2-speed setups?

I've had an idea in the back of my mind for awhile now, maybe I should just keep it there 8-).

I've been thinking of using a singleator chain tensioner and running just a front derailleur. Sort of a singlespeed with a hill gear. Has anyone done this? Any issues that you can think of?

Thanks for any specs, details, thoughts, links, pics,....
treebound is offline   Reply With Quote
Old 12-01-09, 09:12 AM   #2
zacked
-

Join Date: Mar 2006
Location: Banned in DC
Bikes:
Posts: 454
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
It won't work well, you'll always have a bad chainline and the singelator isn't designed to be used like that. I'm not sure that it can even take up that much slack. If you want to switch gears on the fly, than get an IG hub. If you want a bailout gear, use a flip-flop, double cog, or double-ring/double-cog set up.
zacked is offline   Reply With Quote
Old 12-01-09, 09:21 AM   #3
beeftech
Senior Member

beeftech's Avatar

Join Date: Aug 2008
Location: Brooklyn finally.
Bikes: Bianchi San Jose, fixed
Posts: 832
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
You're a bit behind...

But try studying these guys, they already made it to 11.

And these guys do it with computers.
Attached Images
File Type: jpg recordgroupset1.jpg (29.9 KB, 46 views)
File Type: jpg Di2_GROUP-480-90-480-70.jpg (29.5 KB, 44 views)
beeftech is offline   Reply With Quote
Old 12-01-09, 09:52 AM   #4
Saddle Up
I Love My Dream

Join Date: Jan 2008
Bikes:
Posts: 1,076
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Trail/back road gearing


Road gearing


Paul Melvin tensioner


The only bike more functional than a SS is a 2 speed.
Saddle Up is offline   Reply With Quote
Old 12-01-09, 10:05 AM   #5
MIN
big ring

MIN's Avatar

Join Date: Mar 2007
Location: philadelphia
Bikes:
Posts: 5,838
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
you should run white industries DOS ENO freewheel and call it a day.
MIN is offline   Reply With Quote
Old 12-01-09, 10:20 AM   #6
treebound
aka: Mike J.
Thread Starter

treebound's Avatar

Join Date: Apr 2005
Location: between Milwaukee and Sheboygan in Wisconsin
Bikes: 1995 Trek 520 is the current primary bike.
Posts: 3,036
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Thanks Saddle_up, that's close to what I was looking for. The other inputs are appreciated as well
treebound is offline   Reply With Quote
Old 12-01-09, 01:55 PM   #7
dsh
Oh, you know...

dsh's Avatar

Join Date: May 2009
Location: DC
Bikes: '74 Schwinn Sports Tourer (Polo), S-Works E5 Team Festina (Chorus 11), Trek 2200 Bonded Carbon (Fixed), Trek 920 (7 speed IGH), Chesini Olimpiade SL (1x7)
Posts: 2,835
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Saddle Up View Post
The only bike more functional than a SS is a 2 speed.
What about a 3-speed? Triple crank and you're so there!

Looks awesome, by the way.
dsh is offline   Reply With Quote
Old 12-01-09, 02:18 PM   #8
elTwitcho
Live without dead time

Join Date: Jun 2008
Location: Toronto
Bikes:
Posts: 2,137
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Why not just run a rear deraileur and go 1x8?
elTwitcho is offline   Reply With Quote
Old 12-01-09, 02:22 PM   #9
Mos6502
Elitest Murray Owner

Mos6502's Avatar

Join Date: Apr 2006
Bikes: 1972 Columbia Tourist Expert III, Columbia Roadster
Posts: 2,662
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by beeftech View Post
And these guys do it with computers.
Sounds kinky.
Mos6502 is offline   Reply With Quote
Old 12-01-09, 03:37 PM   #10
bionnaki
Senior Member

Join Date: Aug 2006
Bikes:
Posts: 886
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
whats the point? manually changing gears rather than changing them on the fly seems rather unnecessary and a pain in the ass. if you have horizontal/vertical dropouts and all the braze-ons, why not add shifters and derailers as well?
bionnaki is offline   Reply With Quote
Old 12-01-09, 03:40 PM   #11
Mos6502
Elitest Murray Owner

Mos6502's Avatar

Join Date: Apr 2006
Bikes: 1972 Columbia Tourist Expert III, Columbia Roadster
Posts: 2,662
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
If he was running a front derailleur, he could change them on the fly...
Mos6502 is offline   Reply With Quote
Old 12-01-09, 04:13 PM   #12
treebound
aka: Mike J.
Thread Starter

treebound's Avatar

Join Date: Apr 2005
Location: between Milwaukee and Sheboygan in Wisconsin
Bikes: 1995 Trek 520 is the current primary bike.
Posts: 3,036
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
That's my thinking, simplify the bike, but keep the front derailleur to avoid the manual gear change.

The two-cog freewheel is interesting but I don't want to have to adjust the rear wheel to change gears. I've got a Fillmore and don't think I've flipped the wheel on it even once yet.

I've got a couple of old 10/12 speed roadbikes that I'm thinking of converting. If I get one converted and functional I'll probably flip the Fillmore wheel to the fixed side and leave it that way.

Just having fun playing with bikes and trying something a little different.
treebound is offline   Reply With Quote
Old 12-01-09, 04:32 PM   #13
stryper
I just wanna ride

stryper's Avatar

Join Date: Oct 2008
Location: Chico Califo
Bikes: 2013 BMC Impec
Posts: 1,153
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
you should just run a 1 x 2. That way you only have a rear derailleur, instead of a rear tensioner and a front derailleur. Think about the clean lines here, not about being unique.
stryper is offline   Reply With Quote
Old 12-01-09, 04:47 PM   #14
ianjk
:)

Join Date: Nov 2006
Location: duluth
Bikes: '07 Pista, '09 Fantom Cross Uno, '8? Miyata, '67 Stingray, '0? Zoo mod trials, Tallbike, Chopper, '73 Schwinn Collegiate, '67 Triumph Chopper, '69 CB350, '58 BSA Spitfire, '73 CB450
Posts: 3,392
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I've run a dérailleur-less double front on a couple homebuilt choppers. Changing gears is a snap. Would be nice to bomb out to the trails in high gear, flop the chain over and hit some singletrack. That Specialized looks fun.
ianjk is offline   Reply With Quote
Old 12-02-09, 12:26 AM   #15
mcgreivey
STFD

mcgreivey's Avatar

Join Date: Jul 2008
Location: North Bergen, NJ
Bikes: '80 Windsor Carrera Sport, '02 Specialized Sirrus A1, '10 Giant Escape 2
Posts: 778
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Changing the front by hand isn't a big deal, though you do get your hands dirty.
mcgreivey is offline   Reply With Quote
Old 12-02-09, 03:07 AM   #16
WoundedKnee
Antarctica awaits

WoundedKnee's Avatar

Join Date: Jun 2009
Location: Tucson, Zona
Bikes:
Posts: 1,965
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I was wondering, is it possible to have multiple gears(like a 10-speed) without coasting? What would you call that? Because honestly coasting bikes are dangerous for me to ride now.
WoundedKnee is offline   Reply With Quote
Old 12-02-09, 04:43 PM   #17
thedutchtouch
Senior Member

thedutchtouch's Avatar

Join Date: Jun 2008
Location: Baltimore, MD
Bikes: Leader 722ts
Posts: 220
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by WoundedKnee View Post
I was wondering, is it possible to have multiple gears(like a 10-speed) without coasting? What would you call that? Because honestly coasting bikes are dangerous for me to ride now.
read the threads about the s3x hub. 3 speed fixed gear. that's the closest you'll get.


having a rear derallieur on a fixed gear is a recipe for disaster
thedutchtouch is offline   Reply With Quote
Old 12-02-09, 10:25 PM   #18
MnHPVA Guy
Senior Member

Join Date: Aug 2005
Location: Minneapolis, MN
Bikes:
Posts: 754
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by treebound View Post
I've been thinking of using a singleator chain tensioner and running just a front derailleur. Sort of a singlespeed with a hill gear. Has anyone done this? Any issues that you can think of?
Single idler tensioners like the Singleator won't take up much chain so your rings would have to be pretty similar in size. IIRC the limit is about 5-6t difference. The Melvin would wrap up more chain.

But IMHO it seems silly to have both a FD and a tensioner. You could be better off with just an older rear derailleur like a Huret Svelto which is no bulkier than a Melvin and has enough adjustment that you can limit travel to two cogs. I do this to add gears to Sturmey Archer hubs but you can just run two cogs on a freehub or FW with spacers.


Svelto, Sturmey 4 speed FM hub, KMC 1/8" chain, 18t Nexus cog and 24t HyperGlide cog.

2 cog setups shift great, much better than front shifts. Even with crappy cogs and chains from the '70s. With Hyperglide cogs and modern chain, shifting is amazing, even on the 22-34 I did for the wife. Chainline is great compared to a normal derailleur set-up.

Another possibility is that Sturmey is coming out with a modern 2 speed kickback hub w/coaster brake.
MnHPVA Guy is offline   Reply With Quote
Old 12-03-09, 09:18 AM   #19
treebound
aka: Mike J.
Thread Starter

treebound's Avatar

Join Date: Apr 2005
Location: between Milwaukee and Sheboygan in Wisconsin
Bikes: 1995 Trek 520 is the current primary bike.
Posts: 3,036
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
That's an interesting setup combining an internal gear with a derailleur set up. I've got a 700c wheel with a 7-speed IG hub but it takes a different type cog/sprocket.

I thought I might be stretching the envelope in the SS/FG section asking about 2-speeds, I'll head to a different sub-forum if I revisit the 7-speed hub use.

I've got some thinking to do, probably end up with three winter projects.
treebound is offline   Reply With Quote
Old 12-03-09, 09:24 AM   #20
carleton
Elitist

carleton's Avatar

Join Date: Jul 2005
Location: Atlanta, GA
Bikes:
Posts: 13,135
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Quote:
Originally Posted by beeftech View Post
You're a bit behind...

But try studying these guys, they already made it to 11.

And these guys do it with computers.
Awesome.

Next people are gonna ask for water bottle holders and a way to take off wheels without having to use a 15mm wrench.
carleton is offline   Reply With Quote
Old 12-03-09, 12:55 PM   #21
TboneZX11
Effortless Power ...

TboneZX11's Avatar

Join Date: Jan 2009
Location: Kansas City Metro
Bikes: Fixed Gear conversion bike(s), Jamis Quest road; Specialized M2; Puch conversion CX
Posts: 109
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
You could always run a surly dingle: http://harriscyclery.net/itemdetails.cfm?ID=2466
TboneZX11 is offline   Reply With Quote
Old 12-03-09, 01:14 PM   #22
bmike
Bye Bye

Join Date: Jul 2005
Location: Gone gone gone
Bikes:
Posts: 3,677
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
running a surly dingle cog 17/19 with 32/34 up front.
saving my pennies for a dos eno freewheel from white ind.

flip flop wheel on my soma juice, so i can run the same ratios fixed or free, depending on mood.

i had it setup on my crosscheck prior... with a flop for a single ss.

__________________
So long. Been nice knowing you BF.... to all the friends I've made here and in real life... its been great. But this place needs an enema.
bmike is offline   Reply With Quote
Old 03-04-10, 02:12 PM   #23
ken_matthews
Senior Member

ken_matthews's Avatar

Join Date: Oct 2007
Location: Falls Church, VA
Bikes: 1979 Trek 3-sp, 1886 Unknown 52”hiwheel, 1970 Viscount fixed gear
Posts: 217
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by beeftech View Post
You're a bit behind...

But try studying these guys, they already made it to 11.

And these guys do it with computers.
New Yorker...figured as much...

more importantly TREEBOUND, what did you settle on for your 2-fer setup?
ken_matthews is offline   Reply With Quote
Old 03-04-10, 02:20 PM   #24
frymaster
Senior Member

frymaster's Avatar

Join Date: Aug 2007
Location: where the mild things roam
Bikes:
Posts: 1,092
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
i'm confused....

what was wrong with this?

http://www.bikesdirect.com/products/...kilott_s3x.htm
frymaster is offline   Reply With Quote
Old 03-04-10, 04:20 PM   #25
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Bikes: Several, mostly not name brands.
Posts: 16,451
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 90 Post(s)
How about a 2-speed coaster hub?



There's usually some on eBay:
http://shop.ebay.com/i.html?_nkw=ben..._dmd=1&_ipg=50
JohnDThompson is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 08:46 PM.
