question about crown race install

i'm installing a crown race on my new cinelli vogorelli steer tube.

never installed this stuff before, first bike build. i noticed though that the crown race they gave me is not a complete circle. they split it so it could expand it looks like. just wondering if this is normal and where the gap should be when i set the crown race.
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 12:40 PM   #2
TejanoTrackie
Veteran Racer

TejanoTrackie's Avatar

Join Date: Jul 2009
Location: Ciudad de Vacas, Tejas
Bikes: 29 frames + 73 wheels
Posts: 10,439
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 232 Post(s)
I've never seen a "split" fork crown race. Are you sure it's the race and not some other part of the headset, such as a dust shield? What brand and type of headset is it? Integrated, semi-integrated, external? Sealed or open bearing? Can you show us a photo of all the parts?
__________________
What, Me Worry? - Alfred E. Neuman

Quote:
Originally Posted by Dcv View Post
I'd like to think i have as much money as brains.
I see the light at the end of the tunnel, but the tunnel keeps getting longer - me
TejanoTrackie is offline   Reply With Quote
Old 07-21-10, 12:45 PM   #3
desconhecido
Senior Member

Join Date: Mar 2010
Bikes:
Posts: 949
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
I don't know how common it is, but some sealed cartridge bearing headsets these days have a crown race that is split and can be installed without tools. It's sort of wrong to call it a "race," as it's not a surface for bearings, it's a fitting to mate the fork crown and cartridge bearing.

That's my understanding, anyway.
desconhecido is offline   Reply With Quote
Old 07-21-10, 12:50 PM   #4
carleton
Elitist

carleton's Avatar

Join Date: Jul 2005
Location: Atlanta, GA
Bikes:
Posts: 13,364
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 169 Post(s)
You should ask in the Mechanics forum.
__________________
Quote:
Originally Posted by gtrob View Post
Roadies can run tempo all year as that's what humans were designed for. If you want to be a cheetah, lay around and lick your paws more.
carleton is offline   Reply With Quote
Old 07-21-10, 02:45 PM   #5
rustybrown
Senior Member

rustybrown's Avatar

Join Date: Jul 2009
Location: DeSouf
Bikes:
Posts: 2,147
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quite odd. I'd be skeptical.
rustybrown is offline   Reply With Quote
Old 07-21-10, 05:04 PM   #6
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)


plowmanjoe is offline   Reply With Quote
Old 07-21-10, 05:06 PM   #7
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
you can see that it doesn't sit well right now. do you think once i set the star nut in and torque it down that it'll mesh completely?
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 05:09 PM   #8
AEO
Senior Member

AEO's Avatar

Join Date: Jun 2007
Location: A Coffin Called Earth. or Toronto, ON
Bikes: Bianchi, Miyata, Dahon, Rossin
Posts: 12,258
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
it's not a race.
It's just a guide.

the race is in the cartridge bearings.

are you sure you have the correct integrated headset for your frame?

there are only about 20 to choose from, and all are incompatible with each other.
__________________
Food for thought: if you aren't dead by 2050, you and your entire family will be within a few years from starvation. Now that is a cruel gift to leave for your offspring. ;)
http://sanfrancisco.ibtimes.com/arti...ger-photos.htm
AEO is offline   Reply With Quote
Old 07-21-10, 05:11 PM   #9
TejanoTrackie
Veteran Racer

TejanoTrackie's Avatar

Join Date: Jul 2009
Location: Ciudad de Vacas, Tejas
Bikes: 29 frames + 73 wheels
Posts: 10,439
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 232 Post(s)
Wierd. Something's not right here. Perhaps you can get some info from FSA on this. I definitely wouldn't just try to force it on.
__________________
What, Me Worry? - Alfred E. Neuman

Quote:
Originally Posted by Dcv View Post
I'd like to think i have as much money as brains.
I see the light at the end of the tunnel, but the tunnel keeps getting longer - me
TejanoTrackie is offline   Reply With Quote
Old 07-21-10, 05:12 PM   #10
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by AEO View Post
it's not a race.
It's just a guide.

the race is in the cartridge bearings.

are you sure you have the correct integrated headset for your frame?

there are only about 20 to choose from, and all are incompatible with each other.
everything was included with the frame. so i couldn't have messed up on getting the right parts.
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 05:14 PM   #11
AEO
Senior Member

AEO's Avatar

Join Date: Jun 2007
Location: A Coffin Called Earth. or Toronto, ON
Bikes: Bianchi, Miyata, Dahon, Rossin
Posts: 12,258
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
actually, I think that piece you're calling the crown race is for the upper section of the steerer tube. It's supposed to sit on top of the upper headset bearing with the cover over it.

the crown race looks more like a dish plate.

page 2
http://docs.google.com/viewer?a=v&q=...masILlbvHT9mAQ
__________________
Food for thought: if you aren't dead by 2050, you and your entire family will be within a few years from starvation. Now that is a cruel gift to leave for your offspring. ;)
http://sanfrancisco.ibtimes.com/arti...ger-photos.htm
AEO is offline   Reply With Quote
Old 07-21-10, 05:16 PM   #12
Scrodzilla
There goes Tokyo

Scrodzilla's Avatar

Join Date: May 2009
Location: San Diego, CA
Bikes: EAI Bare Knuckle, 1975 Raleigh Pro Track
Posts: 26,765
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 217 Post(s)
That's definitely not right. There shouldn't be a huge gap between your headset and fork. That looks more like the compression ring that sits above the top bearing. Can you take a pic of all the parts you have laid out on a table or something?
__________________

Last edited by Scrodzilla; 07-21-10 at 05:17 PM. Reason: AEO beat me to the punch
Scrodzilla is offline   Reply With Quote
Old 07-21-10, 05:18 PM   #13
grymg
Senior Member

grymg's Avatar

Join Date: Oct 2008
Location: Fremont, CA
Bikes:
Posts: 211
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
^^Agree, I have the same frame. Best not to mess with this stuff. I took my fork and all of the headset parts to my LBS and they installed the crown race for $5. The tool to do it is pretty expensive for how many times you would use it.
grymg is offline   Reply With Quote
Old 07-21-10, 05:23 PM   #14
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 05:26 PM   #15
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by AEO View Post
actually, I think that piece you're calling the crown race is for the upper section of the steerer tube. It's supposed to sit on top of the upper headset bearing with the cover over it.

the crown race looks more like a dish plate.

page 2
http://docs.google.com/viewer?a=v&q=...masILlbvHT9mAQ
you're right it looks like i have it wrong.

i have two of the parts mixed up.
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 05:32 PM   #16
Scrodzilla
There goes Tokyo

Scrodzilla's Avatar

Join Date: May 2009
Location: San Diego, CA
Bikes: EAI Bare Knuckle, 1975 Raleigh Pro Track
Posts: 26,765
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 217 Post(s)
Yes. The piece above what you originally thought to be the crown race is the right one. Throw it in the freezer for a while. The metal will expand slightly and you may be able to drop it right on your fork without much effort. Whatever you do, DO NOT force it on with a hammer and flathead screwdriver.
__________________
Scrodzilla is offline   Reply With Quote
Old 07-21-10, 05:38 PM   #17
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Scrodzilla View Post
Yes. The piece above what you originally thought to be the crown race is the right one. Throw it in the freezer for a while. The metal will expand slightly and you may be able to drop it right on your fork without much effort. Whatever you do, DO NOT force it on with a hammer and flathead screwdriver.
thanks. i will freeze it and see how it goes.

how about a hammer and a wrench? i have one that fits perfectly
Attached Images
File Type: jpg 7748_view..jpg (19.7 KB, 3 views)
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 05:46 PM   #18
Scrodzilla
There goes Tokyo

Scrodzilla's Avatar

Join Date: May 2009
Location: San Diego, CA
Bikes: EAI Bare Knuckle, 1975 Raleigh Pro Track
Posts: 26,765
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 217 Post(s)
I wouldn't even try that. The best thing to do if you don't have a crown race install tool is get a piece of PVC pipe that fits nicely over your steerer tube and gently tap it on.

Installing Fork Crown Race

either that or go to the LBS. They'll install it for a few bucks.
__________________
Scrodzilla is offline   Reply With Quote
Old 07-21-10, 06:09 PM   #19
mumblesmumbles
just mumbling

mumblesmumbles's Avatar

Join Date: Aug 2009
Location: Alameda CA
Bikes:
Posts: 83
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Scrodzilla View Post
Throw it in the freezer for a while. The metal will expand slightly
Cold makes metal contract.

Heat expands.

Not to nitpick or anything.
mumblesmumbles is offline   Reply With Quote
Old 07-21-10, 06:12 PM   #20
Scrodzilla
There goes Tokyo

Scrodzilla's Avatar

Join Date: May 2009
Location: San Diego, CA
Bikes: EAI Bare Knuckle, 1975 Raleigh Pro Track
Posts: 26,765
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 217 Post(s)
****, yeah...you're right. It's been too long a day. It's been a long time since I've had to install one without the proper tools but I should definitely know that metal shrinks when it's cold. I can see the poor dude now, taking his crown race from the freezer and cursing me out because it's smaller than it was before.

I need a nap. Boil that sucker.
__________________
Scrodzilla is offline   Reply With Quote
Old 07-21-10, 06:14 PM   #21
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
next thing.

what's the best way to get the star nut in there?

i saw a video using a screw driver and a hammer.
plowmanjoe is offline   Reply With Quote
Old 07-21-10, 06:16 PM   #22
Scrodzilla
There goes Tokyo

Scrodzilla's Avatar

Join Date: May 2009
Location: San Diego, CA
Bikes: EAI Bare Knuckle, 1975 Raleigh Pro Track
Posts: 26,765
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 217 Post(s)
I saw a video of a guy going to his local shop and having them do it.

I'm kidding. Did you get the race seated properly?
__________________
Scrodzilla is offline   Reply With Quote
Old 07-21-10, 06:19 PM   #23
AEO
Senior Member

AEO's Avatar

Join Date: Jun 2007
Location: A Coffin Called Earth. or Toronto, ON
Bikes: Bianchi, Miyata, Dahon, Rossin
Posts: 12,258
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
using a starnut setter is the best method.
if you screw up and hammer it in on an angle, that means you'll have to buy a new starnut.
__________________
Food for thought: if you aren't dead by 2050, you and your entire family will be within a few years from starvation. Now that is a cruel gift to leave for your offspring. ;)
http://sanfrancisco.ibtimes.com/arti...ger-photos.htm
AEO is offline   Reply With Quote
Old 07-21-10, 06:26 PM   #24
TejanoTrackie
Veteran Racer

TejanoTrackie's Avatar

Join Date: Jul 2009
Location: Ciudad de Vacas, Tejas
Bikes: 29 frames + 73 wheels
Posts: 10,439
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 232 Post(s)
Quote:
Originally Posted by plowmanjoe View Post
next thing.

what's the best way to get the star nut in there?

i saw a video using a screw driver and a hammer.
If you do that you're likely to get it in crooked and mangle the threads, which are pretty soft. What I do is get a long screw with the same threads from the hardware store, thread it in fully, use the cap as a guide, and hammer the screw to drive the star nut into the steerer tube. Make sure you don't drive it in too far, or the bolt won't thread fully into it. When you go to cut the steerer tube, you first drive the star nut in further past to cut point.
__________________
What, Me Worry? - Alfred E. Neuman

Quote:
Originally Posted by Dcv View Post
I'd like to think i have as much money as brains.
I see the light at the end of the tunnel, but the tunnel keeps getting longer - me
TejanoTrackie is offline   Reply With Quote
Old 07-21-10, 06:27 PM   #25
plowmanjoe
Senior Member
Thread Starter

plowmanjoe's Avatar

Join Date: Oct 2009
Location: NYC
Bikes: Cinelli Vigorelli
Posts: 482
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
all set, just went for it and it all worked out.

just waiting on a few more parts to arrive and it'll be complete.
plowmanjoe is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 05:28 AM.
