French dilemma

I'm just finishing up a build on my Peugeot Super Competition and decided to ditch the drop bars and go with some kind of upright bar. Well easier said than done I'm finding out since it's impossible to find an upright bar that fits the French stem clamp dimensions which is 25mm. Everything nowadays is 25.4mm I'm finding out. Don't really want to try and shave off .4mm from the bar or stem clamp the idea kind of scares me even though the bike is just an around town single speed. I'm kind of an old guy with some back issues and really don't want to put back those drop bars. Any suggestions out there? Thanks for any input.
Crosse531 is offline
Old 11-09-18, 03:58 PM
  #2
scozim
Ellensburg, WA

scozim's Avatar

Join Date: Aug 2008
Location: Ellensburg, WA
Posts: 3,394

Bikes: See my signature

Mentioned: 56 Post(s)
Tagged: 0 Thread(s)
Quoted: 186 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
I have seen some French stems (22.0 quill) with 25.4 clamp size. That would be your best option. You can also sand down a 22.2 quill stem to fit in the steerer.
__________________
1984 Gitane Sprint; 1984 Gitane Tour de France; 1982 Trek 610; 1968 Peugeot PL8; 1982 Nishiki Marina 12; 1972 Peugeot PX-10; 1987 Trek 800 Antelope (touring/commuting set up); 1993 Trek 950 mtb; 1997 Klein Pulse Comp mtb; 1989 Peugeot Limestone hybrid (for touring); 1975 Gitane Olympic; 1983 Vitus 979; 1989 Spectrum Titanium:

Last edited by scozim; 11-10-18 at 06:36 PM.
scozim is offline
Old 11-09-18, 04:01 PM
  #3
due ruote
Senior Member

due ruote's Avatar

Join Date: Dec 2006
Posts: 6,708
Mentioned: 19 Post(s)
Tagged: 0 Thread(s)
Quoted: 495 Post(s)
Likes: 0
Liked 14 Times in 12 Posts
Sanding down a 22.2mm stem quill to fit a French 22.0 steerer is no big deal. I would do that with a stem that has the clamp size to fit your bars of choice.
due ruote is offline
Old 11-09-18, 04:14 PM
  #4
greg3rd48
Senior Member

greg3rd48's Avatar

Join Date: Aug 2014
Location: Bronx, NYC
Posts: 1,730

Bikes: '19 Fuji Gran Fondo 1.5, '72 Peugeot PX10, '74 Peugeot U08, '78 Fuji Newest, '89 Fuji Ace, '94 Cannondale R600

Mentioned: 67 Post(s)
Tagged: 0 Thread(s)
Quoted: 222 Post(s)
Liked 8 Times in 7 Posts
I have confirmed that these Origin 8 stems do fit in French headsets and have a 25.4 clamp size. I used on a build for a friend a while back.

https://www.modernbike.com/product-2...SABEgL4GPD_BwE


IMG_0651 by irishbx4th, on Flickr
greg3rd48 is offline
Old 11-09-18, 04:18 PM
  #5
greg3rd48
Senior Member

greg3rd48's Avatar

Join Date: Aug 2014
Location: Bronx, NYC
Posts: 1,730

Bikes: '19 Fuji Gran Fondo 1.5, '72 Peugeot PX10, '74 Peugeot U08, '78 Fuji Newest, '89 Fuji Ace, '94 Cannondale R600

Mentioned: 67 Post(s)
Tagged: 0 Thread(s)
Quoted: 222 Post(s)
Liked 8 Times in 7 Posts
This is another option if you wish to use a threadless stem. I picked one up a while back but haven't used it yet. It does fit though!

https://www.bandlbicycles.com/about/...vice-pg348.htm
greg3rd48 is offline
Old 11-09-18, 04:46 PM
  #6
ryansu
Ride.Smile.Repeat

ryansu's Avatar

Join Date: May 2011
Location: Seattle WA
Posts: 1,773

Bikes: 2009 Handsome Devil, 1978 Motobecane Grand Touring, 1987 Nishiki Cresta GT, Former bikes; 1986 Miyata Trail Runner, 1979 Miyata 912, 2011 VO Rando, 1999 Cannondale R800, 2012 Soma Smoothie, 1986 Schwinn Passage

Mentioned: 47 Post(s)
Tagged: 0 Thread(s)
Quoted: 464 Post(s)
Liked 40 Times in 33 Posts
+3 on sanding down a 22.2 stem to fit done it a few times no big deal then you have many bar options -Velo Orange has some very nice city bars and brake levers and thumbie shifter mounts if you want to go whole hog



bars and levers from VO
ryansu is offline
Old 11-09-18, 05:04 PM
  #7
noobinsf
Senior Member

Join Date: Sep 2005
Location: Oakland, CA
Posts: 1,187

Bikes: '04 Felt SR91, '82 Univega Competizione, '72 Motobecane Grand Record, '72 Puch Bergmeister

Mentioned: 30 Post(s)
Tagged: 0 Thread(s)
Quoted: 317 Post(s)
Likes: 0
Liked 17 Times in 14 Posts
Originally Posted by greg3rd48 View Post
I have confirmed that these Origin 8 stems do fit in French headsets and have a 25.4 clamp size. I used on a build for a friend a while back.

https://www.modernbike.com/product-2...SABEgL4GPD_BwE


IMG_0651 by irishbx4th, on Flickr
I can second this — I have two bikes with French-size steerers on which these stems work. I think this stem is also available with a 26.0 clamp, which widens options.

Last edited by noobinsf; 11-09-18 at 06:08 PM.
noobinsf is offline
Old 11-09-18, 06:04 PM
  #8
jcb3
Senior Member

jcb3's Avatar

Join Date: Sep 2014
Location: Irvine, CA
Posts: 570

Bikes: 1983 Trek 700, 1972 Peugeot PX10, 1989 Nishiki Cascade, 2014 Focus Izalco

Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 120 Post(s)
Likes: 0
Liked 3 Times in 3 Posts

+10 - does not take much sanding to fit a std quill into a french fork/headset


jcb3 is online now
Old 11-10-18, 07:10 AM
  #9
rustystrings61
Senior Member

Join Date: May 2013
Location: Greenwood SC USA
Posts: 775

Bikes: 2002 Mercian Vincitore, 1982 Mercian Colorado, 1976 Puch Royal X, 1973 Raleigh Competition, 1971 Gitane Tour de France and others

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 267 Post(s)
Liked 38 Times in 24 Posts
Nitto Technomic stems are often actually 21.9 mm and will fit French steerers without sanding. You may have to open up the headset locknut on some headsets. They come with 24.4 and 26 mm bar clamps.
rustystrings61 is offline
Old 11-10-18, 08:17 AM
  #10
63rickert
Senior Member

Join Date: Dec 2013
Posts: 1,067
Mentioned: 36 Post(s)
Tagged: 0 Thread(s)
Quoted: 486 Post(s)
Likes: 0
Liked 20 Times in 17 Posts
Philippe and Milremo stems @25.4. I have reamed a Pivo (which had lots of metal) to 25.4.
63rickert is offline
Old 11-10-18, 09:04 AM
  #11
verktyg
verktyg

verktyg's Avatar

Join Date: Jul 2006
Location: SF Bay Area
Posts: 2,893

Bikes: Current favorites: 1988 Peugeot Birraritz, 1984 Gitane Super Corsa, 1981 Bianchi Campione Del Mondo, 1992 Paramount OS, 1990 Bianchi Mondiale, 1988 Colnago Technos, 1985 RalieghUSA Team Pro, 1973 Holdsworth

Mentioned: 127 Post(s)
Tagged: 0 Thread(s)
Quoted: 503 Post(s)
Likes: 0
Liked 22 Times in 20 Posts
Nitto Stem Diamter

Originally Posted by rustystrings61 View Post
Nitto Technomic stems are often actually 21.9 mm and will fit French steerers without sanding. You may have to open up the headset locknut on some headsets. They come with 24.4 and 26 mm bar clamps.
Actually no, they are marked 22.2mm but measure 22.1mm. Reason, you can't fit a 22.2mm stem into an accurately sized 22.2mm steerer.

The French standard was a 22.0mm steerer which took a 21.9mm stem. When Cinelli and 3ttt started producing "French" stems in the early 70's they were 22.0mm.

How's that work? Most steerers are not accurately sized and frequently a 22.1mm Nitto stem will fit in a 22.0mm French steerer without any modification.

Clean out all the gunk and rust out of the steerer. Run a hone through the upper half. Rolled up 100 grit emery cloth or sand paper will work too. Take a fine round or half round file an make a slight chamfer inside the top of the steerer. It will remove any burrs and make insertion smoother. Note, remove the top nut before doing any work inside the steerer. When you insert the stem don't tighten the top lock until you've tightened the stem. In some cases you may need to enlarge the hole in the top lock nut.

Nitto used to make 22.0mm (21.9mm) stems for French, Spanish and some Swiss bikes too. They've been discontinued for years.

verktyg
__________________
Things aren't always what they seem... Don't believe everything you think!

Chas. ;-)
verktyg is offline
Old 11-10-18, 09:06 AM
  #12
Aubergine
Bad example

Join Date: Nov 2015
Location: Seattle and Reims
Posts: 2,930
Mentioned: 33 Post(s)
Tagged: 0 Thread(s)
Quoted: 771 Post(s)
Liked 17 Times in 14 Posts
French eBay has a lot of options for bars at 25 mm, and also has lots of stems that fit both the old 22 mm steerer tubes and 25.4 mm bars. I’ve bought a few on there and had them shipped to Seattle.
__________________
Keeping Seattle’s bike shops in business since 1978
Aubergine is offline
