Old 07-20-17, 07:10 AM   #51
OldsCOOL
Senior Member

OldsCOOL's Avatar

Join Date: Jul 2004
Location: northern michigan
Bikes: '77 Colnago Super, '76 Fuji The Finest, '88 Cannondale Criterium, '86 Trek 760, '87 Miyata 712
Posts: 12,086
Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 324 Post(s)
Here is my '89 PRE purchased 5 years ago for 120.00, was kept in the back room of a bike shop, paint was cherry. I thoroughly enjoyed the ride until giving it over to my son. Here is a pic from a few years back.

OldsCOOL is offline   Reply With Quote
Old 07-20-17, 08:34 AM   #52
TenGrainBread
Senior Member

TenGrainBread's Avatar

Join Date: Sep 2015
Location: Madison, WI
Bikes:
Posts: 803
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Quote:
Originally Posted by 9volt View Post
Any concerns about the corrosion at the seat cluster?
The paint bubbling is over the aluminum lugs. Aluminum's oxide is non-corrosive (actually protective), so the bubbling is probably just due to some contaminents messing with the paint.
TenGrainBread is offline   Reply With Quote
Old 07-20-17, 09:20 AM   #53
bloom87
Senior Member

Join Date: Dec 2009
Bikes:
Posts: 622
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
nice livery for the PRE... should look even better with patina ;-)

i learned just recently that the steel front-end and backends + the forks on the Olympian (at least) were of japanese origin.

that explains why the fork accepts a 27.0 diameter crown race rather than a 26.4 (which is why I had quite a bit of filing to do until the campy HS could fit, and then I realized it gave me a stack height problem, AKA the locknut won't engage because it's too thick...)
bloom87 is offline   Reply With Quote
Old 07-20-17, 09:53 AM   #54
tiredhands
Sempiternal Newb

tiredhands's Avatar

Join Date: Dec 2014
Location: Panama City, FL
Bikes: 1984 Trek 510, 1990 Trek 520, 1992 Trek 750
Posts: 273
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 100 Post(s)
I put together this Heat earlier this year for a friend's oldest kid. I was worried an 8-year old boy wouldn't be down with hot pink grips, but he's cool. The frame is really nice, and it I'd love to find one in my size, the color is so rad.
tiredhands is offline   Reply With Quote
Old 08-01-17, 02:43 PM   #55
T-Mar
Senior Member

Join Date: Nov 2004
Bikes:
Posts: 15,034
Mentioned: 246 Post(s)
Tagged: 1 Thread(s)
Quoted: 1382 Post(s)
Here's the 1990 Technium info from my catalogue & price list.

Road:

1990 Olympian, Shimano 300EX, $375-$425
1990 Supercourse, 6061 T8 aluminum, w/CrMo stays & fork, Shimano 400EX, $45-$525.
1990 Grand Prix, 6061 T8 aluminum, w/CrMo stays & fork, SunTour Radius, $550-$625
1990 Prestige, Easton E9 aluminum, w/CrMo stays & fork, Shimano RX100, $600-$700
1990 Pro, Easton E9 aluminum, w/CrMo stays & fork, Shimano 105SC, $875-750

ATB:

1990 Obsession, 6061 T8 aluminum, w/CrMo stays & fork, Shimano 300LX, $450-$500
1990 Heat, 6061 T8 aluminum, w/CrMo stays & fork, Shimano 500LX, $525-$575
1990 Instinct LX, Easton E9 aluminum, w/CrMo stays & fork, Shimano Deore LX, $575-$650
1990 Instinct XCD, Easton E9 aluminum, w/CrMo stays & fork, SunTour XCD, $625-$7000
1990 Chill, Easton E9 aluminum, w/CrMo stays & fork, Shimano Deore DX, $675-$750
1990 Peak, Easton E9 aluminum, w/CrMo stays & fork, Shimano Deore XT, $950-$1050

Hybrid:

1990 Olympian CX, 6061 T8 aluminum, w/CrMo stays & fork, Shimano 300LX, $425-$450

I believe I also have 1991 & 1992 price lists. I also have sporadic info on pre-1990 Technium models from road tests, advertisements, etc. I will slowly add these to the thread. The OP may want to ammend post #1, to include these, to make it an easier to find resource.
T-Mar is offline   Reply With Quote
Old 08-01-17, 03:03 PM   #56
T-Mar
Senior Member

Join Date: Nov 2004
Bikes:
Posts: 15,034
Mentioned: 246 Post(s)
Tagged: 1 Thread(s)
Quoted: 1382 Post(s)
1991 models. Sorry, no info on stay & fork mat'l.

Road:

1991 Olympian FT, 6061 T6 aluminum, Shimano 300EX/LX, $435
1991 Supercourse FT, 6061 T8 aluminum, Shimano 500EX/LX, $560
1991 Grand Prix, 6061 T8 aluminum, SunTour Radius, $535
1991 Pro, Easton E9 aluminum, Shimano 105SC, $760
1991 Competition, Reynolds 531, Shimano 600 Ultegra, $1200
1991, Team, Reynolds 753, Shimano Dura-Ace STI, $2000

ATB:

1991 Obsession, 6061 T8 aluminum, Shimano 400LX, $515
1991 Heat, 6061 T8 aluminum, Shimano 500LX, $585
1991 Instinct, 6061 T8 aluminum, Shimano Deore LX/DX, $625
1991 Chill, Easton E9 aluminum, Shimano Deore DX, $750
1991 Peak, Easton E9 aluminum, Shimano Deore XT, $1050

Hybrid:

1991 Olympian CX, 6061 T8 aluminum, Shimano 300EX/LX, $475

Last edited by T-Mar; 08-01-17 at 03:15 PM.
T-Mar is offline   Reply With Quote
Old 08-01-17, 03:34 PM   #57
T-Mar
Senior Member

Join Date: Nov 2004
Bikes:
Posts: 15,034
Mentioned: 246 Post(s)
Tagged: 1 Thread(s)
Quoted: 1382 Post(s)
1992 line:

Road:

1992 Olympian, 6061 T6 aluminum,CrMo fork, Shimano 300EX, $419
1992 Supercourse FT, 6061 T8 aluminum, CrMo fork, Shimano 500EX/LX, $625
1992 Pro, Easton E9 aluminum, CrMo fork, Shimano 105SC, $854
1992 Competition, Reynolds 531, Reynolds 531 fork, Shimano 600 Ultegra STI, $1406
1992 Team, Reynolds 753, Reynolds 753 fork, Shimano Dura-Ace STI, $2317

ATB:

1992 Heat, 6061 T8 aluminum, CrMo fork, Shimano Deore LX, $636
1992 Chill, Easton E9 aluminum, CrMo fork, Shimano Deore DX, $782
1992 Peak, Easton E9 aluminum, aluminum fork, Shimano Deore XT, $1094
1992 Sheer, Easton E9 aluminum w/carbon fibre wrap, Rock Shox Mag 20, Shimano Deore XT, $1552

Hybrid:

1992 Dash AL, 6061 T8 aluminum w/CrMo stays and forks, Shimano 300LX, $460
1992 Dash MAX, 6061 T8 aluminum w/CrMo stays and forks, Shimano 500CX, $545
T-Mar is offline   Reply With Quote
Old 10-03-17, 05:18 PM   #58
Aubergine
Senior Member

Join Date: Nov 2015
Location: Seattle and Reims
Bikes: Too many to list
Posts: 1,170
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 196 Post(s)
This one was donated to our bike co-op recently. It looks like it is original except for the seat. Remarkably clean too!





EDITED TO ADD THE SERIAL NUMBER: R808560130

Last edited by Aubergine; 10-08-17 at 03:44 PM.
Aubergine is offline   Reply With Quote
Old 10-03-17, 05:25 PM   #59
thumpism
Bikes are okay, I guess.

thumpism's Avatar

Join Date: Jan 2015
Location: Richmond, Virginia
Bikes: Waterford Paramount Touring, Bridgestone RB-T, Trek 510 city build, Giant CFM-2, Raleigh Sports 3-speeds in M23 L23 and L19, Schwinn Cimarron oddball build, Raleigh DL-1
Posts: 2,952
Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Here's a Reynolds 531 Technium at our local co-op. Unfortunately, it's been hit in front and you can see wrinkles in the top and town tubes back from the head tube. Shame.

thumpism is offline   Reply With Quote
Old 10-03-17, 05:57 PM   #60
Lascauxcaveman
Senior Member
Thread Starter

Lascauxcaveman's Avatar

Join Date: Nov 2011
Location: Port Angeles, WA
Bikes: A green one, "Ragleigh," or something.
Posts: 5,909
Mentioned: 105 Post(s)
Tagged: 0 Thread(s)
Quoted: 709 Post(s)
@Aubergine @thumpism: if you get a chance, note the serial numbers on those bikes and edit them into your posts, for posterity.
__________________
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1972 Peugeot UE-18 Mixte ● 1980 Apollo "Legnano" ● 1982 Bianchi Limited ● 1984 Nishiki Landau ● 1984 Peugeot Vagabond ● 1985 Trek 600 ● 1985 Shogun Prairie Breaker ● 1986 Univega Nuovo Sport ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Trek 400 ● 1990 Cannondale ST600 ● 1990 Technium Pro ● 1993 Technium RT600 ● 1996 Kona Lava Dome ● And a Bike to Be Named Later ●
Lascauxcaveman is offline   Reply With Quote
Old 10-03-17, 06:04 PM   #61
Aubergine
Senior Member

Join Date: Nov 2015
Location: Seattle and Reims
Bikes: Too many to list
Posts: 1,170
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 196 Post(s)
Quote:
Originally Posted by Lascauxcaveman View Post
@Aubergine @thumpism: if you get a chance, note the serial numbers on those bikes and edit them into your posts, for posterity.
Oh, good idea. I will be back in the co-op Thursday and will look for it then.
Aubergine is offline   Reply With Quote
Old 10-04-17, 05:30 PM   #62
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Quote:
Originally Posted by Aubergine View Post
This one was donated to our bike co-op recently. It looks like it is original except for the seat. Remarkably clean too!
I actually put a deposit on one of those pinkish/purplish ones back around '88. I couldn't complete the purchase, though. I think the white saddle goes good with the bike frame and bar tape. Silver, polished rack would be better, in my eyes, though.
1989Pre is offline   Reply With Quote
Old 10-04-17, 05:33 PM   #63
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Quote:
Originally Posted by Chuckk View Post
What a long wheelbase!

Mine is a 58cm, and the wheelbase is 1004 with a 38mm rake fork, which is pretty average. If you want to shorten yours, you can use dropout adjusters.
The Tech 440's had 27" wheels. Raleigh USA didn't change to 700c till 1988.
1989Pre is offline   Reply With Quote
Old 10-04-17, 07:41 PM   #64
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Quote:
Originally Posted by Chuckk View Post
Mine's a 23" (58cm) 440 and the wheelbase is 41" 1045!

Yep, I just re-measured and I got 39.5 inches, which is 1004mm. The relatively laid-back geometry on the older (86-87) Techniums, the 27" wheels, the presence of eyelets on the bottom of the seat stays, and the softer aluminum (6013-T6) suggests that in the first two years, Raleigh USA was gearing the Techniums more toward the recreational/sport rider than something specifically built for speed.
The pics I originally posted of my Technium were shot in the dark and not particularly appealing, so I thought I'd send some outdoor snaps along, especially to compare side-view geometry with Chuc's:
Attached Images
File Type: jpg Techfront10-05-17-min.jpg (98.7 KB, 179 views)
File Type: jpg Techrear10-05-17-min.jpg (99.6 KB, 178 views)
File Type: jpg Techleft10-05 -17-min.jpg (98.5 KB, 179 views)
File Type: jpg Techright10-05-17-min.jpg (98.4 KB, 177 views)

Last edited by 1989Pre; 10-05-17 at 12:53 PM.
1989Pre is offline   Reply With Quote
Old 10-05-17, 02:52 PM   #65
jimjim58
Member

Join Date: Aug 2017
Location: Central oHIo
Bikes: '18 Trek Domane SL6
Posts: 29
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
jimjim58 is offline   Reply With Quote
Old 10-05-17, 04:58 PM   #66
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Quote:
Originally Posted by jimjim58 View Post
I think the head is 72 degrees and seat tube 73. Touring bike geometry on something looking like a sport bike?

That's pretty close to parallel, so you can storm with this bike if you want. I think its more of a roadie than a tourer.

I'm wondering about the development history. Was the Technium idea from Huffy during their license, did they buy it the technology or did Derby create the technique and Kent factory?
The way I (currently) understand it is that the Techniums came out during the Derby ownership, not the Huffy one.

Those blue Tech 440's are beautiful-looking bikes. How do you like the ride?
1989Pre is offline   Reply With Quote
Old 10-05-17, 07:28 PM   #67
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Regarding the Derby ownership of Raleigh USA in 86-87, yes, I see what you are saying about tooling up and drawing plans for such an innovative bike. The Olympic cycle team that won several medals on Techniums did it in '84, but I have heard that these were Italian-designed and built. I would like to know more about these olympic bikes.



Quote:
Originally Posted by Chuckk View Post
One ride around the neighborhood and I'm thinking meh. Maybe it will change after a couple hundred miles.
When I first rode my Technium, I noticed that it did not give the feedback and ride with the "personality" of my previous bike, an '80 Raleigh Gran Prix. The ride was not as responsive or "lively". On my long rides, though, I am not looking for personality: I only want lightness, good energy return and nimbility, and I get those things and more from the Technium. The weight trade-off is worth it, and I think that's what Raleigh was going for. I'm not sure if the steel parts of the bicycle translate into a nicer ride, but it is very likely that they do to some extent.
1989Pre is offline   Reply With Quote
Old 10-12-17, 06:00 PM   #68
abshipp
Senior Member

Join Date: Sep 2017
Location: Rockford IL
Bikes: 77 Schwinn Super Le Tour 12.2 Chrome, 85 Schwinn Mirada, 85 Schwinn Tempo, 89 Raleigh Technium Pre, 2017 GT Karakoram Comp
Posts: 85
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 24 Post(s)
Finally got to go on a ride with my new 89 Pre.

First 15 mile impressions:

-Feels fast!
-Very smooth ride, much more so than my other aluminum bike, a 2012 Jamis. That one is a bit of a boneshaker.
-Need more saddle setback, I'm hoping it's not too hard to find a seatpost that will help with that
-Friction shifting across the 8 speed cassette worked great!
-Shifting up in to the big ring is a bit lethargic
-I really like it

abshipp is offline   Reply With Quote
Old 10-13-17, 08:03 PM   #69
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Quote:
Originally Posted by Chuckk View Post
Has anybody thought about the assembly process on the Technium frames? Normally you would build the front triangle and then assemble the rear triangle. But, if you brazed it together, you would be heating up the BB and seat lug red hot after gluing!
Silver solder and it wouldn't be quite as hot, but the dropout is still brazed, so that would be three processes.
The 440 uses socketed seat stay caps, so it could be bonded, but the CityLite has the seat stays brazed to the sides of the seat lug.
My MT500 up on the first page could have had the rear triangle brazed up, then the top and down tubes jigged and glued, mitered, and the head tube welded. But how could they have done the earlier ones efficiently?
I have heard that they heated the lugs and then inserted the maintubes, which had a locking collar of sorts that "snapped" into place. I'll see if I can find the diagram for you. So, not only was the flux part of the bonding, but the locking ring on the lugs and the contraction of the lugs created a solid fit. I'm not sure what you are saying about the brazing of the stays onto the mainframe. The bb and lugs are steel, so it was no problem, as long as they kept the aluminum below melting temperature. I would love to find out everything about the process. The Technium should have had an article of its own in Popular Mechanics.
1989Pre is offline   Reply With Quote
Old 10-13-17, 08:07 PM   #70
1989Pre
Standard Member

Join Date: Apr 2009
Bikes:
Posts: 2,710
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 679 Post(s)
Quote:
Originally Posted by abshipp View Post
Finally got to go on a ride with my new 89 Pre.

First 15 mile impressions:

-Feels fast!
-Very smooth ride, much more so than my other aluminum bike, a 2012 Jamis. That one is a bit of a boneshaker.
-Need more saddle setback, I'm hoping it's not too hard to find a seatpost that will help with that
-Friction shifting across the 8 speed cassette worked great!
-Shifting up in to the big ring is a bit lethargic
-I really like it
I'm glad you like the Technium! Nice wheels. What were you feeling that made you decide you'd like a seatpost with more setback?
1989Pre is offline   Reply With Quote
Old 10-13-17, 11:05 PM   #71
abshipp
Senior Member

Join Date: Sep 2017
Location: Rockford IL
Bikes: 77 Schwinn Super Le Tour 12.2 Chrome, 85 Schwinn Mirada, 85 Schwinn Tempo, 89 Raleigh Technium Pre, 2017 GT Karakoram Comp
Posts: 85
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 24 Post(s)
Quote:
Originally Posted by 1989Pre View Post
I'm glad you like the Technium! Nice wheels. What were you feeling that made you decide you'd like a seatpost with more setback?
Thanks,

The wheels aren't exactly what I want to use on this forever, but I needed a wheelset and they were an absolute steal at $50 for a ~1600g wheelset with two sets of tires and a big box of goodies.

I feel like I need some more setback because in order to get proper pelvis rotation I have to be sitting almost on the back edge of the saddle. I may try a bit higher nose before I buy parts, but getting the right saddle position is always a struggle for my anatomy it seems.
abshipp is offline   Reply With Quote
Old 10-17-17, 10:08 AM   #72
abshipp
Senior Member

Join Date: Sep 2017
Location: Rockford IL
Bikes: 77 Schwinn Super Le Tour 12.2 Chrome, 85 Schwinn Mirada, 85 Schwinn Tempo, 89 Raleigh Technium Pre, 2017 GT Karakoram Comp
Posts: 85
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 24 Post(s)
Anyone have any tips for keeping the rear brake housing from bouncing around inside the top tube?

Rougher roads have been generating a rather annoying recurring *ping*. Honestly, it wouldn't bother me much, but the drivetrain is totally silent, so every little noise jumps out at me.

If I'm able to solve this little problem, it will be the quietest bike I have ever ridden (maybe aside from my old fixed gear).
abshipp is offline   Reply With Quote
Old 11-11-17, 02:18 PM   #73
rodteague
Enjoying the ride

rodteague's Avatar

Join Date: Nov 2017
Location: Tennessee
Bikes: 1986 Raleigh Technium 440, 1989 Bianchi Alante, 1991 Specialized Sirrus
Posts: 100
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 47 Post(s)
Here is my 1986 440

I found scans of the 1986 catalog and it appears some of the components were changed. My hubs are Maillard(rear stamped "25" "86" so it's correct for year of mfg) and the catalog lists they should be Suntour. Shifters, front and rear detailers should be Suntour but are Shimano. Crank/BB, freewheel, pedals, rims, bar/stem, headset, seat post and brakes are correct. She even had all the reflectors on the frame, pedals and wheels. When removing components and bagging them, it appeared they had never been moved or replaced. I had no doubts to it's "virginity" until I found the catalog. I suspect that since this is a very early model; component groups may have been substituted, much like Ford used to do. i suppose however, there is no way to verify it. The seat and tires were the only two parts that I know for sure were not original. Otherwise she looked pristine. I converted her to a single speed and I love it. It has become one of my favorite bikes I've ever owned. She has great curb appeal and the classic Raleigh aesthetic.










The current rear hub is a Shimano 600 UG; the Maillard is being repurposed for a trailer build I currently have in progress. I left the front Maillard hub untouched

Best Regards

Rod

Last edited by rodteague; 11-12-17 at 08:59 PM.
rodteague is offline   Reply With Quote
Old 11-14-17, 03:35 AM   #74
rodteague
Enjoying the ride

rodteague's Avatar

Join Date: Nov 2017
Location: Tennessee
Bikes: 1986 Raleigh Technium 440, 1989 Bianchi Alante, 1991 Specialized Sirrus
Posts: 100
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 47 Post(s)
Quote:
Originally Posted by jimjim58 View Post
Your bike appears to be the same year as mine. Would it be possible to list your components? I'd be interested to know if your 440 has Maillard hubs and shimano shifters and deraillers.

Thanks

Rod
rodteague is offline   Reply With Quote
Old 11-14-17, 06:27 PM   #75
jimjim58
Member

Join Date: Aug 2017
Location: Central oHIo
Bikes: '18 Trek Domane SL6
Posts: 29
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Quote:
Originally Posted by rodteague View Post
Your bike appears to be the same year as mine. Would it be possible to list your components? I'd be interested to know if your 440 has Maillard hubs and shimano shifters and deraillers.

Thanks

Rod
Suntour shifters & derailleurs, hubs have an SR on them.
jimjim58 is offline   Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off



All times are GMT -6. The time now is 07:45 PM.


We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.

  • Ask a Question
    get answers from real people!
Click to start entering your question.
I HAVE A QUESTION
