Wanted: Example of Safer 2-lane Slip Road Crossing [Limited Scope]

Notices
Advocacy & Safety Cyclists should expect and demand safe accommodation on every public road, just as do all other users. Discuss your bicycle advocacy and safety concerns here.

Wanted: Example of Safer 2-lane Slip Road Crossing [Limited Scope]

Old 10-03-22, 10:05 AM
  #1
flangehead
Senior Member
Thread Starter

Join Date: Dec 2006
Location: Houston, TX
Posts: 766

Bikes: 2017 Co-op ADV 1.1; ~1991 Novara Arriba; 1990 Fuji Palisade; mid-90's Moots Tandem; 1985 Performance Superbe

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 328 Post(s)
Liked 477 Times in 280 Posts
Wanted: Example of Safer 2-lane Slip Road Crossing [Limited Scope]

[OK, I'll try "limited scope" again; may be a more appropriate thread. The context is that this project is going to happen and the best I can hope to achieve is to make the best of it. Whether this kind of road should be built in the first place isn't relevant. I'd like to limit the scope to good and bad examples of infrastructure for this situation.]

Design has begun on adding another turn-only lane to the intersection of a major arterial and an interstate frontage road in my area. This intersection provides a key crossing of the interstate linking two major regional MUP.


Existing intersection. MUP connection in yellow. They will add another right-turn-only lane.

I'm looking for examples of "safer" solutions that could be implemented for this situation. My first guess is that a refuge island will be needed, but fundamentally I'm looking for examples of how this has been done well in other locations. And frankly, if you have an example where an attempt was done to protect vulnerable road users but has led to same/more injuries, that could help me influence the designers also.

Thank you.
flangehead is offline
Old 10-03-22, 10:32 AM
  #2
Troul
:D

Troul's Avatar

Join Date: Oct 2013
Location: Mich
Posts: 6,041

Bikes: RSO E-tire dropper fixie brifter

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked 2,121 Times in 1,425 Posts
relocate each ped crossing by put all current ped crossings 500' prior to each light, install ped sensor detection devices, manual ped override crossing mechanisms, add in a cursory for slow speed rumble strips, reflective painted lines & high vis signs for addressing vehicle's approaching with good viewable signage.
Or erect an overpass for the ped's crossing.
__________________
-Oh Hey!
Troul is offline
Old 10-03-22, 11:46 AM
  #3
UniChris
Senior Member

UniChris's Avatar

Join Date: May 2017
Location: Northampton, MA
Posts: 1,841

Bikes: 36" Unicycle, winter knock-around hybrid bike

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 894 Post(s)
Liked 374 Times in 268 Posts
The perfect solution of course would be a flyover bridge for through bike traffic.

Failing that, the most efficient and safe design for cyclists riding typical commuting distances is to provide a through bicycle lane to the left of the right turn lanes.

If people do or do not feel comfortable using that depends on both the user and the traffic flow - there are places where I'd do that at some hours, but not others.

If you're going to keep bikes on the dangerously improper righthand side of the turning lane, then you really have to go through the whole expansive exercise of prohibiting right on red and creating a dedicated signal phase. Doing that means everyone loses. Ideally you make the signal phase on a timer or automatic, if you're going to be using a pedestrian "beg button" as your solution for bike crossing it had better be the only such anti-cyclist intersection in at least a mile of otherwise conflict-free through path.

And for heaven's sake if there has to be a beg button, put the beg button pylon on the right side of the path, not the left! It's absurd how often they get even that wrong.

Alternately you can displace the MUP crossing far enough from the intersection to have its own perpendicular controlled crossing. If you're going to do that, you really should use a motion activated automatic traffic light, not a beg button. And it absolutely has to be an actual traffic light that shows a proper and lasting red to the road - none of this legally meaningless white flasher nonsense, nor lights that go blinking red to allow traffic to resume, as flashing red lights are a recipe for killing the second path user who's following a few seconds behind the first.

So basically build the bridge. If you can't build the bridge build the bike lane to the left of the right turn lanes, and get the pedestrian crossing right so that those who aren't comfortable in that correctly routed bike lane can take the pedestrian option instead.

Last edited by UniChris; 10-03-22 at 11:54 AM.
UniChris is offline
Old 10-04-22, 08:35 AM
  #4
Daniel4
Senior Member

Join Date: Jul 2013
Location: Toronto
Posts: 3,344

Bikes: Sekine 1979 ten speed racer

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 1408 Post(s)
Liked 558 Times in 379 Posts
How do the Dutch and the Danish do it? I googled and the first thing I found was "No unsignalized right turn lanes for cars,..."

Then that reminded me of a challenging intersection in Toronto that had several changes in the past year. It was the east bound end of the Bloor Street viaduct where fast moving cars on the right lane go to the north bound ramp of the DVP and cyclists on the bike lane have to cross over from the right side to the left side of that car lane.

The latest configuration has three phase traffic lights cycling from bicycle, pedestrian and cars with each having its own green and red lights.

That double-right turn in the OP's photo should have a right turn traffic light triggered by detectors on the bike lane. And move the solid stop line backwards further from the intersection. I've seen this in several cities and it gives pedestrians a head start crossing intersections before cars do.

Last edited by Daniel4; 10-04-22 at 08:56 AM.
Daniel4 is offline
Old 10-04-22, 09:17 AM
  #5
flangehead
Senior Member
Thread Starter

Join Date: Dec 2006
Location: Houston, TX
Posts: 766

Bikes: 2017 Co-op ADV 1.1; ~1991 Novara Arriba; 1990 Fuji Palisade; mid-90's Moots Tandem; 1985 Performance Superbe

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 328 Post(s)
Liked 477 Times in 280 Posts
Originally Posted by Daniel4 View Post
...Then that reminded me of a challenging intersection in Toronto that had several changes in the past year. It was the east bound end of the Bloor Street viaduct where fast moving cars on the right lane go to the north bound ramp of the DVP and cyclists on the bike lane have to cross over from the right side to the left side of that car lane.

The latest configuration has three phase traffic lights cycling from bicycle, pedestrian and cars with each having its own green and red lights....
Is Google Map/Streetview current? Or did I even get the right place?


flangehead is offline
Old 10-04-22, 09:36 AM
  #6
Daniel4
Senior Member

Join Date: Jul 2013
Location: Toronto
Posts: 3,344

Bikes: Sekine 1979 ten speed racer

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 1408 Post(s)
Liked 558 Times in 379 Posts
Originally Posted by flangehead View Post
Is Google Map/Streetview current? Or did I even get the right place?


Yes. That's the right place.
Daniel4 is offline
Old 10-04-22, 02:39 PM
  #7
GAtkins
Full Member

Join Date: Aug 2002
Location: Springdale, Arkansas
Posts: 318

Bikes: 2021 Trek Domane SLR7 Project One 62cm- 2010 Specialized Allez 61cm

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 118 Post(s)
Liked 88 Times in 44 Posts
What does "[Limited Scope]" in the thread title mean?

Glenn
GAtkins is offline
Old 10-04-22, 02:52 PM
  #8
masonv45
Junior Member

Join Date: Nov 2014
Location: Arlington, TN
Posts: 131

Bikes: 2005 Giant OCRc2, 2016 GT Aggressor Expert

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 41 Post(s)
Liked 57 Times in 30 Posts
Maybe a version of this could be executed??

Protected Island with 2 traffic buttons in the middle and on the far side of the road. (Once it's green for the cyclists - the next intersection upstream is green longer the next time ... to allow vehicle traffic to "catch back up".
masonv45 is offline
Old 10-04-22, 05:38 PM
  #9
Daniel4
Senior Member

Join Date: Jul 2013
Location: Toronto
Posts: 3,344

Bikes: Sekine 1979 ten speed racer

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 1408 Post(s)
Liked 558 Times in 379 Posts
Originally Posted by flangehead View Post
Is Google Map/Streetview current? Or did I even get the right place?


Here's a picture I just took today. Each mode has two traffic lights to make sure cars and cyclists have no excuses not to see them. Pedestrians have their regular one signal at the crosswalk right on the on-ramp.
