Mavic Crossride 26" Bearing replacement

Hi there

Need some help with my front hub. I have replaced the bearings (6804) on the front hub. Its the strange model that requires the left hand bearing to go through the entire hub body. At first I believe the bearing went in a little crooked as it wasn't spinning freely. Had another go at it this morning and managed to get them seated running buttery smooth.

The problem is when I insert the axle and refit the spacers etc. the axle does not spin freely. it feels like the bearings are grinding. I have checked with the technical manual that all the spacers and circplis are in the right order which they are. It seems like there is too much preload which is binding the bearings but I don't see any way to adjust it.
Anyone had the same issue and know of a possible solution?
Stormy85 is offline
Old 02-04-22, 06:53 AM
  #2
Andrew R Stewart
Senior Member

Andrew R Stewart's Avatar

Join Date: Feb 2012
Location: Rochester, NY
Posts: 16,773

Bikes: Stewart S&S coupled sport tourer, Stewart Sunday light, Stewart Commuting, Stewart Touring, Co Motion Tandem, Stewart 3-Spd, Stewart Track, Fuji Finest, Mongoose Tomac ATB, GT Bravado ATB, JCP Folder, Srewart 650B ATB

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3644 Post(s)
Liked 2,589 Times in 1,626 Posts
I wonder if you pitted the bearings on install.

Bearings could still be crooked WRT each other.

Are you familiar with the preload adjusting ring and could it be too far in? Andy
__________________
AndrewRStewart
Andrew R Stewart is offline
Old 02-04-22, 08:21 AM
  #3
Stormy85
Newbie
Thread Starter

Join Date: Jul 2020
Posts: 47
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 15 Post(s)
Likes: 0
Liked 6 Times in 3 Posts
Originally Posted by Andrew R Stewart View Post
I wonder if you pitted the bearings on install.

Bearings could still be crooked WRT each other.

Are you familiar with the preload adjusting ring and could it be too far in? Andy
Based on how they spin I would say that they are still intact but of course cant tell for sure.
If I only mount the axle then it spins okay and first when I mount the washer and spacers it tightens up. Do you mean the little metal clip that squeezes in between the two washers once installed?
Do you know if the bearing on the right hand side is suppose to sit snug up against the circlip on the inside of the hub?
Stormy85 is offline
Old 02-04-22, 09:05 AM
  #4
Stormy85
Newbie
Thread Starter

Join Date: Jul 2020
Posts: 47
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 15 Post(s)
Likes: 0
Liked 6 Times in 3 Posts
So, I think I might have found the culprit. The inner circlip eyes were a little dent and when the bearing nested up against them they would prohibit the bearing from spinning freely. I turned it around and now everything seems to work.
Stormy85 is offline
Likes For Stormy85:
Old 02-04-22, 11:10 AM
  #5
Barry2
LRP=HR

Join Date: Sep 2019
Location: SF Bay Area
Posts: 1,599

Bikes: Holdsworth 1979 Special, C-dale 1993 MT3000 Tandem & 1996 F700CAD3, Cervelo 2022 R5 & 2018 R3, JustGo Runt, Ridley Oval, Kickr Bike 8-)

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 620 Post(s)
Liked 795 Times in 461 Posts
Bearings

Whose bearings did you purchase?
I've a pair of Ksyriums that are going to need doing this year.

Barry
Barry2 is offline
Old 02-04-22, 02:19 PM
  #6
Stormy85
Newbie
Thread Starter

Join Date: Jul 2020
Posts: 47
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 15 Post(s)
Likes: 0
Liked 6 Times in 3 Posts
Originally Posted by Barry2 View Post
Whose bearings did you purchase?
I've a pair of Ksyriums that are going to need doing this year.

Barry
I bought some "Premo Bearing", at least that's what it says on the bearing. Based on the price they are probably some no-name brand but the wheels are rather old so didn't want to splash out for some pricier options.
Stormy85 is offline
Old 02-04-22, 03:39 PM
  #7
Barry2
LRP=HR

Join Date: Sep 2019
Location: SF Bay Area
Posts: 1,599

Bikes: Holdsworth 1979 Special, C-dale 1993 MT3000 Tandem & 1996 F700CAD3, Cervelo 2022 R5 & 2018 R3, JustGo Runt, Ridley Oval, Kickr Bike 8-)

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 620 Post(s)
Liked 795 Times in 461 Posts
Originally Posted by Stormy85 View Post
I bought some "Premo Bearing"
well, I wont be asking where you got those from. 🙂

Barry
Barry2 is offline
