Modolo Professional stem failures > Help me get this straight

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Modolo Professional stem failures > Help me get this straight

Old 04-25-17, 12:29 PM
  #1
billytwosheds
Senior Member
Thread Starter

billytwosheds's Avatar

Join Date: Aug 2015
Location: Honolulu, HI
Posts: 959

Bikes: Peugeot, Legnano, Fuji, Zunow, De Rosa, Miyata, Bianchi, Pinarello, Specialized, Bridgestone

Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 281 Post(s)
Liked 131 Times in 69 Posts
Modolo Professional stem failures > Help me get this straight

Over in the C&V appraisals, it was mentioned that a stem on one of the bikes was one of the infamous failing Modolo stems from the late 80's / early 90's.

It just so happens that I have a similar stem going on a build right now...

So after some Internet research, I'm nailing down the details of which stem(s) were risky (if not all of the Modolo's of this period).

John Allen wrote up a whole article on why this design fails:

Hazardous bicycle handlebar stems

Here's a pic of a failed Modolo stem from his article:



A note on the Velobase page for Modolo Flash suggests that only a few stems in the line were recalled:

VeloBase.com - Component: Modolo Flash

The Professional was recalled, not the Flash. The design was changed to have less of a V underneath and put more material around the weak point of the countersunk bolt underneath. The photo is of a beefier model. John Allen has a photo of the breaky model on his site.
And then this recall notice (1990) suggests there were reinforced replacement stems that can be identified:



So assuming the stem I have is one of the recalled models, I'll just be taking it off.

But if it's a reinforced/replacement model, am I taking an unnecessary risk by using it?

FWIW no aero bars are in use (which were noted as a common stress-increasing issue for these stems in particular.

TIA
billytwosheds is offline
Old 04-25-17, 12:41 PM
  #2
Chombi1
Senior Member

Chombi1's Avatar

Join Date: Nov 2015
Posts: 3,438
Mentioned: 94 Post(s)
Tagged: 0 Thread(s)
Quoted: 1222 Post(s)
Likes: 0
Liked 250 Times in 185 Posts
Not sure if it has something to do with the failures, but I noticed that unlike most other similar aero style stems from the mid 80's, the Modolos had the upended seam at the clamp on the top of the stem, while the others had it at the bottom. Their design is a bit counterintuitive and frankly, not so attractive, but maybe they did such so as not to end up copying other manufacturer's aero stem designs.
Doing such takes a lot of material off from both top and bottom of the clamp area of the stem which I think could have caused the failures. Seems like Modolos fix was just to add more material at the bottom of the stem where the bolt goes through. I guess the fix worked, but resulted in a heavier stem design.

Last edited by Chombi1; 04-25-17 at 02:25 PM.
Chombi1 is offline
Old 04-25-17, 02:18 PM
  #3
billytwosheds
Senior Member
Thread Starter

billytwosheds's Avatar

Join Date: Aug 2015
Location: Honolulu, HI
Posts: 959

Bikes: Peugeot, Legnano, Fuji, Zunow, De Rosa, Miyata, Bianchi, Pinarello, Specialized, Bridgestone

Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 281 Post(s)
Liked 131 Times in 69 Posts
Originally Posted by Chombi1 View Post
Seems like Modolos fix was just to add more material at the boll Tom of the stem where the bolt goes through. I guess the fix worked, but resulted in a heavier stem design.
Yeah, that sounds about right.

Turns out mine is the weaker original version, and I eyeballed a hairline crack on one side of the clamp after closer inspection. The bike was put on hold after failing to get Sheldon's alternative cable routing working on a 10spd shifter / 9spd cassette, but maybe it's better I didn't ride it after all!

Yikes.
billytwosheds is offline
Old 04-25-17, 05:40 PM
  #4
Wildwood
Veteran, Pacifist

Wildwood's Avatar

Join Date: Dec 2004
Location: Seattle area
Posts: 10,984

Bikes: Bikes??? Thought this was social media?!?

Mentioned: 247 Post(s)
Tagged: 0 Thread(s)
Quoted: 2782 Post(s)
Liked 1,678 Times in 965 Posts
I may have a Speedy with the narrower stem. Closer inspection with magnifying glass required.
Wildwood is online now
Old 04-25-17, 06:26 PM
  #5
tyler_fred
Senior Member

tyler_fred's Avatar

Join Date: Nov 2010
Location: Magnolia State, 100 with 110% humidity
Posts: 1,264

Bikes: American, Italian, and Japanese.. in no particular order.

Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 342 Post(s)
Liked 245 Times in 115 Posts
My two cents...
I've been using a 130mm X-Eras stem for over 20 years with no symptoms such as creaking or stress fractures. The X-Eras is one of the good stems.
tyler_fred is offline
Old 04-26-17, 05:48 AM
  #6
Deal4Fuji
minimalist cyclist

Deal4Fuji's Avatar

Join Date: Mar 2014
Location: North Carolina
Posts: 1,448

Bikes: '82 Fuji Supreme, '83 Raleigh Olympian, '87 Lotus Excelle, '85 Centurion Ironman, '75 Schwinn Continental, '73 Raleigh Grand Prix, '84 Trek 500/400, '89 Schwinn Le Tour, '86 Bianchi Sport SX '12 Trek Alpha 1.1, Ross Central Park

Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 907 Post(s)
Liked 857 Times in 562 Posts
I recently acquired a Modolo stem in a parts box that came with the Ochsner I bought for my daughter. The stem I have is pictured below and I believe the one on Liz's bike looks the same, but she's away at school. All this has me thinking that the one I have may be the recalled stem, although it doesn't look like it from the 1st post. I especially don't want her's to be a potential safety issue....I'll get her to send me a photo when she can.

Does this look like a problem stem ?

Deal4Fuji is online now
Old 04-26-17, 09:25 AM
  #7
Chombi1
Senior Member

Chombi1's Avatar

Join Date: Nov 2015
Posts: 3,438
Mentioned: 94 Post(s)
Tagged: 0 Thread(s)
Quoted: 1222 Post(s)
Likes: 0
Liked 250 Times in 185 Posts
If there is a flat strip running along the bottom of the stem extension, it would be the recalled stem. If it is smooth and rounded from side to side, then you have the improved/safe stem.

Last edited by Chombi1; 04-26-17 at 04:47 PM.
Chombi1 is offline
Old 04-26-17, 11:34 AM
  #8
tyler_fred
Senior Member

tyler_fred's Avatar

Join Date: Nov 2010
Location: Magnolia State, 100 with 110% humidity
Posts: 1,264

Bikes: American, Italian, and Japanese.. in no particular order.

Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 342 Post(s)
Liked 245 Times in 115 Posts
The one of the left is a recall stem. Notice how thin the edges leading up to the counterbore are?
The stem on the right has more metal surrounding the counterbore, thus safe(r).

Modolo stem comparison.jpg
tyler_fred is offline
Old 04-26-17, 11:51 AM
  #9
billytwosheds
Senior Member
Thread Starter

billytwosheds's Avatar

Join Date: Aug 2015
Location: Honolulu, HI
Posts: 959

Bikes: Peugeot, Legnano, Fuji, Zunow, De Rosa, Miyata, Bianchi, Pinarello, Specialized, Bridgestone

Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 281 Post(s)
Liked 131 Times in 69 Posts
Originally Posted by Deal4Fuji View Post
Does this look like a problem stem ?
This looks like a newer or replacement stem -- it's pretty rounded and doesn't have the harder edges of the recalled version.
billytwosheds is offline
Old 04-26-17, 02:59 PM
  #10
Deal4Fuji
minimalist cyclist

Deal4Fuji's Avatar

Join Date: Mar 2014
Location: North Carolina
Posts: 1,448

Bikes: '82 Fuji Supreme, '83 Raleigh Olympian, '87 Lotus Excelle, '85 Centurion Ironman, '75 Schwinn Continental, '73 Raleigh Grand Prix, '84 Trek 500/400, '89 Schwinn Le Tour, '86 Bianchi Sport SX '12 Trek Alpha 1.1, Ross Central Park

Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 907 Post(s)
Liked 857 Times in 562 Posts
Originally Posted by billytwosheds View Post
This looks like a newer or replacement stem -- it's pretty rounded and doesn't have the harder edges of the recalled version.
Originally Posted by tyler_fred View Post
The one of the left is a recall stem. Notice how thin the edges leading up to the counterbore are?
The stem on the right has more metal surrounding the counterbore, thus safe(r).
Thanks guys - I may be back when I can get a photo of my daughter's, if I can't tell from the info you gave me
Deal4Fuji is online now
Old 04-26-17, 03:58 PM
  #11
exmechanic89
Senior Member

exmechanic89's Avatar

Join Date: May 2015
Location: Richmond VA area
Posts: 2,713

Bikes: '00 Koga Miyata Full Pro Oval Road bike.

Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 475 Post(s)
Likes: 0
Liked 4 Times in 4 Posts
Originally Posted by billytwosheds View Post
Yeah, that sounds about right.

Turns out mine is the weaker original version, and I eyeballed a hairline crack on one side of the clamp after closer inspection. The bike was put on hold after failing to get Sheldon's alternative cable routing working on a 10spd shifter / 9spd cassette, but maybe it's better I didn't ride it after all!

Yikes.
Wow, that was close. Sounds like it would've definitely failed, could've been a major crash.
exmechanic89 is offline
Old 04-26-17, 09:57 PM
  #12
billytwosheds
Senior Member
Thread Starter

billytwosheds's Avatar

Join Date: Aug 2015
Location: Honolulu, HI
Posts: 959

Bikes: Peugeot, Legnano, Fuji, Zunow, De Rosa, Miyata, Bianchi, Pinarello, Specialized, Bridgestone

Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 281 Post(s)
Liked 131 Times in 69 Posts
My thoughts indeed, @exmechanic89.

Here's the stem I just removed from the build:



Note the hard edges, pretty sure it's a bad one.



And the crack is visible here:



Either way, I'm glad it's not on a bike. It'd be fine on a trainer. Oh well.
billytwosheds is offline
Old 04-27-17, 09:08 AM
  #13
rowebr
Senior Member

rowebr's Avatar

Join Date: Apr 2011
Location: Washington DC
Posts: 334

Bikes: 1981 Bianchi Limited 650B conversion (sold), 1985(?) Guerciotti retro-roadie, 2018 Specialized Allez Sprint, 2012 Specialized Crux, mid 80's Focus MB-400

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 67 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by billytwosheds View Post
My thoughts indeed, @exmechanic89.

Here's the stem I just removed from the build:



Note the hard edges, pretty sure it's a bad one.



And the crack is visible here:



Either way, I'm glad it's not on a bike. It'd be fine on a trainer. Oh well.

Holy ****. Thank you for this thread! Hopefully lots of people here will see this and be informed about the problem.
rowebr is offline
Old 04-27-17, 09:25 PM
  #14
fleslider
Senior Member

fleslider's Avatar

Join Date: Feb 2014
Location: Fort Collins, CO
Posts: 1,476

Bikes: 1974 Paramount ~ 1974 Raleigh Pro ~ 1977 Pro-Tour ~ 1978 TX900 ~ IronMan 85,87:E/M,88:M/Pro,89:E ~ 98 Peugeot Festina Replica

Mentioned: 86 Post(s)
Tagged: 0 Thread(s)
Quoted: 468 Post(s)
Liked 100 Times in 62 Posts
@tuna , check your Quantum
fleslider is offline
Old 04-27-17, 09:38 PM
  #15
wgscott
Occam's Rotor

Join Date: Jul 2013
Posts: 7,133
Mentioned: 61 Post(s)
Tagged: 0 Thread(s)
Quoted: 2366 Post(s)
Liked 2,232 Times in 1,111 Posts
I continued to ride mine (1987) until a year or two ago, completely ignorant of the recall until then. It provided the main motivation to update my component set (and I used a Nitto stem and bars -- less authentic, I guess, but hopefully less potentially harmful).
wgscott is offline
Old 04-30-17, 08:19 PM
  #16
tuna
The Uberclydesdale

tuna's Avatar

Join Date: Apr 2009
Location: Laramie, WY
Posts: 44

Bikes: 1993 Cannondale M700, 1998 Cannondale Multisport 1000, 1997 Klein Pulse Pro, 1990 Klein Pinnacle Elite, 1989 Klein Quantum, 1987 Schwinn Super Sport

Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked 0 Times in 0 Posts
Originally Posted by fleslider View Post
@tuna , check your Quantum
Thanks @fleslider

I will take a look at mine, it is about that age.

I might have to get a vintage Cinelli bar/stem for that bike.
tuna is offline
