The classic story of...Schwinnderella

So last fall, I followed the stories of RHM's and NLerner's frame modifications by Gugie with great interest. For some time, I'd been looking for a way to update and modify an older Schwinn Voyageur frame to fit 650B wheels and more modern (or at least more effective) brakes. I shopped the idea around to a few frame builders, but none seemed all that excited about working on what is, after all, a production frame. However, with his experience and enthusiasm for similar projects, Gugie (Mark) looked like the perfect choice.


In early December, a frame came up on the Minneapolis CL- a teal green '88-89 that was listed here on the forum. ChromeMolly (Pete) was kind enough to facilitate the purchase and ship me the frame. I checked it here for dents and rust, tapped the threads to make sure they were solid, but to be honest, it was in pretty sad shape. Wish I had taken some pictures of it back then, because I wondered if it was a good deal even for $100.


So, of it went to Gugie. This is the first picture I got back:





Followed by:



Pretty grim, but shortly thereafter, things began to look up:

__________________
Hard at work in the Secret Underground Laboratory...
rccardr is offline
Old 03-22-17, 08:00 AM
  #2
rccardr
aka: Dr. Cannondale
Thread Starter

rccardr's Avatar

Join Date: Jul 2009
Posts: 6,339

Bikes: Lots. Just...lots.

Mentioned: 176 Post(s)
Tagged: 0 Thread(s)
Quoted: 1474 Post(s)
Liked 726 Times in 363 Posts
Gugie proceeded to change the mounting posts for RAID centerpulls and modify the fork:






And then clean everything up in preparation for powder coating:






Still to come: Schwinnderella gets new clothes!
__________________
Hard at work in the Secret Underground Laboratory...
rccardr is offline
Old 03-22-17, 08:11 AM
  #3
pastorbobnlnh
Freewheel Medic

pastorbobnlnh's Avatar

Join Date: Oct 2005
Location: Ascending or Descending the NH Mountains NW of Concord!
Posts: 11,563

Bikes: Snazzy* Schwinns, Classy Cannondales, & a Lonely '83 Santana Tandem (* Ed.)

Mentioned: 97 Post(s)
Tagged: 0 Thread(s)
Quoted: 668 Post(s)
Liked 273 Times in 181 Posts
Wow! Customizing existing frames looks to be a whole lot more fun then building new ones! I like! Can't wait to see the build.

Doc, will you need a custom freewheel for this set up?
__________________
Bob
Dreaming about riding in NH's summertime!

Visit my websites:
FreeWheelSpa.com orpastorbobnlnh.com
pastorbobnlnh is offline
Old 03-22-17, 08:31 AM
  #4
Velocivixen
Senior Member

Velocivixen's Avatar

Join Date: Oct 2013
Location: The Great Pacific Northwest
Posts: 4,515
Mentioned: 87 Post(s)
Tagged: 0 Thread(s)
Quoted: 397 Post(s)
Liked 21 Times in 18 Posts
I've been to @gugie's shop and am always amazed by his creative solutions and outstanding workmanship.

Can't wait to see what else evolves with this bike.
Velocivixen is offline
Old 03-22-17, 08:32 AM
  #5
Bianchigirll
Bianchi Goddess

Bianchigirll's Avatar

Join Date: Apr 2009
Location: Shady Pines Retirement Fort Wayne, In
Posts: 27,328

Bikes: Too many to list here check my signature.

Mentioned: 143 Post(s)
Tagged: 2 Thread(s)
Quoted: 1940 Post(s)
Liked 721 Times in 455 Posts
Looks very interesting. So the Voyager was as 27" wheel canti bike? I love the curve of the new stay bridge and the cleverly hidden fender mount.


Does this have or are you going to add those neat little spoke holders?
__________________
Bianchis '90 Proto, '90 Campione del Fausto Giamondi Specialisma Italiano Mundo, '91 Boarala 'cross, '93 Project 3, '86 Volpe, '97 Ti Megatube, '93 Reparto Corse SBX

Others but still loved; '80 Batavus Professional, '87 Cornelo, '?? Jane Doe (still on the drawing board), '90ish Haro Escape SLX Bertoni "Speckled Trout"
Bianchigirll is offline
Old 03-22-17, 08:57 AM
  #6
3speedslow
Senior Member

3speedslow's Avatar

Join Date: Oct 2010
Location: Jacksonville, NC
Posts: 8,617

Bikes: A few

Mentioned: 111 Post(s)
Tagged: 0 Thread(s)
Quoted: 1697 Post(s)
Liked 490 Times in 353 Posts
Eager to see more.

Ditto on the curved brake bridge( or fender bridge now ) Raleigh USA had a few models with those too.

What colour will this be ?
3speedslow is offline
Old 03-22-17, 09:09 AM
  #7
Sir_Name
Senior Member

Sir_Name's Avatar

Join Date: Oct 2013
Location: Connecticut
Posts: 3,246

Bikes: are fun!

Mentioned: 66 Post(s)
Tagged: 0 Thread(s)
Quoted: 412 Post(s)
Liked 308 Times in 131 Posts
What fun! Looking forward to more.

I assume you/Mark may have kept the fork geo stock, correct?
Sir_Name is offline
Old 03-22-17, 12:22 PM
  #8
gugie
Dilberteur at large

gugie's Avatar

Join Date: Jul 2014
Location: Portland, OR
Posts: 9,065

Bikes: It's complicated.

Mentioned: 991 Post(s)
Tagged: 0 Thread(s)
Quoted: 3182 Post(s)
Liked 1,421 Times in 726 Posts
Originally Posted by pastorbobnlnh View Post
Wow! Customizing existing frames looks to be a whole lot more fun then building new ones!
It's also a lot less work!

Originally Posted by Velocivixen View Post
I've been to @gugie's shop and am always amazed by his creative solutions and outstanding workmanship.
Thanks, and I'm waiting for you to pick up a torch sometime...



Originally Posted by Bianchigirll View Post
Looks very interesting. So the Voyager was as 27" wheel canti bike? I love the curve of the new stay bridge and the cleverly hidden fender mount.

Does this have or are you going to add those neat little spoke holders?
Yes, thanks, and sorry, no. If anyone knows a source for the spoke holder bits that double as a chain guard, let me know. I've been looking for some.

Originally Posted by Sir_Name View Post
What fun! Looking forward to more.

I assume you/Mark may have kept the fork geo stock, correct?
Yep, Doc Cannondale told me he was real happy with the way it handled. If it ain't broke...
__________________
If someone tells you that you have enough bicycles and you don't need any more, stop talking to them. You don't need that kind of negativity in your life.
gugie is online now
Old 03-22-17, 03:31 PM
  #9
Sir_Name
Senior Member

Sir_Name's Avatar

Join Date: Oct 2013
Location: Connecticut
Posts: 3,246

Bikes: are fun!

Mentioned: 66 Post(s)
Tagged: 0 Thread(s)
Quoted: 412 Post(s)
Liked 308 Times in 131 Posts
Originally Posted by gugie View Post
Yep, Doc Cannondale told me he was real happy with the way it handled. If it ain't broke...
'Zactly. Nice work!
Sir_Name is offline
Old 03-22-17, 03:37 PM
  #10
The Golden Boy
Extraordinary Magnitude

The Golden Boy's Avatar

Join Date: Aug 2009
Location: Waukesha WI
Posts: 12,593

Bikes: 1978 Trek TX700; 1978/79 Trek 736; 1984 Specialized Stumpjumper Sport; 1984 Schwinn Voyageur SP; 1985 Trek 620; 1985 Trek 720; 1986 Trek 400 Elance; 1987 Schwinn High Sierra; 1990 Miyata 1000LT

Mentioned: 76 Post(s)
Tagged: 0 Thread(s)
Quoted: 2172 Post(s)
Liked 624 Times in 388 Posts
Schwinderella- she left a tire at the ball...
__________________
*Recipient of the 2006 Time Magazine "Person Of The Year" Award*

Commence to jigglin’ huh?!?!

"But hey, always love to hear from opinionated amateurs." -says some guy to Mr. Marshall.
The Golden Boy is offline
Old 03-22-17, 06:09 PM
  #11
uncle uncle
Senior Member

Join Date: Aug 2010
Location: south kansas america
Posts: 1,728

Bikes: too many

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 338 Post(s)
Liked 89 Times in 69 Posts
I like you Doc, because you don't break the rules, you make your own. Awesome.
uncle uncle is offline
Old 03-22-17, 06:20 PM
  #12
rccardr
aka: Dr. Cannondale
Thread Starter

rccardr's Avatar

Join Date: Jul 2009
Posts: 6,339

Bikes: Lots. Just...lots.

Mentioned: 176 Post(s)
Tagged: 0 Thread(s)
Quoted: 1474 Post(s)
Liked 726 Times in 363 Posts
So, the new clothes. From the beginning, I had a vision of what I wanted the finished product to look like: off-white/creamy white finish, with decals, saddle and bar tape of a certain color combination to be revealed later. Since Len no longer does powder coating and Gugie has a powder coater with whom he's been happy, I asked him to pick out a suitable color and have his guy do the work. And I'm glad I did, since this is the picture Gugie sent me after it came back and before it was shipped:





Meanwhile, anyone who's looking for a guide on how to pack and ship a bike can just send a PM to Mark. A week after FedEx picked it up, this showed up at my doorstep (after having been removed from the box/cocoon):



After all of the packing had been pulled off, it was apparent that the frame and brakes had made the cross country trip (it's third) unscathed:




__________________
Hard at work in the Secret Underground Laboratory...
rccardr is offline
Old 03-22-17, 06:32 PM
  #13
rccardr
aka: Dr. Cannondale
Thread Starter

rccardr's Avatar

Join Date: Jul 2009
Posts: 6,339

Bikes: Lots. Just...lots.

Mentioned: 176 Post(s)
Tagged: 0 Thread(s)
Quoted: 1474 Post(s)
Liked 726 Times in 363 Posts
And so, inch by inch, bit by bit, Schwinnderella got dressed. First the crankset, because I wasn't sure what size spindle it would need and if I needed to order one, it had to happen immediately. As it turned out, a cartridge 115mm fit perfectly:





Yep, that's a 50/34/24 triple on a set of vintage Deore crank arms, courtesy of our own Neal Lerner.


After the BB came the headset. I had a 27.0 Shimano 6207 unit saved for just this build, and it fit like a glove:




Then, the shifters. I actually spent a LOT of time juggling parts from various iterations of 6207 friction shifters to some up with ones that would screw into 5mm bolt holes AND look good. That buffing wheel my daughter gave me for Christmas last year came in handy as well:



Then on to the front derailleur, a 28.6 clamping model Deore from the mid 80's:



...and the rear derailleur, also a Deore mid-80's model:



So, moving onward, mounted up the Nitto Technomic stem modified by Gugie to also act as the front brake cable stop, the Nitto Noodle handlebars, and the NOS Shimano 6207 brake levers:




...at which point I had to go pick up my grandson and watch him for the rest of the day. But on the way back home, picked up the custom built wheels.


Tomorrow: Schwinnderella get some lovely new slippers!!
__________________
Hard at work in the Secret Underground Laboratory...

Last edited by rccardr; 03-23-17 at 06:03 AM.
rccardr is offline
Old 03-22-17, 06:38 PM
  #14
Wildwood
Veteran, Pacifist

Wildwood's Avatar

Join Date: Dec 2004
Location: Seattle area
Posts: 10,815

Bikes: Bikes??? Thought this was social media?!?

Mentioned: 243 Post(s)
Tagged: 0 Thread(s)
Quoted: 2700 Post(s)
Liked 1,517 Times in 896 Posts
AKA, Doc Cannondale - how unobservant of me to have missed that until just now. Even a new (to my eyes) avatar.


Congrats on envisioning a new bike in the SUL (Secret Underground Laboratory) and taking the many steps to make it real. It will be worthy - for the singularity alone.


Wonderful work @gugie - nice finish, I know it takes many hours to do it right.


Minor thread diversion
Honestly speaking out:
I think Sir Gugie needs a nick-name embracing the spirit of his bi-cycle-ness.
I would propose: 6 5 0 Bravo. Whoooops - make that MR. 6 5 0 Bravo
Because he's so good at it.


Now back to the thread.

Last edited by Wildwood; 03-22-17 at 06:42 PM.
Wildwood is offline
Old 03-22-17, 06:45 PM
  #15
Wildwood
Veteran, Pacifist

Wildwood's Avatar

Join Date: Dec 2004
Location: Seattle area
Posts: 10,815

Bikes: Bikes??? Thought this was social media?!?

Mentioned: 243 Post(s)
Tagged: 0 Thread(s)
Quoted: 2700 Post(s)
Liked 1,517 Times in 896 Posts
Originally Posted by rccardr View Post
...... with decals, saddle and bar tape of a certain color combination to be revealed later.

Pink?


....because it just sounds like it goes with a Schwinderella


and pink taffeta mudguards


edit: sorry - too many daughters.

Last edited by Wildwood; 03-22-17 at 07:09 PM.
Wildwood is offline
Old 03-23-17, 01:06 AM
  #16
Lascauxcaveman
Senior Member

Lascauxcaveman's Avatar

Join Date: Nov 2011
Location: Port Angeles, WA
Posts: 7,897

Bikes: A green one, "Ragleigh," or something.

Mentioned: 181 Post(s)
Tagged: 0 Thread(s)
Quoted: 1577 Post(s)
Liked 465 Times in 273 Posts
Originally Posted by Velocivixen View Post
I've been to @gugie's shop and am always amazed by his creative solutions and outstanding workmanship.
I, too, have made the pilgrimage (and have an unfinished Bianchi project that has been blessed by his holy torch). But the thing that weirds me out is how eerily clean and organized his shop is. I mean, how can he possibly be getting anything done in there?

@rccardr, that Schwinnderella thing you got going on looks like it's going to be the perfect Cino Heroica machine; fat tires, hill gearing and non-aero brakes. Not that your ride last year was any slouch. See you there next fall?
__________________
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1980 Apollo "Legnano" ● 1984 Peugeot Vagabond ● 1985 Shogun Prairie Breaker ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Trek 400 ● 1989 Bottechia Team ADR replica ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ●
Lascauxcaveman is offline
Old 03-23-17, 05:32 AM
  #17
qcpmsame
Semper Fi

qcpmsame's Avatar

Join Date: Jan 2008
Location: Barrineau Park, Florida
Posts: 12,788

Bikes: 1980 Medici Pro Strada, 1984 Tommasini Prestige, 2012 Cannondale CAAD 10 Ultegra

Mentioned: 88 Post(s)
Tagged: 0 Thread(s)
Quoted: 1134 Post(s)
Liked 193 Times in 152 Posts
Originally Posted by Lascauxcaveman View Post
I, too, have made the pilgrimage (and have an unfinished Bianchi project that has been blessed by his holy torch). But the thing that weirds me out is how eerily clean and organized his shop is. I mean, how can he possibly be getting anything done in there? .....snip
Pope Gugie DXXXI

Bill
__________________
Semper Fi, USMC, 1975-1977

I Can Do All Things Through Him, Who Gives Me Strength. Philippians 4:13


qcpmsame is offline
Old 03-23-17, 09:17 AM
  #18
Wildwood
Veteran, Pacifist

Wildwood's Avatar

Join Date: Dec 2004
Location: Seattle area
Posts: 10,815

Bikes: Bikes??? Thought this was social media?!?

Mentioned: 243 Post(s)
Tagged: 0 Thread(s)
Quoted: 2700 Post(s)
Liked 1,517 Times in 896 Posts
[QUOTE=Lascauxcaveman;19461558]I, too, have an unfinished Bianchi project that has been blessed by his holy torch. Quote]

Yes, we've been patiently waiting........ I have 'befores'.
Wildwood is offline
Old 03-23-17, 02:28 PM
  #19
rccardr
aka: Dr. Cannondale
Thread Starter

rccardr's Avatar

Join Date: Jul 2009
Posts: 6,339

Bikes: Lots. Just...lots.

Mentioned: 176 Post(s)
Tagged: 0 Thread(s)
Quoted: 1474 Post(s)
Liked 726 Times in 363 Posts
So, everybody knows that Schwinnderella needs to get some fancy sneaks so she can look hot at the ball, right? That's why I had local head mech and wheel builder extraordinare Derrick at The Bike Lane lace up these NOS (yep, as in new in the box) Dura Ace 7403 32 hole hubs to a new pair of 650B Velocity A23 rims- the rear one is offset. According to Randos-in-the-know, these are supposed to be about the best/strongest modern 650B rim you can build today:





But we also know that rims do not a wheelset make, and that a neat-O setup like this demands quality. That's why I opted for Compass Babyshoe Pass 650 X 42 tires with Schwalbe inner tubes:





And, finally (well, for today, anyway) you gotta have gears to get around. This 10 speed Shimano 12-34 cassette ought to do the trick:





Tomorrow: cables, housing and finishing touches!
__________________
Hard at work in the Secret Underground Laboratory...

Last edited by rccardr; 03-23-17 at 07:15 PM.
rccardr is offline
Old 03-23-17, 02:33 PM
  #20
Chrome Molly
Senior Member

Chrome Molly's Avatar

Join Date: Jan 2012
Location: Forksbent, MN
Posts: 3,271

Bikes: Yes

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 301 Post(s)
Likes: 0
Liked 12 Times in 12 Posts
It is very hard to recognize in comparison to what I picked up for you on that windy below zero day last winter. To be honest I thought you would be disappointed with it, but considering it was straight I didn't try to talk you out of it.

I wondered how you would deal with the rust on all the cable eyes and around the bottom bracket. I see it was all filed off (beats OA).

Looking very top shelf now, and digging all the new braze ons!
Chrome Molly is offline
Old 03-23-17, 04:20 PM
  #21
TenGrainBread
Senior Member

TenGrainBread's Avatar

Join Date: Sep 2015
Location: Madison, WI
Posts: 2,589

Bikes: Cherubim, Alps, a few Schwinns

Mentioned: 52 Post(s)
Tagged: 0 Thread(s)
Quoted: 1070 Post(s)
Liked 393 Times in 252 Posts
Can't wait for the finished product. Wheels/tires are perfect.
TenGrainBread is offline
Old 03-23-17, 04:24 PM
  #22
3speedslow
Senior Member

3speedslow's Avatar

Join Date: Oct 2010
Location: Jacksonville, NC
Posts: 8,617

Bikes: A few

Mentioned: 111 Post(s)
Tagged: 0 Thread(s)
Quoted: 1697 Post(s)
Liked 490 Times in 353 Posts
Leave it to Schwinn to make headbadges easy to remove and replace. One less aggravation!

Looking spectacular, frame and parts.
3speedslow is offline
Old 03-23-17, 04:24 PM
  #23
corrado33
Senior Member

Join Date: Jun 2013
Location: Bozeman
Posts: 4,094

Bikes: 199? Landshark Roadshark, 198? Mondonico Diamond, 1987 Panasonic DX-5000, 1987 Bianchi Limited, Univega... Chrome..., 1989 Schwinn Woodlands, Motobecane USA Record, Raleigh Tokul 2

Mentioned: 25 Post(s)
Tagged: 0 Thread(s)
Quoted: 1129 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Super pretty but...

10 speed with friction?
corrado33 is offline
Old 03-23-17, 07:20 PM
  #24
rccardr
aka: Dr. Cannondale
Thread Starter

rccardr's Avatar

Join Date: Jul 2009
Posts: 6,339

Bikes: Lots. Just...lots.

Mentioned: 176 Post(s)
Tagged: 0 Thread(s)
Quoted: 1474 Post(s)
Liked 726 Times in 363 Posts
Yep, 10 speed friction is the bees knees. Small lever movements get you into the next gear change, HG cassette with a 10 speed chain shifts effortlessly. I tried this maybe 6-7 years ago and loved it, always regretted selling that bike.

If you ride friction a lot, it takes maybe 5 minutes to get it down pat.

Meanwhile, got it all cabled up today, put on the decals, hand painted the lug lining. Had to do some bottom bracketage to get the chainline set up correctly, but it now shifts up and down thru the triple pretty well. Have some braking issues to resolve, but parts are on the way!
__________________
Hard at work in the Secret Underground Laboratory...

Last edited by rccardr; 03-23-17 at 07:23 PM.
rccardr is offline
Old 03-23-17, 10:00 PM
  #25
Jeff Wills
Insane Bicycle Mechanic

Jeff Wills's Avatar

Join Date: Mar 2008
Location: other Vancouver
Posts: 9,501
Mentioned: 31 Post(s)
Tagged: 0 Thread(s)
Quoted: 660 Post(s)
Liked 293 Times in 191 Posts
Originally Posted by rccardr View Post
[/URL]

Yep, that's a 50/34/24 triple on a set of vintage Deore crank arms, courtesy of our own Neal Lerner.
Hmm... be prepared for adjustments to that setup. A smaller-than-usual middle chainring can mean that the front derailleur will push the chain onto the big chainring when trying to shift from the granny to the middle. These chainrings might work with older chains (which were stiffer laterally). With a flexible 10-speed chain and an old front derailleur... I don't know. I'd be prepared to change the middle to a 38 tooth. Another possibility it a Shimano 36-tooth ring with "Hyperdrive" pick-up teeth... but that may not work with 10-speed chain.

As I said- hmmm...
__________________
Jeff Wills

Comcast nuked my web page. It will return soon..
Jeff Wills is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright © 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
