Seatpost snapped 20 miles from home

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Seatpost snapped 20 miles from home

Old 05-20-20, 06:46 AM
  #1
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Seatpost snapped 20 miles from home

So I'm out in the country, coming down a hill and go over a harder than expected bump at speed. My seat snaps off the seatpost and I'm thrown on the bank. Looking at the damage the post is snapped right at the very top, by the seat attachment.

I'm pretty far from home, but there's a Halfords 3 miles away, where I can probably buy one of these: https://www.halfords.com/cycling/bike-parts/saddles-seats-posts/micro-adjust-seat-pillar-27.2-591166.html

Sadly my Internet connection is too weka to upload a photo out here, but I don't know my seat post size. It's a vitus 787. Any advice on how to figure out my seatpost size without a tape measure, or guesses on how likely that one is to fit?

Thanks!
​​​
Funktopus is offline
Old 05-20-20, 06:49 AM
  #2
Lemond1985
Sophomore Member

Lemond1985's Avatar

Join Date: Jan 2019
Posts: 2,353
Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 1422 Post(s)
Liked 766 Times in 480 Posts
What year is yours? I see a couple "for sale" ads that list 25 mm. Might be a hard size to find.
Lemond1985 is offline
Likes For Lemond1985:
Old 05-20-20, 06:51 AM
  #3
Moe Zhoost
Half way there

Moe Zhoost's Avatar

Join Date: Sep 2015
Location: Durham, NC
Posts: 2,155

Bikes: Many, and the list changes frequently

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 672 Post(s)
Liked 408 Times in 247 Posts
Seat posts are usually stamped with the diameter. Remove what you have and look around the bottom where the size will be near the minimum insertion line. Good luck.
Moe Zhoost is offline
Likes For Moe Zhoost:
Old 05-20-20, 06:53 AM
  #4
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Update: some photos https://photos.app.goo.gl/K8AcLZY4G8ofmQfe7
Funktopus is offline
Old 05-20-20, 06:54 AM
  #5
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Originally Posted by Lemond1985 View Post
What year is yours? I see a couple "for sale" ads that list 25 mm. Might be a hard size to find.
I don't know unfortunately, but that's a good place to start. Options are pretty limited out here though!
Funktopus is offline
Old 05-20-20, 06:58 AM
  #6
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Originally Posted by Moe Zhoost View Post
Seat posts are usually stamped with the diameter. Remove what you have and look around the bottom where the size will be near the minimum insertion line. Good luck.
https://photos.app.goo.gl/mot8Btt4FeBbuvd66

Clearly its in a bit of a state, but looks like the 25mm theory is plausible.
Funktopus is offline
Old 05-20-20, 07:00 AM
  #7
Moe Zhoost
Half way there

Moe Zhoost's Avatar

Join Date: Sep 2015
Location: Durham, NC
Posts: 2,155

Bikes: Many, and the list changes frequently

Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 672 Post(s)
Liked 408 Times in 247 Posts
The Sheldon Brown site says 25.0mm for a Vitus 787
Moe Zhoost is offline
Likes For Moe Zhoost:
Old 05-20-20, 07:11 AM
  #8
jethin
Senior Member

jethin's Avatar

Join Date: Oct 2009
Posts: 837
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 170 Post(s)
Liked 56 Times in 34 Posts
It looks like the bottom cradle snapped? Maybe you could find a way to re-attach the saddle/clamp to the post and gingerly ride it home? Or clamp on something else to sit on? Or just ride home without a saddle as best you can. Good luck.
jethin is offline
Likes For jethin:
Old 05-20-20, 08:17 AM
  #9
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Phoned the local bike shop and they thought they had something to fit a 25mm seatpost. Rode the 7 miles over there without a seat - never have I appreciated how much core strength cycling standing up uses! Turns out they had a 25.4mm and it just doesn't fit. So on this occasion it's the local train station that saves the day.

Might see if I can find a size that's smaller and shim it with a beer can. I need a beer anyway, so it's a two birds one stone kind of situation.

Thanks all for your help and research, I appreciate it!
Funktopus is offline
Old 05-20-20, 08:18 AM
  #10
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Originally Posted by jethin View Post
It looks like the bottom cradle snapped? Maybe you could find a way to re-attach the saddle/clamp to the post and gingerly ride it home? Or clamp on something else to sit on? Or just ride home without a saddle as best you can. Good luck.
I think if I'd had some cable ties handy this would have been possible. Might start carrying some in future.
Funktopus is offline
Likes For Funktopus:
Old 05-20-20, 08:39 AM
  #11
Miele Man
Senior Member

Join Date: Jun 2014
Location: Ontario, Canada
Posts: 4,190

Bikes: iele Latina, Miele Suprema, Miele Uno LS, Miele Miele Beta, MMTB, Bianchi Model Unknown, Fiori Venezia, Fiori Napoli, VeloSport Adamas AX

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 1127 Post(s)
Liked 675 Times in 478 Posts
I wonder if you could scrounge a straight seat pillar and clamp as found on a lot of cheap mountain bikes or department store bikes? At least that'd let you sit for the ride home.

This is the type of seat pillar and clamp I'm talking about.




Good luck and cheers

Edit. iirc BMX seatposts are/were often 25.0mm in diameter.

Last edited by Miele Man; 05-20-20 at 09:36 AM. Reason: Added comment
Miele Man is online now
Likes For Miele Man:
Old 05-20-20, 12:19 PM
  #12
oneclick
Senior Member

Join Date: Feb 2020
Posts: 341
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 123 Post(s)
Likes: 0
Liked 123 Times in 76 Posts
Be a man, stand up and ride. It's only 20 miles.
oneclick is offline
Likes For oneclick:
Old 05-20-20, 12:55 PM
  #13
scarlson
Senior Member

scarlson's Avatar

Join Date: Jun 2010
Location: Medford MA
Posts: 910

Bikes: Ron Cooper touring, 1959 Jack Taylor 650b ladyback touring tandem, Vitus 979, Joe Bell painted Claud Butler Dalesman, Colin Laing curved tube tandem, heavily-Dilberted 1982 Trek 6xx

Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 395 Post(s)
Liked 430 Times in 260 Posts
Shimming a seatpost in aluminum frame is not a real good idea, unless you buy a shim or precision machine one yourself. If you're off even by a little bit in thickness, you might cause a fatigue crack in the frame. Hell, I've seen an 0.2mm undersize seatpost cause a crack in a 531 frame!

Since you mention Halfords, I guess you are probably in the UK. It looks like you can get a cheap Velo-orange "Dajia" post on ebay UK for £26.39.

Last edited by scarlson; 05-20-20 at 01:02 PM.
scarlson is offline
Old 05-20-20, 01:20 PM
  #14
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Originally Posted by scarlson View Post
Shimming a seatpost in aluminum frame is not a real good idea, unless you buy a shim or precision machine one yourself. If you're off even by a little bit in thickness, you might cause a fatigue crack in the frame. Hell, I've seen an 0.2mm undersize seatpost cause a crack in a 531 frame!

Since you mention Halfords, I guess you are probably in the UK. It looks like you can get a cheap Velo-orange "Dajia" post on ebay UK for £26.39.
Actually I was looking at the exact same listing. I wasn't aware of Velo Orange, but they seem to get pretty good reviews for their frames. And they also make a reproduction of the cables that were originally on my Vitus, which is cool. Just waiting for someone to turn down my lowball offer on a vintage Shimano seatpost before I grab that Velo Orange.
​​​
Funktopus is offline
Old 05-20-20, 01:22 PM
  #15
Funktopus
Senior Member
Thread Starter

Join Date: May 2020
Posts: 102
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 31 Post(s)
Liked 4 Times in 4 Posts
Originally Posted by oneclick View Post
Be a man, stand up and ride. It's only 20 miles.
If we're talking business I should have just sat on the snapped off seatpost 💁‍♂️
Funktopus is offline
Likes For Funktopus:
Old 05-20-20, 01:23 PM
  #16
Dfrost
Senior Member

Dfrost's Avatar

Join Date: May 2013
Location: Pacific Northwest
Posts: 1,608

Bikes: ‘87 Marinoni SLX Sports Tourer, ‘79 Miyata 912 by Gugificazione

Mentioned: 132 Post(s)
Tagged: 0 Thread(s)
Quoted: 355 Post(s)
Liked 89 Times in 66 Posts
Pretty sure that lower end Peugeot used 25.0mm seatposts, but they aren’t common.
Dfrost is offline
Old 05-20-20, 01:42 PM
  #17
scarlson
Senior Member

scarlson's Avatar

Join Date: Jun 2010
Location: Medford MA
Posts: 910

Bikes: Ron Cooper touring, 1959 Jack Taylor 650b ladyback touring tandem, Vitus 979, Joe Bell painted Claud Butler Dalesman, Colin Laing curved tube tandem, heavily-Dilberted 1982 Trek 6xx

Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 395 Post(s)
Liked 430 Times in 260 Posts
Originally Posted by Dfrost View Post
Pretty sure that lower end Peugeot used 25.0mm seatposts, but they aren’t common.
Likely a French thing. Some high-end constructeurs also would shim larger sized tubes to take 25.0 seatposts, at least in the late '40s and early '50s.
scarlson is offline
Old 05-20-20, 03:28 PM
  #18
63rickert
Senior Member

Join Date: Dec 2013
Posts: 1,636
Mentioned: 41 Post(s)
Tagged: 0 Thread(s)
Quoted: 808 Post(s)
Liked 178 Times in 132 Posts
Kalloy has seatposts in that size. Don’t know offhand who the UK distributor is, it is normal bike parts, should not be hard to find. If you need to have a specific brand and style of correct seatpost that could be hard.
63rickert is offline
Old 05-20-20, 03:30 PM
  #19
merziac
Senior Member

merziac's Avatar

Join Date: Oct 2015
Location: PDX
Posts: 6,243

Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2

Mentioned: 128 Post(s)
Tagged: 0 Thread(s)
Quoted: 1862 Post(s)
Liked 802 Times in 576 Posts
Originally Posted by Funktopus View Post
I think if I'd had some cable ties handy this would have been possible. Might start carrying some in future.
Do not shim, it can distort the ST/lug and be unreliable.

I would get a proper sized one or sand down a 25.4 carefully to fit.
merziac is online now
