Repainting a 68 Schwinn Twinn Deluxe, might as well add some braze-ons...

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Repainting a 68 Schwinn Twinn Deluxe, might as well add some braze-ons...

Old 06-14-20, 03:08 PM
  #1
Mista Sparkle
Senior Member
Thread Starter

Join Date: Sep 2016
Location: Aurora, IL
Posts: 109

Bikes: 2007 Fuji Roubaix, 2018 Trek Marlin 5, Huffy Baron (Retired), Schwinn Twinn (On Deck)

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 23 Times in 20 Posts
Repainting a 68 Schwinn Twinn Deluxe, might as well add some braze-ons...

So I recently picked up a Schwinn Twinn Deluxe as I though it would be a fun way to haul my kids around the neighborhood. I figured it would take a little work, but perhaps I got a bit carried away. It turns out that the rear axle was busted, and the rear wheels were a bit on the rusty side, so I'm gonna get to learn how to build wheels... A post on that will likely come a bit later.

Anyway, so the frame was in pretty good shape and the paint was OK, but since I was cleaning up the rest of it, I decided I would just strip it and repaint. Since it is being stripped, I then figured, "Hey, I might as well add some braze-ons."

The bike didn't come with any holes for water bottles, and I personally don't mind if it departs from vintage a bit if it makes it more interesting, and I figure I will have a hard time getting my wife on it, without a water bottle. I could get some clip on ones, but 5 pairs of bottle bosses are cheap, and it gives me a reason to play with the torch. Any excuse to play with a torch that isn't plumbing is a good one in my book. While I'm at it I'll be adding some bosses for a rack and using remaining braze-ons where previous hardware was nut and bolt attached, as well as a bracket to attach the reaction arm from the drum brake. The stupid little tab that was on it originally looks cheap, and of poor quality.

Ideally I'd like to get more than 2 bottle on the bike, but I just don't see any practical way to do more than what I have in the image below. Any suggestions here? Any other suggestions on what to do with the other remaining bosses, I was thinking maybe on the front fork to make it more convenient to remove the front wheel for transport?

Once that is taken care of I'm off to painting. Here I plan on Urethane paint, so I guess just a 2K primer, followed by some blue, Either something along the lines of Mach Blue, or maybe Miami blue. I'm not quite set on a color, but hopefully something of reasonable price, I need to wait until Monday to get some quotes on paint costs from the local Sherwin Williams automotive shop. Is that it paint wise?? I have never used a urethane system before, lots of learning on this one.

Mista Sparkle is offline
Likes For Mista Sparkle:
Old 06-14-20, 05:12 PM
  #2
The Golden Boy
Extraordinary Magnitude

The Golden Boy's Avatar

Join Date: Aug 2009
Location: Waukesha WI
Posts: 12,814

Bikes: 1978 Trek TX700; 1978/79 Trek 736; 1984 Specialized Stumpjumper Sport; 1984 Schwinn Voyageur SP; 1985 Trek 620; 1985 Trek 720; 1986 Trek 400 Elance; 1987 Schwinn High Sierra; 1990 Miyata 1000LT

Mentioned: 77 Post(s)
Tagged: 0 Thread(s)
Quoted: 2280 Post(s)
Liked 793 Times in 484 Posts
Looking forward to seeing this!

Weren't these built in "The Cage" in Chicago?
__________________
*Recipient of the 2006 Time Magazine "Person Of The Year" Award*

Commence to jigglin’ huh?!?!

"But hey, always love to hear from opinionated amateurs." -says some guy to Mr. Marshall.
The Golden Boy is offline
Old 06-14-20, 05:39 PM
  #3
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 7,933

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400, 2013 Novara Randonee, 1990 Trek 970

Mentioned: 28 Post(s)
Tagged: 0 Thread(s)
Quoted: 1708 Post(s)
Liked 1,360 Times in 880 Posts
A good cage should hold a bottle on the underside of the top tube.
dedhed is offline
Likes For dedhed:
Old 06-14-20, 06:01 PM
  #4
Kat12
Senior Member

Join Date: Aug 2009
Posts: 201
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 134 Post(s)
Liked 104 Times in 74 Posts
Originally Posted by The Golden Boy View Post
Looking forward to seeing this!

Weren't these built in "The Cage" in Chicago?
That year? I believe so. A friend of mine just bought a Deluxe Twinn from around that era (still looking for the serial number to be able to date it precisely, but based on color and features, some time between '68 and '73, I think I found through Google) and hers was made in Chicago.
Kat12 is offline
Old 06-14-20, 07:40 PM
  #5
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 7,933

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400, 2013 Novara Randonee, 1990 Trek 970

Mentioned: 28 Post(s)
Tagged: 0 Thread(s)
Quoted: 1708 Post(s)
Liked 1,360 Times in 880 Posts
Look into powdercoating as well.

https://www.ebay.com/itm/Vintage-Sch...-/372635641534
dedhed is offline
Old 06-14-20, 08:09 PM
  #6
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,620

Bikes: https://www.theheadbadge.com

Mentioned: 74 Post(s)
Tagged: 0 Thread(s)
Quoted: 1569 Post(s)
Liked 1,823 Times in 1,051 Posts
Bring the stoker's bottle down a bit so they can pull it out. Front one looks good. Add a third under the downtube, just so it's there.

If you want to get particularly adventurous, use this as an opportunity to braze in an eccentric BB shell in place of the Ashtabula in front. It'll lock you into using square taper cranks in front, but you'll never have to fight a chain tensioner again. You can always put a square taper BB adapter in the rear shell to match them up.

-Kurt
__________________







cudak888 is offline
Old 06-14-20, 08:13 PM
  #7
thumpism
Bikes are okay, I guess.

thumpism's Avatar

Join Date: Jan 2015
Location: Richmond, Virginia
Posts: 7,321

Bikes: Waterford Paramount Touring, Giant CFM-2, Raleigh Sports 3-speeds in M23 & L23, Schwinn Cimarron oddball build, Marin Palisades Trail dropbar conversion, Nishiki Cresta GT

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 2099 Post(s)
Liked 960 Times in 704 Posts
Originally Posted by cudak888 View Post
...use this as an opportunity to braze in an eccentric BB shell in place of the Ashtabula in front. It'll lock you into using square taper cranks in front, but you'll never have to fight a chain tensioner again.
Can't you just slot the existing front BB shell and then add pinch bolt tabs bridging the slot? Fit the eccentric into that and go.
thumpism is offline
Old 06-14-20, 08:21 PM
  #8
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,620

Bikes: https://www.theheadbadge.com

Mentioned: 74 Post(s)
Tagged: 0 Thread(s)
Quoted: 1569 Post(s)
Liked 1,823 Times in 1,051 Posts
Originally Posted by thumpism View Post
Can't you just slot the existing front BB shell and then add pinch bolt tabs bridging the slot? Fit the eccentric into that and go.
I haven't done this myself, but what are the chances that a tandem eccentric assembly's OD matches and the Ashtabula BB shell's ID?

-Kurt
__________________







cudak888 is offline
Old 06-14-20, 08:36 PM
  #9
thumpism
Bikes are okay, I guess.

thumpism's Avatar

Join Date: Jan 2015
Location: Richmond, Virginia
Posts: 7,321

Bikes: Waterford Paramount Touring, Giant CFM-2, Raleigh Sports 3-speeds in M23 & L23, Schwinn Cimarron oddball build, Marin Palisades Trail dropbar conversion, Nishiki Cresta GT

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 2099 Post(s)
Liked 960 Times in 704 Posts
Originally Posted by cudak888 View Post
I haven't done this myself, but what are the chances that a tandem eccentric assembly's OD matches and the Ashtabula BB shell's ID?
As a buddy of mine was wont to say about the probability of an unlikely event (such as an attractive female showing up at his door out of the blue), "50/50, it will or it won't."
thumpism is offline
Likes For thumpism:
Old 06-14-20, 08:44 PM
  #10
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,620

Bikes: https://www.theheadbadge.com

Mentioned: 74 Post(s)
Tagged: 0 Thread(s)
Quoted: 1569 Post(s)
Liked 1,823 Times in 1,051 Posts
Originally Posted by thumpism View Post
As a buddy of mine was wont to say about the probability of an unlikely event (such as an attractive female showing up at his door out of the blue), "50/50, it will or it won't."
I'll put my money on the attractive female showing up at his door before figuring on an eccentric to have the right diameter.

EDIT: Tell your buddy he's about to get lucky. Ashtabula BB I.D.: 51.3 mm. Bushnell eccentric BB: 54mm. On the plus side, this means that the replacement shell will be larger. Should be easier to miter the existing tubes to it.

-Kurt
__________________








Last edited by cudak888; 06-14-20 at 08:47 PM.
cudak888 is offline
Old 06-15-20, 07:21 AM
  #11
thumpism
Bikes are okay, I guess.

thumpism's Avatar

Join Date: Jan 2015
Location: Richmond, Virginia
Posts: 7,321

Bikes: Waterford Paramount Touring, Giant CFM-2, Raleigh Sports 3-speeds in M23 & L23, Schwinn Cimarron oddball build, Marin Palisades Trail dropbar conversion, Nishiki Cresta GT

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 2099 Post(s)
Liked 960 Times in 704 Posts
Originally Posted by cudak888 View Post
Ashtabula BB I.D.: 51.3 mm. Bushnell eccentric BB: 54mm. On the plus side, this means that the replacement shell will be larger. Should be easier to miter the existing tubes to it.
Hey, that's what 50/50 is all about.
thumpism is offline
Old 06-15-20, 07:36 AM
  #12
cudak888
www.theheadbadge.com

cudak888's Avatar

Join Date: Sep 2005
Location: Southern Florida
Posts: 26,620

Bikes: https://www.theheadbadge.com

Mentioned: 74 Post(s)
Tagged: 0 Thread(s)
Quoted: 1569 Post(s)
Liked 1,823 Times in 1,051 Posts
Originally Posted by thumpism View Post
Hey, that's what 50/50 is all about.
Isn't it great how we've hijacked the OP's original intentions with the Twinn?

"I just wanted some bottle cage mounts, darn it!"

-Kurt
__________________







cudak888 is offline
Old 06-15-20, 08:28 AM
  #13
himespau
Senior Member

himespau's Avatar

Join Date: Jun 2008
Location: Louisville, KY
Posts: 12,213
Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 2848 Post(s)
Liked 1,413 Times in 829 Posts
Any way a cage would fit on the captains seat tube above the top tube? Or would that interfere with the seatpost too much?
himespau is offline
Old 06-15-20, 09:22 AM
  #14
thumpism
Bikes are okay, I guess.

thumpism's Avatar

Join Date: Jan 2015
Location: Richmond, Virginia
Posts: 7,321

Bikes: Waterford Paramount Touring, Giant CFM-2, Raleigh Sports 3-speeds in M23 & L23, Schwinn Cimarron oddball build, Marin Palisades Trail dropbar conversion, Nishiki Cresta GT

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 2099 Post(s)
Liked 960 Times in 704 Posts
Originally Posted by cudak888 View Post
Isn't it great how we've hijacked the OP's original intentions with the Twinn?

"I just wanted some bottle cage mounts, darn it!"
Not at all. Once he mentioned braze-ons he opened the door to just such suggestions and, while the eccentric idea might have been a little, er...eccentric, it was not without a reasonable foundation. However, speaking as someone who has owned, ridden and maintained a Schwinn Deluxe Twinn I do think that the OP has moved beyond the level of putting lipstick on a pig and now firmly into the territory of extensive elective surgery on that same pig.
thumpism is offline
Likes For thumpism:
Old 06-15-20, 11:07 AM
  #15
Mista Sparkle
Senior Member
Thread Starter

Join Date: Sep 2016
Location: Aurora, IL
Posts: 109

Bikes: 2007 Fuji Roubaix, 2018 Trek Marlin 5, Huffy Baron (Retired), Schwinn Twinn (On Deck)

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 29 Post(s)
Liked 23 Times in 20 Posts
Great guys!

So I'll probably toss on on the underside of the top tube, The braze-ons came in a pack of 10 so 3 mounts and tidying up some other holes uses 9. I don't think I can reasonably put one on the seat tube in the space that exists.

Though it looks cool, I'm gonna skip the eccentric BB as that cost more than the bike to begin with...

As far as lipstick on a pig, yeah, it is a bit of that, if urethane paint costs too much I'll likely just end up putting some cheaper enamel on it (safety blue?). I'll probably paint our newly acquired trail-a-bike to match for fun. I looked a bit into powder coating and it didn't seem unreasonable, but still probably outside of my budget.

I did see the stickers, I may or may not go that route, we have a vinyl cutter at work I might be able to run some stuff off on. That can be added later.

I have some time to work on this as it is unlikely my wife will be able to join me until we can add our youngest to the trailer. So I'm fine with things that are in-expensive (bosses, paint, lube, general cleanup) even if they are otherwise rather involved. I did shoot myself in the foot on the wheels though.
Mista Sparkle is offline
