new forks for old bikes?

anybody got the time to explain this to me?

The issue is lateral deflection. I have a 1970s panasonic. At the bottom the fork has the inner race pressed onto it and the frame is the outer race. At the top the setup is similar, dig it?

what kind and how could I replace it? Considering geometry, strength, etc.
larsalan is offline   Reply With Quote
Old 12-31-08, 12:46 PM   #2
frankenmike
mechanically sound

frankenmike's Avatar

Join Date: Jan 2007
Location: Dover, NH
Bikes: rigid 29er moto, s-works stumpjumper fsr,black fixie,masi roadbike, ugly old hardrock commuter
Posts: 1,379
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 11 Post(s)
Integrated headset cups in the 70s? Pics please!
frankenmike is offline   Reply With Quote
Old 12-31-08, 01:02 PM   #3
larsalan
Senior Member
Thread Starter

Join Date: Dec 2008
Bikes:
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
maybe 80s
yeah, I dunno anything about this so that's why I am asking. Sry I have no photos. I am assuming not every fork fits every bike. I am wanting to know what these fork types are called. The frame steering tube has outer races at the top and bottom where ball bearing sit between them and the pressed on fork inner race and the headset hardware's inner race.
sry there is no pics, myb I should move this to the mechanic forum?
larsalan is offline   Reply With Quote
Old 12-31-08, 01:06 PM   #4
larsalan
Senior Member
Thread Starter

Join Date: Dec 2008
Bikes:
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
This is the style I am talking about, only my steering tube is longer.
larsalan is offline   Reply With Quote
Old 12-31-08, 01:14 PM   #5
wearyourtruth
Ride for Life

wearyourtruth's Avatar

Join Date: Jun 2004
Location: Baltimore
Bikes:
Posts: 2,729
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
that picture does not have an integrated headset, and i don't believe that's what you are talking about. those races on the frame can be removed. your fork sounds like it's called a "1 inch threaded fork" the same fork used on bikes for deeeeeeeeeeeecades

if you can't accurately describe it because you don't know the terminology and you can't take pictures, it is going to be much more worth your time to take it to a local bike shop and ask them, instead of face the wrath of the SSFG forum.
wearyourtruth is offline   Reply With Quote
Old 12-31-08, 01:14 PM   #6
huerro
Villainous

huerro's Avatar

Join Date: Sep 2006
Location: Austin
Bikes: Trek 420, Cyclops
Posts: 1,894
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Those headset cups are not part of the frame, they are pressed into it.

Read this: http://www.parktool.com/repair/readhowto.asp?id=127

As far as new forks fitting, you will need a 1 inch fork (the other option is 1 1/8). You may or may not need to replace the whole headset depending on its condition and the kind of replacement fork you get.

Why do you need a new one?
huerro is offline   Reply With Quote
Old 12-31-08, 01:34 PM   #7
larsalan
Senior Member
Thread Starter

Join Date: Dec 2008
Bikes:
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by wearyourtruth View Post
those races on the frame can be removed. your fork sounds like it's called a "1 inch threaded fork" the same fork used on bikes for deeeeeeeeeeeecades
Quote:
Originally Posted by huerro View Post
Those headset cups are not part of the frame, they are pressed into it.

Read this: http://www.parktool.com/repair/readhowto.asp?id=127

As far as new forks fitting, you will need a 1 inch fork (the other option is 1 1/8). You may or may not need to replace the whole headset depending on its condition and the kind of replacement fork you get.

Why do you need a new one?
Yes I see that it is a "threaded headset" probably 1" cause it says that is the japanese standard.
I would not want to have to pull those cups.
My thinking was that a carbon or round fork might be more laterally stable than the one I have if the process was as simple as unscrewing the old and putting the new in it's place.
Should I just leave well enough alone?
larsalan is offline   Reply With Quote
Old 12-31-08, 01:37 PM   #8
huerro
Villainous

huerro's Avatar

Join Date: Sep 2006
Location: Austin
Bikes: Trek 420, Cyclops
Posts: 1,894
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by larsalan View Post
Should I just leave well enough alone?
Yes. Or pay a bike shop to do it for you. It requires special tools.
huerro is offline   Reply With Quote
Old 12-31-08, 02:48 PM   #9
wearyourtruth
Ride for Life

wearyourtruth's Avatar

Join Date: Jun 2004
Location: Baltimore
Bikes:
Posts: 2,729
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
huerro who knew you cleaned up so nicely
wearyourtruth is offline   Reply With Quote
Old 12-31-08, 03:02 PM   #10
huerro
Villainous

huerro's Avatar

Join Date: Sep 2006
Location: Austin
Bikes: Trek 420, Cyclops
Posts: 1,894
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That's my life in the tropics look. I'm back to a full beard now.
huerro is offline   Reply With Quote
Old 12-31-08, 03:19 PM   #11
bbattle
.

bbattle's Avatar

Join Date: Aug 2005
Location: Rocket City, No'ala
Bikes: 2014 Trek Domane 5.2, 1985 Pinarello Trevisio, 1991 Colnago Master, '06 Bianchi San Jose, 1987 Moulton Fuso, 1990 Gardin Shred, '82 John Howard(Dave Tesch)
Posts: 12,568
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Quote:
Originally Posted by huerro View Post
Yes. Or pay a bike shop to do it for you. It requires special tools.
You need one of these:



To get the headset cups out of the headtube. You will have to hit it with a hammer:



You need one of these:





To set the cups in place. You can carefully bang them in place with a piece of wood in between them and the hammer but the press is way better.

When you take them off, clean them in kerosene or mineral spirits and a brush to get any gunk out. You can polish the outsides with wax after you put them back on. Throw away the old bearings and get new ones. Loose balls are best. Apply a bunch of waterproof grease like Phil Woods or automotive bearing grease into the cups then add the bearings. Completely fill the cup then remove one ball bearing. Complete reassembly.

By the way, that bike is one of mine. The headset was the only original part I reused on the bike.
bbattle is offline   Reply With Quote
Old 12-31-08, 03:41 PM   #12
huerro
Villainous

huerro's Avatar

Join Date: Sep 2006
Location: Austin
Bikes: Trek 420, Cyclops
Posts: 1,894
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
^^^plus tools for the crown race and possibly for cutting and threading the new fork.
huerro is offline   Reply With Quote
Old 12-31-08, 03:42 PM   #13
larsalan
Senior Member
Thread Starter

Join Date: Dec 2008
Bikes:
Posts: 128
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Why should the cups need to be removed? I am over the whole plan now due to the tools and effort. But, why couldn't I just pull the original fork out and jammer in a steel round tube of the same size?

here are some
http://cgi.ebay.com/Schwinn-1-1-8-St...3A1|240%3A1318

http://cgi.ebay.com/700c-Cyclocross-...3A1|240%3A1318
larsalan is offline   Reply With Quote
Old 12-31-08, 03:49 PM   #14
huerro
Villainous

huerro's Avatar

Join Date: Sep 2006
Location: Austin
Bikes: Trek 420, Cyclops
Posts: 1,894
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by larsalan View Post
Why should the cups need to be removed? I am over the whole plan now due to the tools and effort. But, why couldn't I just pull the original fork out and jammer in a steel round tube of the same size?

here are some
http://cgi.ebay.com/Schwinn-1-1-8-St...3A1|240%3A1318

http://cgi.ebay.com/700c-Cyclocross-...3A1|240%3A1318
First, those are two different sizes one of which won't work. Also, they would both require you to either install a new type of headset and stem or remove the crown race from your old fork and install it on the new fork, cut it to the right length, and cut threads in it.
huerro is offline   Reply With Quote
Old 12-31-08, 05:09 PM   #15
darksiderising
Senior Member

Join Date: Mar 2007
Location: Rohnert Park, CA
Bikes: Pake track, Soma DoubleCross, LeMond Etape, Maruishi RoadAce 303
Posts: 1,248
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
You need a 1" threaded fork if you want to minimize the work needed.

You should have a bike shop remove the crown race from your old fork and put it on the new one. The hiccup that can occur at this point is if your fork takes a different sized crown race. There are two sizes that are less than a millimeter different in diameter. I believe the different sized came about as a result of different material being used.

Then install the new fork...and do it right.
darksiderising is offline   Reply With Quote
Old 01-01-09, 05:39 AM   #16
cs1
Senior Member

cs1's Avatar

Join Date: Feb 2004
Location: Clev Oh
Bikes: Specialized, Schwinn
Posts: 6,705
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 33 Post(s)
Quote:
Originally Posted by larsalan View Post
anybody got the time to explain this to me?

The issue is lateral deflection. I have a 1970s panasonic. At the bottom the fork has the inner race pressed onto it and the frame is the outer race. At the top the setup is similar, dig it?

what kind and how could I replace it? Considering geometry, strength, etc.
Were you by chance born after 1988? Most guys your age have never seen a threaded headset. My kids have no idea of what they are either.
cs1 is offline   Reply With Quote
Old 01-01-09, 07:12 AM   #17
bbattle
.

bbattle's Avatar

Join Date: Aug 2005
Location: Rocket City, No'ala
Bikes: 2014 Trek Domane 5.2, 1985 Pinarello Trevisio, 1991 Colnago Master, '06 Bianchi San Jose, 1987 Moulton Fuso, 1990 Gardin Shred, '82 John Howard(Dave Tesch)
Posts: 12,568
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Sheldon will set you straight: http://www.sheldonbrown.com/headsets.html
bbattle is offline   Reply With Quote
Old 01-01-09, 09:42 AM   #18
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Bikes: Several, mostly not name brands.
Posts: 16,764
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 209 Post(s)
Tools

Quote:
Originally Posted by huerro View Post
^^^plus tools for the crown race and possibly for cutting and threading the new fork.
Get 'em all in one place:



JohnDThompson is offline   Reply With Quote
Old 01-03-09, 04:09 AM   #19
xiamsammyx
Harbinger

xiamsammyx's Avatar

Join Date: Sep 2007
Location: Milwaukee
Bikes: IRO Jamie Roy, Old Araya fixed conversion.
Posts: 564
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
there was a guy on the local CL here asking for a 1" carbon threadless fork to replace the fork on his bike, when i sent him an email offering to sell him mine he responded by saying
"no thanks, thats a bit out of my price range, I am hoping to find something off a throw-away bike from the 70's or 80's"

... i just shook my head.
xiamsammyx is offline   Reply With Quote
Old 01-03-09, 04:17 PM   #20
ianjk
:)

Join Date: Nov 2006
Location: duluth
Bikes: '07 Pista, '09 Fantom Cross Uno, '8? Miyata, '67 Stingray, '0? Zoo mod trials, Tallbike, Chopper, '73 Schwinn Collegiate, '67 Triumph Chopper, '69 CB350, '58 BSA Spitfire, '73 CB450
Posts: 3,392
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Crown race removal isn't usually hard at all.
