Tips For FD Cable Tension Adjustment When No Barrel Adjuster

Greetings, Geniuses--

My FD cable just snapped at the bolt, for some reason. Internally routed and never replaced those before myself, but I am going to try to figure out how to replace it anyway, given all the LBS folks are inaccessible. Anyhow, for some odd reason, BMC did not put a front der barrel adjuster on this bike. Looking for any tricks any of you sage humans have about how to adjust that cable tension, other than just repeatedly unclamping/clamping at the bolt. This does not seem like a very scientific or clever way to go about it, but what do I know... Many thanks!!!
bpcyclist is offline
Old 03-26-20, 09:22 AM
  #2
DaveSSS
Senior Member

Join Date: Sep 2008
Location: Loveland, CO
Posts: 5,671

Bikes: TWO Colnago C-RS w/Chorus 12

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 330 Post(s)
Liked 108 Times in 85 Posts
One solution is to install an inline cable tension adjuster. Another solution is to deliberately turn the low limit screw in by a half turn or more, then pull the cable tight, tighten the clamp bolt, then return the limit screw to its proper position. This increases the cable tension. It may take multiple attempts to get the correct tension.
DaveSSS is offline
Likes For DaveSSS:
Old 03-26-20, 09:49 AM
  #3
biker222
Senior Member

Join Date: Oct 2006
Posts: 121
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 33 Post(s)
Liked 7 Times in 3 Posts
The link below is what I used to adjust FD for a Ultegra 6800 FD:

biker222 is offline
Likes For biker222:
Old 03-26-20, 10:02 AM
  #4
base2
Senior Member

base2's Avatar

Join Date: Jun 2015
Location: Pacific Northwest
Posts: 1,175

Bikes: N+1

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 619 Post(s)
Liked 150 Times in 103 Posts
I find that about a full turn to a turn on the low limit screw is right. I also use pliers or wrap the extra cable around my hand to pull & hold tension on the cable while tightening the fixing bolt. With Ultegra 6800, at least, It seems to come out right. I shoot for just missing contact with the chain when the chain is in in small ring/big cog combination. Things will invariably settle with time under system tension. So if it is lightly touching the chain on small/big but not small/second big, that's ok. Give it a day or 2.

Don't forget to completly relax your shifter. It's super lame to think you're all good to go, only to realize you did everything in the "trim" position.
__________________
My lights are obscenly bright because drivers are dim.

I shouldn't have to "make myself more visible;" Drivers should just stop running people over.
base2 is online now
Likes For base2:
Old 03-26-20, 10:24 AM
  #5
HillRider
Senior Member

Join Date: Aug 2005
Location: Pittsburgh, PA
Posts: 31,902

Bikes: '''96 Litespeed Catalyst, '05 Litespeed Firenze, '06 Litespeed Tuscany, '12 Surly Pacer, All are 3x8,9 or 10. It is hilly around here!

Mentioned: 34 Post(s)
Tagged: 0 Thread(s)
Quoted: 1313 Post(s)
Likes: 0
Liked 143 Times in 117 Posts
Originally Posted by DaveSSS View Post
One solution is to install an inline cable tension adjuster.
This is the real answer. Otherwise you are going to have to do a series of trial-and-error adjustments and probably wind up settling for "close enough". The in-line adjuster makes accurate initial setting and later adjustments for minor cable "stretch" easy.
HillRider is offline
Likes For HillRider:
Old 03-26-20, 11:35 AM
  #6
dsbrantjr
Senior Member

dsbrantjr's Avatar

Join Date: Sep 2010
Location: Roswell, GA
Posts: 6,828

Bikes: '93 Trek 750, '92 Schwinn Crisscross, '93 Mongoose Alta

Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 901 Post(s)
Liked 230 Times in 183 Posts
Originally Posted by HillRider View Post
This is the real answer. Otherwise you are going to have to do a series of trial-and-error adjustments and probably wind up settling for "close enough". The in-line adjuster makes accurate initial setting and later adjustments for minor cable "stretch" easy.
The adjuster also helps avoid chewing up the wire by clamping it repeatedly.
dsbrantjr is offline
Likes For dsbrantjr:
Old 03-27-20, 01:53 AM
  #7
tFUnK
Senior Member

Join Date: Jun 2002
Location: San Jose, CA
Posts: 2,502

Bikes: GT Forte Ti, GT GTR Carbon Sport, BMC RaceMachine, Guru Photon, Bianchi San Jose, Trek Portland, Xootr Swift

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 49 Post(s)
Liked 13 Times in 11 Posts
Inline adjuster as mentioned is the way to go but I've also had success with using pliers to pull the cable tight before tightening the fixing bolt.
tFUnK is offline
Likes For tFUnK:
Old 03-27-20, 07:20 AM
  #8
nomadmax
Senior Member

Join Date: Jun 2018
Location: SW Ohio
Posts: 1,293
Mentioned: 88 Post(s)
Tagged: 0 Thread(s)
Quoted: 566 Post(s)
Liked 514 Times in 271 Posts
Originally Posted by biker222 View Post
The link below is what I used to adjust FD for a Ultegra 6800 FD:

https://www.youtube.com/watch?v=-5jnNScKhRs
That's a good way ^. On bikes that don't have a cable tension adjustment for the FD I screw in the low limit until it touches the chain when it's on the innermost cog in back. Then I pull the cable tight, lock it down and back the low limit screw out until I have proper clearance between the inner FD cage and the chain (when on the inner most cog and small chain ring).

Some shifting set ups don't have the ability to include a tension adjustment.

Last edited by nomadmax; 03-27-20 at 07:24 AM.
nomadmax is offline
Likes For nomadmax:
Old 03-27-20, 11:12 AM
  #9
bpcyclist
Senior Member
Thread Starter

Join Date: Sep 2019
Location: Portland
Posts: 1,092
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 421 Post(s)
Liked 328 Times in 206 Posts
Great stuff, guys. I'm on it Thanks a million!!
bpcyclist is offline
Old 03-27-20, 01:30 PM
  #10
LV2TNDM
Senior Member

Join Date: Apr 2005
Location: Northern CA
Posts: 353

Bikes: Cannondale tandems: '92 Road, '97 Mtn. Mongoose 10.9 Ti, Kelly Deluxe, Tommaso Chorus, Cdale MT2000, Schwinn Deluxe Cruiser, Torker Unicycle, among others.

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 69 Post(s)
Liked 13 Times in 12 Posts
Originally Posted by nomadmax View Post
That's a good way ^. On bikes that don't have a cable tension adjustment for the FD I screw in the low limit until it touches the chain when it's on the innermost cog in back. Then I pull the cable tight, lock it down and back the low limit screw out until I have proper clearance between the inner FD cage and the chain (when on the inner most cog and small chain ring).

Some shifting set ups don't have the ability to include a tension adjustment.
