Grocery Cart

I decided to take AdamDZ's magnificent cart design, and adapt it to my gutted Instep trailer. The square shape of the frame beams makes the In-Step very easy to work with. I used angle irons to attach the box to the frame. The holes in the angle irons give me the option of moving the box further backward later on if needed. The way that the bolts attach to the recessed areas inside the box should keep items from being scratched by the button heads.

I still need to finish trimming the angle irons down to size, but that's merely a cosmetic thing. Reflectors and other accessories will be added on later.

I also bought cross braces too attach to the angle irons, underneath the box, but I'm not sure if they're really needed. The setup feels pretty sturdy the way it is.

I'll post more as the design evolves.






AlmostGreenGuy is offline   Reply With Quote
Old 03-04-12, 11:34 PM   #2
alexaschwanden
Bike rider

alexaschwanden's Avatar

Join Date: Jun 2010
Location: san jose
Bikes: 2015 Raleigh Revenio 1.0
Posts: 3,143
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Great work!
alexaschwanden is offline   Reply With Quote
Old 03-06-12, 08:52 AM   #3
ks1g
Because I thought I could

ks1g's Avatar

Join Date: Dec 2004
Location: Wash DC Metro
Bikes: November, Trek OCLV, Bianchi Castro Valley commuter
Posts: 969
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
A very nice job! Did this trailer start out as a kid trailer before you removed the fabric? About the only things I'd do: Cut back and slide/fold old innter tubes over the ends of the angle iron to reduce the chance of a nasty cut or snag, and put some trailor reflectors, reflective tape, and lights on the back (maybe a bullseye for irony <grin> ). I'd consider reinforcing the bottom of the box where the bolts are located with two strips of aluminum sheet or plate, thin plywood or pegboard, or fender washers. Depending on the material used, the plastic may be prone to cracking over time.
ks1g is offline   Reply With Quote
Old 03-06-12, 12:31 PM   #4
Nightshade
Humvee of bikes =Worksman

Nightshade's Avatar

Join Date: May 2004
Bikes:
Posts: 5,363
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by AlmostGreenGuy View Post
Sorry but those protruding added angle brackets are a injury waiting to happen. Either cut them off flush with the trailer frame of remove them completely. A simple 3/8" plywood bed the same size as the trailer deck will serve you better and safer.
__________________
My preferred bicycle brand is.......WORKSMAN CYCLES
I dislike clipless pedals on any city bike since I feel they are unsafe.

Originally Posted by krazygluon
Steel: nearly a thousand years of metallurgical development
Aluminum: barely a hundred, which one would you rather have under your butt at 30mph?
Nightshade is offline   Reply With Quote
Old 03-06-12, 12:45 PM   #5
badmother
Senior Member

badmother's Avatar

Join Date: Nov 2007
Bikes:
Posts: 3,134
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Quote:
Originally Posted by Nightshade View Post
Sorry but those protruding added angle brackets are a injury waiting to happen. Either cut them off flush with the trailer frame of remove them completely. A simple 3/8" plywood bed the same size as the trailer deck will serve you better and safer.
If you try hard and keep practicing it is always possible to find something negative to say. Did you notice he wrote: "I still need to finish trimming the angle irons down to size, but that's merely a cosmetic thing. Reflectors and other accessories will be added on later."? Actually they both said the same.

I think they did a great job. I wish I could find such big boxes w lid around here!

Last edited by badmother; 03-06-12 at 12:47 PM. Reason: zPelLiNg
badmother is offline   Reply With Quote
Old 03-06-12, 09:15 PM   #6
AlmostGreenGuy
Intrepid Bicycle Commuter
Thread Starter

AlmostGreenGuy's Avatar

Join Date: Sep 2009
Location: Upstate New York
Bikes: Salsa Vaya, Trek 4300, Fyxation Eastside
Posts: 637
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Yep. Angle irons will be cut down on Saturday. Just didn't have time last weekend.

I'm not so sure that plywood would be an upgrade either. The aluminum angle irons are relatively light in comparison to wood, and give me some very nice mounting points for reflector brackets and other accessories.
AlmostGreenGuy is offline   Reply With Quote
Old 03-07-12, 04:24 AM   #7
badmother
Senior Member

badmother's Avatar

Join Date: Nov 2007
Bikes:
Posts: 3,134
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Quote:
Originally Posted by AlmostGreenGuy View Post
Yep. Angle irons will be cut down on Saturday. Just didn't have time last weekend.

I'm not so sure that plywood would be an upgrade either. The aluminum angle irons are relatively light in comparison to wood, and give me some very nice mounting points for reflector brackets and other accessories.

Sounds right. Plywood would be more heavy, and need much more maintenance not to look ugly fast. The "bucket" should be sturdy enough not to need an extra floor.
badmother is offline   Reply With Quote
Old 03-07-12, 11:41 AM   #8
hopperja
Senior Member

Join Date: Sep 2006
Bikes:
Posts: 892
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
If it was my trailer, I would not cut the angle iron or aluminum off, whatever it is. I'd cut notches in it so I could bend it straight up and attach it to the corners of the container. That way, the lower, bottom corners (on the front at least) would be protected from accidental damage.

I also noticed your box doesn't cover the entire floor of the trailer. If you want a bigger box, you might be able to find one of those
ABS plastic truck-bed boxes that would fit.
hopperja is offline   Reply With Quote
Old 03-07-12, 12:12 PM   #9
Nightshade
Humvee of bikes =Worksman

Nightshade's Avatar

Join Date: May 2004
Bikes:
Posts: 5,363
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by badmother View Post
if you try hard and keep practicing it is always possible to find something negative to say. did you notice he wrote: "i still need to finish trimming the angle irons down to size, but that's merely a cosmetic thing. Reflectors and other accessories will be added on later."? actually they both said the same.

I think they did a great job. I wish i could find such big boxes w lid around here!
no.....
__________________
My preferred bicycle brand is.......WORKSMAN CYCLES
I dislike clipless pedals on any city bike since I feel they are unsafe.

Originally Posted by krazygluon
Steel: nearly a thousand years of metallurgical development
Aluminum: barely a hundred, which one would you rather have under your butt at 30mph?
Nightshade is offline   Reply With Quote
Old 03-07-12, 01:31 PM   #10
Digital_Cowboy
Senior Member

Digital_Cowboy's Avatar

Join Date: May 2009
Location: Tampa/St. Pete, Florida
Bikes: Specialized Hardrock Mountain (Stolen); Giant Seek 2 (Stolen); Diamondback Ascent mid 1980 - 1997
Posts: 9,302
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
About the only "change" I can think that I'd make is to use machine bolts with acorn nuts, placing the nuts inside of the box. And installing hasps of some sort so as to be able to lock box to keep people honest.
Digital_Cowboy is offline   Reply With Quote
Old 03-07-12, 02:51 PM   #11
AlmostGreenGuy
Intrepid Bicycle Commuter
Thread Starter

AlmostGreenGuy's Avatar

Join Date: Sep 2009
Location: Upstate New York
Bikes: Salsa Vaya, Trek 4300, Fyxation Eastside
Posts: 637
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Digital_Cowboy View Post
About the only "change" I can think that I'd make is to use machine bolts with acorn nuts, placing the nuts inside of the box. And installing hasps of some sort so as to be able to lock box to keep people honest.
Hmmmmm.... If they had the proper spacing, to fit through the holes in the angle irons, u-bolts would work quite nicely on the outside. Then the nuts go on the inside. The lid of the tub has holes that go through the lip of the tub itself, which could be locked closed.
AlmostGreenGuy is offline   Reply With Quote
Old 03-07-12, 08:43 PM   #12
dayworks
Senior Member

Join Date: Mar 2009
Bikes:
Posts: 65
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I once made a trailer with a plastic top it didn't have hasps but it was lockable. I got it from www.uline.com
Attached Images
File Type: jpg plastic bin.jpg (81.9 KB, 19 views)
dayworks is offline   Reply With Quote
Old 03-08-12, 08:29 AM   #13
badmother
Senior Member

badmother's Avatar

Join Date: Nov 2007
Bikes:
Posts: 3,134
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Quote:
Originally Posted by hopperja View Post

I also noticed your box doesn't cover the entire floor of the trailer. If you want a bigger box, you might be able to find one of those
ABS plastic truck-bed boxes that would fit.
I am thinking that this trailer was made for transporting children. The main weight of them would be where they are sitting and I would expect that to be close to the axels. Feet are not so heavy but they need room.

When this trailer is converted you still want most of the weight close to the axels, so mowing the box forwards is not a good idea in my opinion. I would maybe slide it backwards a bit. the empty space is empty space, unless you can carry something light and bulky there from time to time.
badmother is offline   Reply With Quote
Old 03-10-12, 04:56 PM   #14
AdamDZ
Bike addict, dreamer

AdamDZ's Avatar

Join Date: Nov 2009
Location: Queens, New York
Bikes:
Posts: 5,166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I am flattered Totally so!

If I may: I would consider moving the wheels more towards the middle of the trailer so the weight is supported by the trailer wheels rather than the tongue and the bike's rear axle. Or at least move the box back as far as you can. Great work otherwise.

I don't think you need the cross braces: this tote is very strong and can handle the weight; what you have seems plenty enough to keep the tote securely in place as well.

Oh, what I found great for protecting edges and stuff is a washing machine hose that you can also get in your Home Depot or Lowe's. It's just thick enough and seems to have the perfect balance of hardness/softness for such applications: it can be attached over tubing or cut into smaller pieces and folded over edges and fastened with zip ties.

Last edited by AdamDZ; 03-10-12 at 05:06 PM.
AdamDZ is offline   Reply With Quote
Old 03-10-12, 08:46 PM   #15
AlmostGreenGuy
Intrepid Bicycle Commuter
Thread Starter

AlmostGreenGuy's Avatar

Join Date: Sep 2009
Location: Upstate New York
Bikes: Salsa Vaya, Trek 4300, Fyxation Eastside
Posts: 637
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I got the angle irons cut down this afternoon, and had my daughter assist me with a 60lb load test. Hahahaha. It was a great ride.




I also stopped by Home Depot and picked up some clevis pins tonight. I'll slide the tub back on the angle irons tomorrow, and see if I can use the clevis pins as sort of quick connects either for the angle irons or the tub. I'm not sure which. I just know that I'd like to be able to easily remove the tub for storage reasons.



Adam - Great to see you chime in Obi-Wan!!!!
AlmostGreenGuy is offline   Reply With Quote
Old 03-11-12, 05:12 PM   #16
AdamDZ
Bike addict, dreamer

AdamDZ's Avatar

Join Date: Nov 2009
Location: Queens, New York
Bikes:
Posts: 5,166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Nothing like an able assistant for testing

I was thinking about some sort of quick connect/release as well, but I didn't have a concrete idea, or actually... any idea. Mainly to be able to swap the box with a flat floor, to convert to a flatbed. I will need to revisit that when it gets warmer outside.

One way would simply be to install the flat floor and attach the tote to it with a few bolts with butterfly nuts through the tote's floor, but it would raise the center of gravity when the tote is loaded. But that might be the compromise I'd have to go with.

Last edited by AdamDZ; 03-11-12 at 05:16 PM.
AdamDZ is offline   Reply With Quote
Old 03-11-12, 07:06 PM   #17
pick
Senior Member

pick's Avatar

Join Date: Sep 2011
Location: Antelope Valley, CA
Bikes: ABT1X (retired), KHS TR 101, '84 motocruiser frame
Posts: 108
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I use this SmartBin that I attach by straps when I need a bin to haul stuff:

Attached Images
File Type: jpg Recyclerun-Aug1611.jpg (99.6 KB, 26 views)
pick is offline   Reply With Quote
Old 03-11-12, 08:41 PM   #18
Rimmer
Senior Member

Join Date: Jul 2011
Location: US
Bikes:
Posts: 595
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Many of the bike trailers I've seen have the wheels halfway between the rear and the middle--about 3/4 toward the end like this.



Are you going to bring it in the grocery store?
Rimmer is offline   Reply With Quote
Old 03-12-12, 06:20 PM   #19
pick
Senior Member

pick's Avatar

Join Date: Sep 2011
Location: Antelope Valley, CA
Bikes: ABT1X (retired), KHS TR 101, '84 motocruiser frame
Posts: 108
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by Rimmer View Post
Many of the bike trailers I've seen have the wheels halfway between the rear and the middle--about 3/4 toward the end like this.



Are you going to bring it in the grocery store?

Uhhh, look at the top of this forum and you will see the sticky thread about trailler construction tips...there is an actual formula for placing the wheels on a home built trailer...I followed that formula when I built mine and most dog/kid trailers do not follow that formula...
pick is offline   Reply With Quote
Old 03-18-12, 04:48 PM   #20
AlmostGreenGuy
Intrepid Bicycle Commuter
Thread Starter

AlmostGreenGuy's Avatar

Join Date: Sep 2009
Location: Upstate New York
Bikes: Salsa Vaya, Trek 4300, Fyxation Eastside
Posts: 637
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I haven't had time to play with the quick disconnects yet, but did have time to move the tub back closer to the rear axle, mount some reflectors to the tub, and to mount the flag to the frame. I had a second bike mount for the trailer, so I added the extra mount to the rear axle of my daughter's trailer bike.

Abby and I had a ton of fun testing it out yesterday. We loaded the cart with kites, a cooler, and lots of outdoor play toys, visited a few playgrounds, and ran some shopping errands. The combination of my $25.00 garage sale Schwinn bike, $50.00 Craigslist Burley trailer bike, and the repurposed trailer cart earned a lot of attention at our various stops. Lots of kids wishing that their parents had a fun method of transportation like we did, and lots of questions from parents on how to build such a thing.
