Uncle Sixty's Gearing Primer for Newbs

So, you just built your first fixed gear or single speed and now you are obsessing over the question we have all asked ourselves... "What gear ratio should I use?".

And then, you start a thread asking the question that has been asked a thousand times.

If you want to calculate gear inches go here:

Sheldon Brown's Gear Inch Calculator

Rabbit Calculator

When you get that number calculated it might not mean a thing to you so maybe this will help.

When you buy a stock bike many companies set them up with a gearing in the high 70's which is what most folks would use if they were riding on the track, if your name is Boonen and have knees and legs of steel you might be running something in the mid to high 80's or the very low 90's.

For the rest of us mortals a gearing of 72 seems to be just about right for healthy individuals as this is low enough that you can tackle reasonable hills, ride into the wind, and still dial it up when you need to haul some ass.

If you want to go fast on a fixed gear you will need to learn how to spin efficiently at higher rpms which will make your knees, heart, and lungs very happy.

If you live in hill country or like to tour on your fixed gear a lower gearing can be preferable and I would suggest running a double stepped hub to give you a couple of gears to play with.

If you ride in the winter something in the high 50 to low 60 gear inch range will allow you to slog through some pretty nasty snow and allow you to do seated skids to keep your weight balanced and prevent wipe outs.

My fixed gear road bike runs a 72/80 and the 72 gets the lions share of use while my winter bike ran a 59, and my vintage club bike has a 69/76.

The cheapest way to change gearing is to change your rear cog and running the largest combination of chain ring and cog to get your desired gearing will make your drive more efficient and reduce drive train wear... and a 52:17 (80 gi) looks pretty badass to boot.

Messengers usually don't run monster gearing... when I did this I ran 76 gear inches in the summer and worked in a pretty flat area.

Last edited by Sixty Fiver; 02-28-11 at 04:30 PM.
Sixty Fiver is offline   Reply With Quote
Old 02-27-11, 07:13 PM   #2
I Have a Bike
Makin it Trizzle

I Have a Bike's Avatar

Join Date: Aug 2010
Bikes:
Posts: 196
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I smell a new sticky
I Have a Bike is offline   Reply With Quote
Old 02-27-11, 07:22 PM   #3
Scrodzilla
There goes Tokyo

Scrodzilla's Avatar

Join Date: May 2009
Location: San Diego, CA
Bikes: EAI Bare Knuckle, 1975 Raleigh Pro Track
Posts: 26,476
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 39 Post(s)
Your nose knows.
__________________
__________________________________
Scrodzilla is offline   Reply With Quote
Old 02-27-11, 07:32 PM   #4
Motopecane
Senior Member

Motopecane's Avatar

Join Date: Aug 2010
Location: lynnwood, WA
Bikes: AWOL, Stache 7, Keirin Pro
Posts: 229
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thank you for this.
Motopecane is offline   Reply With Quote
Old 02-27-11, 07:40 PM   #5
xkillemallx16
Senior Member

Join Date: Sep 2009
Location: im, hungary
Bikes:
Posts: 1,983
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Sixty Fiver View Post
Messengers usually don't run monster gearing... when I did this I ran 76 gear inches in the summer and worked in a pretty flat area.
a large amount of messengers used geared bikes too.
xkillemallx16 is offline   Reply With Quote
Old 02-27-11, 07:53 PM   #6
Sixty Fiver
Bicycle Repair Man !!!
Thread Starter

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by xkillemallx16 View Post
a large amount of messengers used geared bikes too.
I could post a gearing primer for that as well but this is ss/fg and in here we know that multiple gears are for people over 45.

Sixty Fiver is offline   Reply With Quote
Old 02-27-11, 08:10 PM   #7
Squirrelli
GONE~

Join Date: Apr 2010
Bikes:
Posts: 6,757
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I'd like to contribute my little calculation formula without using a program...

Basically, charing (44) divided by cog (17) times tire size in inches (23c or 26.275") = 68 gi

All you have to do is remember the number for your tire and you're good to go. Here's a list of popular tire sizes:

23c - 26.275"
25c - 26.375"
28c - 26.775"
32c - 27"
35c - 27.175"
38c - 27.3"

I find this very useful when I don't have internet handy.
Squirrelli is offline   Reply With Quote
Old 02-27-11, 09:14 PM   #8
Sixty Fiver
Bicycle Repair Man !!!
Thread Starter

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Squirelli - The manual calculation works really well... actual diameter will vary depending on tyre sizes and some of us run other wheel sizes on or fg bikes... 26 inch mtb tyres and 20 inch wheels will have greater variance than road tyres due to different tread patterns and the 20 inch tyres on my folder are actually 19.5 since they are low profile, high performance tyres.
Sixty Fiver is offline   Reply With Quote
Old 02-27-11, 09:54 PM   #9
Ken Cox
King of the Hipsters

Join Date: Jan 2005
Location: Bend, Oregon
Bikes: Realm Cycles Custom
Posts: 2,129
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I like Bare Knuckle Brigade's Rabbit Applet for studying gear ratios:

http://software.bareknucklebrigade.c...it.applet.html
Ken Cox is offline   Reply With Quote
Old 02-27-11, 09:57 PM   #10
Lilcphoto
My name is Alex

Lilcphoto's Avatar

Join Date: Jul 2010
Location: PDX
Bikes: Mercier Kilo TT Stripper in RAW, Schwinn Madison 2008 Blue, Leader 725tr, Brassknuckle, Leader 722, Traitor Ruben
Posts: 1,701
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Ken Cox View Post
I like Bare Knuckle Brigade's Rabbit Applet for studying gear ratios:

http://software.bareknucklebrigade.c...it.applet.html
Google Chrome Browser doesn't seem to like that one... So I use All-City's
Lilcphoto is offline   Reply With Quote
Old 02-27-11, 10:12 PM   #11
1nput0utput
Senior Member

Join Date: Oct 2010
Location: Boston, MA, USA
Bikes:
Posts: 61
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Lilcphoto View Post
Google Chrome Browser doesn't seem to like that one... So I use All-City's
Unfortunately that one only allows 622 mm BSD wheels and doesn't account for different crank arm lengths. The other ones have a much larger selection of wheel sizes and variable crank arm lengths.

Last edited by 1nput0utput; 02-27-11 at 10:15 PM. Reason: clarification
1nput0utput is offline   Reply With Quote
Old 02-27-11, 11:02 PM   #12
Sixty Fiver
Bicycle Repair Man !!!
Thread Starter

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by Ken Cox View Post
I like Bare Knuckle Brigade's Rabbit Applet for studying gear ratios:

http://software.bareknucklebrigade.c...it.applet.html
This is also a very good application and will add the link to the OP.

Crank length has nothing to do with calculating gear inches and is only a factor if you are calculating gain ratios... for as much as I loved Sheldon his preference for this and prediction that an inch based measurement would fade away, I still prefer gear inches.
Sixty Fiver is offline   Reply With Quote
Old 02-28-11, 01:21 AM   #13
puppypilgrim
Senior Member

Join Date: May 2007
Location: Vancouver, Canada
Bikes: Brodie Force w/ Xtracycle, Dahon Helios, Merida Folding, Pacific Carryme, Softride Classic
Posts: 791
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I prefer Gear Inches too! Currently 72 on my road bike and 66 on my folding bike. SS\FG riders (not hipsters) march to the beat of a different drum I guess.
puppypilgrim is offline   Reply With Quote
Old 02-28-11, 09:08 AM   #14
markaitch
Banned

Join Date: Jan 2011
Location: A1A
Bikes:
Posts: 594
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
finally...
a thread that i think is really helpful...glad it got made into a sticky!
anyway, i am never completely happy with the gear ratio (or gear inches) i have on my road bike at any given moment.
yeah, i know that's part of fg/ss riding, but i still have plenty of q's on this subject & hope that you guys will bear with me if i come back here on occasion with some of them.
markaitch is offline   Reply With Quote
Old 02-28-11, 10:57 AM   #15
Sixty Fiver
Bicycle Repair Man !!!
Thread Starter

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
mark - There are many helpful threads here... the sticky guide is full of them.
Sixty Fiver is offline   Reply With Quote
Old 02-28-11, 02:03 PM   #16
Decepticondc5
I am ill

Decepticondc5's Avatar

Join Date: Feb 2011
Location: Baton Rouge, LA
Bikes: 2020 Vilano POS
Posts: 205
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
noob question:

would a persons weight affect what gear ratio they should select?
Decepticondc5 is offline   Reply With Quote
Old 02-28-11, 02:25 PM   #17
Squirrelli
GONE~

Join Date: Apr 2010
Bikes:
Posts: 6,757
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Not necessarily, it depends on the person's ability to use that ratio.

For example:



Chris Hoy, 200lbs, claimed to ride 52/14 ratio in all his races.

Compared to Eddy Merckx during his Hour Record:



He is only about 170lbs or so but he is able to push a 53/11 gear to set the record.

In summation, a riders weight does not necessarily affect the ability of the rider to use the gear to the fullest, quite the contrary, a lot of track riders are pretty massive like:

Kevin Sireau




Theo Bos



Gregory Bauge



But there are skinny road riders that could push a huge gear as well:

Alberto Contador:



Andy Schleck



All in all, weight doesn't matter much, it's the strength of the rider that counts.

Last edited by Squirrelli; 02-28-11 at 03:00 PM.
Squirrelli is offline   Reply With Quote
Old 02-28-11, 02:44 PM   #18
funkycharms
Choo Choo!

funkycharms's Avatar

Join Date: Feb 2011
Location: Bay Area, CA
Bikes: SE Lager SS/FG
Posts: 19
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
just the thread I was looking for, thanks!
funkycharms is offline   Reply With Quote
Old 02-28-11, 02:55 PM   #19
Decepticondc5
I am ill

Decepticondc5's Avatar

Join Date: Feb 2011
Location: Baton Rouge, LA
Bikes: 2020 Vilano POS
Posts: 205
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
thank you squirrelli
Decepticondc5 is offline   Reply With Quote
Old 02-28-11, 04:28 PM   #20
famous amos
Senior Member

Join Date: Jul 2007
Location: Portland
Bikes:
Posts: 98
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
BTW OP, 52x17 isn't 72gi, its more like 80.
famous amos is offline   Reply With Quote
Old 02-28-11, 04:41 PM   #21
caloso
Packfodding 3

caloso's Avatar

Join Date: Jul 2002
Location: Sacramento, California, USA
Bikes: Ridley Excalibur, Gazelle Champion Mondial, On-One Pompino, Specialized Rock Hopper
Posts: 33,626
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 59 Post(s)
Very nice.

FWIW, I ran a 52-15 for a flat 10 mile TT last summer. I was 30 seconds faster than the previous year on my geared bike, but that was probably due to the aero helmet and shoe covers.
caloso is offline   Reply With Quote
Old 02-28-11, 04:43 PM   #22
Sixty Fiver
Bicycle Repair Man !!!
Thread Starter

Sixty Fiver's Avatar

Join Date: Sep 2007
Location: YEG
Bikes: See my sig...
Posts: 27,255
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Quote:
Originally Posted by famous amos View Post
BTW OP, 52x17 isn't 72gi, its more like 80.
Thanks !

Got my numbers swapped... my 52 with a 17 /19 is a 72/80 gearing.

Used to rock a single gearing of 83 gear inches and that was my daily driver for 5000 miles... dropped that back to 76 after that and just found that I could go even faster.

In the old days, time trialists would run a 76 inch gear to do a sub hour 40 (25 miles) and this was also the gearing road racers used for much of their spring training.

I f'd up my back some years ago and the resulting nerve damage affects my left leg which makes it hard for me to mash as big a gear and usually find myself running that 72 which I can spin like a gerbil on crack.
Sixty Fiver is offline   Reply With Quote
Old 02-28-11, 08:17 PM   #23
1nput0utput
Senior Member

Join Date: Oct 2010
Location: Boston, MA, USA
Bikes:
Posts: 61
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Sixty Fiver View Post
… spin like a gerbil on crack.
Excellent mental image.
1nput0utput is offline   Reply With Quote
Old 02-28-11, 11:17 PM   #24
NikZak
Bike Hoarder

NikZak's Avatar

Join Date: Jan 2011
Location: Melbourne, Australia
Bikes: 80's Graecross Courier Fixie, 2010 Bauer Suburban, 1988 Thruster 300 Volt BMX
Posts: 156
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
i think this thread should be subtitled:

"Now noobs have no excuse to post new threads about gear inches every three days"
NikZak is offline   Reply With Quote
Old 03-21-11, 03:25 PM   #25
revelstone
Senior Member

Join Date: Aug 2008
Location: UTAH
Bikes: centurions (lemans and sports dlx both 1981)
Posts: 127
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
exceptions to every rule

Quote:
Originally Posted by Sixty Fiver View Post
I could post a gearing primer for that as well but this is ss/fg and in here we know that multiple gears are for people over 45.

now now lets not write anything in stone. i ride a ss/fg, 700 wheels, 44/16 gearing. and i like it more than my 21 speed mountain bike that's spending most of march and the rest of summer and most of it not all of fall in the shed. same as last year. i'll be 55 on my next birthday.
revelstone is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 05:58 PM.
