Need HELP removing rim from fork on BMX bike

Notices
Bicycle Mechanics Broken bottom bracket? Tacoed wheel? If you're having problems with your bicycle, or just need help fixing a flat, drop in here for the latest on bicycle mechanics & bicycle maintenance.

Need HELP removing rim from fork on BMX bike

Old 07-20-16, 07:58 AM
  #1
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Need HELP removing rim from fork on BMX bike

I recently picked up a 1983 GT Pro BMX bike. I am comfortable wrenching on most bikes, but this one has me stumped. As I was taking it apart to clean it up, I tried to remove the front rim with no success. The axle is larger than the fork drop out slots (The axle is round and not slotted). I measured the slots at 8.34 mm and the axle at 9.07 mm. There is also a hex lock spacer between the fork and hub on both sides. A normally easy task has me baffled. If you know how to remove the rim, please let me know and help restore my sanity!

Thanks!


Gthoro is offline
Old 07-20-16, 08:11 AM
  #2
fietsbob
Banned

Join Date: Jun 2010
Location: NW,Oregon Coast
Posts: 43,599

Bikes: 8

Mentioned: 197 Post(s)
Tagged: 0 Thread(s)
Quoted: 7607 Post(s)
Liked 1,333 Times in 841 Posts
It got in there some how. obviously . both Axle nuts loose on both sides?

axle flattened on the sides like 3 speed rear hubs are?
fietsbob is offline
Old 07-20-16, 08:18 AM
  #3
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Nuts are completely loosened and the axle is not flattened. Do I just try and strong arm it off? I don't want to damage it.
Gthoro is offline
Old 07-20-16, 08:31 AM
  #4
fietsbob
Banned

Join Date: Jun 2010
Location: NW,Oregon Coast
Posts: 43,599

Bikes: 8

Mentioned: 197 Post(s)
Tagged: 0 Thread(s)
Quoted: 7607 Post(s)
Liked 1,333 Times in 841 Posts
make the slot wider? with a Dremel grinder? (take it to a Bike shop now?)

I See Set Screws in the Hub the axle may slip out of the hub sideways ..

Some Past Owner foolishness in that rather cheap Bike there.

Last edited by fietsbob; 07-20-16 at 09:47 AM.
fietsbob is offline
Old 07-20-16, 09:07 AM
  #5
RubeRad
Keepin it Wheel

RubeRad's Avatar

Join Date: Aug 2011
Location: San Diego
Posts: 9,857

Bikes: Surly CrossCheck, Krampus

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked 2,231 Times in 1,616 Posts
yeah, what's that set screw? take that out, see what happens
RubeRad is offline
Old 07-20-16, 09:09 AM
  #6
dsbrantjr
Senior Member

dsbrantjr's Avatar

Join Date: Sep 2010
Location: Roswell, GA
Posts: 8,253

Bikes: '93 Trek 750, '92 Schwinn Crisscross, '93 Mongoose Alta

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1414 Post(s)
Liked 1,005 Times in 680 Posts
Originally Posted by RubeRad View Post
yeah, what's that set screw? take that out, see what happens
Yes, when in doubt remove any fasteners you can find and see what comes loose.
dsbrantjr is offline
Old 07-20-16, 09:16 AM
  #7
pwyg
Senior Member

Join Date: May 2013
Posts: 55
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 19 Post(s)
Likes: 0
Liked 6 Times in 5 Posts
The slot may have been pinched together somehow so grinding or pulling the slot open is ok. You are however missing the stepped washer that should go with that drop out the step should drop in to axle opening to center axle in opening so axle does not move in the larger diameter opening.
pwyg is offline
Old 07-20-16, 10:05 AM
  #8
cny-bikeman
Mechanic/Tourist

Join Date: Apr 2007
Location: Syracuse, NY
Posts: 7,510

Bikes: 2008 Novara Randonee - love it. Previous bikes:Motobecane Mirage, 1972 Moto Grand Jubilee (my fave), Jackson Rake 16, 1983 C'dale ST500.

Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 482 Post(s)
Likes: 0
Liked 9 Times in 9 Posts
Loosening the set screw and axle nut on the same side may allow the axle to slide out as the hub appears to have cartridge bearings (I believe I see the edge of a black seal for the bearings).
cny-bikeman is offline
Old 07-20-16, 10:05 AM
  #9
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Hex set screws are loose on both sides. I'm not able to get any sideways movement with the axle. So it looks like it comes down to grinding or spreading. Grinding seems safer. Thoughts?
Gthoro is offline
Old 07-20-16, 10:16 AM
  #10
fietsbob
Banned

Join Date: Jun 2010
Location: NW,Oregon Coast
Posts: 43,599

Bikes: 8

Mentioned: 197 Post(s)
Tagged: 0 Thread(s)
Quoted: 7607 Post(s)
Liked 1,333 Times in 841 Posts
You competent? have used the tools needed before ?
fietsbob is offline
Old 07-20-16, 10:22 AM
  #11
RubeRad
Keepin it Wheel

RubeRad's Avatar

Join Date: Aug 2011
Location: San Diego
Posts: 9,857

Bikes: Surly CrossCheck, Krampus

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked 2,231 Times in 1,616 Posts
with the set screws loose, can those collars unscrew? Does the whole threaded axle unscrew out the middle? (If the whole axle is threaded, where are the cones for the bearings?)
RubeRad is offline
Old 07-20-16, 10:27 AM
  #12
Gthoro
Senior Member
Thread Starter

Gthoro's Avatar

Join Date: Apr 2007
Location: SW Wisconsin
Posts: 107
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Update: before I started grinding, I decided to give the axle ends a few taps with a hammer - success! Rim is off! Now what should I do to the dropout/axle before I reinstall. Thanks for the helpful feedback thus far!
Gthoro is offline
Old 07-20-16, 10:34 AM
  #13
RubeRad
Keepin it Wheel

RubeRad's Avatar

Join Date: Aug 2011
Location: San Diego
Posts: 9,857

Bikes: Surly CrossCheck, Krampus

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked 2,231 Times in 1,616 Posts
So the axle slid through the dropouts anyways? Cool.

What should you do? How should we know? Why did you want to take it off?
RubeRad is offline
Old 07-20-16, 11:08 AM
  #14
cny-bikeman
Mechanic/Tourist

Join Date: Apr 2007
Location: Syracuse, NY
Posts: 7,510

Bikes: 2008 Novara Randonee - love it. Previous bikes:Motobecane Mirage, 1972 Moto Grand Jubilee (my fave), Jackson Rake 16, 1983 C'dale ST500.

Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 482 Post(s)
Likes: 0
Liked 9 Times in 9 Posts
Originally Posted by Gthoro View Post
Update: before I started grinding, I decided to give the axle ends a few taps with a hammer - success! Rim is off! Now what should I do to the dropout/axle before I reinstall. Thanks for the helpful feedback thus far!
Should not have to do anything to the dropouts/axle.

Rotate the bearings to make sure they are still smooth, might want to carefully pop off the black seals to check/add grease (use a very pointed probe to pry them off). If the bearings are rough they can be carefully driven out of the hub and replaced (size/spec printed on bearing).

To reassemble just insert the axle through the collars, center the axles, snug both collars against the bearing, and then tighten the set screws and then the axle nuts.
