Suntour "bass-ackwards" front derailleur - questions

Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Suntour "bass-ackwards" front derailleur - questions

Old 03-31-19, 12:33 PM
  #1
madpogue
Senior Member
Thread Starter

Join Date: Jan 2004
Location: Madison, WI USA
Posts: 2,871
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 654 Post(s)
Liked 52 Times in 43 Posts
Suntour "bass-ackwards" front derailleur - questions

This is on a '75 (or is it '73?...) Raleigh Gran Sport, purchased back in the '80s. Something's always vexed me about the FD. It's a Suntour Compe V. The action is "reversed", that is, you pull the cable and wind up the spring to put it on the smaller chainring. I've never been too pleased with the action; it just seems like it's going against physics trying to get the chain to climb onto a larger sprocket by releasing tension.

I suppose for a novice it sorta makes sense "visually" - shifter further forward means higher gear ratio, applies to both rear and front. So I wonder if that's the only reason they came up with this design; one of those "it seemed like a good idea at the time" things. Might make sense for a casual user with one bike, but of course, for me, switching between bikes, it feels like driving a truck with the clutch pedal on the opposite side of the footwell.

It's original to the bike AFAIK. So would it be blasphemy to replace it? Just find a V-GT or some similar period-correct Suntour at the bike kitchen? The bike's mostly original otherwise; Weinmann brakes, Normandy hubs, that randonneur bar they used to throw on them, etc.

I'm guessing no, but is it of any added value just because of its oddity?


(Yeah, it needs a cleaning....) Kind of a pretty cage, too bad there's not a way to reverse the action.....
madpogue is offline
Old 03-31-19, 12:43 PM
  #2
stardognine
Turquoise gatherer.

stardognine's Avatar

Join Date: Jan 2016
Location: Arid Arizona, for now.
Posts: 1,571

Bikes: 1985 Cannondale ST400

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 330 Post(s)
Likes: 0
Liked 17 Times in 17 Posts
They had at least one other model too, the Spirt. Not Spirit, and not Sprint, but Spirt. What the heck is that? 🤔😁
I say get a "normal" one and use, and put that oddball on the back edge of the top shelf, in the dark corner of your garage. Just in case some collector decides they're worth a small fortune. 🙄😉
stardognine is offline
Old 03-31-19, 12:45 PM
  #3
3speedslow
Senior Member

3speedslow's Avatar

Join Date: Oct 2010
Location: Jacksonville, NC
Posts: 7,273

Bikes: A few

Mentioned: 92 Post(s)
Tagged: 0 Thread(s)
Quoted: 1241 Post(s)
Likes: 0
Liked 25 Times in 22 Posts
Suntour had 2 models which used the big ring default. Good, bad, right or wrong it works well and those I believe will throw across three rings.

i like them. They do look classy and are robust. I would keep it on there after cleaning it up.
3speedslow is offline
Old 03-31-19, 12:55 PM
  #4
noglider
aka Tom Reingold

noglider's Avatar

Join Date: Jan 2009
Location: West Village, New York City
Posts: 37,067

Bikes: 1962 Rudge Sports, 1971 Raleigh Super Course, 1971 Raleigh Pro Track, 1973 Raleigh Twenty, 1974 Raleigh International, 1975 Viscount Fixie, 1982 McLean, 1996 Lemond (Ti), 2002 Burley Zydeco tandem

Mentioned: 420 Post(s)
Tagged: 0 Thread(s)
Quoted: 5402 Post(s)
Liked 98 Times in 74 Posts
I like them, and I wouldn't expect them to work well, but they work perfectly for me. I like them because they're different. Also, I think there is a value in shifting in the same direction as the rear derailleur.

I don't have one of these on a bike now, but one is in the parts bin, just because.
__________________
Tom Reingold, tom@noglider.com
New York City and High Falls, NY
Blogs: The Experienced Cyclist; noglider's ride blog

“When man invented the bicycle he reached the peak of his attainments.” — Elizabeth West, US author

Please email me rather than PM'ing me. Thanks.
noglider is online now
Old 03-31-19, 01:03 PM
  #5
Glennfordx4
Holy Spokes it's Batsman!

Glennfordx4's Avatar

Join Date: Nov 2008
Location: South Jersey
Posts: 1,860

Bikes: Too many Bicycles to list

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 58 Post(s)
Likes: 0
Liked 0 Times in 0 Posts


I have 3 or 4 NOS Suntour SL FD's out in the shop. I built up a Schwinn Varsity drivetrain with modern ramped FW, chain, cables,RD and the High normal Suntour SL Fd and it was one of the best shifting bikes I have ridden. I like them.
Glenn
Glennfordx4 is offline
Old 03-31-19, 01:05 PM
  #6
crank_addict
Senior Member

crank_addict's Avatar

Join Date: Aug 2013
Posts: 6,421
Mentioned: 80 Post(s)
Tagged: 0 Thread(s)
Quoted: 1064 Post(s)
Likes: 0
Liked 18 Times in 13 Posts
I concur with the OP and its not one of the better products of Suntour. That said, I like it for its quirkiness weird and belongs on my 76 Viscount.... along with the 'death fork', this-that bottom bracket, tubular / clincher rims, etc....



crank_addict is offline
Old 03-31-19, 01:18 PM
  #7
Cougrrcj
Over forty victim of Fate

Cougrrcj's Avatar

Join Date: Jul 2011
Location: NE Ohio
Posts: 3,002

Bikes: A few...

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 295 Post(s)
Liked 3 Times in 3 Posts
I rode my old Fuji with it's 'backwards' SL and now Compe V front derailleur for soooo long, I've accepted it as normal -- i.e. both shifters are positioned forward to go faster. Now that I have other bikes with Cyclone derailleur sets, I find those harder to get used to! And yes, the Compe V shifts across the 48/38/28 triple crankset just fine!
__________________
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Huffy MTB - for trips to corner store
MTB of questionable lineage aka 'Mutt Trail Bike'

Last edited by Cougrrcj; 03-31-19 at 01:58 PM.
Cougrrcj is offline
Old 03-31-19, 02:32 PM
  #8
SurferRosa
Senior Member

SurferRosa's Avatar

Join Date: Dec 2018
Posts: 902

Bikes: old school 531c & campy

Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 371 Post(s)
Liked 48 Times in 34 Posts
Originally Posted by madpogue
would it be blasphemy to replace it?
All the gods want you to replace it and then burn it at the stake.

Or just toss it. No sense in wasting a good fire on one of those...
SurferRosa is offline
Old 03-31-19, 03:08 PM
  #9
seedsbelize
necessary illusions

Join Date: Nov 2010
Location: Tixkokob, Yucatán, México
Posts: 11,304
Mentioned: 94 Post(s)
Tagged: 1 Thread(s)
Quoted: 4735 Post(s)
Liked 34 Times in 27 Posts
Top normal Spirt is the best fd I've ever used. Crisp! shifting. I currently have one mounted and two more awaiting builds.
seedsbelize is offline
Old 03-31-19, 03:15 PM
  #10
TomJD
Member

Join Date: May 2006
Posts: 29
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
One advantage of this style FD is that when pedalling uphill with increasing tension on the chain and needing to downshift that you don't need to rely on a spring to make this critical shift, but instead can directly pull the chain over with the cable (like the RD). In contrast when upshifting there will tend to be less tension on the chain and so you can rely on a spring to make this shift.
TomJD is offline
Old 03-31-19, 04:06 PM
  #11
ed4406
Senior Member

Join Date: Dec 2015
Location: The Motor City
Posts: 80

Bikes: Fuji Finest, Trek 460, 970, Miyata One Ten, Maruishi 606, Univega Alpina Uno LX, Browning Grade V

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 13 Post(s)
Likes: 0
Liked 1 Time in 1 Post
I've had good luck with the Compe-V, sturdy and responsive. Downshifts are a bit quicker in my experience as well.
ed4406 is offline
Old 03-31-19, 04:10 PM
  #12
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Posts: 20,386

Bikes: Several, mostly not name brands.

Mentioned: 110 Post(s)
Tagged: 0 Thread(s)
Quoted: 1702 Post(s)
Liked 66 Times in 45 Posts
Originally Posted by stardognine View Post
They had at least one other model too, the Spirt.
And the "SL" which used an exotic aluminum cage rather than steel as on the Spirt and Compe-V.
JohnDThompson is offline
Old 03-31-19, 04:13 PM
  #13
dweenk
Senior Member

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,145

Bikes: 1971 Fuji Finest, Royale, S-10-S, 1976 Motobecane Mirage, 1989 Trek 330, 1100, 1970 Raleigh Sport, and more

Mentioned: 37 Post(s)
Tagged: 0 Thread(s)
Quoted: 575 Post(s)
Liked 11 Times in 9 Posts
I like top normal FDs and open cage RDs as well.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 03-31-19, 04:19 PM
  #14
repechage
Senior Member

Join Date: Jun 2006
Posts: 13,341
Mentioned: 77 Post(s)
Tagged: 0 Thread(s)
Quoted: 936 Post(s)
Likes: 0
Liked 13 Times in 11 Posts
Way back I think the reason Suntour created this model was to make the left and right shift levers do the same general thing, pull back and it is easier to pedal. These derailleur were fitted primarily to bikes that did not appeal to sophisticated buyers who already learned “ the gears”.
repechage is offline
Old 03-31-19, 04:36 PM
  #15
steelbikeguy
Senior Member

steelbikeguy's Avatar

Join Date: Feb 2008
Location: Peoria, IL
Posts: 1,591
Mentioned: 50 Post(s)
Tagged: 0 Thread(s)
Quoted: 508 Post(s)
Liked 2 Times in 2 Posts
Originally Posted by TomJD View Post
One advantage of this style FD is that when pedalling uphill with increasing tension on the chain and needing to downshift that you don't need to rely on a spring to make this critical shift, but instead can directly pull the chain over with the cable (like the RD). In contrast when upshifting there will tend to be less tension on the chain and so you can rely on a spring to make this shift.
I concur.

There is a hill on my commute home from work that has a sudden transition from a few percent grade to 14% grade. There have been a number times where I waited too long to drop to the granny and tried to let the Cyclone derailleur spring shove the chain off of the middle gear and down to the granny gear.
Well, as long as there was tension on the chain, that little spring couldn't do the job. It is possible that the Spirt or Compe V might have been able to do the job, utilizing my strength to force the lever.

I did used to have a bike with the Spirt derailleur on it. Under normal conditions, I don't recall any problems with it. Maybe it's easier to live with if you only have one bike and don't have to adapt to using two types of front derailleurs?

Steve in Peoria
steelbikeguy is offline
Old 03-31-19, 04:50 PM
  #16
markk900
Senior Member

markk900's Avatar

Join Date: Jan 2007
Location: Ontario
Posts: 1,806
Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 141 Post(s)
Liked 2 Times in 2 Posts
Seems to me other than being different in direction of action, whether the spring pushes left or right is no difference at all.

I’ve had Comp-V and SLs for 40+ years and liked them; I’ve had others that are “normal-low” and liked them too. I’d say change if you want but you’ll not find substantially better shifting for the money. My first Comp-V replaced the simplex on my AO-8 in 1973....
markk900 is offline
Old 03-31-19, 08:48 PM
  #17
madpogue
Senior Member
Thread Starter

Join Date: Jan 2004
Location: Madison, WI USA
Posts: 2,871
Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 654 Post(s)
Liked 52 Times in 43 Posts
Originally Posted by repechage View Post
Way back I think the reason Suntour created this model was to make the left and right shift levers do the same general thing, pull back and it is easier to pedal. These derailleur were fitted primarily to bikes that did not appeal to sophisticated buyers who already learned “ the gears”.
Yup, that's what I was trying to convey in my opening post. Seems like a way to cater to novices. Fah, maybe I'll keep it, as y'all advise, just because it's different.
madpogue is offline
Old 04-01-19, 12:09 AM
  #18
DiegoFrogs
Senior Member

DiegoFrogs's Avatar

Join Date: Feb 2005
Location: Toledo, OH
Posts: 2,371

Bikes: '77 Centurion "Pro Tour"; '67 Carlton "The Flyer"; 1984 Ross MTB (in USA)

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 92 Post(s)
Likes: 0
Liked 1 Time in 1 Post
One can identify these because the housing stop is the part that pivots. I have an early AG Tech that also incorporates this feature, in addition to the inner plate that pivots up and down while shifting.
DiegoFrogs is offline
Old 04-01-19, 07:04 AM
  #19
Ol Danl
Senior Member

Join Date: Dec 2004
Location: Chattanooga
Posts: 244

Bikes: 1977 Raleigh Record, 1987 Schwinn Prelude, 1971 Raleigh Record, 1988 Schwinn Traveller, 1967 (?) Carlton Super Course

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 0 Times in 0 Posts
This is the fd that came on my '77 Raleigh. Used it for years, even though I had ridden other bikes with low normal fd's. Finally decided to put fenders on the old Record, and found that the Compe-V kinda sticks out on the rear if the seat tube, and couldn't use it with the fenders. Stuck on a Huret-made Schwinn Approved derailleur. Suddenly wondered why I'd been putting up with the high normal Compe-V all these years. I guess I stay on the small chainring most of the time, so it really doesn't seem like a good idea to me.
Ol Danl is offline
Old 04-01-19, 12:00 PM
  #20
The Golden Boy
Extraordinary Magnitude

The Golden Boy's Avatar

Join Date: Aug 2009
Location: Waukesha WI
Posts: 11,367

Bikes: 1977 Trek TX700; 1978/79 Trek 736; 1984 Specialized Stumpjumper Sport; 1984 Schwinn Voyageur SP; 1985 Trek 620; 1985 Trek 720; 1986 Trek 400 Elance; 1987 Schwinn High Sierra; 1990 Miyata 1000LT

Mentioned: 71 Post(s)
Tagged: 0 Thread(s)
Quoted: 1713 Post(s)
Liked 46 Times in 36 Posts
Originally Posted by TomJD View Post
One advantage of this style FD is that when pedalling uphill with increasing tension on the chain and needing to downshift that you don't need to rely on a spring to make this critical shift, but instead can directly pull the chain over with the cable (like the RD). In contrast when upshifting there will tend to be less tension on the chain and so you can rely on a spring to make this shift.
Originally Posted by steelbikeguy View Post
I concur.

There is a hill on my commute home from work that has a sudden transition from a few percent grade to 14% grade. There have been a number times where I waited too long to drop to the granny and tried to let the Cyclone derailleur spring shove the chain off of the middle gear and down to the granny gear.
Well, as long as there was tension on the chain, that little spring couldn't do the job. It is possible that the Spirt or Compe V might have been able to do the job, utilizing my strength to force the lever.
That's a really good point- something I hadn't thought of- I tend to think of the "sprung" direction as the automatic direction- but you really only have "control" over what you're pulling on the cable... Interesting thought...
__________________
*Recipient of the 2006 Time Magazine "Person Of The Year" Award*

Commence to jigglin’ huh?!?!

"But hey, always love to hear from opinionated amateurs." -says some guy to Mr. Marshall.
The Golden Boy is offline
Old 04-01-19, 12:28 PM
  #21
bikeaddiction1
Senior Member

bikeaddiction1's Avatar

Join Date: Jan 2015
Location: Calgary Alberta
Posts: 139

Bikes: Many

Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 36 Post(s)
Liked 4 Times in 4 Posts
I often "upgrade" personal vintage bikes so they perform they way I like them. However, I always keep the removed items so they can be reinstalled if I sell the bike or want decide to return it to original.
bikeaddiction1 is offline
Old 04-01-19, 02:42 PM
  #22
52telecaster
ambulatory senior

52telecaster's Avatar

Join Date: Dec 2016
Location: Peoria Il
Posts: 2,642

Bikes: Bob Jackson World Tour, 81 miyata 912 and 86 miyata 312.

Mentioned: 35 Post(s)
Tagged: 0 Thread(s)
Quoted: 818 Post(s)
Likes: 0
Liked 21 Times in 10 Posts
I love spirts. I wish all my bikes had em.
52telecaster is offline
Old 04-01-19, 06:09 PM
  #23
SurferRosa
Senior Member

SurferRosa's Avatar

Join Date: Dec 2018
Posts: 902

Bikes: old school 531c & campy

Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 371 Post(s)
Liked 48 Times in 34 Posts
Originally Posted by 52telecaster View Post
I love spirts. I wish all my bikes had em.
They're a whole $9 (shipped) on ebay, so, go for it.
SurferRosa is offline
Old 04-01-19, 07:23 PM
  #24
52telecaster
ambulatory senior

52telecaster's Avatar

Join Date: Dec 2016
Location: Peoria Il
Posts: 2,642

Bikes: Bob Jackson World Tour, 81 miyata 912 and 86 miyata 312.

Mentioned: 35 Post(s)
Tagged: 0 Thread(s)
Quoted: 818 Post(s)
Likes: 0
Liked 21 Times in 10 Posts
Originally Posted by SurferRosa View Post
They're a whole $9 (shipped) on ebay, so, go for it.
my bobjackson has too much drop for the spirt to work well or i would. Ive got the derailleur for it but cant use it.
52telecaster is offline
Old 04-02-19, 12:15 AM
  #25
Lascauxcaveman
Senior Member

Lascauxcaveman's Avatar

Join Date: Nov 2011
Location: Port Angeles, WA
Posts: 7,260

Bikes: A green one, "Ragleigh," or something.

Mentioned: 158 Post(s)
Tagged: 0 Thread(s)
Quoted: 1307 Post(s)
Liked 22 Times in 19 Posts
Gimme one of those every time. Half of my (vintage, friction) FDs don't want to go down to the small ring when I really need it, climbing under load. And if you adjust them so they will do it every time, then half the time they overshoot and end up dropping the chain inside. It's a very fine line with an elderly bottom-normal FD, but with a top normal, getting to that inner ring is just a matter of muscle, not wishful thinking.

They should all be made that way.
__________________
● 1971 Grandis SL ● 1972 Lambert Grand Prix frankenbike ● 1972 Raleigh Super Course fixie ● 1973 Nishiki Semi-Pro ● 1980 Apollo "Legnano" ● 1981 Miyata 1000 ● 1984 Bianchi Limited ● 1984 Nishiki Landau ● 1984 Peugeot Vagabond ● 1985 Trek 600 ● 1985 Shogun Prairie Breaker ● 1986 Univega Nuovo Sport ● 1986 Merckx Super Corsa ● 1987 Schwinn Tempo ● 1988 Schwinn Voyageur ● 1989 Trek 400 ● 1990 Cannondale ST600 ● 1993 Technium RT600 ● 1996 Kona Lava Dome ● And a Bike to Be Named Later ●
Lascauxcaveman is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service

Copyright © 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
