Thread: chainring sizes

  1. #1
    Senior Member
    Join Date
    Apr 2012
    My Bikes
    peugeot u010, giant scr4, raleigh road bike
    Posts
    59
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)

    chainring sizes

    i recently got a create frame and when i put a 46 tooth chainring on it catches the chainstay ( i think thats what its called). I checked the chainring to see if it was bent but i don't think it is and the bottom bracket is crooked either. Is the only way to fix this to get a smaller chainring.

    thanks
    Attached Images Attached Images

  2. #2
    Veteran Bastard Scrodzilla's Avatar
    Join Date
    May 2009
    Location
    San Diego, CA
    My Bikes
    EAI Bare Knuckle / Leader 725 / 1975 Raleigh Professional Track
    Posts
    23,904
    Mentioned
    22 Post(s)
    Tagged
    2 Thread(s)
    Cool story.

    You could be using a BB with the wrong length spindle for your crankset.

  3. #3
    Senior Member gigantor's Avatar
    Join Date
    Jan 2012
    Posts
    949
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Quote Originally Posted by tadhgnealon View Post
    i recently got a create frame and when i put a 46 tooth chainring on it catches the chainstay ( i think thats what its called). I checked the chainring to see if it was bent but i don't think it is and the bottom bracket is crooked either. Is the only way to fix this to get a smaller chainring.

    thanks
    Just curious, but how come you didn't go to a bike shop and ask them to do this for you, or ask them what BB they would recommend using with this frame?

    I think it would have ended up being cheaper for you in the long run.
    "I wanted to test his might" -Jaytron
    "Dark Stella" - FM015 | Purple bike with no name

  4. #4
    hamcycles.com hamfoh's Avatar
    Join Date
    Mar 2011
    Posts
    3,893
    Mentioned
    3 Post(s)
    Tagged
    0 Thread(s)
    tell us your parts
    Bikes - past and present

  5. #5
    I fear angry birds Santaria's Avatar
    Join Date
    Apr 2005
    Location
    Recalculating
    My Bikes
    2013 Salsa Vaya
    Posts
    2,154
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    THE DEVIL

    Originally Posted by Scrodzilla
    If that was my house and you put your stupid bike in my flower garden to take a picture, I would come outside in my underwear and light you on fire.

  6. #6
    Senior Member gigantor's Avatar
    Join Date
    Jan 2012
    Posts
    949
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    Hahaha
    "I wanted to test his might" -Jaytron
    "Dark Stella" - FM015 | Purple bike with no name

  7. #7
    Delusional Laserbrain Germanicus's Avatar
    Join Date
    Jul 2009
    Location
    South Orange, NJ
    My Bikes
    2008 Specialized Tricross, 1993 Giant Iguana rebuild w/ singlespeed drive train
    Posts
    396
    Mentioned
    0 Post(s)
    Tagged
    0 Thread(s)
    I had the same problem on my SS build up but mine was an even noobier mistake. I bought a an S300 courier track crank to use on a rigid MTB frame. BAM right into the chain stays before it was half screwed in. Don't know why it didn't occur to me before I bought the crank. Still trying to sell that crank.

    10 things the noob (me) learned:
    1. Road and track cranks don't usually work on a mountain bikes for this reason.
    2. Cranks with attached spindles need a perfect fit because you can't swap out for a shorter or longer spindle.
    3. Different bikes have different chain stay curve angles and different chainrings will hit it at different places.
    4. Mtn bike cranks have a wider q factor than road bikes to allow clearance of the wider chain stays
    5. It is possible to mount the chainring on the inside or outside of the crank arms depending on the model to adjust chain line and chain stay clearance.
    6. If your frame is made of steel and the chainring just barely touches, you can dent your chain stay with a hammer to make it fit. (or so Ive been told.)
    7. If you have to swap out the crank or chain ring remember to get a smaller cog and/or shorter lever arms to compensate for the adjusted Gain ratio.
    8. Better to ask dumb questions at the bike shop before buying the parts online at the discount vendor that doesn't take returns.
    9. It might be better to have the guys at the bike shop do this particular job for you so they can play around with different size chainrings and cogs until they find a combo that works right.
    10. Don't get too attached to any particular component until after you find out if it even fits on your bike.

    Good luck.
