Singlespeed & Fixed Gear "I still feel that variable gears are only for people over forty-five. Isn't it better to triumph by the strength of your muscles than by the artifice of a derailer? We are getting soft...As for me, give me a fixed gear!"-- Henri Desgrange (31 January 1865 - 16 August 1940)

User Tag List

Reply

Thread Tools Search this Thread
Old 10-21-05, 12:04 AM   #1
nicelysmiling
Junior Member
Thread Starter

Join Date: Sep 2004
Location: Brooklyn, NY
Bikes:
Posts: 22
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I've been running 52X19 since I set up my Peugeot over a year ago. Today I was riding just south of Dupont Circle in DC, I was going over some bumps, and my cog broke. This of course caused the wheel to lock up as the chain wrapped around it. It sent me into a pretty awesome skid, but I maintained balance.


Here is the piece that broke off

While I've had the set up for a long time, I've been out of the country of 8 months, and thus the cog has pretty little wear. My chain tension was good... What could have caused this?

btw, I had noticed some slight warping in the chain-ring, it's the original peugeot, and kinda wimpy... could the slight side to side motion of the chain have caused the cog to fracture?
nicelysmiling is offline   Reply With Quote
Old 10-21-05, 12:15 AM   #2
nicelysmiling
Junior Member
Thread Starter

Join Date: Sep 2004
Location: Brooklyn, NY
Bikes:
Posts: 22
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
And I know it has been a year, but should I send this back to EAI?

-ty
nicelysmiling is offline   Reply With Quote
Old 10-21-05, 12:24 AM   #3
baxtefer
Cornucopia of Awesomeness

baxtefer's Avatar

Join Date: Oct 2004
Location: not where i used to be
Bikes:
Posts: 4,847
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
this is the 3rd report I've read of an exploding EAI cog.
baxtefer is offline   Reply With Quote
Old 10-21-05, 12:30 AM   #4
Grunk
Senior Member

Grunk's Avatar

Join Date: May 2003
Location: Denver, CO
Bikes: Gunnar Street Dog, Bianchi Pista, ****ty Road Conversion, Fit Van Homan BMX
Posts: 348
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Mine did the same thing. EAI 16t. Broke into 3 pieces.
Grunk is offline   Reply With Quote
Old 10-21-05, 02:12 AM   #5
trespasser
Senior Member

trespasser's Avatar

Join Date: May 2004
Location: london
Bikes:
Posts: 307
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
they are heat treated. if one gets too much heat, it becomes brittle. It's their quality control problem, so send it back and get it replaced.
trespasser is offline   Reply With Quote
Old 10-21-05, 03:34 AM   #6
fixedpip
asleep at the wheel

fixedpip's Avatar

Join Date: Aug 2004
Location: Chicago
Bikes: Custom Richie Ditta Track Bike, Eddie Merckx Corsa, Marioni Custom Pista, Dolan Cyclocross
Posts: 974
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Are these 3/32" cogs or 1/8" cogs? Or is it a mix?

Its shame to hear that EAI have some quality control issues, cause their cogs are normally bomb-proof.
fixedpip is offline   Reply With Quote
Old 10-21-05, 04:41 AM   #7
travsi
i don't stop

travsi's Avatar

Join Date: Mar 2005
Location: basel, switzerland
Bikes: soma rush, giro
Posts: 1,058
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
another question: are these exploding cogs alloy or steel?
__________________
velospace
travsi is offline   Reply With Quote
Old 10-21-05, 06:53 AM   #8
trespasser
Senior Member

trespasser's Avatar

Join Date: May 2004
Location: london
Bikes:
Posts: 307
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by travsi
another question: are these exploding cogs alloy or steel?
I guess it's steel from the photo.
Will at www.63xc.com has done a good article about cog choice, and explains these sudden failures quite well here.

excerpt
--------------------
Secondly, consider carefully the implications of heat treatment.

Materials don't cost much. The steel in your cog was probably cheaper than the packaging in which you bought it. The reason why an ounce or two of metal ended up costing as much as a pair of good jeans was that the manufacturer subjected it to various post-machining treatments to make it wear better.

Durability in a component is a complex phenomenon. Consider a samurai sword.

At its edge, the sword needs to be very hard, to take and hold a keen edge. If the metal at the edge of the sword was soft, the sword would blunt too quickly to be of use.

At its centre, the sword needs to be pliable. This allows it to bend and absorb impact. If the metal in the centre of the sword was hard, the sword would likely shatter against other metal weapons.

The skill of the swordsmith lies in judging hardness and softness and how to combine them.

In just the same way, a sprocket needs hard teeth to withstand wear, but must retain enough pliability to cope with road shocks, sudden changes of speed, and so on.

Case hardening, the deliberate creation of a hard crystalline 'skin' on the outside of a metal component, requires very precise control. Since it isn't economic to process sprockets one by one, they must be batched, and there is then the danger that individual sprockets within a batch may be over- or undercooked. An undertreated sprocket will be too soft and will wear quickly. An overtreated sprocket will be too hard and may shatter in use.

This gives rise to an odd paradox: expensive cogs subjected to serious heat treatment wear better than cheapies, but at an increased risk of sudden failure. Brittle failures are rare, but they do happen, and here is a photo to prove it.
trespasser is offline   Reply With Quote
Old 10-21-05, 01:08 PM   #9
nicelysmiling
Junior Member
Thread Starter

Join Date: Sep 2004
Location: Brooklyn, NY
Bikes:
Posts: 22
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Hey everyone,

you hit the nail on the head, or the cog on the tooth. I took the cog to CityBikes today, and they called EAI. They immediately jumped to the flawed manufacturing process conclusion and asked for the destroyed cog, saying that they would send me a new one.

So for now the bike is out of commission while I ride the beater...

thanks
nicelysmiling is offline   Reply With Quote
Old 10-21-05, 01:19 PM   #10
48x16
Geriatric Member

48x16's Avatar

Join Date: Feb 2005
Location: Ottawa, Canada
Bikes: Surly CrossCheck
Posts: 485
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Has anyone here experienced a DA cog failing?
48x16 is offline   Reply With Quote
Old 10-21-05, 01:43 PM   #11
drolldurham
ogre

Join Date: Oct 2004
Location: arlington, va
Bikes: surly steamroller fixie, '90 cannondale SR 800
Posts: 399
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
hmm... has anyone considered using an exploding cog as a weapon? someone should try to throw an exploding cog at some suvs, then run and take cover. i'm surprised you can buy them without a permit....

i kid, i kid.
drolldurham is offline   Reply With Quote
Old 10-21-05, 01:49 PM   #12
HereNT
無くなった

HereNT's Avatar

Join Date: Mar 2004
Location: Sci-Fi Wasabi
Bikes: I built the Bianchi track bike back up today.
Posts: 5,073
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by drolldruaham
hmm... has anyone considered using an exploding cog as a weapon? someone should try to throw an exploding cog at some suvs, then run and take cover. i'm surprised you can buy them without a permit....

i kid, i kid.
It would be cool to sharpen the teeth and throw them like ninja stars
HereNT is offline   Reply With Quote
Old 10-21-05, 02:28 PM   #13
treechunk
information sponge

Join Date: Feb 2005
Location: Little Village, Chicago, IL
Bikes: Lots. Mostly steel. Mostly heavy. Mostly geared, and very low, at that.
Posts: 692
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by 48x16
Has anyone here experienced a DA cog failing?
nope. I love 'em.
__________________
Philosophy and feelings don't change the laws of physics
