Wrapping a handle bar with cotton tape?

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Wrapping a handle bar with cotton tape?

Old 07-18-19, 04:32 PM
  #1
robertj298
Senior Member
Thread Starter

robertj298's Avatar

Join Date: Jun 2018
Location: NW Ohio
Posts: 1,101

Bikes: 1983 Univega Super Strada, 1986 Panasonic DX5000, 1984 Fuji Team 85 Univega Gran Turismo, 1984 Lotus Unique, 1987 Centurion Expert, 1987 Centurion Ironman Master,

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 658 Post(s)
Liked 418 Times in 169 Posts
Wrapping a handle bar with cotton tape?

I've watched some videos on this and several say you can wrap cloth tape from the middle of the bars down. So do you wrap around the brake hoods the same way you would coming from the opposite direction? I also noticed when they wrap this way they don't use any tape at the beginning of the bar in the center. Will the bar tape hold there by itself? Thanks
robertj298 is offline
Old 07-18-19, 04:49 PM
  #2
due ruote
Senior Member

due ruote's Avatar

Join Date: Dec 2006
Posts: 7,590
Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 866 Post(s)
Liked 437 Times in 269 Posts
Begin with the tape straight, then begin angling as you complete the first wrap. I always cut a couple inches off first to go around the brake hoods. Newbaumís Tape makes this easy as itís a longer roll.
I was taught to wrap dry, and thatís generally how I do it, but some folks suggest soaking the roll in warm water before wrapping. I have done it a few times that way and it is noticeably easier to do tight curved sections. The downside is the adhesive loses its effectiveness when wet. Itís fine once it dries, but the trade off is itís harder to manage the roll when itís all trying to unravel.
due ruote is offline
Old 07-18-19, 04:55 PM
  #3
Velo Mule
Senior Member

Velo Mule's Avatar

Join Date: Dec 2016
Location: Long Island, NY
Posts: 1,632

Bikes: Trek 800 x 2, Schwinn Heavy Duti, Schwinn Traveler, Schwinn Le Tour Luxe, Schwinn Continental, Cannondale M400 and Lambert

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 589 Post(s)
Liked 577 Times in 415 Posts
I never heard of soaking the cotton tape on water first. You learn something everyday. I also started from the center and worked my way to the end with a cut piece of tape for the brake area. At the the end, just fold the tape inside the tube and put in the bar end.
Velo Mule is offline
Old 07-18-19, 05:07 PM
  #4
randyjawa
Senior Member

randyjawa's Avatar

Join Date: Apr 2007
Location: Thunder Bay, Ontario, Canada - burrrrr!
Posts: 11,337

Bikes: 1958 Rabeneick 120D, 1968 Legnano Gran Premio, 196? Torpado Professional, 2000 Marinoni Piuma

Mentioned: 202 Post(s)
Tagged: 0 Thread(s)
Quoted: 1272 Post(s)
Likes: 0
Liked 1,406 Times in 789 Posts
This is how I wrap handlebar tape, be it cloth or rubberized cork. For cloth tape, which is a little harder to work with, I start in the middle and wrap towards the ends, allowing the end caps to secure the wrap. These days, I always use this style of end cap. They never come loose and look very vintage, in my opinion...



I make darn sure that the brake levers are exactly where I want them to be BEFORE wrapping. This means, bike built and and road worthy. Ride it and adjust lever position, up down tilt in out or what ever. When satisfied, using clear packing tape or something similar, temporarily tape the lever clamps into position, doing your best to ensure that they do not move once wrapping starts...



Start your wrap at the middle, working towards the ends. The ribbon end faces forward to begin (this will help prevent loosening when in use during rides). Start with one full cover wrap then begin to angle the ribbon to achieve partial coverage each wrap. Look at what you are doing. Compare each wrap, focusing on "is it about the same width exposed as the preceding one". Move the ribbon, which is ALWAYS under considerable tension, until things do look even and ensure that you eliminate any loose edges or wrinkles before moving on to the next wrap. Keep going always with tension and always comparing the present wrap to the one before.


Maintaining tension, considerable tension on the tape, continue but be forewarned. When you get into curves the wraps will not be as uniform looking. Again, seek pleasing appearance, making each wrap as similar as possible to the one before it. It is in the curves where wrinkles and gaps could be an issue. Be patient, try different tensions and positions until all looks good. Go on to the next wrap.

This is a forgiving task that can be backed up on, time and again, as one attempts to get it right. Give it a try. It is not as difficult as one might think. All that said...

I am always a bit fatigues after wrapping bars. Just keeping the tension strong can be tiring. And tension is the key to nicely wrapped bars. My opinion, of course...
__________________
"98% of the bikes I buy are projects".
randyjawa is offline
Likes For randyjawa:
Old 07-18-19, 05:10 PM
  #5
P!N20
Senior Member

P!N20's Avatar

Join Date: Aug 2010
Posts: 1,967
Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 854 Post(s)
Liked 1,259 Times in 645 Posts
Originally Posted by robertj298 View Post
I also noticed when they wrap this way they don't use any tape at the beginning of the bar in the center. Will the bar tape hold there by itself? Thanks
Is that where they fold the end so it's kind of 'captured' by the wrap? I've never done it this way, but it's a tried and true method, so I don't think you'll have any problems.

Personally I like the twine finish:



P!N20 is offline
Likes For P!N20:
Old 07-18-19, 05:56 PM
  #6
delbiker1
Mother Nature's Son

delbiker1's Avatar

Join Date: Mar 2016
Location: Sussex County, Delaware
Posts: 2,563

Bikes: Early 90's Ochsner road, 2006 Schwinn SS DBX, 2014 Orbea Avant MD30, 2004 Airborne Zeppelin TI, 2003 Lemond Poprad, 1989? Fuji Ace, 2001 Lemond Tourmalet, 2014? Soma Smoothie

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 680 Post(s)
Liked 983 Times in 573 Posts
Originally Posted by randyjawa View Post
This is how I wrap handlebar tape, be it cloth or rubberized cork. For cloth tape, which is a little harder to work with, I start in the middle and wrap towards the ends, allowing the end caps to secure the wrap. These days, I always use this style of end cap. They never come loose and look very vintage, in my opinion...



I make darn sure that the brake levers are exactly where I want them to be BEFORE wrapping. This means, bike built and and road worthy. Ride it and adjust lever position, up down tilt in out or what ever. When satisfied, using clear packing tape or something similar, temporarily tape the lever clamps into position, doing your best to ensure that they do not move once wrapping starts...



Start your wrap at the middle, working towards the ends. The ribbon end faces forward to begin (this will help prevent loosening when in use during rides). Start with one full cover wrap then begin to angle the ribbon to achieve partial coverage each wrap. Look at what you are doing. Compare each wrap, focusing on "is it about the same width exposed as the preceding one". Move the ribbon, which is ALWAYS under considerable tension, until things do look even and ensure that you eliminate any loose edges or wrinkles before moving on to the next wrap. Keep going always with tension and always comparing the present wrap to the one before.


Maintaining tension, considerable tension on the tape, continue but be forewarned. When you get into curves the wraps will not be as uniform looking. Again, seek pleasing appearance, making each wrap as similar as possible to the one before it. It is in the curves where wrinkles and gaps could be an issue. Be patient, try different tensions and positions until all looks good. Go on to the next wrap.

This is a forgiving task that can be backed up on, time and again, as one attempts to get it right. Give it a try. It is not as difficult as one might think. All that said...

I am always a bit fatigues after wrapping bars. Just keeping the tension strong can be tiring. And tension is the key to nicely wrapped bars. My opinion, of course...
Good post, some real good advice in it.
delbiker1 is offline
Old 07-18-19, 06:18 PM
  #7
robertj298
Senior Member
Thread Starter

robertj298's Avatar

Join Date: Jun 2018
Location: NW Ohio
Posts: 1,101

Bikes: 1983 Univega Super Strada, 1986 Panasonic DX5000, 1984 Fuji Team 85 Univega Gran Turismo, 1984 Lotus Unique, 1987 Centurion Expert, 1987 Centurion Ironman Master,

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 658 Post(s)
Liked 418 Times in 169 Posts
Originally Posted by P!N20 View Post
Is that where they fold the end so it's kind of 'captured' by the wrap? I've never done it this way, but it's a tried and true method, so I don't think you'll have any problems.

Personally I like the twine finish:



https://www.youtube.com/watch?v=tO8DcaOJzrA
From what I could tell they started in the middle and wrapped 2 times straight around then just angled from there. What I am wondering is if you need to do anything to the start to keep it from unraveling?
robertj298 is offline
Old 07-18-19, 06:28 PM
  #8
Kactus
Senior Member

Kactus's Avatar

Join Date: Jul 2012
Location: Tacoma, WA
Posts: 2,828

Bikes: 1962 Schwinn Paramount P12, 1971 Schwinn Paramount P13-9

Mentioned: 30 Post(s)
Tagged: 0 Thread(s)
Quoted: 344 Post(s)
Liked 31 Times in 19 Posts
Originally Posted by robertj298 View Post
From what I could tell they started in the middle and wrapped 2 times straight around then just angled from there. What I am wondering is if you need to do anything to the start to keep it from unraveling?
The adhesive on the tape will hold it to prevent unraveling.
Kactus is offline
Old 07-18-19, 10:12 PM
  #9
Salamandrine
Senior Member

Join Date: Oct 2015
Location: Los Angeles
Posts: 6,287

Bikes: 78 Masi Criterium, 68 PX10, 2016 Mercian King of Mercia, Rivendell Clem Smith Jr

Mentioned: 120 Post(s)
Tagged: 0 Thread(s)
Quoted: 2317 Post(s)
Liked 583 Times in 421 Posts
I've never tried the wrapping from the levers out method, but if you are wrapping the top section upward, yeah, you will need to secure the end with tape or twine. You can use superglue if you want to be stealthier.

Seems like a lot of trouble for not much benefit, but if it works for people, more power to 'em. I prefer to wrap cotton from the top down, the old school way. No tape or twine required. Being fidgety, I tend to shred tape quickly regardless, and it makes little to no difference which way I wrap. If anything top down holds up a bit better for me.
Salamandrine is offline
Old 07-19-19, 01:46 AM
  #10
canklecat
Me duelen las nalgas

canklecat's Avatar

Join Date: Aug 2015
Location: Texas
Posts: 13,225

Bikes: Centurion Ironman, Trek 5900, Univega Via Carisma, Globe Carmel

Mentioned: 196 Post(s)
Tagged: 0 Thread(s)
Quoted: 4389 Post(s)
Liked 2,430 Times in 1,578 Posts
The middle-out wrap can work with thin tape -- cloth or old style cello -- because the "wrong-way" edges don't peel up as easily. Some folks varnish the cloth wrap so it's even less likely to snag.

I've tried the middle-out wrap with foam tape and it doesn't work as well unless the thicker tape has beveled or skived edges, so they lay flat. I wrapped some thick Arundel Synth Gecko that way a month or so ago. It almost worked, but I didn't have the right bar end plugs to hold it properly without cutting the tape against the bare metal edges. But it looked better -- no need for tape.
canklecat is offline
Old 07-19-19, 04:38 AM
  #11
J.Higgins
2-Wheeled Fool

J.Higgins's Avatar

Join Date: Sep 2016
Location: New Hampshire
Posts: 2,485

Bikes: Surly Ogre, Brompton

Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 1385 Post(s)
Liked 671 Times in 454 Posts
Originally Posted by robertj298 View Post
From what I could tell they started in the middle and wrapped 2 times straight around then just angled from there. What I am wondering is if you need to do anything to the start to keep it from unraveling?
I've done it this way for almost 50 years and never had one unravel.

I'll put my two cents in here, because there are pros and cons of wrapping in either direction. Wrapping from the bar-end is more complicated, but the wrap lays down nicer. Wrapping from the middle is clean and easy, but the trailing edge of the wrap is left exposed. Its not covered over by the next wrap, so Its easier (albeit slightly) to snag or roll it over with your hands. Either way, tape is cheap, and replaceable. Eventually everyone finds out how they like it.
