Gravel Bike Conversion - talk me out of it?

Notices
Bicycle Mechanics Broken bottom bracket? Tacoed wheel? If you're having problems with your bicycle, or just need help fixing a flat, drop in here for the latest on bicycle mechanics & bicycle maintenance.

Gravel Bike Conversion - talk me out of it?

Old 09-19-21, 05:32 PM
  #1
Plainsman
Senior Member
Thread Starter

Join Date: Jan 2005
Posts: 1,438
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 144 Post(s)
Liked 28 Times in 20 Posts
Gravel Bike Conversion - talk me out of it?

I have this flat bar hybrid bike with V-brakes and 38c gravel tires. Lots of parts in the bin (bars, stems, etc.). Instead of buying a drop bar gravel bike, Iím thinking about just swapping out the bars and picking up some used 9 speed shift levers. Horrible idea?
Plainsman is offline
Old 09-19-21, 05:45 PM
  #2
shelbyfv
Senior Member

shelbyfv's Avatar

Join Date: Jun 2007
Location: TN
Posts: 10,039
Mentioned: 32 Post(s)
Tagged: 0 Thread(s)
Quoted: 2970 Post(s)
Liked 3,754 Times in 1,931 Posts
Why not ride gravel on your flat bar bike? No law against it. Think about your reach to the bars. If the bike fits you now with flat bars, it won't fit with the additional reach of drop bars. That's not to say you can't pursue kludges like skyscraper stem stacks, extensions, other foolishness. If you want a clown bike....
shelbyfv is offline
Likes For shelbyfv:
Old 09-19-21, 05:48 PM
  #3
Hondo6
Senior Member

Join Date: Sep 2021
Location: SW Florida
Posts: 136

Bikes: Yes

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 48 Post(s)
Likes: 0
Liked 45 Times in 30 Posts
Originally Posted by Plainsman View Post
I have this flat bar hybrid bike with V-brakes and 38c gravel tires. Lots of parts in the bin (bars, stems, etc.). Instead of buying a drop bar gravel bike, I’m thinking about just swapping out the bars and picking up some used 9 speed shift levers. Horrible idea?
I ride exclusively road, so take this for what it's worth. But if you haven't done much gravel biking, that might be a quick and inexpensive way to see if you liked that type of bike and riding.

If you like it enough to want to continue, you could get a newer, purpose-built gravel bike. If not, you could always restore the bike to it's original flat-bar configuration.

Only caveat is you'd need to make sure the drop-bar shifters are compatible with your existing drivetrain. Shouldn't be a problem for Shimano 9 speed or below, but will be for 10/11/12 speed. Can't speak to SRAM, MicroShift, or others.

Last edited by Hondo6; 09-19-21 at 05:52 PM. Reason: Add last para.
Hondo6 is offline
Old 09-19-21, 06:38 PM
  #4
Plainsman
Senior Member
Thread Starter

Join Date: Jan 2005
Posts: 1,438
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 144 Post(s)
Liked 28 Times in 20 Posts
Originally Posted by shelbyfv View Post
Why not ride gravel on your flat bar bike? No law against it. Think about your reach to the bars. If the bike fits you now with flat bars, it won't fit with the additional reach of drop bars. That's not to say you can't pursue kludges like skyscraper stem stacks, extensions, other foolishness. If you want a clown bike....
True about riding on a flat bar. Sometimes I just come up with projects in search of a need :-). Bike fits like an upright hybrid should, but itís a jumbo frame with a long stem. Figuring I have plenty of stem to play with. But you may be right.
Plainsman is offline
Old 09-19-21, 06:40 PM
  #5
Plainsman
Senior Member
Thread Starter

Join Date: Jan 2005
Posts: 1,438
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 144 Post(s)
Liked 28 Times in 20 Posts
Originally Posted by Hondo6 View Post
I ride exclusively road, so take this for what it's worth. But if you haven't done much gravel biking, that might be a quick and inexpensive way to see if you liked that type of bike and riding.

If you like it enough to want to continue, you could get a newer, purpose-built gravel bike. If not, you could always restore the bike to it's original flat-bar configuration.

Only caveat is you'd need to make sure the drop-bar shifters are compatible with your existing drivetrain. Shouldn't be a problem for Shimano 9 speed or below, but will be for 10/11/12 speed. Can't speak to SRAM, MicroShift, or others.
Hmmm, rear derailleur is a Deore, FD is Microshift. Wonder if I would run into issues? 9 speed.
Plainsman is offline
Old 09-19-21, 09:09 PM
  #6
jonathanf2
Senior Member

Join Date: Dec 2020
Location: Los Angeles
Posts: 401

Bikes: '17 105 2x11 Sprint CF Comp / '21 GRX400 2x10 Poseidon X

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 184 Post(s)
Liked 338 Times in 166 Posts
Get Surly corner bars and have drop bar handling without changing out your brakes/shifters/drivetrain. This would probably be the easiest and cheapest way to doing a "gravel" conversion.

https://surlybikes.com/blog/the_surl...bike_handlebar

Last edited by jonathanf2; 09-19-21 at 09:14 PM.
jonathanf2 is online now
Likes For jonathanf2:
Old 09-19-21, 09:39 PM
  #7
thook
(rhymes with spook)

thook's Avatar

Join Date: Aug 2009
Location: Winslow, AR
Posts: 2,784

Bikes: '83 univega gran turismo x2, '85 schwinn super le tour,'89 miyata triple cross, '91 GT tequesta, '90 yokota grizzly peak, '94 GT backwoods, '95'ish scott tampico, '98 bonty privateer, '93 mongoose crossway 625, '98 parkpre ariel, 2k'ish giant fcr3

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 914 Post(s)
Liked 733 Times in 540 Posts
I don't think it's such a poo poo idea, myself. I really don't care for flat atb/mtb bars on a bike unless it's a genuine trail bike.
On that note, I'd found a Giant FCR-3 hybrid at a thrift store a few years ago ...much like this one...only in red/silver



I swapped it over to a drop bar; FSA Omega compact with a short 80mm of reach and a Giant 90mm stem with about 10 degrees of rise. Swapped the V's for canti's I had and got some 10spd Veloce shifters for it retaining the MTB derailleurs
Like your bike, it has a sloping top tube and tall'ish head tube. So, despite the longer hybrid top tube (56cm), I still managed to make the reach work fine (I'm 5'6 and a half) and the bars are at saddle height with maybe 4-5cm of spacers.
Anyway, the frame will accommodate a full set of touring racks, fenders, two water bottles, and up to 40mm tires. I didn't install racks, though. So, being an aluminum frame/steel fork, it makes for quite a lightweight gravel bikepacking rig.
Oh, and I used a zero offset seat post with the saddle modestly set backwards. IOW's, it's probably only 1cm forward of where I ride on a "normal size" set up

Last edited by thook; 09-19-21 at 09:43 PM.
thook is offline
Old 09-19-21, 10:10 PM
  #8
csport
Senior Member

Join Date: Sep 2015
Location: /dev/null
Posts: 494

Bikes: Soma Double Cross Disc (2018)

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 158 Post(s)
Liked 55 Times in 38 Posts
Originally Posted by Plainsman View Post
I have this flat bar hybrid bike with V-brakes and 38c gravel tires. Lots of parts in the bin (bars, stems, etc.). Instead of buying a drop bar gravel bike, Iím thinking about just swapping out the bars and picking up some used 9 speed shift levers. Horrible idea?
Some compatibility issues:
  • Road shifters will have a different cable pull for the front derailleur.
  • Road brake levers have a short cable pull, V-brakes use long cable pull. There are multiple solutions: mini V-brakes; Problem Solvers Travel Agents with regular V-brakes; drop bar levers with long pull like Tektro RL520 -- in the latter case you will have to use the bar end shifters; maybe you can use canti brakes instead of the V-brakes as well.
Originally Posted by Hondo6 View Post
I ride exclusively road, so take this for what it's worth. But if you haven't done much gravel biking, that might be a quick and inexpensive way to see if you liked that type of bike and riding.

If you like it enough to want to continue, you could get a newer, purpose-built gravel bike. If not, you could always restore the bike to it's original flat-bar configuration.
This is exactly what I went through. Here is my thread about this kind of conversion:
Yet another drop bar conversion
After some time I restored some of the original components (including the stock wheels) and sold the bike to a friend. I rebuilt the Velomine wheels in the picture with disc hubs, bought the Double Cross frame and now I am happy with it.

Originally Posted by Plainsman View Post
Hmmm, rear derailleur is a Deore, FD is Microshift. Wonder if I would run into issues? 9 speed.
You may need to change the FD to a "road" one, unless you use bar end shifters where the left is in the friction mode. RD should work, personally I have had better experience with Microshift M46 RD and road shifters compared to Deore M591 RD.
csport is offline
Old 09-19-21, 10:21 PM
  #9
zandoval
Senior Member

zandoval's Avatar

Join Date: May 2010
Location: Bastrop Texas
Posts: 3,015

Bikes: Univega, Peu P6, Peu PR-10, Ted Williams, Peu UO-8, Peu UO-18 Mixte, Peu Dolomites

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 412 Post(s)
Liked 586 Times in 401 Posts
Just keep adjusting your bike for what you want. My Gravel Bike did not start as one and I am very happy with it...
__________________
No matter where your at... There you are... Δf:=f(1/2)-f(-1/2)
zandoval is offline
Old 09-19-21, 10:45 PM
  #10
cpach
Senior Member

Join Date: Oct 2009
Location: Mt Shasta, CA, USA
Posts: 2,040

Bikes: Too many. Cannondale SuperSix, Trek Remedy 8, Trek Crossrip+ get the most ride time.

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 489 Post(s)
Liked 262 Times in 201 Posts
csport lays out some of the component compatibility issues and possible solutions.

I'd first compare the geometry of your bike to that of a purpose built gravel bike in the correct size for you. Flat bar/hybrid geometry is all over the place, but it's likely that it has a longer top tube in particular than a gravel bike in your size. You can run a shorter stem to account for it, but if things are way off the handling can be far less than ideal.
cpach is offline
Old 09-19-21, 11:30 PM
  #11
Geepig
Senior Member

Geepig's Avatar

Join Date: Sep 2020
Location: Eastern Poland
Posts: 736

Bikes: Romet Jubilat x 4, Wigry x 1, Turing x 1

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 194 Post(s)
Liked 193 Times in 146 Posts
Unless you need to have a bike to fit some kind of class regulations, forget what other people might call it and have fun playing around with parts to see if they work for you. In the late 1970s my Carlton Continental ended up being what people today might call a gravel bike but to me was just an experiment in available parts to get the best out of riding on and off road. Today I buy very cheap old bikes to raid for parts and will put up with inconveniently placed levers and gearchangers just to try out some different bars.
Geepig is offline
Likes For Geepig:
Old 09-20-21, 01:47 AM
  #12
Lazyass
Senior Member

Join Date: Jul 2008
Location: Minas Ithil
Posts: 9,330
Mentioned: 66 Post(s)
Tagged: 0 Thread(s)
Quoted: 2425 Post(s)
Liked 609 Times in 379 Posts
Look at the new Surly Corner bars. They're made for people who want to do a drop bar conversion but don't want to convert to road shifters.

Lazyass is offline
Likes For Lazyass:
Old 09-20-21, 03:40 AM
  #13
Hondo6
Senior Member

Join Date: Sep 2021
Location: SW Florida
Posts: 136

Bikes: Yes

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 48 Post(s)
Likes: 0
Liked 45 Times in 30 Posts
Originally Posted by csport View Post
You may need to change the FD to a "road" one, unless you use bar end shifters where the left is in the friction mode. RD should work, personally I have had better experience with Microshift M46 RD and road shifters compared to Deore M591 RD.
Thanks for pointing out the other possible issues I didn't.

I've read that about front FDs multiple places, but I've never been able to find actual data on FD actuation ratios. Do you happen to know any source that would give those? I'm quite curious, because I've seen one or two claims regarding mixed configurations that make me think it's not necessary always an issue for indexed road shifters, and I'm considering such a setup as for possible build sometime in the future (SA 3-speed hybrid IGH/cassette rear instead of a front triple). That hub supposedly requires use of a mountain shifter, but I've seen accounts of someone using "brifters" (their term; they didn't identify which make or model) with one with no issues. I'd love to see real data on the actuation ratios before going down that road, though.

Last edited by Hondo6; 09-20-21 at 03:53 AM. Reason: Added phrase and changed wording for clarity.
Hondo6 is offline
Old 09-20-21, 03:44 AM
  #14
Hondo6
Senior Member

Join Date: Sep 2021
Location: SW Florida
Posts: 136

Bikes: Yes

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 48 Post(s)
Likes: 0
Liked 45 Times in 30 Posts
Originally Posted by Plainsman View Post
Hmmm, rear derailleur is a Deore, FD is Microshift. Wonder if I would run into issues? 9 speed.
See csport's comment above. It addresses that plus possible brake issues that I'd forgotten about.

Last edited by Hondo6; 09-20-21 at 03:45 AM. Reason: Changed wording for clarity.
Hondo6 is offline
Old 09-20-21, 08:15 PM
  #15
Plainsman
Senior Member
Thread Starter

Join Date: Jan 2005
Posts: 1,438
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 144 Post(s)
Liked 28 Times in 20 Posts
Hmmm, hadnít thought about the brake pull issue. Coupling that with the FD issue and a longer reach, maybe I will just leave it be for now. Eyeore has been amazing as a frankenbike so far - SAVE CAAD aluminum frame, bar ends, shorty aero bars, triple crank with road gearing and mountain low end, carbon fork, V brakes, and 38c tires. I guess itís not AMAZING at any one thing, but does everything okay - 17-18 mph road rides, camping trail rides, neighborhood cruises - and now looking to add okay gravel excursions.
Plainsman is offline
Likes For Plainsman:
Old 09-20-21, 11:11 PM
  #16
thook
(rhymes with spook)

thook's Avatar

Join Date: Aug 2009
Location: Winslow, AR
Posts: 2,784

Bikes: '83 univega gran turismo x2, '85 schwinn super le tour,'89 miyata triple cross, '91 GT tequesta, '90 yokota grizzly peak, '94 GT backwoods, '95'ish scott tampico, '98 bonty privateer, '93 mongoose crossway 625, '98 parkpre ariel, 2k'ish giant fcr3

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 914 Post(s)
Liked 733 Times in 540 Posts
maybe it's just me, but it seems converting this bike over to a drop bar gravel crusher is being made out to be more problematic than it is. four of my bikes are hybrids converted to drop/gravel rides. i'm just saying if you really wanted to make do with it, it's not that big of a deal. for instance, if you got "brifters" you just reroute the cable on the front derailleur to change the pull actuation so it can shift all three rings. or, just get some used bar end shifters. a pair just sold in the classic and vintage sales section for $50 shipped. the road/v brake tektro levers are >$30 and work nicely. they even have quick release buttons. otoh, by the time you buy the necessary parts on the cheap for $150 (my estimate), i suppose you could find another bike that already works. maybe
thook is offline
Old 09-21-21, 10:52 AM
  #17
Flatforkcrown
Senior Member

Flatforkcrown's Avatar

Join Date: Jun 2021
Location: Barboursville, Va
Posts: 286

Bikes: N+1

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 92 Post(s)
Liked 391 Times in 154 Posts
In regards to the road shifter/ mtb front derailer issue, it could work. I have an ultegra 9 speed shifter that shifts an first gen xtr front over a triple and it works fine.
Flatforkcrown is offline
