Noise coming from cranks(?) when standing

Bicycle Mechanics Broken bottom bracket? Tacoed wheel? If you're having problems with your bicycle, or just need help fixing a flat, drop in here for the latest on bicycle mechanics & bicycle maintenance.

Noise coming from cranks(?) when standing

Old 05-29-19, 09:10 AM
  #1
NoWhammies
Senior Member
Thread Starter

NoWhammies's Avatar

Join Date: Jul 2017
Location: Vancouver, BC
Posts: 825

Bikes: Argon 18 Gallium, BH G7

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 341 Post(s)
Liked 31 Times in 25 Posts
Noise coming from cranks(?) when standing

Out for a ride with Mrs. NoWhammies last night. When she stood up in the saddle and pedaled I could hear some noising coming from her bike. I cannot describe the noise, as I was a bit away from her, but there is definitely something going on.

After the ride I asked her about it and her reply was "yes, there is noise from the cranks when I stand up and pedal".

Anyone have any tips on where I can start to diagnose the problem? I'll take the bike out for a test drive when I get home from work and see if I can find out some more info/noise.

Cheers.
NoWhammies is offline
Old 05-29-19, 09:12 AM
  #2
wgscott
Occam's Rotor

wgscott's Avatar

Join Date: Jul 2013
Location: The Timbers of Fennario (CL77)
Posts: 4,885

Bikes: Steel

Mentioned: 61 Post(s)
Tagged: 0 Thread(s)
Quoted: 2366 Post(s)
Liked 211 Times in 130 Posts
Start here:

https://sheldonbrown.com/creaks.html

I've developed a slight clunk that goes away when I stand up.
wgscott is offline
Old 05-29-19, 11:01 AM
  #3
dbf909
Senior Member

Join Date: Dec 2016
Location: South Florida
Posts: 79

Bikes: '79 Schwinn LeTour IV, '11 Giant Roam1, '17 Specialized Pitch Comp, '18 Marin Hawk Hill 1, '15 Giant Defy1, '17 Jamis Earth Cruiser1 (x2)

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 8 Times in 5 Posts
My MTB developed a creaky sound when pedaling hard (standing up mostly) but only on the left downstroke. After some investigation and troubleshooting, it turned out to be the chainring mounting bolts holding the ring to the crank spider. I removed them, cleaned the threads, applied blue locktite, and re-torqued to spec. Now its all quiet...
dbf909 is offline
Likes For dbf909:
Old 05-29-19, 11:03 AM
  #4
Weresquatch
Senior Member

Join Date: May 2019
Location: Pacific NW (of the US)
Posts: 73

Bikes: Just the normal stuff, cruisers, duilies, fatbike, road bikes, single speeds...

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 16 Post(s)
Liked 10 Times in 9 Posts
Originally Posted by NoWhammies View Post
Out for a ride with Mrs. NoWhammies last night. When she stood up in the saddle and pedaled I could hear some noising coming from her bike. I cannot describe the noise, as I was a bit away from her, but there is definitely something going on.

After the ride I asked her about it and her reply was "yes, there is noise from the cranks when I stand up and pedal".

Anyone have any tips on where I can start to diagnose the problem? I'll take the bike out for a test drive when I get home from work and see if I can find out some more info/noise.

Cheers.
Most likely BB or pedals. I know it sounds weird, but with the bike elevated, turn the cranks slowly while putting the horn of your saddle (gently) in your ear. While you turn the cranks, listen for the BB making grindy noises (I have an old stethoscope I use personally but this old method works ok). Check the bearings in your pedals then lastly, cranks (if those are too loose it will become very obvious shortly). What kind of BB interface does the bike have?
Weresquatch is offline
Old 05-29-19, 11:07 AM
  #5
tyrion
Senior Member

tyrion's Avatar

Join Date: Oct 2015
Location: San Diego, California
Posts: 2,299

Bikes: Breezer Radar

Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 1212 Post(s)
Liked 76 Times in 51 Posts
Originally Posted by dbf909 View Post
My MTB developed a creaky sound when pedaling hard (standing up mostly) but only on the left downstroke. After some investigation and troubleshooting, it turned out to be the chainring mounting bolts holding the ring to the crank spider. I removed them, cleaned the threads, applied blue locktite, and re-torqued to spec. Now its all quiet...
+1, but before doing this I'd clean/lube/retorque the pedals to see if that fixes it.
tyrion is offline
Old 05-29-19, 01:20 PM
  #6
Happy Feet
Senior Member

Happy Feet's Avatar

Join Date: Sep 2015
Posts: 3,197
Mentioned: 19 Post(s)
Tagged: 0 Thread(s)
Quoted: 1211 Post(s)
Liked 107 Times in 64 Posts
If it were a creaking old leather sound it may be the crank arms on the axle spindles.
With no grease it can be metal on metal that creaks when torqued, especially if the retaining bolt is a little loose, which you won't get just spinning the crank on a stand.

If so, pull the arms, add a little grease to the axle and re seat.
Happy Feet is offline
Old 05-29-19, 02:28 PM
  #7
NoWhammies
Senior Member
Thread Starter

NoWhammies's Avatar

Join Date: Jul 2017
Location: Vancouver, BC
Posts: 825

Bikes: Argon 18 Gallium, BH G7

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 341 Post(s)
Liked 31 Times in 25 Posts
Originally Posted by wgscott View Post
Start here:

https://sheldonbrown.com/creaks.html

I've developed a slight clunk that goes away when I stand up.
Thanks. I'll check that out.

Originally Posted by dbf909 View Post
My MTB developed a creaky sound when pedaling hard (standing up mostly) but only on the left downstroke. After some investigation and troubleshooting, it turned out to be the chainring mounting bolts holding the ring to the crank spider. I removed them, cleaned the threads, applied blue locktite, and re-torqued to spec. Now its all quiet...
I'll have a closer look at the mounting bolts when I get home. Mrs. NoWhammies doesn't do a lot of riding, so I'm surprised that noise is starting all of a sudden. Were the bolts loose at all? Or did you just remove and clean them as a matter of course.

Originally Posted by tyrion View Post
+1, but before doing this I'd clean/lube/retorque the pedals to see if that fixes it.
The pedals on her bike are speedplay pedals. They haven't been messed, but I guess they can loosen up/get dirty over time. Is it possible that dirty/old grease is the cause of the noise?

Originally Posted by Happy Feet View Post
If it were a creaking old leather sound it may be the crank arms on the axle spindles.
With no grease it can be metal on metal that creaks when torqued, especially if the retaining bolt is a little loose, which you won't get just spinning the crank on a stand.

If so, pull the arms, add a little grease to the axle and re seat.
Never done this ^^ before. I hope this work isn't required. I'm worried it may be out of my area of expertise.
NoWhammies is offline
Old 05-29-19, 04:10 PM
  #8
Happy Feet
Senior Member

Happy Feet's Avatar

Join Date: Sep 2015
Posts: 3,197
Mentioned: 19 Post(s)
Tagged: 0 Thread(s)
Quoted: 1211 Post(s)
Liked 107 Times in 64 Posts
Originally Posted by NoWhammies View Post

Never done this ^^ before. I hope this work isn't required. I'm worried it may be out of my area of expertise.
For a quick and dirty test, the next time you are riding with Mrs Whammies take a small can of WD40 and the little red nozzle tube with you. If the creak develops, carefully squirt a little into the crankarm/spindle interface (from the bottom bracket outward). If the noise goes away you know it's that.

Pulling a crank arm is easy if you have this tool: https://www.amazon.com/Park-Tool-Cra.../dp/B07C44CX35
Happy Feet is offline
Old 05-29-19, 04:21 PM
  #9
wgscott
Occam's Rotor

wgscott's Avatar

Join Date: Jul 2013
Location: The Timbers of Fennario (CL77)
Posts: 4,885

Bikes: Steel

Mentioned: 61 Post(s)
Tagged: 0 Thread(s)
Quoted: 2366 Post(s)
Liked 211 Times in 130 Posts
Originally Posted by NoWhammies View Post
I'll have a closer look at the mounting bolts when I get home. Mrs. NoWhammies doesn't do a lot of riding, so I'm surprised that noise is starting all of a sudden. Were the bolts loose at all? Or did you just remove and clean them as a matter of course.
I had this happen on another bike. I tightened them up to the torque spec, and the noise did not go away. In frustration, I eventually took it to the bike shop, who fixed it immediately, and pointed out it was indeed the mounting bolts. I said I tightened them. They asked "well, did you loosen them up first?"

I learned something.
wgscott is offline
Old 05-30-19, 11:49 AM
  #10
dbf909
Senior Member

Join Date: Dec 2016
Location: South Florida
Posts: 79

Bikes: '79 Schwinn LeTour IV, '11 Giant Roam1, '17 Specialized Pitch Comp, '18 Marin Hawk Hill 1, '15 Giant Defy1, '17 Jamis Earth Cruiser1 (x2)

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 8 Times in 5 Posts
Originally Posted by tyrion View Post
+1, but before doing this I'd clean/lube/retorque the pedals to see if that fixes it.
Definitely...

In fact my investigation and troubleshooting prior to resolving the problem with the chain ring bolts included (but not limited to and not in this order):

- removed, lubed, and replaced the rear thru-axle.
- removed the rear der. hanger, cleaned, lubed, and replaced.
- removed both pedals, cleaned threads, lubed, and replaced.
- replaced both pedals with brand new (tried 2 different new sets).
- added thin shim washers on pedal bolts.
- removed chain, cleaned, lubed, replaced.
- removed cassette, cleaned, lubed, replaced.
- removed crankset, cleaned, lubed, replaced.
- removed bottom bracket, cleaned, lubed, replaced.
- used teflon tape on bottom bracket threads.
- checked all suspension nuts and bolts for proper torque.
- inspected and tightened all saddle and seatpost fasteners.
- checked the entire bike for any other loose fasteners.

I immediately went to the pedals but was initially stumped when working with them and actually replacing them with others did not address the creak at all. Only then did I take a few steps back and start working my way through all of the stuff that could possibly cause the creak.
dbf909 is offline
Old 05-30-19, 11:58 AM
  #11
dbf909
Senior Member

Join Date: Dec 2016
Location: South Florida
Posts: 79

Bikes: '79 Schwinn LeTour IV, '11 Giant Roam1, '17 Specialized Pitch Comp, '18 Marin Hawk Hill 1, '15 Giant Defy1, '17 Jamis Earth Cruiser1 (x2)

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 8 Times in 5 Posts
Originally Posted by NoWhammies View Post
I'll have a closer look at the mounting bolts when I get home. Mrs. NoWhammies doesn't do a lot of riding, so I'm surprised that noise is starting all of a sudden. Were the bolts loose at all? Or did you just remove and clean them as a matter of course.
They might have been loose to some degree but required a wrench to remove. I had replaced the 32T stock chain ring with a Blackspire 34T aluminum ring about a year ago. It was quiet up until about a month ago. So either they loosened up some or possibly the mounting holes in the aluminum ring have slightly enlarged creating some slack for movement and creak. Not entirely sure.

I removed them, cleaned them up, and replaced them with locktite. I was initially concerned about the torque since the (rather thin) ring is threaded and the steel bolts screw directly into the ring rather than into steel "T" style nuts on the back side of the ring. I didn't want to strip the threads in the ring. The spec as found online was 12-14nm so I torqued them to 12nm and that seemed to work for now.

Time will tell if the creak comes back...

Last edited by dbf909; 05-30-19 at 12:15 PM.
dbf909 is offline
Old 05-30-19, 10:18 PM
  #12
Jon T
Senior Member

Join Date: Jun 2017
Location: West Orange County, CA
Posts: 994

Bikes: '84 Peugeot PH10LE

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 355 Post(s)
Likes: 0
Liked 17 Times in 12 Posts
Believe it or not, it could be the QR's on the wheels. I have a friend who rides a Cervello and he had a creaky bb. Had it replaced. Still creaky. I told him to remove the QR's, thoroughly saturate them with oil, wipe off the excess and reinstall. The noise went away. I'm just sayin'........
Jon
Jon T is offline
Old 05-30-19, 10:25 PM
  #13
Jeff Wills
Insane Bicycle Mechanic

Jeff Wills's Avatar

Join Date: Mar 2008
Location: other Vancouver
Posts: 8,960
Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 427 Post(s)
Liked 17 Times in 13 Posts
Originally Posted by NoWhammies View Post
The pedals on her bike are speedplay pedals. They haven't been messed, but I guess they can loosen up/get dirty over time. Is it possible that dirty/old grease is the cause of the noise?
I had a creak/click that did not go away despite several sessions of disassembly/greasing/reassembly. It went away when I removed the pedals, cleaned the threads, and reinstalled with new grease.
__________________
Jeff Wills

Comcast nuked my web page. It will return soon..
Jeff Wills is offline
Old 05-30-19, 10:31 PM
  #14
canklecat
Me duelen las nalgas

canklecat's Avatar

Join Date: Aug 2015
Location: Texas
Posts: 9,071

Bikes: Centurion Ironman, Trek 5900, Univega Via Carisma, Globe Carmel

Mentioned: 157 Post(s)
Tagged: 0 Thread(s)
Quoted: 2772 Post(s)
Liked 142 Times in 116 Posts
Creaks are tricky. I've overhauled bikes just chasing down creaks and it usually turned out to be the last thing I tried.
  • One chainring bolt.
  • Handlebar/stem.
  • Spokes (soft wax from an old scented candle between the crossed spokes fixes the problem for a month or so at a time)
  • Saddle (I just ignored it for a couple of years, then replaced the saddle.)
If I checked those first, it'd turn out to be something else.

So far it's never been the bottom bracket, crank arms, pedals, hubs, chain, cassette or freewheel... but eventually it'll probably be one of those. Whatever the cause, it'll be the last thing I check.
canklecat is offline
Old 05-30-19, 10:41 PM
  #15
AnkleWork
Senior Member

Join Date: Jan 2013
Location: Llano Estacado
Posts: 3,305

Bikes: old clunker

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 540 Post(s)
Likes: 0
Liked 25 Times in 15 Posts
Originally Posted by NoWhammies View Post
... I cannot describe the noise...

Anyone have any tips on where I can start to diagnose the problem? ...
Crazy idea: start with a description of the noise. Then, search this forum for suggested solutions -- many hundred have already been posted. Good luck.
AnkleWork is offline
Old 05-30-19, 11:33 PM
  #16
woodcraft
Senior Member

woodcraft's Avatar

Join Date: Apr 2012
Location: Nor Cal
Posts: 4,227
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1021 Post(s)
Likes: 0
Liked 33 Times in 19 Posts
Originally Posted by NoWhammies View Post
Thanks. I'll check that out.



I'll have a closer look at the mounting bolts when I get home. Mrs. NoWhammies doesn't do a lot of riding, so I'm surprised that noise is starting all of a sudden. Were the bolts loose at all? Or did you just remove and clean them as a matter of course.



The pedals on her bike are speedplay pedals. They haven't been messed, but I guess they can loosen up/get dirty over time. Is it possible that dirty/old grease is the cause of the noise?



Never done this ^^ before. I hope this work isn't required. I'm worried it may be out of my area of expertise.



Not so much the pedal itself, as removing the pedals from the crank & cleaning etc. the threads
woodcraft is offline
Old 05-31-19, 06:23 AM
  #17
mitchmellow62
Senior Member

Join Date: Aug 2014
Posts: 91
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 24 Post(s)
Likes: 0
Liked 1 Time in 1 Post
NoWhammies: Is this the bike that you removed and cleaned the cassette on? It could just be coincidence but I'd look at the rear wheel mounting and QR's first, pedals next and bb last.
mitchmellow62 is offline
Old 05-31-19, 06:25 AM
  #18
bakerjw
Senior Member

Join Date: Sep 2008
Location: NE Tennessee
Posts: 784

Bikes: Giant TCR/Surly Karate Monkey/Foundry FireTower/Curtlo Tandem

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 128 Post(s)
Liked 48 Times in 36 Posts
I have a light creak too when I pedal. Press fit BB too which it just a darn PITA.
I'll have to check the pedals and chainring bolts.
Absolute worst case is a frame crack.
bakerjw is offline
Old 05-31-19, 09:54 AM
  #19
NoWhammies
Senior Member
Thread Starter

NoWhammies's Avatar

Join Date: Jul 2017
Location: Vancouver, BC
Posts: 825

Bikes: Argon 18 Gallium, BH G7

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 341 Post(s)
Liked 31 Times in 25 Posts
@Mitchmellows62 yes, this is the same bike. Poor Mrs. NoWhammies. She's a good sport to let me work on her bike. @Jon T suggestion to look at the QR is a good idea too. When I was having issues with the cassette I had the wheel on and off multiple times.


I'll also give removing the pedals a shot first. Clean the threads, at some grease, and see what that takes me. Even if that does not solve the problem it couldn't hurt giving her bike a bit of TLC.
NoWhammies is offline
Old 05-31-19, 11:18 AM
  #20
dbf909
Senior Member

Join Date: Dec 2016
Location: South Florida
Posts: 79

Bikes: '79 Schwinn LeTour IV, '11 Giant Roam1, '17 Specialized Pitch Comp, '18 Marin Hawk Hill 1, '15 Giant Defy1, '17 Jamis Earth Cruiser1 (x2)

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 8 Times in 5 Posts
Originally Posted by canklecat View Post
Creaks are tricky. I've overhauled bikes just chasing down creaks and it usually turned out to be the last thing I tried.
  • One chainring bolt.
  • Handlebar/stem.
  • Spokes (soft wax from an old scented candle between the crossed spokes fixes the problem for a month or so at a time)
  • Saddle (I just ignored it for a couple of years, then replaced the saddle.)
If I checked those first, it'd turn out to be something else.

So far it's never been the bottom bracket, crank arms, pedals, hubs, chain, cassette or freewheel... but eventually it'll probably be one of those. Whatever the cause, it'll be the last thing I check.
If you think about it, won't it always be the "last thing you check"? Said differently, would you continue to look AFTER you fixed the problem?

I often hear people say things like "Every time I mis-place my car keys, they are always in the last place I look". Of course they are. Why would you keep looking after you found them?

Just saying... Or maybe that was your point... ;-)
dbf909 is offline
Likes For dbf909:
Old 05-31-19, 04:58 PM
  #21
canklecat
Me duelen las nalgas

canklecat's Avatar

Join Date: Aug 2015
Location: Texas
Posts: 9,071

Bikes: Centurion Ironman, Trek 5900, Univega Via Carisma, Globe Carmel

Mentioned: 157 Post(s)
Tagged: 0 Thread(s)
Quoted: 2772 Post(s)
Liked 142 Times in 116 Posts
Originally Posted by dbf909 View Post
If you think about it, won't it always be the "last thing you check"? Said differently, would you continue to look AFTER you fixed the problem?

I often hear people say things like "Every time I mis-place my car keys, they are always in the last place I look". Of course they are. Why would you keep looking after you found them?

Just saying... Or maybe that was your point... ;-)
Holy epiphany! I'll never waste time again trying to track down a creak! I'll go directly to the last thing I think of.

C'mon, kids, let's hop in the Biketardis!

Seriously, tho', I need to wax my spokes again. But it'll turn out to be something else.

canklecat is offline
Old 06-01-19, 09:02 AM
  #22
biker222
Senior Member

Join Date: Oct 2006
Posts: 110
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Likes: 0
Liked 6 Times in 2 Posts
I had a similar issue with creaking only when standing out of saddle.
Tried all the obvious solutions then pulled seat post and added new grease, installed and No Creaking.

The frame flex would interact internally with post and creak.
biker222 is offline
Old 06-01-19, 04:46 PM
  #23
davidad
Senior Member

Join Date: Feb 2009
Posts: 5,812
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 302 Post(s)
Likes: 0
Liked 11 Times in 11 Posts
I had a friend had the problem and it turned out the front QR was not tight enough. The next thing to check is for looseness in the pedal bearings. They will usually click.
davidad is offline
Old 06-03-19, 09:24 AM
  #24
63rickert
Senior Member

Join Date: Dec 2013
Posts: 1,066
Mentioned: 36 Post(s)
Tagged: 0 Thread(s)
Quoted: 484 Post(s)
Likes: 0
Liked 19 Times in 16 Posts
So what are the cranks? I will guess if using Speedplay pedals they are not cottered steel. If new fashion press fit crank bearings the creaks could be normal OEM creaks. Many assumptions above the cranks are aluminum mounted on a square tapered spindle but we don't know that.

If it is a square taper spindle those are assembled dry and never lubricated. Not even superficially with WD-40 (mineral oil). And the reason those sometimes get quite loose is they don't make noises until plain flopping about.
63rickert is offline
Old 06-03-19, 11:41 AM
  #25
NoWhammies
Senior Member
Thread Starter

NoWhammies's Avatar

Join Date: Jul 2017
Location: Vancouver, BC
Posts: 825

Bikes: Argon 18 Gallium, BH G7

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 341 Post(s)
Liked 31 Times in 25 Posts
Going to tackle Mrs. NoWhammies bike tonight. I'll let you know how it goes. Great suggestions everyone. Thanks.
NoWhammies is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service

Copyright 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
