc View Post

Excited to see how these hubs hold up to their original duomatic fame!
I have an original Duomatic hub and the new S2C hub (since September). The S2C is very impressive. Biggest improvement is in the braking. The Duo brake does not inspire confidence at all, and I would never dream of riding one without a front brake. OTOH, the S2C's braking is very solid. I can easily lock up the rear wheel if I'm not paying attention.

A nice comparison of the two can be found here: http://www.moultonbuzz.com/2011/02/s...er-s2c-review/ . I basically agree with their findings.
__________________
SesameCrunch is offline   Reply With Quote
Old 03-11-11, 04:13 AM   #89
Pat McCarthy
Junior Member

Join Date: Jun 2007
Bikes:
Posts: 9
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Hi all,

Any thoughts on whether a similar gear ratio provides comparable performance on a folder and a full-size non-folder?

I have a 2-speed Brompton (133%, 4.45m - 5.93m) and was thinking of getting a bike with the 2C (138% - http://www.achielle.be/EN/samsaar.php) for days I don't have to fold.

Is it safe to assume that anything I currently tackle on the Brompton will be equally "tackle-able" with the full-size bike?

Thanks!
Pat
Pat McCarthy is offline   Reply With Quote
Old 03-14-11, 05:22 AM   #90
jerrysimon
Senior Member

Join Date: Jan 2010
Bikes:
Posts: 433
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I am still not certain if my S2C hub has worn in yet. I have done about 150 miles and although only a little bit of oil/grease is still oozing out it does rumble a little when pedaling in the higher +38% gear ?

I am definately getting use to it especially the need to have your foot in the right position when stopping ready to take off again, but sometimes I find it also changes gear when I go over a bump or I jolt a little ?

Sometimes it refuses to change gear until I pedal back a few time to hear that defining "click" ?

Also sometimes I almost feel a little click/slip as it changes gear when setting off again ?

Maybe I'm being paranoid

Regards

Jerry

Last edited by jerrysimon; 03-14-11 at 11:51 AM.
jerrysimon is offline   Reply With Quote
Old 05-07-11, 04:03 PM   #91
ahoihoi
Newbie

Join Date: May 2011
Bikes:
Posts: 1
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
S2C - A mixed bag?

I've used the s2c as a replacement of a f&s 3-speed on my cohabitant's dutch bike, so far it's done about 130 km. Sadly, the experience with the hub has not been without issues.
1. Firstly, the hub looks ace, kickback-shifting is fun and much easier than anticipated. The range is so huge the use of a big cog, e.g. 22 or more, is not unreasonable, especially for a lady's bike! (700c/44 blade/22 cog). Also, it really is a heavy piece of kit!
2. FWIW, the hub is next to inaudible in comparison to the torpedo.
3. The s2c is too tightly packed albeit the excess seems to get squeezed out nicely Ours already lost quite a proportion of its initial friction quite probably due to this, though there still is room for better performance…
As to the issues we observed, some of which were already voiced, e.g. by evinem. With the cohabitant's hub there seem to be issues with the adjustment and precision of the hub.
4. Braking forcefully provokes loud ticking and pedal-kickback which is bad for modulation and does not infuse confidence. The brakes perform well enough and are not yet broken in, so I hold my judgment here.
5.The kick-shift into 2nd gear frequently puts the hub in a limbo between 1st and 2nd gear; it then takes about half a revolution of forward-pedaling in 1st gear until suddenly the 2nd gear kicks in.
Quote:
Originally Posted by jerrysimon View Post
Sometimes it refuses to change gear until I pedal back a few times to hear that defining "click"
Jerry
This seems to be a (worse?) variant of that same behaviour and constitutes the main complaint I have atm. Not sure how it can be resolved.
6. It is possible to lock the hub while backwheeling. This might be related to the aforementioned limbo-state and could be resolved with gentle forward-backward turning of wheel and pedals. I strongly suspect the hub can be damaged in this state with too much force applied. I'm not exactly sure whether this is a problem of the coaster brakes though.
7. Lastly, coasting at higher speeds frequently causes involuntary gear changes. This happens even when the rider takes care not to make back-pedaling motions. I assume this also is due to the relatively high internal friction of a new and excessively packed hub, so it might be premature to judge on that one.
TL,DR: Looks ace, is a tad heavy, operation is easy, but not sure whether its precision is as good as it should. Those are the problems with mail-ordered fringe products, I guess.

Last edited by ahoihoi; 05-07-11 at 04:19 PM.
ahoihoi is offline   Reply With Quote
Old 05-08-11, 06:17 AM   #92
jerrysimon
Senior Member

Join Date: Jan 2010
Bikes:
Posts: 433
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Since that post I am now up to about 300 miles and things have really settled down.

Consistant changing has been possible since I changed my technique as follows:

I take the cranks horizontal and stop pedaling then move the cranks slightly
forward and then back to change. I have tried this on the bike in my work stand
by hand and it changes every time. Then taking it out on the road once I got my
legs set up to do the same thing, it now works a treat.

I don't think it matters where the cranks are, the trick seems to be the very slight foward movement after you stop pedaling and then you can back pedal and change every time!

This hub certainly takes a while to settle down and need wearing in but I am pleased with it now.

Regards

Jerry
jerrysimon is offline   Reply With Quote
Old 05-08-11, 09:29 AM   #93
mconlonx
Nobody

mconlonx's Avatar

Join Date: Jun 2007
Bikes:
Posts: 7,148
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 612 Post(s)
Folding S2C build:

__________________
I know next to nothing. I am frequently wrong.
mconlonx is offline   Reply With Quote
Old 08-02-11, 12:06 PM   #94
bretterb
Newbie

Join Date: Aug 2011
Location: Bloomington, Indiana, USA
Bikes: Giant OCR-A1, Spot Coyote Belt Drive, Moulton TSR2, Sillgey Piccolo
Posts: 1
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I have an almost new (2-weeks old and less than 5 miles on it) Orange Moulton TSR-2 for sale if anyone's interested. Paid $1890 for it new and willing to sell it for $1600. bretterb@gmail.com if interested. Thanks.
bretterb is offline   Reply With Quote
Old 08-24-11, 08:36 PM   #95
elfneedsfoodbad
Junior Member

Join Date: Aug 2011
Bikes:
Posts: 8
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by jerrysimon View Post
Since that post I am now up to about 300 miles and things have really settled down.

...

This hub certainly takes a while to settle down and need wearing in but I am pleased with it now.

Regards

Jerry
Am I understanding this right? You're referring to the S2C on a Brompton? I'm picking my first one up soon but this sounds like a future mod - no cables to the rear and one lever. If this is a Brompton, how does the coaster brake function with the chain tensioner? Any chance you'd post a pic?
elfneedsfoodbad is offline   Reply With Quote
Old 08-26-11, 06:21 PM   #96
SesameCrunch
Eschew Obfuscation

SesameCrunch's Avatar

Join Date: Aug 2005
Location: San Francisco Bay Area
Bikes: 2005 Fuji Professional, 2002 Lemond Zurich, Folders - Strida, Merc, Dahon, Downtube, Recumbent folder
Posts: 3,850
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
My S2C hub, which is now 9 months old, has mysteriously locked up on me. It's done it twice. I haven't been able to figure why it locks up and why it suddenly unlocks. It's a little worrisome.

Great hub otherwise. After the initial settling in period, I've enjoyed this hub tremendously. Hope this locking up habit doesn't persist. If it does, there's a SRAM Automatic hub waiting in the wings to replace it....
__________________
SesameCrunch is offline   Reply With Quote
Old 10-17-11, 11:18 AM   #97
max_r
Newbie

Join Date: Oct 2011
Bikes:
Posts: 4
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I have built 700cc wheel with S2C hub for my homemade bike/commuter. It has all the same symptoms as described here. Lots of grease coming out of hub and it makes really annoying noise and clicking when both braking and pedaling in high gear. I contacted Sturmey Archer and they said that some hubs were not machined properly, here is the quote from reply:
"We had some hubs have an issue with the brake surface not being fully polished so when braking it would make clicking, popping, sounds. But I have never heard any complaints about abnormal clicking in second just while pedaling along. If the clicking is happening under braking load I would replace your hub for you. I just need to know the color and hole drilling and a good shipping address."
so it looks like there should not be any sound to start with. I have already made more than 100km for sure and the hub only sounds worse. My concern is it will brake somewhere in the middle of my commute, which is 18km one way. So I will probably go ahead a rebuild a wheel with a new hub if they send it to me. It also ceased a few times to the point when the wheel was locked completely. Considering the weight of the hub I'd expect it to be bulletproof and reliable. So far it is not. I am thinking about eventually switching to shimano nexus if this keeps going on.
max_r is offline   Reply With Quote
Old 10-17-11, 11:29 AM   #98
fwd-bwd
Senior Member

Join Date: Feb 2009
Bikes:
Posts: 218
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
My S2C locked up on me twice as well. Not cool. Mine is from one of the earliest productions and hopefully SA has improved it since.
fwd-bwd is offline   Reply With Quote
Old 10-19-11, 12:03 PM   #99
fwd-bwd
Senior Member

Join Date: Feb 2009
Bikes:
Posts: 218
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
One additional note: A few times my S2C got stuck in the high or low gear. I had to kept riding and braking to somehow bring the shifting ability back. Perhaps mine is an isolated case, or I simply don't know how to ride it "properly." Either way it isn't reliable enough to put my life on it. I'm getting a new hub.
fwd-bwd is offline   Reply With Quote
Old 02-16-12, 06:19 AM   #100
7VEN
Newbie

Join Date: Sep 2011
Bikes:
Posts: 4
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I know it's not a folding bike, but if anyones interested, here is a pic of my red 32H S2C (laced into a 26" Sun Ringle Rhyno Lite XL rim with a fat frank tyre) that i'm putting on a Pashley Trade Bike. The front hub is a SA HBT.

Last edited by 7VEN; 02-16-12 at 09:12 AM.
7VEN is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 12:39 PM.
