Sram Spectro S7 2003 shifting issues

Anyone have experience with this hub that could help me? Manual says 2005, but drum plate is stamped 2003. Don’t know which year it’s from or if it matters.

Im having difficulty with the clickbox shifting. I rebuilt the hub over the summer and I think the overhaul went fine. Everything is really smooth and the rod pushes in no problem, springs back well. Im at a complete loss as to what might be happening. I install the clickbox with the grip shifter in first gear, I can shift to 2, but I can’t tell if it is shifting or not. When I try to shift to third it is very difficult to do, to the point that I don’t want to force it for fear of breaking it.

The clickbox will shift through the gears if it isn’t installed on to the hub, but as soon as it’s on the hub axle, it has issues.

Really could use some help everyone.

Last edited by boneshaker78; 01-20-23 at 08:48 PM.
boneshaker78 is offline
Old 01-20-23, 09:13 PM
  #2
Dan Burkhart
Senior member

Dan Burkhart's Avatar

Join Date: Oct 2004
Location: Oakville Ontario
Posts: 7,962
Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 883 Post(s)
Liked 500 Times in 290 Posts
There should be a spring loaded rod and an outer sleeve protruding from the axle with the clickbox removed. The fingers in the clickbox engage with the rod and sleeve and push on them to select the various gears.
You should be able to push the rod and sleeve both back into the axle without too much resistance and they should spring back. If you find you can not then something is wrong inside.
It is also important that the notch in the sleeve is correctly oriented so the fingers in the clickbox can properly engage. That is the job of the red plastic clip that fits over the axle.
If that clip is missing it will not work correctly.

Last edited by Dan Burkhart; 01-20-23 at 09:19 PM.
Dan Burkhart is offline
Likes For Dan Burkhart:
Old 01-20-23, 09:24 PM
  #3
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Originally Posted by Dan Burkhart View Post
There should be a spring loaded rod and an outer sleeve protruding from the axle with the clickbox removed. The fingers in the clickbox engage with the rod and sleeve and push on them to select the various gears.
You should be able to push the rod and sleeve both back into the axle without too much resistance and they should spring back. If you find you can not then something is wrong inside.
It is also important that the notch in the sleeve is correctly oriented so the fingers in the clickbox can properly engage. That is the job of the red plastic clip that fits over the axle.
If that clip is missing it will not work correctly.
Thanks for the reply. The rod pushes in and springs back very freely. I had the hub completely disassembled and nothing inside seemed broken or worn that much at all. I followed the manual instructions when assembling the rod, tube and red clip. It sounds like everything you mentioned is in good order. Some of what you mentioned does help to understand it better though. Thank you
boneshaker78 is offline
Old 01-20-23, 09:41 PM
  #4
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Originally Posted by boneshaker78 View Post
Thanks for the reply. The rod pushes in and springs back very freely. I had the hub completely disassembled and nothing inside seemed broken or worn that much at all. I followed the manual instructions when assembling the rod, tube and red clip. It sounds like everything you mentioned is in good order. Some of what you mentioned does help to understand it better though. Thank you
I took another look and made sure the red clip clicked in, actually engaged the way the manual says and it made all the difference. Shifting through the gears when attached to the hub axle. Not sure why I didnít think to make sure that the red clip was fully engaged, but thatís what seemed to be the fix. Iíll have to test ride tomorrow to confirm itís working correctly, but everything seems right now. Thanks for your help, understanding the importance of that red clip made me take a second look at it.

I know nothing about IGH, but this was one hell of a learning experience, going back 5 or 6 monthsÖ what a journey.
boneshaker78 is offline
Old 01-20-23, 09:55 PM
  #5
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
It is shifting now through the gears, but something is clearly not right. I’m getting a tha-thup, tha-thup sound in 5th gear and it seems to continue freewheeling in 6 and 7. What a disappointment. Does anyone know why this might be happening?
boneshaker78 is offline
Old 01-20-23, 10:48 PM
  #6
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Well, I test rode it just now. This is what it’s doing.

1st and 2nd gear work as they should
3rd gear doesn’t work at all, just spinning with no gear engaged
4th gear works, but makes freewheeling sound while pedaling
5th gear works, but makes the “tha-thump” “tha-thump” noise
6th and 7th gear work, but make freewheeling sounds while pedaling

Seems really bad. So sad 😩

Last edited by boneshaker78; 01-20-23 at 11:49 PM.
boneshaker78 is offline
Old 01-21-23, 05:01 AM
  #7
Dan Burkhart
Senior member

Dan Burkhart's Avatar

Join Date: Oct 2004
Location: Oakville Ontario
Posts: 7,962
Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 883 Post(s)
Liked 500 Times in 290 Posts
You said you rebuilt the hub. If you removed the planetary carrier it is vitally important to Time the planetary gears on assembly. Failure to do so can result in broken sun gears. That would cause all kinds of issues.

Last edited by Dan Burkhart; 01-21-23 at 06:07 AM.
Dan Burkhart is offline
Old 01-21-23, 06:05 AM
  #8
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Originally Posted by Dan Burkhart View Post
You said you rebuilt the hub. If you removed the planetary carrier it is vitally important to Time the planetary gears on assembly. Failure to do so can result in broken sun gears. That would cause all kinds of issues.
Great video Dan, thanks for sharing. I wish I had seen this video when I was tinkering with the hub before, difficult to find anything on youtube about it.

I understand how important the planetary gears are. When I reassembled it, it seemed as though I had it lined up right, but it isn’t necessarily an easy thing to do without the guide and at the time I had no idea where to find it. It’s quite possible that is the issue, but given the fact that the hub has a poor history as well, no anti-rotation washers used for who knows how long, what riding conditions it was used under… it’s just too hard to tell definitively at the moment.

I suppose I have nothing to lose by opening the hub back up to see what might be going on. Anyone know where to find the guide they mention in the manual for aligning the planetary gears? Of course, with the video Dan has shared I have more confidence aligning them if i were to do so again anyway.

In my experience, Sram has pretty good customer service. I reached out to them and I’m waiting to see what they might have to say.

Last edited by boneshaker78; 01-21-23 at 06:17 AM.
boneshaker78 is offline
Old 01-21-23, 06:12 AM
  #9
Dan Burkhart
Senior member

Dan Burkhart's Avatar

Join Date: Oct 2004
Location: Oakville Ontario
Posts: 7,962
Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 883 Post(s)
Liked 500 Times in 290 Posts
SRAM North American support for gear hubs was pretty much non existent even during production let alone now that these hubs have been orphaned.
I wish you luck but I would not expect much help from SRAM
Dan Burkhart is offline
Old 01-21-23, 06:26 AM
  #10
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Originally Posted by Dan Burkhart View Post
SRAM North American support for gear hubs was pretty much non existent even during production let alone now that these hubs have been orphaned.
I wish you luck but I would not expect much help from SRAM
Thatís not great news. I guess Iíll do my very best to see what might be happening. Thanks for your help Dan.
boneshaker78 is offline
Old 01-21-23, 06:31 AM
  #11
Dan Burkhart
Senior member

Dan Burkhart's Avatar

Join Date: Oct 2004
Location: Oakville Ontario
Posts: 7,962
Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 883 Post(s)
Liked 500 Times in 290 Posts
Originally Posted by boneshaker78 View Post
Thatís not great news. I guess Iíll do my very best to see what might be happening. Thanks for your help Dan.
With regard to timing the planetaries, I made this video ten years ago showing my technique without the guide tool.
Dan Burkhart is offline
Old 01-21-23, 06:34 AM
  #12
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Originally Posted by Dan Burkhart View Post
With regard to timing the planetaries, I made this video ten years ago showing my technique without the guide tool.
https://www.youtube.com/watch?v=p9A8XWPzwVg
Yes, I found it very helpful. Unfortunately I didnít see it when I was overhauling the hub some 5 months ago, I wish I had seen it then. I hope it might come in handy now if I were to open the hub back up again. Thanks for making the video, I have much more confidence aligning the gears if I end up in that position again.
boneshaker78 is offline
Old 01-21-23, 07:57 AM
  #13
boneshaker78
Commuting Fool
Thread Starter

boneshaker78's Avatar

Join Date: Sep 2012
Location: USA
Posts: 188

Bikes: 1988 Miele Azsora singlespeed, 2022 State All-Road 4130, 2003 Jamis Coda Comp

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 53 Post(s)
Liked 26 Times in 23 Posts
Here is an image of the planetary gear alignment when I took a look inside. They appear aligned well to me, maybe I’m missing it somehow, but they look okay to me.
