Maintenance for Sealed Bottom Bracket? Also, 7-Speed Cassette?

Notices
Bicycle Mechanics Broken bottom bracket? Tacoed wheel? If you're having problems with your bicycle, or just need help fixing a flat, drop in here for the latest on bicycle mechanics & bicycle maintenance.

Maintenance for Sealed Bottom Bracket? Also, 7-Speed Cassette?

Old 04-28-20, 02:12 PM
  #1
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Maintenance for Sealed Bottom Bracket? Also, 7-Speed Cassette?

OK, amateur here trying to research some basic vintage bike mechanics (slow work day). Looked up the catalog entry for my '89 Trek online and it says it has a "sealed" BB. Does this mean the BB doesn't need cleaning and repacking?
Question two, I assumed given the age this bike had a freewheel, but catalog says 7-speed cassette. I assume they're not just using the two terms interchangeably here, that it actually is a cassette?
Thanks everyone as usual.
Miradaman is offline
Old 04-28-20, 02:53 PM
  #2
dsbrantjr
Senior Member

dsbrantjr's Avatar

Join Date: Sep 2010
Location: Roswell, GA
Posts: 7,553

Bikes: '93 Trek 750, '92 Schwinn Crisscross, '93 Mongoose Alta

Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 1153 Post(s)
Liked 540 Times in 391 Posts
Sealed BBs do not require service, just replacement when worn out. Some folks try to open them up and grease them but I don't.
Cassette or freewheel? https://www.sheldonbrown.com/free-k7.html
dsbrantjr is offline
Old 04-28-20, 03:01 PM
  #3
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Originally Posted by dsbrantjr View Post
Sealed BBs do not require service, just replacement when worn out. Some folks try to open them up and grease them but I don't.
Cassette or freewheel? https://www.sheldonbrown.com/free-k7.html
Thanks. So, to quote the article, "Most decent-quality bikes made since the late 1980s have used this greatly improved design", i.e., cassette, then it's safe to assume Trek actually meant "cassette" in the catalog, not freewheel? They're not just using it as a generic term?

Yes, I could probably answer this myself by just taking it apart and looking, but haven't had the time...
Miradaman is offline
Old 04-28-20, 03:10 PM
  #4
dsbrantjr
Senior Member

dsbrantjr's Avatar

Join Date: Sep 2010
Location: Roswell, GA
Posts: 7,553

Bikes: '93 Trek 750, '92 Schwinn Crisscross, '93 Mongoose Alta

Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 1153 Post(s)
Liked 540 Times in 391 Posts
If you would take the time to read the article I linked to you will see this phrase and a picture: "Shimano Cassette Freehub, showing characteristic bulge on the right side of the body." No need to take anything apart, just look.
dsbrantjr is offline
Old 04-28-20, 03:13 PM
  #5
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Originally Posted by dsbrantjr View Post
If you would take the time to read the article I linked to you will see this phrase and a picture: "Shimano Cassette Freehub, showing characteristic bulge on the right side of the body." No need to take anything apart, just look.
I did read it. Hence the quote in my previous post. And the article said some, not all, have the bulge...
Miradaman is offline
Old 04-28-20, 03:39 PM
  #6
Bill Kapaun
Really Old Senior Member

Bill Kapaun's Avatar

Join Date: Feb 2007
Location: Mid Willamette Valley, Orygun
Posts: 11,930

Bikes: 87 RockHopper,2008 Specialized Globe. Both upgraded to 9 speeds.

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1089 Post(s)
Liked 279 Times in 218 Posts
https://www.sheldonbrown.com/free-k7.html
Bill Kapaun is online now
Old 04-28-20, 04:22 PM
  #7
Iride01
Senior Member

Iride01's Avatar

Join Date: Jul 2017
Location: Mississippi
Posts: 4,301

Bikes: '20 Tarmac Disc Comp '91 Schwinn Paramount '78 Raleigh Competition GS

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 1616 Post(s)
Liked 512 Times in 392 Posts
There are some 7 speed cassettes. Someone a few days ago had an issue posted here. I thought he was mistaken when he referred to his as a cassette, but he was correct. However back then, I think that there were some marketing catalogs and other literature that used the terms loosely since cassettes and free hubs were the new thing to have, and they wanted their freewheels to sound more modern than they were.

There was also, a free wheel that did have a cassette that was more easily changed than what the typical freewheels were.
Iride01 is online now
Likes For Iride01:
Old 04-28-20, 04:43 PM
  #8
alcjphil
Senior Member

alcjphil's Avatar

Join Date: Jun 2002
Location: Montreal, Quebec
Posts: 3,940
Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 973 Post(s)
Liked 319 Times in 211 Posts
"Sealed" can mean several things when it comes to bottom brackets. I have seen regular cup and cone bottom brackets that had seals in the cups that would keep dirt out of the inner workings. Similarly, the Campagnolo Record bottom bracket from my 1973 Raleigh Professional had reverse spiral "seals" that would actually throw road dirt and grit out as I pedalled. I could leave the bottom bracket for extended periods and the grease in the cups would stay very clean for a long time. Sealed cartridge bottom brackets are another thing entirely. They are very durable, not serviceable, and require no maintenance until they wear out. I no longer own my Professional, but the semi sealed bottom bracket from that bike is still as smooth and friction free as it was in 1973
alcjphil is online now
Likes For alcjphil:
Old 04-28-20, 04:55 PM
  #9
masi61
Senior Member

masi61's Avatar

Join Date: Oct 2005
Location: SW Ohio
Posts: 2,631

Bikes: Puch Marco Polo, Saint Tropez, Masi Gran Criterium

Mentioned: 21 Post(s)
Tagged: 0 Thread(s)
Quoted: 618 Post(s)
Liked 90 Times in 67 Posts
Originally Posted by Miradaman View Post
OK, amateur here trying to research some basic vintage bike mechanics (slow work day). Looked up the catalog entry for my '89 Trek online and it says it has a "sealed" BB. Does this mean the BB doesn't need cleaning and repacking?
Question two, I assumed given the age this bike had a freewheel, but catalog says 7-speed cassette. I assume they're not just using the two terms interchangeably here, that it actually is a cassette?
Thanks everyone as usual.
Even though the BB is sealed, if you are wanting to service your bike and fully check out it's operation - I would suggest removing your cranks to clean them more thoroughly, then use the correct tools to remove the sealed bottom bracket. Once out of the bike you can check the bearings, check the condition of the bottom bracket threads, clean things, re-grease the threads and reassemble everything properly. This will give you confidence in your bottom bracket.
masi61 is offline
Likes For masi61:
Old 04-28-20, 05:30 PM
  #10
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 6,808

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400

Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 1300 Post(s)
Liked 706 Times in 486 Posts
As said "sealed " means different things. From my experience with that era Trek I'd be surprised if it had a sealed cartridge BB. Likely just means seals on a cup & cone BB.
My 84 Raleigh Gran Prix is "sealed" - Standard cup & cone with rubber seals where the spindle comes through the cups.
If it's cup & cone service it, if it's really a cartridge run it until it dies.

Got a picture?
dedhed is offline
Old 04-28-20, 06:18 PM
  #11
Miele Man
Senior Member

Join Date: Jun 2014
Location: Ontario, Canada
Posts: 4,191

Bikes: iele Latina, Miele Suprema, Miele Uno LS, Miele Miele Beta, MMTB, Bianchi Model Unknown, Fiori Venezia, Fiori Napoli, VeloSport Adamas AX

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1127 Post(s)
Liked 677 Times in 479 Posts
Would you post an image of the non drive side of your bottom bracket? That way we can tell if it's a sealed cup and cone unit or a sealed cartridge unit.

Yes, there were 7-speed cassettes. Most of the ones I'm familiar with were Shimano Uniglide ones where the smallest cog screwed onto the freehub body. I know some 7-speed cassettes were of the newer Hyperglide type where the cogs were held on by a threaded lockring that screwed to the inside of the freehub body. I have one freehub body here that was a hybrid design with both external threads for a Uniglide samll cog and internal threads for a Hypeglide lockring.

Cheers
Miele Man is offline
Old 04-29-20, 08:24 AM
  #12
dsbrantjr
Senior Member

dsbrantjr's Avatar

Join Date: Sep 2010
Location: Roswell, GA
Posts: 7,553

Bikes: '93 Trek 750, '92 Schwinn Crisscross, '93 Mongoose Alta

Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 1153 Post(s)
Liked 540 Times in 391 Posts
Originally Posted by Miele Man View Post
Would you post an image of the non drive side of your bottom bracket? That way we can tell if it's a sealed cup and cone unit or a sealed cartridge unit.

Yes, there were 7-speed cassettes. Most of the ones I'm familiar with were Shimano Uniglide ones where the smallest cog screwed onto the freehub body. I know some 7-speed cassettes were of the newer Hyperglide type where the cogs were held on by a threaded lockring that screwed to the inside of the freehub body. I have one freehub body here that was a hybrid design with both external threads for a Uniglide samll cog and internal threads for a Hypeglide lockring.

Cheers
Were? I run 7-speed Hyperglide cassettes on all 3 of my current bikes. I have NOS spares stashed away, too.
dsbrantjr is offline
Old 04-29-20, 10:39 AM
  #13
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Originally Posted by dsbrantjr View Post
If you would take the time to read the article I linked to you will see this phrase and a picture: "Shimano Cassette Freehub, showing characteristic bulge on the right side of the body." No need to take anything apart, just look.
Yep, it has the bulge, so it is a 7-speed cassette. Puts a new wrinkle in my current quest for a budget wheel upgrade...
Miradaman is offline
Old 04-29-20, 10:42 AM
  #14
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Originally Posted by Miele Man View Post
Would you post an image of the non drive side of your bottom bracket? That way we can tell if it's a sealed cup and cone unit or a sealed cartridge unit.

Yes, there were 7-speed cassettes. Most of the ones I'm familiar with were Shimano Uniglide ones where the smallest cog screwed onto the freehub body. I know some 7-speed cassettes were of the newer Hyperglide type where the cogs were held on by a threaded lockring that screwed to the inside of the freehub body. I have one freehub body here that was a hybrid design with both external threads for a Uniglide samll cog and internal threads for a Hypeglide lockring.

Cheers
I'll try to remember to post a picture tonight when I get home. Now, would I need to remove the crank arm on that side before I take the picture? Or would you guys be able to tell with it on?
Miradaman is offline
Old 04-29-20, 10:47 AM
  #15
Retro Grouch
Senior Member

Retro Grouch's Avatar

Join Date: Feb 2004
Location: St Peters, Missouri
Posts: 29,929

Bikes: Catrike 559 I own some others but they don't get ridden very much.

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 1445 Post(s)
Liked 355 Times in 218 Posts
Originally Posted by Miradaman View Post
it's safe to assume Trek actually meant "cassette" in the catalog, not freewheel? They're not just using it as a generic term?.
Why are you asking?

I presume it's for the purpose of buying replacement parts. If that's the case, that's definitely not a safe assumption.
__________________
My greatest fear is all of my kids standing around my coffin and talking about "how sensible" dad was.
Retro Grouch is offline
Old 04-29-20, 11:12 AM
  #16
Miele Man
Senior Member

Join Date: Jun 2014
Location: Ontario, Canada
Posts: 4,191

Bikes: iele Latina, Miele Suprema, Miele Uno LS, Miele Miele Beta, MMTB, Bianchi Model Unknown, Fiori Venezia, Fiori Napoli, VeloSport Adamas AX

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1127 Post(s)
Liked 677 Times in 479 Posts
Originally Posted by Miradaman View Post
I'll try to remember to post a picture tonight when I get home. Now, would I need to remove the crank arm on that side before I take the picture? Or would you guys be able to tell with it on?
If it's a cup and cone bottom bracket there will be locking on the non-drive side of the bottom bracket. Thus, you should not have to take off the crankarm to get the image we need. Just tak the image from an angle that shows the shell of the bottom bracket behind the crankarm. An angle like this but from the non-drive side should work.


Cheers
Miele Man is offline
Likes For Miele Man:
Old 04-29-20, 11:41 AM
  #17
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Originally Posted by Retro Grouch View Post
Why are you asking?

I presume it's for the purpose of buying replacement parts. If that's the case, that's definitely not a safe assumption.
Yeah, I was kicking around the idea of replacing the wheels. They're mismatched and a bit scuffed up.
Miradaman is offline
Old 04-29-20, 06:07 PM
  #18
ramzilla
Senior Member

ramzilla's Avatar

Join Date: Dec 2014
Location: Fernandina Beach FL
Posts: 3,299

Bikes: Vintage Japanese Bicycles, Tange, Ishiwata, Kuwahara

Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 634 Post(s)
Liked 214 Times in 171 Posts
You can re-grease sealed cartridge bearings if you have the right tools & know how. You have to pluck out the plastic seal on the side. Then flush or soak the bearing to dissolve the old grease. Then, inject new lubricant into the bearing with a grease needle. Pop the plastic seal back on. That's it. That's all. Done deal.
ramzilla is offline
Likes For ramzilla:
Old 04-29-20, 06:57 PM
  #19
Miradaman
Senior Member
Thread Starter

Join Date: Nov 2019
Location: Greater Chicago Area
Posts: 124

Bikes: 1987 Schwinn Mirada, 1989 Trek 420, 1995 GT Timberline

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 32 Times in 19 Posts
Originally Posted by Miele Man View Post
Would you post an image of the non drive side of your bottom bracket? That way we can tell if it's a sealed cup and cone unit or a sealed cartridge unit.

Yes, there were 7-speed cassettes. Most of the ones I'm familiar with were Shimano Uniglide ones where the smallest cog screwed onto the freehub body. I know some 7-speed cassettes were of the newer Hyperglide type where the cogs were held on by a threaded lockring that screwed to the inside of the freehub body. I have one freehub body here that was a hybrid design with both external threads for a Uniglide samll cog and internal threads for a Hypeglide lockring.

Cheers
Can you tell anything from this photo? Thanks
Miradaman is offline
Old 04-29-20, 07:27 PM
  #20
ramzilla
Senior Member

ramzilla's Avatar

Join Date: Dec 2014
Location: Fernandina Beach FL
Posts: 3,299

Bikes: Vintage Japanese Bicycles, Tange, Ishiwata, Kuwahara

Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 634 Post(s)
Liked 214 Times in 171 Posts
That's an adjustable cup on the non drive side. There's plain old ball bearings inside. You'll need a crank arm remover tool. Some kind of spanner hook wrench. And, one of those adjustable pin spanner things to get it all apart. (Sorry, I'm going to have to look up the names of all those tools. Maybe somebody else knows proper nomenclature.)

https://www.amazon.com/Park-Tool-SPA.../dp/B001B6PGHY

https://www.rei.com/product/710554/p...spanner-wrench

https://www.wish.com/product/5dc6110..._wcB&share=web

Last edited by ramzilla; 04-29-20 at 08:01 PM. Reason: tool names
ramzilla is offline
Likes For ramzilla:
Old 04-29-20, 08:09 PM
  #21
Miele Man
Senior Member

Join Date: Jun 2014
Location: Ontario, Canada
Posts: 4,191

Bikes: iele Latina, Miele Suprema, Miele Uno LS, Miele Miele Beta, MMTB, Bianchi Model Unknown, Fiori Venezia, Fiori Napoli, VeloSport Adamas AX

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1127 Post(s)
Liked 677 Times in 479 Posts
Originally Posted by Miradaman View Post
Can you tell anything from this photo? Thanks
Great image.

That's a cup and cone bottom bracket not a sealed cartridge one. The seals on yours are most likely just inside each cup and are set into slight recesses. They are not as well sealed as a true sealed unti.

Cheers
Miele Man is offline
Likes For Miele Man:
Old 04-29-20, 08:19 PM
  #22
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 6,808

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400

Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 1300 Post(s)
Liked 706 Times in 486 Posts
Looks like a Hatta "High Cup" cup & cone bottom bracket.
Service it or replace with a sealed cartridge unit
dedhed is offline
Likes For dedhed:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off


Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
