Semi-horizontal dropout for first frame.

First, I'd like to thank all the contributors on this forum. I've lurked on here for awhile and have enjoyed and learned much from all the threads. I've been researching frame building for about a year now and I'm about to get started on my first frame (after the requisite practice brazing of course).

Here's my dilemma, I'd really like to build an English style internal geared commuter for my first frame, but every source I've come across dissuades first time builders from using anything but vertical dropouts. I realize I could go the vertical route and make do with a half link for the chain or eccentric bottom bracket, but I'd love to just use a semi-horizontal dropout and be done with it.

Is there any sort of homemade jig that I could construct that would easily allow this? Or should I just suck it up and make a road bike frame?

Thanks

Scott
greaper007 is offline   Reply With Quote
Old 12-16-11, 12:12 AM   #2
unterhausen
Randomhead

Join Date: Aug 2008
Location: Happy Valley, Pennsylvania
Bikes:
Posts: 14,585
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
go with horizontal dropouts. What is the rationale for recommending against it? Seems to me that a first time builder is going to make many mistakes that are going to be more problematic than misaligned drops
unterhausen is offline   Reply With Quote
Old 12-16-11, 12:22 PM   #3
Doug Fattic
framebuilder

Join Date: Dec 2009
Location: Niles, Michigan
Bikes:
Posts: 162
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
You do want to use horizontal and not vertical dropouts when making your first frame. No competent advice would suggest it is better to start with verticals because it is much more difficult to get the chainstays to be exactly the same length so a wheel centers. That is one of the most challenging tasks to get right. I discourage my framebuilding class students from using verticals for that reason. An English style frame that uses a wheel with internal gears is a great place to begin.

There are lots of different philosophies on how to fixture (or not fixture) frame assembly. It is difficult to make an accurate rear triangle without an accurately built fixture. It is possible get it right with just a true wheel and a long straight edge with an adjustable screw. That method requires you to spot braze, check, adjust and fully braze each joint one at a time.
Doug Fattic is offline   Reply With Quote
Old 12-16-11, 05:46 PM   #4
unterhausen
Randomhead

Join Date: Aug 2008
Location: Happy Valley, Pennsylvania
Bikes:
Posts: 14,585
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Doug, thanks for your viewpoint. It is amazing how many production bikes are made with dropouts out of alignment. The OP made me wonder if I was missing something for a minute there.
unterhausen is offline   Reply With Quote
Old 12-16-11, 09:19 PM   #5
greaper007
Senior Member
Thread Starter

Join Date: Feb 2004
Location: Denver, CO
Bikes:
Posts: 51
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks for all the replies. I was basing most of my knowledge on this book.



Which I've found to be a decent reference so far but the author discourages anything but vertical socket style dropouts for the first frame.

Doug, do you have a picture of a rear triangle jig like the one you described? I have an image in my head and just want to see if it's the same as what you're describing.

Thanks
greaper007 is offline   Reply With Quote
Old 12-17-11, 12:52 PM   #6
unterhausen
Randomhead

Join Date: Aug 2008
Location: Happy Valley, Pennsylvania
Bikes:
Posts: 14,585
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
I suppose that I should keep quiet about that book, not having read it. But I don't see why anyone that doesn't know how to build would waste any amount of money getting anything other than Paterek.

T-tool (hopefully Herbie Helm doesn't mind)

unterhausen is offline   Reply With Quote
Old 12-19-11, 10:11 AM   #7
rodar y rodar
weirdo

Join Date: Jan 2008
Location: Reno, NV
Bikes:
Posts: 1,962
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
^That tool looks like a god idea, but what does it clamp to? I would guess the DT, but it doesn`t appear to have a way of splitting the clamp to get it around any tube that`s already brazed into a closed triangle.
rodar y rodar is offline   Reply With Quote
Old 12-19-11, 10:41 AM   #8
erik c
Senior Member

Join Date: Feb 2010
Bikes:
Posts: 114
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by unterhausen View Post
I suppose that I should keep quiet about that book, not having read it. But I don't see why anyone that doesn't know how to build would waste any amount of money getting anything other than Paterek.

T-tool (hopefully Herbie Helm doesn't mind)

Your feelings about that book are absolutely correct, or at least they were about the edition I looked at. :2cents:

Quote:
Originally Posted by rodar y rodar View Post
^That tool looks like a god idea, but what does it clamp to? I would guess the DT, but it doesn`t appear to have a way of splitting the clamp to get it around any tube that`s already brazed into a closed triangle.
The Berry T-tool upper "clamp" attaches at the seatpost clamping bolt hole found in most seattube lugs not around a tube itself. Upper clamps in appropriate diameters could be added easily enough but that isn't how it was designed to attach.
erik c is offline   Reply With Quote
Old 12-19-11, 10:47 AM   #9
unterhausen
Randomhead

Join Date: Aug 2008
Location: Happy Valley, Pennsylvania
Bikes:
Posts: 14,585
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
looks like Herbie's version is meant to attach to a seat post. This avoids the problem of crooked seat lugs for the most part.

I got a couple of diameters of used seat posts from my LBS. They occasionally come in handy
unterhausen is offline   Reply With Quote
Old 12-19-11, 11:27 AM   #10
tuz
Senior Member

Join Date: Dec 2006
Location: Toronto/Montréal
Bikes: Homemade mixte, track, commuter and road, Ryffranck road
Posts: 1,180
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I think it attaches to the stub of seat tube that extends passed the lug. I made mine with a hinge just in case.
tuz is offline   Reply With Quote
Old 12-19-11, 11:48 AM   #11
tuz
Senior Member

Join Date: Dec 2006
Location: Toronto/Montréal
Bikes: Homemade mixte, track, commuter and road, Ryffranck road
Posts: 1,180
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
To the OP. I think horizontal dropouts would be better. A discrepancy in chainstay length is multiplied by about 2.5 at the end of the rim. I.e. a chainstay shorter by 0.5 mm moves the rim off-centre by 1+ mm. The other thing to worry about is matching the dropout heights, but you can set that right before brazing the seatstays.

Last edited by tuz; 12-19-11 at 01:23 PM. Reason: bad maths
