New Shimano Freewheels. What cog combinations?

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

New Shimano Freewheels. What cog combinations?

Old 09-05-19, 08:32 AM
  #1
bark_eater
Senior Member
Thread Starter

Join Date: Sep 2017
Location: Eastern Shore, MD
Posts: 891

Bikes: Road ready: 1993 Koga Miyata City Liner Touring Hybrid, 1989 Centurion Sport DLX, "I Blame GP" Bridgestone CB-1. Projects: Yea, I got a problem....

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Liked 91 Times in 61 Posts
New Shimano Freewheels. What cog combinations?

I know that in the golden age there where cog boards, but alas, that ship has sailed...

I was wondering what combinations can be built up with the present production Shimano offerings?

Right now I'm trying to figure out a 6 speed indexing drive train based around a 14-28 free wheel. 14-16-18-21-24-28

in seven speed I've found 12-13-15-18-21-24-28. and 14,16,18,20,22,24,34

Is it possible to get a 14-16-18-20-22-24 on a 6 speed freewheel body?

or a 12-13-15-18-20-22-24 on a 7 speed body?

Or should I be looking at the Sunrace freewheels?
Thanks

Last edited by bark_eater; 09-05-19 at 10:16 AM.
bark_eater is offline
Old 09-05-19, 10:10 AM
  #2
noobinsf
Senior Member

noobinsf's Avatar

Join Date: Sep 2005
Location: Oakland, CA
Posts: 1,994

Bikes: CURRENT: '82 Univega Competizione, '72 Motobecane Grand Record, '74 Campania Professional, '83 Mercian KOM Touring, '91 Univega Alpina Comp PAST: '72 Puch Bergmeister, '72ish Peugeot UO-8, '86 Univega Gran Premio, '85 Univega Viva Touring

Mentioned: 42 Post(s)
Tagged: 0 Thread(s)
Quoted: 609 Post(s)
Liked 330 Times in 231 Posts
I don't know about 14-24, but Sunrace has a 13-25. I am running a Sunrace 13-28 and think it works well.

Is the freewheel with the 11-tooth cog from DNP? I have not seen a current Shimano freewheel with an 11-tooth cog. If DNP, I would be wary of the quality, as the reviews appear to be all over the map.
noobinsf is offline
Old 09-05-19, 10:15 AM
  #3
bark_eater
Senior Member
Thread Starter

Join Date: Sep 2017
Location: Eastern Shore, MD
Posts: 891

Bikes: Road ready: 1993 Koga Miyata City Liner Touring Hybrid, 1989 Centurion Sport DLX, "I Blame GP" Bridgestone CB-1. Projects: Yea, I got a problem....

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Liked 91 Times in 61 Posts
Your right. that should be a 12 instead of 11. Are the Sunrace freewheels compatible with Shimano indexing?
bark_eater is offline
Old 09-05-19, 10:18 AM
  #4
ThermionicScott
7-speed cultist

ThermionicScott's Avatar

Join Date: Aug 2011
Location: CID
Posts: 20,045

Bikes: 1991 Bianchi Eros, 1964 Armstrong, 1988 Diamondback Ascent, 1988 Bianchi Premio, 1987 Bianchi Sport SX, 1980s Raleigh mixte (hers)

Mentioned: 87 Post(s)
Tagged: 0 Thread(s)
Quoted: 2779 Post(s)
Liked 701 Times in 493 Posts
Last I knew, this is what's available from Shimano:

6-speed: 14-28, 14-34
7-speed: 13-28, 14-28, 14-34

I wouldn't want a 14-16-18-20-22-24 freewheel even if it were available. The biggest jumps are at the fast end of the cassette, where you want close gears, and the closest jumps are at the bottom, where you don't need them.

@bark_eater, it sounds like you first need to figure out what gear range you want, then pick your chainrings and freewheel to achieve it. An 11-28 and 14-24 give very different top and bottom gears, given the same chainrings.
__________________
Originally Posted by chandltp View Post
There's no such thing as too far.. just lack of time
Originally Posted by noglider
People in this forum are not typical.
RUSA #7498

Last edited by ThermionicScott; 09-05-19 at 10:31 AM.
ThermionicScott is online now
Old 09-05-19, 10:36 AM
  #5
dddd
Ride, Wrench, Swap, Race

dddd's Avatar

Join Date: Jan 2010
Location: Northern California
Posts: 7,514

Bikes: Cheltenham-Pederson racer, Boulder F/S Paris-Roubaix, Varsity racer, '52 Christophe, '62 Continental, '92 Merckx, '75 Limongi, '76 Presto, '72 Gitane SC, '71 Schwinn SS, etc.

Mentioned: 105 Post(s)
Tagged: 0 Thread(s)
Quoted: 916 Post(s)
Likes: 0
Liked 307 Times in 236 Posts
Who makes a freewheel with a 12t first cog???

Shimano used to offer both 11-28t and 11-34t 7s freewheels, but not in the past decade.

I've seen 7s cassettes with 11-13-15-18-21-24-28t, but haven't ever seen a modern 7s freewheel with 12-13-15-18-21-24-28t

SunRace makes good 7s freewheels in 13-25t and 13-28t.
dddd is offline
Old 09-05-19, 10:43 AM
  #6
bark_eater
Senior Member
Thread Starter

Join Date: Sep 2017
Location: Eastern Shore, MD
Posts: 891

Bikes: Road ready: 1993 Koga Miyata City Liner Touring Hybrid, 1989 Centurion Sport DLX, "I Blame GP" Bridgestone CB-1. Projects: Yea, I got a problem....

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Liked 91 Times in 61 Posts
Originally Posted by ThermionicScott View Post

@bark_eater, it sounds like you first need to figure out what gear range you want, then pick your chainrings and freewheel to achieve it. An 11-28 and 14-24 give very different top and bottom gears, given the same chainrings.
While I got ya... I ended up with 48t and 36t chainrings to go with a 14-28 freewheel. It looks like $$ IRD freewheels are the only way to get anything different.

bark_eater is offline
Old 09-05-19, 11:12 AM
  #7
Vintage_Cyclist
Senior Member

Vintage_Cyclist's Avatar

Join Date: Nov 2013
Location: Big Apple
Posts: 1,342

Bikes: yes

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 389 Post(s)
Likes: 0
Liked 59 Times in 33 Posts
Originally Posted by bark_eater View Post
I know that in the golden age there where cog boards, but alas, that ship has sailed...

I was wondering what combinations can be built up with the present production Shimano offerings?

Right now I'm trying to figure out a 6 speed indexing drive train based around a 14-28 free wheel. 14-16-18-21-24-28

in seven speed I've found 12-13-15-18-21-24-28. and 14,16,18,20,22,24,34

Is it possible to get a 14-16-18-20-22-24 on a 6 speed freewheel body?

or a 12-13-15-18-20-22-24 on a 7 speed body?

Or should I be looking at the Sunrace freewheels?
Thanks
Since it sounds like you're looking to get some freewheels and switch cogs around, be advised that some of the Shimano freewheels are different from the others in construction.

I have two recent Shimano freewheels on bikes.

One is the HG37, which is 13,15,17,19,21,24,28, made in Singapore.



The other is the MF-TZ21, which is 14-16-18-20-22-24-28, made in China.



The difference in construction is that on the HG37, all the cogs are on the freewheel body, which makes them all removable. On the MF-TZ21, only the first five cogs are on the freewheel body, with the sixth cog pinned to the fifth cog (like an outrigger), and the seventh cog pinned to the sixth cog. As a result, the fifth, sixth and seventh cogs are one piece.
Vintage_Cyclist is offline
Old 09-05-19, 11:17 AM
  #8
SurferRosa
Señor Member

SurferRosa's Avatar

Join Date: Dec 2018
Location: Pac NW
Posts: 2,943

Bikes: Old school lightweights

Mentioned: 45 Post(s)
Tagged: 0 Thread(s)
Quoted: 1211 Post(s)
Liked 934 Times in 582 Posts
Originally Posted by bark_eater View Post
Are the Sunrace freewheels compatible with Shimano indexing?
I think so. I've tried it recently with SIS shifters, and it worked well.
SurferRosa is offline
Old 09-05-19, 12:51 PM
  #9
top506
Death fork? Naaaah!!

top506's Avatar

Join Date: Nov 2005
Location: The other Maine, north of RT 2
Posts: 4,809

Bikes: Seriously downsizing.

Mentioned: 37 Post(s)
Tagged: 0 Thread(s)
Quoted: 394 Post(s)
Likes: 0
Liked 106 Times in 65 Posts
Originally Posted by bark_eater View Post
Are the Sunrace freewheels compatible with Shimano indexing?
Very much so. Running 13-25, 13-28, and 13-30 7 cog freewheels with indexing.

Top
__________________
You know it's going to be a good day when the stem and seatpost come right out.

(looking for a picture and not seeing it? Thank the Photobucket fiasco.PM me and I'll link it up.)
top506 is offline
Likes For top506:
Old 09-05-19, 05:07 PM
  #10
bark_eater
Senior Member
Thread Starter

Join Date: Sep 2017
Location: Eastern Shore, MD
Posts: 891

Bikes: Road ready: 1993 Koga Miyata City Liner Touring Hybrid, 1989 Centurion Sport DLX, "I Blame GP" Bridgestone CB-1. Projects: Yea, I got a problem....

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Liked 91 Times in 61 Posts
Apparently there is such a thing as a "SunRace MFR2A 6DP 14-24T 6 Speed Freewheel" available on ebay at least. I believe its 14-16-18-20-22-24
bark_eater is offline
