    Small cut/scratch in carbon frame...

    I put small cut today with a very sharp knive (don't ask) on my cf frame, just above the bottom bracket on the seat tube. It's about 1cm long and wide enough to get your fingernail in. It goes through the clear coat and paint, possibly to the top of the fiber. Can this be easily touched up, or does it need inspected, and by whom?

  2. #2
    W.W.DZ.D? cedricbosch's Avatar
    Join Date
    Sep 2006
    Location
    Arizona
    Posts
    1,978
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Turn that thing over to the NIH or else

    Cat 1 meter- 15%

  3. #3
    Senior Member Jakedatc's Avatar
    Join Date
    Oct 2007
    Location
    Lil Rhody
    Posts
    2,112
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    doomed....
    2007 CSK
    199? Trek 1420 ** 15% Off Hammer Nutrition Referral Code **

  4. #4
    Dog is my co-pilot 2manybikes's Avatar
    Join Date
    Jun 2003
    My Bikes
    2 many
    Posts
    13,783
    Mentioned
    4 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by Jakedatc View Post
    doomed....

    [SIGPIC][/SIGPIC]

  5. #5
    Senior Member tkehler's Avatar
    Join Date
    Feb 2004
    Location
    My family and I -- wife and two young children -- live in Vancouver, British Columbia, Canada
    My Bikes
    TST ti 'cross bike (commuter); Guru ti road bike; Seven Sola ti mtb; recumbent; Airnimal Chameleon folding racing bike
    Posts
    722
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    You must cease and desist with the arcane bicycle circumcision rituals.

    (Joking aside, I have no idea about that cut's significance. Sorry.)

  6. #6
    Senior Member Chevy's Avatar
    Join Date
    Oct 2003
    Location
    Vegas baby and now Denver too
    My Bikes
    Tommaso AS1 road, Novara MTB, Trek road,
    Posts
    41
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    unless you can see cut fiber ends don't worry about it. the layup consists of multiple layers of resin and fibers so no worries unless you trashed an entire layer of fibers or the cut goes through several layers. put a couple dots of super glue on it to make you feel better Composite structures are not susceptible to fatique concentration like metal so crack propagation from the cut isn't likely

  7. #7
    Senior Member
    Join Date
    May 2008
    Location
    NorCal
    My Bikes
    Cervelo R3 (Force)
    Posts
    2,458
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    so what did you do to it?
    Cervelo Soloist Team (Rival)
    Cervelo R3 (Force)

  8. #8
    Senior Member phallenthoul's Avatar
    Join Date
    Sep 2007
    Posts
    534
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by humboldt'sroads View Post
    I put small cut today with a very sharp knive (don't ask) on my cf frame
    why did you cut your frame?
    Neo Exile frameset clearance 10% off. now $675 only!
    only size S available.

    09 Christmas Groupbuy Started
    PM me to join My Mail List

  9. #9
    Senior Member kleng's Avatar
    Join Date
    Mar 2006
    Location
    Perth, Australia and sometimes Penang Malaysia
    My Bikes
    Litespeed L1r, Litespeed Ghisallo 07, TCR Advanced Team SL 0 ISP, Giant TCR Advanced SL, Giant TCR Advanced Team - Tmobile
    Posts
    1,890
    Mentioned
    4 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by phallenthoul View Post
    why did you cut your frame?
    Ah!!! the old knife as a screwdriver trick.

  10. #10
    Senior Member leakysieve's Avatar
    Join Date
    Apr 2008
    Location
    Bellingham, WA
    My Bikes
    2008 Cannondale Six13 now Six Carbon
    Posts
    175
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    All around the bottom bracket is they lay-up a significant number of layers cause is where a lot of strength and stiffness is needed. You should be fine. If cracks extending from the ends of the cut begin to form, then i would start to worry.
    Sometimes, I have to wonder.

  11. #11
    Chieftain
    Join Date
    Feb 2008
    Location
    Oakland
    My Bikes
    2012 Cannondale CAADX 105; Wabi Classic Fixed Gear
    Posts
    545
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by Val23708 View Post
    so what did you do to it?
    Well, I was....
    Quote Originally Posted by phallenthoul View Post
    why did you cut your frame?
    I was..
    Quote Originally Posted by kleng View Post
    Ah!!! the old knife as a screwdriver trick.
    No...almost though-

    I was cutting zip ties after putting on my cadence meter that didn't end up working anyway...

  12. #12
    Village Idiot
    Join Date
    Jan 2007
    Location
    Bahstaaaaan
    Posts
    19,940
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by humboldt'sroads View Post

    I was cutting zip ties after putting on my cadence meter that didn't end up working anyway...
    I almost did that. I cut through the clear on my CAAD9. It was at the BB weld though, and I just put clear nail polish over it. No worries, but it's not carbon and I didn't go through the material.
    Truth, like light, blinds. Falsehood, on the contrary, is a beautiful twilight that enhances every object.
    -Albert Camus

    Hammer Nutrition 15% discount!!!

  13. #13
    Senior Member
    Join Date
    May 2008
    Location
    NorCal
    My Bikes
    Cervelo R3 (Force)
    Posts
    2,458
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by humboldt'sroads View Post
    Well, I was....

    I was..

    No...almost though-

    I was cutting zip ties after putting on my cadence meter that didn't end up working anyway...
    ah see well we can understand that
    Cervelo Soloist Team (Rival)
    Cervelo R3 (Force)

  14. #14
    Senior Member
    Join Date
    Jun 2008
    Location
    Ozark Mountains
    My Bikes
    '64 Varsity, '69 Varsity, '71 Varsity, '71 Super Sport, '72 Super Sport, PX10 times 3, '72 Paramount, '73 Sports Tourer, '73 Paramount '77 Paramount, two NOS Pros
    Posts
    83
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Like most on this thread I agree that it is likely that no fibers were cut by the the knife slip. But with respect to the non-importance of damaged fiber, in the words of Bill Lumbergh: “I’m gonna have to disagree with this.”

    My comments are based on the work I do in aerospace, primarily spacecraft hardware. It is true that many types of composite hardware have great damage tolerance. In the pursuit of low weight much of that robustness can be lost. It is also true that the bottom bracket is an area of many ply's but I believe the reason is driven by the fact that the bottom bracket area is highly loaded. If the bottom bracket area is a location of flex, it is exactly the area I would be concerned about propagation.

    The protocol in my industry for any damage (or suspected damage, hardware is guilty unless proven innocent) is to not trust it unless a cognizant analyst has reviewed the possible damage with respect to the load cases and calculated margin of safety.

    I suspect that a 900 gram frame will be more likely to require a repair that a 1500 gram frame (due to reduced safety factors) but unless there is reasonable certainty that fibers were not cut/broken I strongly advice contacting the manufacturer for their advice. Unfortunately the frame's maker may be operating under prudent legal rather than engineering practices. If that is the case, they will probably say that any damage is too much damage. Someone from the bicycle industry may be able to make a general comment but without knowing the depth of the cut and the local margin of safety it is as they say, just an opinion.

    My colleagues and I have obtained damaged frames over the years from shops doing replacement work. We have performed repairs to the frames as if they were “flight hardware” and successfully ridden these frames for years. However, our philosophy was to repair or reinforce any questionable areas before use.


    Kerry P

  15. #15
    mad11:11one MANTEIGA's Avatar
    Join Date
    Feb 2009
    Location
    ONTARIO CANADA
    My Bikes
    TREK 5.2 (2008) - FULL ULTEGRA - HED C2 WHEELSET
    Posts
    2
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)

    shouldnt use super glue on carbon!

    Quote Originally Posted by Chevy View Post
    unless you can see cut fiber ends don't worry about it. the layup consists of multiple layers of resin and fibers so no worries unless you trashed an entire layer of fibers or the cut goes through several layers. put a couple dots of super glue on it to make you feel better Composite structures are not susceptible to fatique concentration like metal so crack propagation from the cut isn't likely
    cyanoacrylate cant flex like resin, very brittle under cold temp, very hard to work with, will melt through clear coat instantly.. cant wipe up!.
    "I KNOW OF NO REASON WHY THE *** POWDER TREASON SHOULD EVER BE FORGOT........."
    97 Trek 5200 oclv
    08 Trek Madone 5.2

  16. #16
    Banned
    Join Date
    Feb 2009
    Location
    Painville, USA
    My Bikes
    2007 Tarmac Pro
    Posts
    1,915
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Bad news: end of frame

    Good news: you now have a reason to get a new one

  17. #17
    No matches Flatballer's Avatar
    Join Date
    Aug 2008
    Location
    Charlotte, NC
    My Bikes
    two wheeled ones
    Posts
    10,182
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by humboldt'sroads View Post
    I was cutting zip ties after putting on my cadence meter that didn't end up working anyway...
    I figured. Use diagonal cutters in the future and go right up to the frame, but not into it.

  18. #18
    Senior Member
    Join Date
    Jun 2008
    Location
    Kent, WA
    My Bikes
    '07 Specialized Tarmac Pro
    Posts
    315
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    I think the important thing to note between the two useful replies here, (Chevy and KerryP) is whether or not you cut any fibers or it's just the resin/clearcoat. If you didn't get to any fibers, I really wouldn't worry about it. If you did, then it depends entirely on how robustly your particular frame was designed. I have a VERY hard time believing that the designer designed the margins so close, that a single ply of carbon would mean the difference between a good product and failure, though it's impossible to know for sure.
    Quote Originally Posted by caloso View Post
    Good lord. Why do we keep trying to make cycling attractive to people who are not attracted to cycling?

  19. #19
    Chieftain
    Join Date
    Feb 2008
    Location
    Oakland
    My Bikes
    2012 Cannondale CAADX 105; Wabi Classic Fixed Gear
    Posts
    545
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Ok - so I checked it out under better light...I mean, the cut is 1/2 inch long at most, and looks like it went through paint, but I don't see anything that's obviously a fiber, but the cut really is too small to tell. I can tell that if any fiber got cut, it wouldn't be more than a millimeter or two and one layer thick, and that's a big if, from what I can tell. At this point, I can't afford a new frame, even an aluminum one, so I think I'm gonna ride this and see if it makes any noise and see if the clear coat cracks any.
    Further opinions?

  20. #20
    Senior Member Tariq08's Avatar
    Join Date
    Sep 2008
    Location
    Phoenix
    My Bikes
    Felt F4
    Posts
    856
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    i think they're messing with you dude..

    at least i hope so anyway, i have mad nicks in my frame just from riding on rough roads
    Felt F4

  21. #21
    Senior Member
    Join Date
    Oct 2005
    Location
    Berkeley, CA
    Posts
    272
    Mentioned
    1 Post(s)
    Tagged
    0 Thread(s)
    The scar on my thumb is from cutting a cable tie with a boxcutter.


  22. #22
    Senior Member MrCrassic's Avatar
    Join Date
    Jun 2007
    Location
    Brooklyn, NY
    My Bikes
    2008 Giant OCR1 (with panda bear on the back!)
    Posts
    3,648
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Just ride the bike. Worst case scenario, your frame breaks while going downhill, then you fall down a ditch and die. Best case, you'll enjoy your bike for a while
    Ride more.

    Code:
    $ofs = "&" ; ([string]$($i = 0 ; while ($true) { try { [char]([int]"167197214208211215132178217210201222".substring($i,3) - 100) ; $i =
     $i+3 > catch { break >>)).replace('&','') ; $ofs=" " # Replace right angles with right curly braces

  23. #23
    No matches Flatballer's Avatar
    Join Date
    Aug 2008
    Location
    Charlotte, NC
    My Bikes
    two wheeled ones
    Posts
    10,182
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by kpfeif View Post
    The scar on my thumb is from cutting a cable tie with a boxcutter.

    I have a scar on my thumb from cutting a zip tie with a knife... towards my other hand. Brilliant!

  24. #24
    Senior Member bigtea's Avatar
    Join Date
    Nov 2004
    Posts
    1,639
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Actually the fix is quite simple.

    1) loosen and then detach all components from frame.
    2) slide out defective carbon fiber frame
    3) insert superior titanium frame
    4) reattach and tighten components.
    I will make you suffer on the downhills with my superior body weight.

  25. #25
    Senior Member Chevy's Avatar
    Join Date
    Oct 2003
    Location
    Vegas baby and now Denver too
    My Bikes
    Tommaso AS1 road, Novara MTB, Trek road,
    Posts
    41
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by humboldt'sroads View Post
    Ok - so I checked it out under better light...I mean, the cut is 1/2 inch long at most, and looks like it went through paint, but I don't see anything that's obviously a fiber, but the cut really is too small to tell. I can tell that if any fiber got cut, it wouldn't be more than a millimeter or two and one layer thick, and that's a big if, from what I can tell. At this point, I can't afford a new frame, even an aluminum one, so I think I'm gonna ride this and see if it makes any noise and see if the clear coat cracks any.
    Further opinions?
    Ride it.

    Okay a short tutorial on composites. We have been building metal airplanes for 85 yrs and composite ones for 25.There are several types of non destructive inspections you can do for metal (dye penetrant, X-ray, eddy current, etc) but very few for composite structures. Ultrasound is about the only game in town. Also our capability to model composites' behavior under various loads is still in it's infancy. Especially a complex shape.
    As a result for aircraft applications (and I suspect bike frames) composite structures are grossly overdesigned. (spacecraft are a different story then most aircraft structures because they will except lower margins to shave a few pounds) If the resin fiber matrix can carry load X, we typically design to twice that due to the uncertainities involved.
    How these things typically fail are void propagations between layers, ; i.e. delamination, followed by failures of the layers themselves . Think phone book. No one can tear a whole phone book in half but a toddler can destroy one a few layers at a time once it is "delaminated". Failure across intact fiber layup, i.e. cracking simply never happens unless the loads are horrendous.
    So if you want to have a warm fuzzy then get a quarter and do a "tap test". This is what we do with really really expensive composite aircraft structures before we untrasound them. You can actually map the edges of a void pretty well with a quarter. Once we know there is a void we will mark the edges after an ultrasound and check it periodiaclly with a tap test to make sure it isn't growing. Tap the edge of the coin along the frame and it should have a nice crisp click noise in response. If it clunks instead of clicks then that means there is a void underneath. Since the BB and tubing are hollow they will have a drum like response to a degree but a real void sounds sorta dead. Assuming you have had no voids propagated yet, tap the suspect area and listen. Do this occaisionally and as long as it keeps clicking then you are fine. Even if it starts clunking you can probably ride it a very long time before it falls apart.
    Yes composite frames fail. Poorly designed, poorly built frames of all kinds fail. But if a composite structure doesn't fail in it's infancy they usually live forever unlike aluminum or steel.
    Remember Orville and Wilbur started off building bikes...
