Roller Bearing Headset adjustment

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Roller Bearing Headset adjustment

Old 08-08-20, 05:56 PM
  #1
Mr. Spadoni
Senior Member
Thread Starter

Join Date: Jan 2015
Posts: 415
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 159 Post(s)
Liked 53 Times in 31 Posts
Roller Bearing Headset adjustment

Just about to get a bike on the road that has a Galli headset that I just discovered has roller bearings.
I like the idea of roller bearings, and have had one on another bike BUT
before I screw this one up, is there anything different about adjustment/tightness/etc. that I should keep in mind before I take it on the road?
Mr. Spadoni is offline
Old 08-08-20, 06:09 PM
  #2
canopus
Senior Member

canopus's Avatar

Join Date: Mar 2009
Location: Kingwood, TX
Posts: 1,351

Bikes: 1985 Cannondale SR300, 1985 Cannondale ST400, 1984 Trek 760, 1984 Trek 610, 1984 Trek 720, 1981 Trek 710, 1979 Trek 710, Gary Littlejohn Cruiser, BMX

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 55 Post(s)
Liked 50 Times in 38 Posts
They pretty much adjust the same. They can usually handle a little more preload than round bearings but I wouldn't put it in if not needed. There is nothing really different about them. I am not familiar with the Galli but on the Stronglights (aluminum & plastic versions) they had metal races (top & bottom of the bearing) that when left out would ruin the headset.
__________________
1984 Cannondale ST
1985 Cannondale SR300
1980 Gary Littlejohn Cruiser
1984 Trek 760
1981 Trek 710
Pics
canopus is offline
Old 08-08-20, 07:03 PM
  #3
steelbikeguy
Senior Member

steelbikeguy's Avatar

Join Date: Feb 2008
Location: Peoria, IL
Posts: 2,005
Mentioned: 57 Post(s)
Tagged: 0 Thread(s)
Quoted: 688 Post(s)
Liked 227 Times in 140 Posts
I've been using the Stronglight Delta and A9 headsets for 30 years now, so I may have forgotten what is most surprising when first fiddling with this style of headset. Still, I'd say that the big difference is that there is more rotational drag with roller bearings. This can lead you to think the bearings are tight when they are still a hair loose. You'll want to rely more on the method of applying the front brake and rocking the bike fore and aft to look for play.

Steve in Peoria
steelbikeguy is offline
Likes For steelbikeguy:
Old 08-08-20, 07:17 PM
  #4
Salamandrine
Senior Member

Join Date: Oct 2015
Location: Los Angeles
Posts: 6,154

Bikes: 78 Masi Criterium, 68 PX10, 2016 Mercian King of Mercia, Rivendell Clem Smith Jr

Mentioned: 118 Post(s)
Tagged: 0 Thread(s)
Quoted: 2252 Post(s)
Liked 462 Times in 347 Posts
I remember them from decades ago. Adjust normally to as loose as it goes, but with no play at all. They'll feel subjectively a little tight. +1 to what steelbikeguy says. In addition, I'd do the bounce the front wheel on the floor trick. You'll hear and/or feel a bit of a rattle if it's loose. Sometimes the front brake trick will miss the final last bit of looseness.
Salamandrine is offline
Likes For Salamandrine:
Old 08-09-20, 08:57 AM
  #5
Mr. Spadoni
Senior Member
Thread Starter

Join Date: Jan 2015
Posts: 415
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 159 Post(s)
Liked 53 Times in 31 Posts
Thanks. Glad I asked. I was feeling a little bit more bind than I expected but am at the point that I am not getting any fork rocking so I think I am good to go.
Mr. Spadoni is offline
Old 08-09-20, 10:32 AM
  #6
3alarmer
Friendship is Magic

3alarmer's Avatar

Join Date: Nov 2010
Location: The Big Tomato
Posts: 18,893

Bikes: old ones

Mentioned: 259 Post(s)
Tagged: 0 Thread(s)
Quoted: 18548 Post(s)
Liked 2,100 Times in 1,541 Posts
.
...I can't add much. Just that they are similar in design to an automotive wheel bearing, thus require a slight pre-load in order to function as designed. Not certain if it is specified anywhere in the literature. I adjust them to where the wheel in the fork will just flop over under its own weight.
3alarmer is online now
Likes For 3alarmer:
Old 08-09-20, 01:47 PM
  #7
unworthy1
Stop reading my posts!

unworthy1's Avatar

Join Date: Sep 2004
Posts: 10,803
Mentioned: 55 Post(s)
Tagged: 0 Thread(s)
Quoted: 548 Post(s)
Liked 182 Times in 147 Posts
And probable that your Galli is either a rebranded Stronglight A-9 (all alloy) or B-10 (plastic cups) so exactly like a Stronglight!
But Galli DID have one unique model with rollers that's entirely different, has thicker rollers in metal cages at a more "upright" angle than the Stronglight resin cages with smaller rollers.
Here's a link to that rare bird from velobase: VeloBase.com - Component: Galli (tapered roller bearing, cuscinetto di rulli conici)
unworthy1 is offline
Old 08-09-20, 01:56 PM
  #8
steelbikeguy
Senior Member

steelbikeguy's Avatar

Join Date: Feb 2008
Location: Peoria, IL
Posts: 2,005
Mentioned: 57 Post(s)
Tagged: 0 Thread(s)
Quoted: 688 Post(s)
Liked 227 Times in 140 Posts
Originally Posted by unworthy1 View Post
And probable that your Galli is either a rebranded Stronglight A-9 (all alloy) or B-10 (plastic cups) so exactly like a Stronglight!
But Galli DID have one unique model with rollers that's entirely different, has thicker rollers in metal cages at a more "upright" angle than the Stronglight resin cages with smaller rollers.
Here's a link to that rare bird from velobase: VeloBase.com - Component: Galli (tapered roller bearing, cuscinetto di rulli conici)
I was just poking through an old Bike Warehouse catalog and saw that they sold that headset. The illustration leaves a bit to be desired, but the angle of the bearing really looks better suited to an axle bearing than something like a headset that is carrying a thrust load.




Steve in Peoria
steelbikeguy is offline
Old 08-09-20, 04:05 PM
  #9
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Posts: 21,707

Bikes: Several, mostly not name brands.

Mentioned: 126 Post(s)
Tagged: 0 Thread(s)
Quoted: 2240 Post(s)
Liked 629 Times in 423 Posts
Originally Posted by unworthy1 View Post
And probable that your Galli is either a rebranded Stronglight A-9 (all alloy) or B-10 (plastic cups) so exactly like a Stronglight!
But Galli DID have one unique model with rollers that's entirely different, has thicker rollers in metal cages at a more "upright" angle than the Stronglight resin cages with smaller rollers.
Here's a link to that rare bird from velobase: VeloBase.com - Component: Galli (tapered roller bearing, cuscinetto di rulli conici)
The tapered roller bearing unit has less inherent friction than the Stronglight cylindrical roller bearing units since there is no sliding contact on the tapered rollers. IMO, the slight drag of sliding contact with the Stronglight units is not a concern, since headsets are not in constant rotation in use. The tapered roller bearings are also much fussier about frame prep than the Stronglight units with their floating races.
JohnDThompson is offline
Old 08-09-20, 04:36 PM
  #10
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Posts: 21,707

Bikes: Several, mostly not name brands.

Mentioned: 126 Post(s)
Tagged: 0 Thread(s)
Quoted: 2240 Post(s)
Liked 629 Times in 423 Posts
Originally Posted by steelbikeguy View Post
I was just poking through an old Bike Warehouse catalog and saw that they sold that headset. The illustration leaves a bit to be desired, but the angle of the bearing really looks better suited to an axle bearing than something like a headset that is carrying a thrust load.
I suspect Galli used a standard bearing for that headset. A less acute angle would have required far more taper on the rollers to eliminate the sliding contact as the bearing rotates. The Stronglight is probably more suited for thrust loads, but does have more inherent friction than the tapered rollers.
JohnDThompson is offline
Old 08-09-20, 07:55 PM
  #11
Mr. Spadoni
Senior Member
Thread Starter

Join Date: Jan 2015
Posts: 415
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 159 Post(s)
Liked 53 Times in 31 Posts
Well now I am going to have to open it up to see which type it us. Stay tuned. It’s going to be a few days.
Mr. Spadoni is offline
Old 08-15-20, 05:01 PM
  #12
Mr. Spadoni
Senior Member
Thread Starter

Join Date: Jan 2015
Posts: 415
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 159 Post(s)
Liked 53 Times in 31 Posts
Turns out I do have the Galli as pictured in the ad. As a I do have the SL on another bike, the internal difference is obvious. Might have to drop out the spacer. Locknut is only engaging on about three threads with spacer in place and it is all alloy. Genuflecting towards the nearest aluminum smelter now.....
Mr. Spadoni is offline
