Using CarboLift to strip carbon fiber

I bought a '90 TVT92 from an eBay seller in Hungary. When it arrived I found that the FD clamp had been overtightened at some point slightly crushing the seat tube. I didn't want to keep the frame but it was too expensive to return it so I came to an agreement with the seller to split the costs. He refunded me half the buy it now price and shipping. The bike had been badly repainted but I wanted to see if I could use the fork on my CT3000. It would need to be stripped and repainted.
I searched on the interwebs and came across a product called CarboLift thats made to strip paint from carbon fiber. I couldn't find many reviews. I did find one not so glowing review but it had been commented on by someone at CarboLift saying they had reformulated and asking the reviewer to give it another try. I decided to give it a shot. The stuff is not cheap. Their standard size bottle cost $55 delivered from Canada to California. After ordering the stuff I sent an email to their contact address and asked for any tips they could give me. They responded asking for my phone number but never returned the call. After it arrived I downloaded the instructions and tried to follow them as closely as possible. Here are my results so far;

Here is the part I'm stripping. They recommend sanding with a purple scotchbrite pad first. I had green ones so used those.


The instructions said to apply a thin coat and wait 30 minutes


After about 20 minutes the paint started to bubble


After that you're supposed to re-apply the stripper and wrap the work in cling film. I used a trash bag. the directions say you should try to keep the temp between 75-90F so I set the piece on top of a lighting transformer and let it sit. You can let it sit for up to 24 hours but I could see the whole thing bubbled up after about an hour. I gave it another 2 hours and then opened it up.


After about 5 minutes of scrubbing with a green scotchbrite pad and water you could see clearly that this fork used to be on Jeff Gordon's NASCAR or possibly the bike was originally a Greg LeMond TdF replica.


The carbon fiber weave below the paint was starting to become visible.


Ready for another application.


Now that we're down to factory paint I expected the process to get harder and I was correct. After 30 minutes wait time there was very little bubbling in the factory paint but the blue tinted clearcoat at the top did start to budge.


I've wrapped it up tight in plastic again and set it back on the warm transformer. This time I will let it go much longer unless I see some significant bubbling.

So far I would say the stuff works as described. I got it on myself a couple times while working with it and it didn't burn like normal paint stripper does. It didn't seem to have any smell either but I'm practically smell blind so I'm not the best judge. There were no fumes to bother my eyes or make me cough and sneeze though. I'll follow up tomorrow and show you guys how the second application went. At this rate I would expect to need 2 bottles if I were going to strip an entire bike. That seems a little pricey to me but for the right frame I may do it.
eastbay71 is offline
Old 05-26-16, 08:16 AM
  #2
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Posts: 11,935
Mentioned: 73 Post(s)
Tagged: 0 Thread(s)
Quoted: 990 Post(s)
Liked 508 Times in 416 Posts
interesting but not so much a burning issue (yet) for most of us C&Vers who own little CF stuff.
Seems they came up with a formula that will attack paint but leave the resin (polyester?) that binds the carbon fabric alone. is there any info in an MSDS that sheds some light on the chemistry?
Has anybody experimented with 3M Safe Stripper or similar water-based strippers on a broken CF part to see what happens?
unworthy1 is offline
Old 05-26-16, 08:34 AM
  #3
nlerner
Senior Member

Join Date: Dec 2005
Posts: 15,762
Mentioned: 405 Post(s)
Tagged: 0 Thread(s)
Quoted: 3007 Post(s)
Liked 3,866 Times in 1,703 Posts
I admire your willingness to experiment, but can't help asking: If you were going to repaint anyway, why bother stripping down to naked CF? Why not lightly sand existing paint smooth and re-coat?
nlerner is offline
Old 05-26-16, 08:46 AM
  #4
Chombi
Senior Member

Chombi's Avatar

Join Date: Jul 2009
Posts: 11,138

Bikes: 1986 Alan Record Carbonio, 1985 Vitus Plus Carbone 7, 1984 Peugeot PSV, 1972 Line Seeker, 1986(est.) Medici Aerodynamic (Project), 1985(est.) Peugeot PY10FC

Mentioned: 21 Post(s)
Tagged: 0 Thread(s)
Quoted: 147 Post(s)
Likes: 0
Liked 26 Times in 21 Posts
That stuff works quite slowly.......24 hours for the first application, wrapped in plastic??
Most in this forum who restored C&V CF bikes use just a sanding method to get the finish off, usually clear coats but I can see why you cosine red this stripper as you have multiple color paint coats on the frame......
Keep us posted on how it goes as I am considering stripping and refinishing a Trek OCLV frame in the future....
Chombi is offline
Old 05-26-16, 08:25 PM
  #5
eastbay71
Senior Member
Thread Starter

eastbay71's Avatar

Join Date: Apr 2014
Location: SF Bay Area
Posts: 691

Bikes: the bikes own me

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
Originally Posted by unworthy1 View Post
interesting but not so much a burning issue (yet) for most of us C&Vers who own little CF stuff.
Seems they came up with a formula that will attack paint but leave the resin (polyester?) that binds the carbon fabric alone. is there any info in an MSDS that sheds some light on the chemistry?
Here is a link to the MSDS. https://eco-lifting.com/wp-content/up...olift_MSDS.pdf


Originally Posted by nlerner View Post
I admire your willingness to experiment, but can't help asking: If you were going to repaint anyway, why bother stripping down to naked CF? Why not lightly sand existing paint smooth and re-coat?
My original goal with this project was to see if I could just expose the original paintwork below the poor quality respray. After some searching this product seemed to have to have best potential to do that. I bought the CarboLift before I saw the frame and realized I didn't want to use it. Then I decided to see if I could strip the fork to the bare carbon fiber weave to match my Miyata. My surgically repaired shoulder is already sore from the scotchbrite work I've been doing so sanding would have not been a choice for me.

Since I'm not planning on using the frame I may try a standard paint stripper like Klean-Strip on it to see how it affects the resin. It could be that this product is completely un-necessary.

Last edited by eastbay71; 05-26-16 at 08:26 PM. Reason: spelling
eastbay71 is offline
Old 05-26-16, 08:35 PM
  #6
eastbay71
Senior Member
Thread Starter

eastbay71's Avatar

Join Date: Apr 2014
Location: SF Bay Area
Posts: 691

Bikes: the bikes own me

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
I took the plastic off after about 16 hours to see ow it was progressing. Most of the fork crown is bare to the resin now with no damage to the resin itself. The tough factory paint hasn't bubbled but it is noticebly grittier and anywhere there was a chip or a crack in the paint the stripper seems to have gotten down to the base. Maybe I should have used a more aggressive abrasive after I cleaned off the first layer of paint. Its looking promising so I applied another coat. If I can get all the original paint off I'll spray it with a 2K clearcoat to get that nice shine back.

Here is what it looked like after the wrap was removed


After a little scrubbing



Chips allowed the stripper to get all the way to the base in some areas

eastbay71 is offline
Old 05-26-16, 11:46 PM
  #7
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Posts: 11,935
Mentioned: 73 Post(s)
Tagged: 0 Thread(s)
Quoted: 990 Post(s)
Liked 508 Times in 416 Posts
hmmm, I'm a little skeptical of the cosmetically enhanced MSDS provided by the company that sells it, I'd like to see one from a neutral party but online searching turns up only this one. If it's reliable info, seems the active ingredient is 5% hydrogen peroxide...surprised that's an effective paint remover, but...looks like it can be.
unworthy1 is offline
Old 05-27-16, 02:01 AM
  #8
eastbay71
Senior Member
Thread Starter

eastbay71's Avatar

Join Date: Apr 2014
Location: SF Bay Area
Posts: 691

Bikes: the bikes own me

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
@unworthy1 I've worked in industry for over 25 years. No company provides neutral party MSDS and there is very little standardization. Maybe that will change with the recent changes to toxic chemical regulations.
eastbay71 is offline
Old 05-27-16, 03:46 AM
  #9
Prowler
Senior Member

Join Date: Nov 2013
Location: Near Pottstown, PA: 30 miles NW of Philadelphia
Posts: 1,966

Bikes: 2 Trek Mtn, Cannondale R600 road, 6 vintage road bikes

Mentioned: 77 Post(s)
Tagged: 0 Thread(s)
Quoted: 399 Post(s)
Liked 589 Times in 282 Posts
Originally Posted by eastbay71 View Post
Since I'm not planning on using the frame I may try a standard paint stripper like Klean-Strip on it to see how it affects the resin. It could be that this product is completely un-necessary.
Interesting winter project: use sections of the scrap frame to conduct unspeakable experiments on. Various mechanical and chemical paint removal methods to characterize their impact on the base carbon/resin layer. Post results. Maybe even find friends and neighbors who will give you a wee bit of the various paint strippers they have on the shelf. Reminds me of the racks of paint samples you sometimes see out in the sun and weather - various compounds on the same base to measure durability. You can even tape off sections of a seat stay in order to test 3 or 4 methods on the one stay. Go for it Inspector Gadget.
Prowler is online now
Old 05-27-16, 09:00 AM
  #10
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Posts: 11,935
Mentioned: 73 Post(s)
Tagged: 0 Thread(s)
Quoted: 990 Post(s)
Liked 508 Times in 416 Posts
Originally Posted by eastbay71 View Post
@unworthy1 I've worked in industry for over 25 years. No company provides neutral party MSDS and there is very little standardization. Maybe that will change with the recent changes to toxic chemical regulations.
That makes sense: I used to work at a Co. that had an online account that we downloaded all the MSDS we ever wanted and they all looked consistent and 'official' so i got this mistaken impression there was some gov. agency distributing them...thanks for clarifying.
unworthy1 is offline
Old 05-28-16, 03:41 AM
  #11
eastbay71
Senior Member
Thread Starter

eastbay71's Avatar

Join Date: Apr 2014
Location: SF Bay Area
Posts: 691

Bikes: the bikes own me

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
Thread Update; I let it sit for another 16 hours wrapped in plastic at about 85F and when I opened it up the paint was pretty soft. It didn't just slough off but I was able to scrub all the remaining paint off with a scotchbrite pad. I think thats how this product really works. You don't get the dramatic bubbling of a convential stripper. Its more of a softening that allows you to safely strip off the paint. But it does take some elbow grease. It took about an hour and a half to scrub off the remaining paint. One of the things I was concerned about when stripping the paint was exposing the carbon fiber weave causing it to fray possibly making the fork unusable. That did not happen so I'm pretty happy. Overall I'm not sure how many people would want to use this product. My number 1 complaint would be the price, followed by the manufacturers lack of support or even to respond to the emails I sent. I think they should also sell the stuff in a bigger bottle. But if you have something you want to strip really carefully this may be the right stuff for you. It did do what it said it would. It lifted the paint off the carbon fiber without damaging the base material. I would want to try some other products like the 3M safe strip mentioned earlier in the thread before recommending it to anyone. I'm also going to go ahead with some standard strippers on my frame so I'll update this thread when I've done that.





After the scrubbing was done.



eastbay71 is offline
Old 05-28-16, 11:47 AM
  #12
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Posts: 11,935
Mentioned: 73 Post(s)
Tagged: 0 Thread(s)
Quoted: 990 Post(s)
Liked 508 Times in 416 Posts
in addition to the commonly available (in the US, anyway) 3M Safer Stripper and CitraStrip that I have used on "plastic" paints so MIGHT be attacking to the CF resin, there are those sold as "poultice" or "blanket" strippers such as Peelaway 1 and 7 popular in the UK and particularly good for really heavy multiple coats of housepaint. I have no idea about the active ingredients in this stuff, which you spread on with a spatula and cover with the "blanket" they supply, then wrap with Saran plastic to extend the working time. All the paint sticks to the blanket (in theory) and you throw the whole thing away, simplifying cleanup. They sell a 'trial pot' of both formulas so you can test first (which they stress to do), they sell this in the US but harder to find than the other stuff.
https://www.decoratingwarehouse.co.uk...a782232a0c.pdf
Another one you might test are the (relatively new) soy-based strippers, sold as environmentally friendly...I have yet to try any cause they are pricey and I still have plenty of the others back stocked.
unworthy1 is offline
Old 07-22-16, 01:53 PM
  #13
jumpstartjonny
Newbie

jumpstartjonny's Avatar

Join Date: Jan 2011
Location: Healdsburg, CA
Posts: 12

Bikes: 1958 Olmo Professional, 1981 Bianchi Campione Del Mondo, 1984 Paramount, 2009 S-Works Roubaix, 2018 Roubaix Pro

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
I know the thread is getting old but I'm very curious about this product and might want to use it to strip original paint off of an old carbon Specialized Roubaix. The last picture you posted is of the completely stripped fork and it appears that there is some removal of carbon at the crown – or is that just the photo creating that appearance? I’m also in the east bay, btw.
jumpstartjonny is offline
Old 07-22-16, 03:00 PM
  #14
DMC707
Banned.

Join Date: Jan 2013
Location: Norman, Oklahoma
Posts: 5,024

Bikes: Too many to list

Mentioned: 36 Post(s)
Tagged: 0 Thread(s)
Quoted: 1606 Post(s)
Liked 873 Times in 587 Posts
If the problem was in the clamp area --- you could have sleeved it internally then touched up the carbon outer layer

easy fix, but may add a few oz.
DMC707 is offline
Old 07-22-16, 03:26 PM
  #15
Grand Bois
Senior Member

Grand Bois's Avatar

Join Date: Mar 2005
Location: Pinole, CA, USA
Posts: 17,415
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 441 Post(s)
Likes: 0
Liked 13 Times in 13 Posts
Originally Posted by nlerner View Post
I admire your willingness to experiment, but can't help asking: If you were going to repaint anyway, why bother stripping down to naked CF? Why not lightly sand existing paint smooth and re-coat?
My thoughts exactly.
Grand Bois is offline
Old 07-22-16, 03:52 PM
  #16
RobbieTunes
Banned.

Join Date: Dec 2007
Posts: 27,297
Mentioned: 34 Post(s)
Tagged: 1 Thread(s)
Quoted: 378 Post(s)
Liked 1,389 Times in 898 Posts
Interesting, as I have an older carbon frame that someone else stripped and cleared, but it's so nice you really can't tell.
It does give me a $55 starting point and guidance if I decide to buy a real ugly duckling version of the same bike or a Y-Foil
__________________

BLDMAMTAOLD



Last edited by RobbieTunes; 07-22-16 at 04:02 PM.
RobbieTunes is offline
Old 07-22-16, 04:54 PM
  #17
randyjawa
Senior Member

randyjawa's Avatar

Join Date: Apr 2007
Location: Thunder Bay, Ontario, Canada - burrrrr!
Posts: 11,316

Bikes: 1958 Rabeneick 120D, 1968 Legnano Gran Premio, 196? Torpado Professional, 2000 Marinoni Piuma

Mentioned: 201 Post(s)
Tagged: 0 Thread(s)
Quoted: 1265 Post(s)
Likes: 0
Liked 1,370 Times in 773 Posts
If it's reliable info, seems the active ingredient is 5% hydrogen peroxide...surprised that's an effective paint remover, but...looks like it can be.
Hydrogen Peroxide is a really strong oxidizing agent.
When putting a recycle paper plant on line, a HP salesman demonstrated the power of the stuff. We bought it at 70% and diluted it to 50%. At 70%, the salesman spilled a few drops onto a work glove, that he had placed on the concrete floor of the Recycle Plant. With-in seconds the glove burst into flame.

That stuff was always transported through the mill inside a double pipe. One pipe inside of another. If a leak occurred in the inner pipe, the outside pipe chamber recognized the change in pressure, and shut the pumping system down.

INcidentally, the HP we cleanse a wound with is 0.03% strong. Not sure I would want that stuff anywhere near one of my bicycles. But that is just me.
__________________
"98% of the bikes I buy are projects".
randyjawa is offline
Old 09-09-16, 02:38 PM
  #18
CliffordK
Senior Member

CliffordK's Avatar

Join Date: Nov 2014
Location: Eugene, Oregon, USA
Posts: 26,901
Mentioned: 213 Post(s)
Tagged: 0 Thread(s)
Quoted: 15956 Post(s)
Liked 3,285 Times in 2,441 Posts
Thanks for the writeup.

I snagged a badly abused, and repainted CADEX frame yesterday.

There is also a bottle of CarboLift for sale on Craigslist.

I just have to decide how much money I want to put into the frame. It might make a great "beater", and something I could experiment with a bit. RACKS?
CliffordK is offline
Old 09-09-16, 04:24 PM
  #19
eastbay71
Senior Member
Thread Starter

eastbay71's Avatar

Join Date: Apr 2014
Location: SF Bay Area
Posts: 691

Bikes: the bikes own me

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 18 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
Originally Posted by CliffordK View Post
Thanks for the writeup.

I snagged a badly abused, and repainted CADEX frame yesterday.

There is also a bottle of CarboLift for sale on Craigslist.

I just have to decide how much money I want to put into the frame. It might make a great "beater", and something I could experiment with a bit. RACKS?
I should be getting onto phase 2 of this project sometime this winter. I've decided to try to salvage the frame. The seat tube had been crushed by overtightening a FD clamp. I'm going to try to use some fiberfix to patch up the damage and use a new SRAM 1X drivetrain on it to eliminate the front derailleur. So I'll need to strip off the previous owners really poorly applied rattle can job and the base coat applied by TVT.

Valu Home Centers Watch FiberFix Drive A Car With A Duct Tape Roll Cage Off A Cliff!
eastbay71 is offline
Old 10-05-18, 10:10 AM
  #20
BrooklynRunner
Newbie

Join Date: May 2015
Location: Brooklyn
Posts: 3

Bikes: 2006 Felt F4C Carbon w/ Ultegra & Dura Ace

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by eastbay71 View Post
I should be getting onto phase 2 of this project sometime this winter. I've decided to try to salvage the frame. The seat tube had been crushed by overtightening a FD clamp. I'm going to try to use some fiberfix to patch up the damage and use a new SRAM 1X drivetrain on it to eliminate the front derailleur. So I'll need to strip off the previous owners really poorly applied rattle can job and the base coat applied by TVT.
What was the outcome with removing the paint from the frame and using fiberfix? Don't leave us hanging!
BrooklynRunner is offline
Related Topics
Thread
Thread Starter
Forum
Replies
Last Post
dksix
General Cycling Discussion
1
03-07-16 09:48 AM
spectastic
Bicycle Mechanics
7
12-28-14 04:42 AM
pkpyro
Framebuilders
2
10-05-11 08:59 PM
Rob13
Road Cycling
21
07-28-11 02:49 PM
frpax
Bicycle Mechanics
12
10-15-10 06:24 PM

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off


Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
