I want to make this Lemond a fixed commuter

....and I have no idea where to start. I've been lurking in ya'll's forum for a while. I've read a couple of sites about gearing choices, horizontal dropouts, brakes, no brakes and it's all got me kind of lost. I'm a roadie *gasp* at heart but I'd love to have an FG to commute on. Economical's good so don't let me screw up and build an overly expensive bike. I'm up for used, old, anything....just want it finished. Here's the bike -- a ~2000 Zurich 853 Reynolds.









I appreciate all of your suggestions.

Michael
__________________
RIP Stacey. =3.
gapowermike is offline   Reply With Quote
Old 04-11-06, 03:18 PM   #2
onetwentyeight
blah

onetwentyeight's Avatar

Join Date: Oct 2005
Location: Oakland, CA
Bikes:
Posts: 5,573
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
http://sheldonbrown.com/fixed-conversion.html

cuz someone else will post it if I dont
onetwentyeight is offline   Reply With Quote
Old 04-11-06, 03:25 PM   #3
explody pup
Guest

Bikes:
Posts: n/a
Mentioned: Post(s)
Tagged: Thread(s)
Quoted: Post(s)
It'll work. What's the rear dropout spacing?

These wheels popped up on the forum today. Seem to be a good choice. You might need to buy spacers for the rear axle, I'm sure your LBS could help you out w/ that. Sugino RD single speed cranks w/ a 110mm spindle BB and a EAI cog (avaliable at Harris Cyclery or Business Cycles) w/ a matching lockring should get you a good chainline. Or use an existing crankset, if you have one laying around. Gearing: My suggestion would be to start out around 65 to 70 gear inches (calculate gear choice here) and adjust from there. Fill out the rest of your equipment from your spare parts bin and you have a nice, inexpensive fixed gear.

Easy as pi.
  Reply With Quote
Old 04-11-06, 06:12 PM   #4
Aeroplane
jack of one or two trades

Aeroplane's Avatar

Join Date: Jun 2005
Location: Suburbia, CT
Bikes: Old-ass gearie hardtail MTB, fix-converted Centurion LeMans commuter, SS hardtail monster MTB
Posts: 5,637
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That is a pretty frame. Get the formula wheels, and you have the hard part done. Get a Surly, EAI, or Dura-Ace cog and lockring. Cranks, chainring, tires, seatpost, blah blah blah from the parts bin or the used pile at the LBS. Put a front brake on if you aren't sure if you want a brake or not. No rear brake to worry about. Put the chain on, pull it tight, wrench the wheels down... ta-da!!! Done.
Aeroplane is offline   Reply With Quote
Old 04-11-06, 07:57 PM   #5
jyossarian
SERENITY NOW!!!

jyossarian's Avatar

Join Date: Aug 2005
Location: In the 212
Bikes: Haro Vector, IRO Rob Roy, Bianchi Veloce
Posts: 8,756
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Seems you're not the only one considering a fixed gear commuter...
Fixed-Gear Commuter Conversion
Gonna make me a fixed gear...
__________________
HHCMF - Take pride in your ability to amaze lesser mortals! - MikeR



We demand rigidly defined areas of doubt and uncertainty!
jyossarian is offline   Reply With Quote
Old 04-11-06, 08:01 PM   #6
Joe Dog
One Hep Cat

Joe Dog's Avatar

Join Date: Jun 2005
Location: N 44.91577 W093.25327
Bikes: Surly Cross-Check (commuter), Lemond Sarthe (sports car), Schwinn fixed gear conversion (for fun)
Posts: 748
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That will make a nice bike. Double check the spacing on the rear wheel. That's a potentially expensive mistake. Follow the link to Sheldon - it's very good. Good luck!
__________________
BikeLove

Website
Joe Dog is offline   Reply With Quote
Old 04-11-06, 08:10 PM   #7
wagathon
Banned

wagathon's Avatar

Join Date: Apr 2005
Bikes:
Posts: 1,727
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
It's not a Y2K Zurich because that is red, white and blue (unless it's been repainted). That's a good bike and I know it will accommodate 28 tires without a problem if you get brakes with enough clearance. It takes wheels right off the shelf, e.g., Mavic rims with Ultegra hubs from Precision.

The 2000 Zurich that I had came with Rolf Vector Comps whereas the BAs came with just the Vectors.

Last edited by wagathon; 04-11-06 at 08:16 PM.
wagathon is offline   Reply With Quote
Old 04-12-06, 01:02 AM   #8
paul_in_toronto
Senior Member

paul_in_toronto's Avatar

Join Date: Apr 2006
Bikes:
Posts: 83
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
The rear spacing on that frame is 130.

If you buy the wheels you need to have the rear one respaced to 130

The rear hub on that wheelset is 120mm.
paul_in_toronto is offline   Reply With Quote
Old 04-12-06, 01:38 AM   #9
MacG
don't pedal backwards...

MacG's Avatar

Join Date: Jul 2005
Location: Minneapolis
Bikes: Surly Long Haul Trucker set up for commuting and loaded touring, old Sekine road frame converted to fixed-gear, various beaters and weird bikes, waiting on the frame for my Surly Big Dummy build
Posts: 754
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Step 1: remove those little axle positioner bolt thingies you can see in the rear dropouts. They won't help you any and they're hogging your useful dropout space.

the $125 Mavic/Formula wheelset mentioned above is fantastic for the price. If you buy a set, make sure to have the spokes tensioned and trued properly by someone that knows what they are doing. Mine were acceptably true right out of the box, but undertensioned and some nipples on the rear started backing off within 100 miles.

The wheelset should come with the extra-long axles if it's identical to the same wheelset Nashbar sells (where I got mine and paid $25 more. grr.) so adding spacers to the axle to match your frame should be no problem. Sounds like you need 5mm on each side and you'll be good to go. LBS should have spacers.

I'll echo what others say and recommend sticking to EAI, Dura Ace, or Surly for your cog, probably in that order of preference. Get a Dura Ace lockring.

For a commuter, something right around 70 gear inches should be pretty comfortable up to 25mph or so, and faster than that if you don't mind spinning faster than most geared-bike riders are used to. Here's a starting point for you. Set the tire size to what you plan to use. Red means a taller gearing than the target value, blue means a shorter gear. White is a perfect match, and anything fading from white to red or blue indicates the value is within the spread percentage above or below your value. You can control the target and spread and reload the chart to see what combinations gets you where you want to be. Pick something that gives you more skid patches if you can so your tires wear a bit more evenly.

http://www.basementfreaks.com/member...i=on&target=70
MacG is offline   Reply With Quote
Old 04-12-06, 06:15 AM   #10
queerpunk
aka mattio

queerpunk's Avatar

Join Date: May 2005
Bikes:
Posts: 6,054
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
when it comes to cranks, bottom brackets, and chainline, sheldon brown's site (actually, harris cyclery, same deal) lists what chainlines you'll get with what cranks on what spindles. don't forget about that part.
queerpunk is offline   Reply With Quote
Old 04-12-06, 09:24 AM   #11
gapowermike
Senior Member
Thread Starter

gapowermike's Avatar

Join Date: Jun 2005
Location: McDonough, Georgia
Bikes: Trek 1000 & 4100 & 5500
Posts: 861
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks guys for a great load of advice. The spacing is 130mm as someone already mentioned. I was guessing on the year, but I really don't care what year it is. I just want to build it and ride it. I'll post a review when I compile the info and finish the project.

Thanks again,
Michael
__________________
RIP Stacey. =3.
gapowermike is offline   Reply With Quote
Old 04-12-06, 09:45 AM   #12
Doctor Who
Lotion/Basket/Hose

Doctor Who's Avatar

Join Date: Apr 2004
Location: Chicago
Bikes: 1992 Schwinn Paramount
Posts: 1,368
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I ride one of those as a fixed-gear. Mine is a 2001, I think. I bought mine used for about $200 to build up with Ultegra 600 stuff, but ended up putting my track wheelset on it, due to the shifters breaking.

It's awesome; a fantastic frame to ride, both as a fixed or geared. I've now outfitted mine with time-trial handlebars and a disc wheel in order to do time trials, with a gear ratio of 50x15
Doctor Who is offline   Reply With Quote
