Is there a bottom bracket cartridge that will work?

Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Is there a bottom bracket cartridge that will work?

Old 04-29-19, 04:43 PM
  #26
repechage
Senior Member

Join Date: Jun 2006
Posts: 13,341
Mentioned: 77 Post(s)
Tagged: 0 Thread(s)
Quoted: 936 Post(s)
Likes: 0
Liked 13 Times in 11 Posts
Ditch the spacer on the drive side, add it to the other side if you must.
I think though that the chainline is all out of whack, why it wont shift.
As there is no chain, what you need to do is get a 24" long straight edge, a framing square at hand?
position it against the inside surface of the large chainring, extending over the cogs, the backside of that square should be essentially at the resting over the middle of the rear cogs, no matter the number of them.
I bet it is to the outside, that difference, is the amount closer the drive side crank needs to be to the centerline of the bike.
repechage is offline
Old 04-29-19, 06:06 PM
  #27
mmcc73
Senior Member
Thread Starter

Join Date: Apr 2013
Posts: 122
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 23 Post(s)
Liked 1 Time in 1 Post
The chain line was indeed pretty bad. I removed the spacer from the drive side and put it on the non drive side (BB wouldn't thread all the way on my 66mm shell without it). My front derailleur now seems to have enough range to move the chain to the big chain ring, based on visual analysis. However, the line from big chainring to rear cogs (there are 5) hits between the smallest and second smallest cogs.

So, not optimal. But maybe good enough?

If not, I could get another UN55 with a 118mm spindle (I'm currently at 122.5mm). I think I have 2mm to spare on either side.
mmcc73 is offline
Old 04-29-19, 06:55 PM
  #28
madpogue
Senior Member

Join Date: Jan 2004
Location: Madison, WI USA
Posts: 2,864
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 652 Post(s)
Liked 49 Times in 42 Posts
I always thought the "big chainring" rule applied only to doubles, that with triples, you line up the middle chainring with the middle cog. Is that about where you are?
madpogue is offline
Old 04-29-19, 07:04 PM
  #29
mmcc73
Senior Member
Thread Starter

Join Date: Apr 2013
Posts: 122
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 23 Post(s)
Liked 1 Time in 1 Post
Originally Posted by madpogue View Post
I always thought the "big chainring" rule applied only to doubles, that with triples, you line up the middle chainring with the middle cog. Is that about where you are?
I have a double.
mmcc73 is offline
Old 04-29-19, 07:08 PM
  #30
madpogue
Senior Member

Join Date: Jan 2004
Location: Madison, WI USA
Posts: 2,864
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 652 Post(s)
Liked 49 Times in 42 Posts
^^^^^ Duh, as the photo above, which I COMPLETELY ignored, clearly illustrates. Ooopsieeee.....
madpogue is offline
Old 04-29-19, 07:44 PM
  #31
RandolphCarter
Senior Member

RandolphCarter's Avatar

Join Date: Apr 2014
Location: Round Lake. NY
Posts: 231

Bikes: 1986 Trek 310 Elance, 1997 Schwinn HydraGlide, 1987 Trek Antelope 800, 2003 Haro F4, 198? Allsop Offroad Climber

Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 4 Times in 2 Posts
Originally Posted by ryansu View Post
Sometimes working on vintage bikes is like a story problem from middle school math Jimmy has 3 bottom bracket spacers, a cartridge BB and an BSD threaded BB shell, how many beers will it take before Jimmy makes his bike work again? Show your work.
Oooh, this is math I can solve!

All of the beers. Duh.

Here's the work shown:
RandolphCarter is offline
Likes For RandolphCarter:
Old 04-29-19, 08:50 PM
  #32
madpogue
Senior Member

Join Date: Jan 2004
Location: Madison, WI USA
Posts: 2,864
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 652 Post(s)
Liked 49 Times in 42 Posts
^^^^^^ Hmm, whenever I try to solve that kind of math problem, my ability to do math gets worse, and worse, and.....
madpogue is offline
Likes For madpogue:
Old 04-30-19, 02:09 AM
  #33
dddd
Ride, Wrench, Swap, Race

dddd's Avatar

Join Date: Jan 2010
Location: Northern California
Posts: 6,526

Bikes: Cheltenham-Pederson racer, Boulder F/S Paris-Roubaix, Varsity racer, '52 Christophe, '62 Continental, '92 Merckx, '75 Limongi, '76 Presto, '72 Gitane SC, '71 Schwinn SS, etc.

Mentioned: 78 Post(s)
Tagged: 0 Thread(s)
Quoted: 536 Post(s)
Likes: 0
Liked 19 Times in 19 Posts
I would go with a 115mm bottom bracket, and no spacers, assuming your pictured fitment was with the crankarm actually torqued onto the spindle.

It looks like there is a lot of clearance to the chainstay, and changing from the 122mm bb to 115mm will only move in the drive-side crankarm 3.5mm, about an eighth of an inch!
From there, the option would remain to add a drive-side spacer, but not so thick as the one you had on there.

The left-side bb cup doesn't have and doesn't need a real flange on it, it is supposed to bottom out against the cartridge inside of the bb shell, NOT against the left-side face of the bb shell (or the bb cartridge would be left unsupported on it's left end).
So don't add any spacer on the left side.

Your chainline preference really depends on whether you favor use of the small or large chainring. If you favor the big ring most of the time, then the shorter spindle is the better choice as long as the chainrings still clear the chainstay and as long as the front derailer can still pull the chain sufficiently inward with authority sufficient to reliably shift down under at least some pedaling force.

It was very common for lower-to-mid level bikes to have a relatively long chainline dimension as sold, likely because so many beginning riders were unfamiliar with accurately moving their shift levers while riding, with both levers often left in the full-forward position where they couldn't slip and cause chain-grinding noises. So on these bikes that I will ride, I eventually replace the bottom bracket with one that is considerably shorter than the one fitted at the factory.
dddd is offline
Old 04-30-19, 06:05 AM
  #34
Road Fan
Senior Member

Road Fan's Avatar

Join Date: Apr 2005
Location: Ann Arbor, MI
Posts: 14,208

Bikes: 1980 Masi, 1984 Mondonico, 1984 Trek 610, 1980 Woodrup Giro, 2005 Mondonico Futura Leggera ELOS, 1967 PX10E, 1971 Peugeot UO-8

Mentioned: 32 Post(s)
Tagged: 0 Thread(s)
Quoted: 807 Post(s)
Liked 11 Times in 10 Posts
Originally Posted by mmcc73 View Post
Thanks - though I don't know what "offset DS" is. Would you mind explaining that term?
offset on the drive side.
Road Fan is offline
Old 04-30-19, 06:46 AM
  #35
repechage
Senior Member

Join Date: Jun 2006
Posts: 13,341
Mentioned: 77 Post(s)
Tagged: 0 Thread(s)
Quoted: 936 Post(s)
Likes: 0
Liked 13 Times in 11 Posts
Originally Posted by mmcc73 View Post
The chain line was indeed pretty bad. I removed the spacer from the drive side and put it on the non drive side (BB wouldn't thread all the way on my 66mm shell without it). My front derailleur now seems to have enough range to move the chain to the big chain ring, based on visual analysis. However, the line from big chainring to rear cogs (there are 5) hits between the smallest and second smallest cogs.

So, not optimal. But maybe good enough?

If not, I could get another UN55 with a 118mm spindle (I'm currently at 122.5mm). I think I have 2mm to spare on either side.
I would consider that chain line way off. The spindle is too long. Donít eyeball it, measure it.
repechage is offline
Old 05-14-19, 04:03 PM
  #36
mmcc73
Senior Member
Thread Starter

Join Date: Apr 2013
Posts: 122
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 23 Post(s)
Liked 1 Time in 1 Post
Originally Posted by repechage View Post
I would consider that chain line way off. The spindle is too long. Donít eyeball it, measure it.
Measure, eh?

Measure I did, and ended up getting a 110mm spindle. The inner chain ring just barely clears the chain stay, but it does clear, and the chain line looks way better.
mmcc73 is offline
Old 05-14-19, 07:24 PM
  #37
dddd
Ride, Wrench, Swap, Race

dddd's Avatar

Join Date: Jan 2010
Location: Northern California
Posts: 6,526

Bikes: Cheltenham-Pederson racer, Boulder F/S Paris-Roubaix, Varsity racer, '52 Christophe, '62 Continental, '92 Merckx, '75 Limongi, '76 Presto, '72 Gitane SC, '71 Schwinn SS, etc.

Mentioned: 78 Post(s)
Tagged: 0 Thread(s)
Quoted: 536 Post(s)
Likes: 0
Liked 19 Times in 19 Posts
Good call there, I always try for the shortest chainline that still allows the front derailer to downshift with authority!

And if the driveside crankarm ever drifts up the taper, you can just add a 1mm steel fixed-cup spacer.
dddd is offline
