trouble installing wheels

Notices
Singlespeed & Fixed Gear "I still feel that variable gears are only for people over forty-five. Isn't it better to triumph by the strength of your muscles than by the artifice of a derailer? We are getting soft...As for me, give me a fixed gear!"-- Henri Desgrange (31 January 1865 - 16 August 1940)

trouble installing wheels

Old 06-30-07, 05:27 AM
  #1
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
trouble installing wheels

so I finally got the wheels for my new bike (njs bridgestone) but im having trouble installing the wheels. I've never had brand new hubs before, is this a common issue with them? The wheels simply wont slide into the dropouts.
abeabe is offline
Old 06-30-07, 06:54 AM
  #2
aka mattio

queerpunk's Avatar

Join Date: May 2005
Posts: 6,586

Bikes: yes

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 344 Post(s)
Liked 58 Times in 35 Posts
some NJS bikes are built for 110 spaced hubs (instead of 120), which also have narrower (9mm instead of 10? i'm not sure) axles.

that could be your problem. search for "110 spaced" for more info. you can coldset your frame to 120 and file your axles (or your trackends, but i'd rather file a replaceable axle than risk messing up on a frame) to accept standard hubs. but you should know what you're doing.
queerpunk is offline
Old 06-30-07, 07:00 AM
  #3
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
no i have 110 spaced rear hub they just are being extremelly stiff. I guess im gonna try to file the bolt down a little
abeabe is offline
Old 06-30-07, 07:04 AM
  #4
Banned

Join Date: Nov 2004
Posts: 10,082
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by abeabe
no i have 110 spaced rear hub they just are being extremelly stiff. I guess im gonna try to file the bolt down a little
That should be the last thing you do! Ask a buddy for a second opinion before you do irreparable damage to your hub. Maybe he can see something you are missing. One slip of the file and your threads are toast.
Cyclist0383 is offline
Old 06-30-07, 07:09 AM
  #5
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
i mean, i see that the axles have that indented space that allows them so slide on, but despite how carefully i allign the space and the track ends it wont slide on, neither the front nor back.

Last edited by abeabe; 06-30-07 at 07:14 AM.
abeabe is offline
Old 06-30-07, 07:45 AM
  #6
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
anyone? please? I'm dying to get this bike on the road and im running out of ideas
abeabe is offline
Old 06-30-07, 08:05 AM
  #7
Run What 'Ya Brung

bonechilling's Avatar

Join Date: Jun 2006
Posts: 5,694
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
See a mechanic?
bonechilling is offline
Old 06-30-07, 09:35 AM
  #8
Guest

Join Date: Aug 2004
Posts: 3,242
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
post a pic of both the hub and rear ends.

S/F,
CEYA!
Ceya is offline
Old 06-30-07, 10:24 AM
  #9
aka mattio

queerpunk's Avatar

Join Date: May 2005
Posts: 6,586

Bikes: yes

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 344 Post(s)
Liked 58 Times in 35 Posts
what is hitting what? is the axle still too large for the slots in each trackend? or will the hub not fit between the two trackends?

i think in order to offer suggestions, we're going to need more information.

and while i do urge you to be cautious and get good information on what to do before filing anything, i'd disgree with the poster who fearmongeringly warned that you could irreparable damage a hub. axles are completely replacable. you're not doing anything to the bearings or hub body.

but yes, don't jump into anything.
queerpunk is offline
Old 06-30-07, 11:20 AM
  #10
Banned

Join Date: Nov 2004
Posts: 10,082
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by queerpunk
what is hitting what? is the axle still too large for the slots in each trackend? or will the hub not fit between the two trackends?

i think in order to offer suggestions, we're going to need more information.

and while i do urge you to be cautious and get good information on what to do before filing anything, i'd disgree with the poster who fearmongeringly warned that you could irreparable damage a hub. axles are completely replacable. you're not doing anything to the bearings or hub body.

but yes, don't jump into anything.
Call me a fear monger if you will, but something tells me that if the OP is having such troubles getting a wheel into a trackend he's not going to be swapping axles on his own anytime in the near future.

Fuked axle = lot's of downtime for the OP.
Cyclist0383 is offline
Old 06-30-07, 11:23 AM
  #11
yo yo yo yo yo

Join Date: Nov 2005
Location: delaware
Posts: 2,518
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by queerpunk
some NJS bikes are built for 110 spaced hubs (instead of 120), which also have narrower (9mm instead of 10? i'm not sure) axles.
8mm
trons is offline
Old 06-30-07, 11:45 AM
  #12
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
ok well it seems to be that the issue is the axles are 8mm rather than the traditional 9 or 10mm because the axles are whats not going in. What are my options?
abeabe is offline
Old 06-30-07, 11:50 AM
  #13
Banned

Join Date: Nov 2004
Posts: 10,082
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by abeabe
ok well it seems to be that the issue is the axles are 8mm rather than the traditional 9 or 10mm because the axles are whats not going in. What are my options?
Having the axle swapped for the proper size is the proper thing to do.....

Last edited by Cyclist0383; 06-30-07 at 12:39 PM.
Cyclist0383 is offline
Old 06-30-07, 12:13 PM
  #14
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
upon closer inspection of the dropouts, both front and back, they read "UFP - 8" I suppose I'll have to get the axles replaced.

ceya, do you have any 8mm axles in stock?

Last edited by abeabe; 06-30-07 at 12:34 PM.
abeabe is offline
Old 06-30-07, 09:59 PM
  #15
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
bump for extra help, what is the process for replacing an axle?
abeabe is offline
Old 06-30-07, 10:11 PM
  #16
Guest

Join Date: Aug 2004
Posts: 3,242
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
let me see.

S/F,
CEYA!
Ceya is offline
Old 06-30-07, 10:38 PM
  #17
aka mattio

queerpunk's Avatar

Join Date: May 2005
Posts: 6,586

Bikes: yes

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 344 Post(s)
Liked 58 Times in 35 Posts
Originally Posted by Ziemas
Call me a fear monger if you will, but something tells me that if the OP is having such troubles getting a wheel into a trackend he's not going to be swapping axles on his own anytime in the near future.

Fuked axle = lot's of downtime for the OP.
meh, your logic is right. it was the way it came across to me, i didn't like, but i didn't need to call you a fearmonger.
queerpunk is offline
Old 06-30-07, 11:06 PM
  #18
Senior Member

Join Date: Jun 2006
Posts: 1,276
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by abeabe
bump for extra help, what is the process for replacing an axle?
Some cone wrenches, some grease, and a sharp eye for dropped ball-bearings (assuming your fancy 110mm spaced hub is loose-ball). Nothing out of reach for even the clumsiest of home mechanics.
Igneous Faction is offline
Old 07-01-07, 02:29 AM
  #19
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
front hub/dropout:





read hub/dropout:



abeabe is offline
Old 07-01-07, 03:04 AM
  #20
:jarckass:

deathhare's Avatar

Join Date: Aug 2006
Location: Nashville
Posts: 6,562
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 1 Time in 1 Post
You could always have the rear drop outs spaced.
Kalavinka does that for fairly cheap iirc.
Of course, getting an axle may be the best for you.
deathhare is offline
Old 07-01-07, 09:42 AM
  #21
a drinking idea
Thread Starter

abeabe's Avatar

Join Date: Apr 2007
Posts: 164
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
where could i pick up that axle in tokyo? what stores have good spare parts like that?
abeabe is offline
Old 07-01-07, 11:17 AM
  #22
Senior Member

Join Date: Apr 2006
Location: PGH, PA
Posts: 50
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
why don't people use the macro button on their cameras when they take close up pics?
Steve K is offline
Old 07-01-07, 11:21 AM
  #23
extra bitter

kyselad's Avatar

Join Date: Apr 2006
Posts: 1,586

Bikes: Miyata 210, Fuji Royale II, Bridgestone Kabuki, Miyata Ninety

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 23 Post(s)
Liked 5 Times in 5 Posts
Originally Posted by Steve K
why don't people use the macro button on their cameras when they take close up pics?
More gently, those close-up pics are out-of-focus b/c the auto-focus can't handle it.
There should be a macro function on your camera (it may have an icon of a little flower) that will provide crisp close-ups.
kyselad is offline
Old 07-01-07, 12:12 PM
  #24
skinning up

Join Date: Jul 2006
Location: cleveland
Posts: 1,243
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
take a file to the dropouts if youre crazy
gargiulo.mike is offline
Old 07-01-07, 12:37 PM
  #25
:jarckass:

deathhare's Avatar

Join Date: Aug 2006
Location: Nashville
Posts: 6,562
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by abeabe
where could i pick up that axle in tokyo? what stores have good spare parts like that?
Punch
deathhare is offline
