Replacing my All Round Bike. A Build Thread.

When I became a father the pressure to have a sturdy all purpose bike reached the realm of necessity. I wanted to trailer the kid when the wife and I took weekend rides.

I also wanted a bike to ride to beer store, grocery store or lunch place. A bike to carry photo stuff on dirt trails.

This is what I ended up with:



The bike was stolen the other day so now I need to replace it.

I ride two other bikes, both road bikes - a really nice geared CF frame - and a sweet Single Speed AL frame. I also have a folder but that's a convenience bike.

So I went to all of my LBSs but nothing they had really met my criteria but I did get a sense of replacement cost.




Realizing my All Rounder was in essence a really plush commuter I posted in the Commuter forum asking for input and really got some great ideas. I think it was member megalowmatt that pointed me in my current direction. Building a new All Rounder on a Nashbar AL Touring frame.

So, I've ordered a frame and fork from Nashbar.

Everything else I think I'll need I'm buying from several different sources.


TBC...
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.

Last edited by ahsposo; 10-29-12 at 10:10 AM. Reason: Spelling
ahsposo is offline   Reply With Quote
Old 10-11-12, 06:07 PM   #2
Violet
Senior Member

Join Date: Aug 2008
Bikes:
Posts: 149
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
+1 for all rounder bikes.

Road and Mountain Bikes are great, but simply don't fit my style of riding. If I am riding out on the country somewhere I like to be able to come across a gravel road or forest trail or 4wd track and go "hey, why not?". But most of my riding is on the road and I don't need 2" tires and suspension to deal with that sort of thing.
Violet is offline   Reply With Quote
Old 10-11-12, 06:25 PM   #3
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Exactly.

What I didn't like about the old bike was it was heavy. This bike will be no lightweight but it will be lighter. Also when I had really loaded panniers I'd get some heel slap. Hopefully the touring geometry will fix that.
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-12-12, 10:39 AM   #4
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
I received my new frame! It's like an early Christmas or a late B'day!

It's pretty light and packed well enough. It's a dark green metallic piant. Ships with the BB cable guide and almost enough screws for the bottle cage bosses and rack and fender eyelets (it's 2 short) and the derailleur hanger.



The welds are robust and consistent.





There are 3 sets of bottle bosses, nice...



And a nifty chain hanger. Never had a frame with one of these.



The fork and seatpost should arrive later today.

The other stuff should be here late next week.
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-12-12, 11:19 AM   #5
Doohickie
You gonna eat that?

Doohickie's Avatar

Join Date: Sep 2008
Location: Fort Worth, Texas Church of Hopeful Uncertainty
Bikes: 1966 Raleigh DL-1 Tourist, 1973 Schwinn Varsity, 1983 Raleigh Marathon, 1994 Nishiki Sport XRS
Posts: 14,320
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Nice.
__________________
I stop for people / whose right of way I honor / but not for no one.



Originally Posted by bragi "However, it's never a good idea to overgeneralize."
Doohickie is offline   Reply With Quote
Old 10-17-12, 06:49 PM   #6
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Got some bits and pieces today and the fork and seatpost 2 days ago.

This coming Friday almost everything except the stem will arrive.



I'd like input on having a LBS press the headset vs. using my homemade press with allthread nuts and washers.
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-17-12, 08:16 PM   #7
fietsbob
coprolite

fietsbob's Avatar

Join Date: Jun 2010
Location: NW,Oregon Coast
Bikes: 7
Posts: 18,737
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 203 Post(s)
you had a rack and mudguards, etc on the other one,
Realize: that is where a significant amount of the extra weight was added.


the edge of some headset cups may not like big flatwashers of an allthread press

but I suspect you are not fitting a King headset..

the cups will level out against the headtube faces to be square enough.
check that the fork spins without tight spots.

Last edited by fietsbob; 10-17-12 at 08:21 PM.
fietsbob is offline   Reply With Quote
Old 10-24-12, 01:15 PM   #8
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
OK. I decided to have my LBS install the headset bearings and crown race. They were also willing to loan me some spacers and stem to help me finish the build and begin fitting the bike.



One issue I've dealt with is the bolts for the cantilever brakes are 25mm in length. This is about 10mm too long for the sleeves supplied with the carbon fork. I used a Dremel tool with a cutting wheel to remove the excess length.



At this point I've hung all the major components. I used Loctite blue on the threads that shouldn't come loose and grease on the BB spindle.









I'm off to the LBS to get some rim tape. Tubes and tires next!
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-26-12, 08:13 PM   #9
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Light at the End of the Tunnel!



Shifters in place, Mudguards and kickstand in place needs a chain.

The stays on the mudguards are gonna be a problem. I had to hacksaw and then polish a disc brake tab to fit the left front fender stay so I could attach the stays.


And then the SKS stay caps were a unit. I had to cut the plastic "join" unit's stay socket and let the stay move many mm's out.



All that stainless steel stay you are seeing from the edge of the fender into the black cap is excess. I've cut it off and will post pics of the result.

Here's what the Greenfield rear triangle kickstand attachment looks like fitted.

__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.

Last edited by ahsposo; 10-29-12 at 10:13 AM.
ahsposo is offline   Reply With Quote
Old 10-27-12, 01:15 AM   #10
spectastic
Supreme Adrninistrator

spectastic's Avatar

Join Date: Aug 2012
Location: inside my body
Bikes: a few
Posts: 3,506
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 42 Post(s)
how much did this end up costing?
spectastic is offline   Reply With Quote
Old 10-27-12, 03:59 PM   #11
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Quote:
Originally Posted by spectastic View Post
how much did this end up costing?
Complete including rack, kickstand, fenders around $1100. The only stuff that I already had that I used were pedals and bottle cages. I finished the bike today and rode it around a bit.

I'll post some pictures of the completed project tomorrow.
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-27-12, 06:18 PM   #12
Dahon.Steve
Senior Member

Join Date: Dec 2001
Location: New Jersey
Bikes:
Posts: 6,826
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 23 Post(s)
You're bike came out very nice. You did spend alot by the way.
Dahon.Steve is offline   Reply With Quote
Old 10-27-12, 07:26 PM   #13
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Quote:
Originally Posted by Dahon.Steve View Post
You're bike came out very nice. You did spend alot by the way.
No. I think I was fairly tight-fisted and penny-pinching. It may bite me in the ass before we're all said and done.

Frame, CF fork and seatpost from Nashbar delivered for $233. Total crap shoot. They are really spare on specs. Could be they change vendors all the time.

My first impression is that it's kinda weird up front.

I purchased Shimano bits mostly down-end except my shifters. Dura-Ace downtube shifters almost feel like Veloce so I really couldn't go any lower.
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-27-12, 08:15 PM   #14
spectastic
Supreme Adrninistrator

spectastic's Avatar

Join Date: Aug 2012
Location: inside my body
Bikes: a few
Posts: 3,506
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 42 Post(s)
I guess I don't quite understand why you invested in a carbon frame, yet still add a whole bunch of stuff on your bike. Why not just get a decent aluminum frame at 1/2 the price and <2 lbs difference? I got my ultegra bike for $800, and I could easily turn it into my all around bike with an extra wheel set ($130 on bikeisland), some thicker tires/tubes, and some fenders if I really had to. If it's a really nasty day, I'll just swap out the wheels.

I upgraded my old vintage not too long ago. Spent around $500 on it, and basically replaced everything except the frame, crank and derailleurs. I would've been better off to have just spent an extra $100 on a new bike that's probably better and faster.
spectastic is offline   Reply With Quote
Old 10-27-12, 08:27 PM   #15
Ancient Mariner
Senior Member

Ancient Mariner's Avatar

Join Date: Oct 2012
Location: Indian Wells, CA (near Palm Springs)
Bikes: Giant Defy Comp 2, Specialized Rockhopper Hard Tail 29er
Posts: 326
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That is a very nice looking build. You certainly don't have to explain yourself to anyone regarding your choices. It meets all your requirements, and it's your money. For sure it will be your fanny on the saddle when you're pedaling the thing around, so be proud of it. You have something that's really unique and reflective of your tastes. Well done, and thanks for the pictures.
Ancient Mariner is offline   Reply With Quote
Old 10-27-12, 08:54 PM   #16
clarkbre
Senior Member

clarkbre's Avatar

Join Date: Aug 2012
Location: Everett, WA
Bikes: 1995 Giant Innova, 2012 Surly Pacer
Posts: 304
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by spectastic View Post
I guess I don't quite understand why you invested in a carbon frame
Read the OP's posts. Hell, you don't even have to read between the lines...it's spelled out that it's an aluminum frame.

Quote:
Originally Posted by spectastic View Post
Why not just get a decent aluminum frame at 1/2 the price and <2 lbs difference?
1/2 the price of $233 for a frame, fork, and seatpost? The full price is still a great deal.

Quote:
Originally Posted by spectastic View Post
I got my ultegra bike for $800, and I could easily turn it into my all around bike with an extra wheel set ($130 on bikeisland), some thicker tires/tubes, and some fenders if I really had to. If it's a really nasty day, I'll just swap out the wheels.
Was that bike used or new? $800 + $130 (wheels) + $70 (tires/tubes) + $40 (fenders)= $1040...for a bike similar to what the OP built for $1100. Wow, $60 savings.

Quote:
Originally Posted by spectastic View Post
I upgraded my old vintage not too long ago. Spent around $500 on it, and basically replaced everything except the frame, crank and derailleurs. I would've been better off to have just spent an extra $100 on a new bike that's probably better and faster.
So, you're knocking the OP for how much he spent on his bike yet you are stating that you dumped $$$ into one of your old bikes and are not thrilled with the results....


AHSPOSO: You've built an awesome looking bike. I hope when it's all said and done it serves you for many years to come. It looks like you've put a lot of time and thought into it. Let us know how that first ride goes!
clarkbre is offline   Reply With Quote
Old 10-27-12, 09:24 PM   #17
spectastic
Supreme Adrninistrator

spectastic's Avatar

Join Date: Aug 2012
Location: inside my body
Bikes: a few
Posts: 3,506
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 42 Post(s)
^what the hell is your problem? talking like a real troll behind that computer screen. stfu
-----

OP: I wasn't putting you down or anything. In my opinion, it's not really worth building a bike from scratch unless you really want to customize it to your liking, but you can really do that with any bike. All I'm saying is that if I were you, I would have bought something new, and worked from there.
spectastic is offline   Reply With Quote
Old 10-27-12, 09:37 PM   #18
clarkbre
Senior Member

clarkbre's Avatar

Join Date: Aug 2012
Location: Everett, WA
Bikes: 1995 Giant Innova, 2012 Surly Pacer
Posts: 304
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by spectastic View Post
^what the hell is your problem? talking like a real troll behind that computer screen. stfu
-----

OP: I wasn't putting you down or anything. In my opinion, it's not really worth building a bike from scratch unless you really want to customize it to your liking, but you can really do that with any bike. All I'm saying is that if I were you, I would have bought something new, and worked from there.
Not a troll at all. I'm just not into someone knocking another guy's project without actually looking at the facts. Your post implied the OP was an idiot for building that bike for how much he did. And then, you said how much cheaper your all-round bike would be when it would realistically be only 5.5% less $.

So, no, I'm not a troll and I don't have any problems. I was just citing that your post needed some corrections to be taken seriously.
clarkbre is offline   Reply With Quote
Old 10-27-12, 11:54 PM   #19
cale
Senior Member

cale's Avatar

Join Date: Oct 2004
Location: Seattle
Bikes: Kuota Ksano. Litespeed T5 gravel - brilliant!
Posts: 3,250
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Nice build. I like the green and black combination (frame, fork and fenders). The downtube shifters are a little too precious but if it rocks your world, go for it. Couple quick observations. 1) The rear tube stem looks crooked and if left as is may lead to premature wear. 2) There's an awful lot of excess wire coming off that front derailleur, you might want to tidy that up. :-)
cale is offline   Reply With Quote
Old 10-28-12, 07:50 AM   #20
ahsposo
Big Blubbery Member
Thread Starter

ahsposo's Avatar

Join Date: Jan 2010
Location: On a floe
Bikes: A Home Built All Rounder, Bianchi 928, Specialized Langster, Dahon Folder
Posts: 7,062
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Quote:
Originally Posted by cale View Post
Nice build. I like the green and black combination (frame, fork and fenders). The downtube shifters are a little too precious but if it rocks your world, go for it. Couple quick observations. 1) The rear tube stem looks crooked and if left as is may lead to premature wear. 2) There's an awful lot of excess wire coming off that front derailleur, you might want to tidy that up. :-)
Yeah all fixed. Trimming the excess wire was the last step. I'll post some final pics later today.
__________________
Quote:
Originally Posted by 3alarmer View Post
...ixnay on the exsay alktay.
ahsposo is offline   Reply With Quote
Old 10-28-12, 10:38 AM   #21
rdtompki
Senior Member

rdtompki's Avatar

Join Date: Nov 2008
Location: Hollister, CA
Bikes: Volagi, daVinci Joint Venture
Posts: 3,962
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Very nice looking build. I'm curious about the location of the third bottle mount. I assume this is for a bottle-shaped container for tools and such?
rdtompki is offline   Reply With Quote
Old 10-28-12, 10:56 AM   #22
Flying Merkel
Senior Member

Flying Merkel's Avatar

Join Date: Mar 2008
Location: Costa Mesa CA
Bikes:
Posts: 2,639
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
I built up a Nashbar mountain bike frame with one of their carbon forks & disc brake sets. It's a good frame for the price, $80 after discount. In hind sight, I'd use a regular steel or suspension fork & V-brakes. The only real complaint I have is that my size 12 feet can hit the chainstays.

Maybe your (and my) project don't make perfect economic sense. The bookkeepers aren't accounting for the fun factor. I learned a lot & ended up with a good bike.
Flying Merkel is offline   Reply With Quote
Old 10-28-12, 12:45 PM   #23
cale
Senior Member

cale's Avatar

Join Date: Oct 2004
Location: Seattle
Bikes: Kuota Ksano. Litespeed T5 gravel - brilliant!
Posts: 3,250
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
^+1

The economy of a bike isn't terribly important although in the context of this build, I admire the the OPer's restraint in component selection. I don't have much knowledge of the quality of Alivio components and that would probably make me spend more than necessary, even for an "all-arounder".

Last edited by cale; 10-28-12 at 12:49 PM.
cale is offline   Reply With Quote
Old 10-28-12, 12:51 PM   #24
cale
Senior Member

cale's Avatar

Join Date: Oct 2004
Location: Seattle
Bikes: Kuota Ksano. Litespeed T5 gravel - brilliant!
Posts: 3,250
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by rdtompki View Post
Very nice looking build. I'm curious about the location of the third bottle mount. I assume this is for a bottle-shaped container for tools and such?
A lot of touring frames include a third bottle cage position to allow touring riders to carry more fluids when they ride.
cale is offline   Reply With Quote
Old 10-28-12, 01:42 PM   #25
cale
Senior Member

cale's Avatar

Join Date: Oct 2004
Location: Seattle
Bikes: Kuota Ksano. Litespeed T5 gravel - brilliant!
Posts: 3,250
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I'm impressed that you documented the build. I did a similar build (didn't document) of an all-rounder and hope you don't mind my sharing my build as a comparison. I think it is important to consider that when assembling a bike from scratch, cost is an important but generally not overriding goal.




Last edited by cale; 10-28-12 at 04:21 PM.
cale is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 12:07 AM.
