Columbus tubing sticker question

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Columbus tubing sticker question

Old 08-10-20, 12:20 PM
  #1
bikemig
Senior Member
Thread Starter

bikemig's Avatar

Join Date: Apr 2012
Location: Middle Earth (aka IA)
Posts: 17,319

Bikes: A bunch of old bikes and a few new ones

Mentioned: 140 Post(s)
Tagged: 0 Thread(s)
Quoted: 4620 Post(s)
Liked 994 Times in 681 Posts
Columbus tubing sticker question

So I picked up recently what looks to be a 1985-1986 tretubi pinarello cross bike. I am trying to figure out the sticker. I can make out the words tubi and reinforzati. That means reinforced tubes, right? Does that mean that the bike has a double butted main triangle? Aelle was plain gauge right? Columbus SL, SP, and Cromor I believe are all double butted?

This is from 1989 but it has a good summary of the various Columbus steels.

https://www.equusbicycle.com/bike/co...umbuschart.htm



bikemig is offline
Old 08-10-20, 12:32 PM
  #2
SJX426
Senior Member

SJX426's Avatar

Join Date: May 2008
Location: Fredericksburg, Va
Posts: 7,122

Bikes: '73 Bottecchia Giro d'Italia, '83 Colnago Superissimo, '84 Trek 610, '84 Trek 760, '88 Pinarello Veneto, '90 De Rosa Professional, '91 Pinarello Montello, '94 Burley Duet, 97 Specialized RockHopper, 2010 Langster, Tern Link D8

Mentioned: 49 Post(s)
Tagged: 0 Thread(s)
Quoted: 742 Post(s)
Liked 300 Times in 197 Posts
Have you checked the Pinarello catalogs?
__________________
Bikes don't stand alone. They are two tired.
SJX426 is offline
Old 08-10-20, 12:38 PM
  #3
scarlson
Senior Member

scarlson's Avatar

Join Date: Jun 2010
Location: Medford MA
Posts: 917

Bikes: Ron Cooper touring, 1959 Jack Taylor 650b ladyback touring tandem, Vitus 979, Joe Bell painted Claud Butler Dalesman, Colin Laing curved tube tandem, heavily-Dilberted 1982 Trek 6xx

Mentioned: 27 Post(s)
Tagged: 0 Thread(s)
Quoted: 398 Post(s)
Liked 436 Times in 263 Posts
Originally Posted by bikemig View Post
That means reinforced tubes, right? Does that mean that the bike has a double butted main triangle?
Yeah, I'd wager on at least this much because of the "tretubi" meaning "three tubes" AKA the main triangle, and renforzati meaning butted.

I leave the rest to the experts as my Italian stops there.

scarlson is offline
Likes For scarlson:
Old 08-10-20, 12:40 PM
  #4
T-Mar
Senior Member

Join Date: Nov 2004
Posts: 20,067
Mentioned: 524 Post(s)
Tagged: 1 Thread(s)
Quoted: 3392 Post(s)
Likes: 0
Liked 788 Times in 613 Posts
This is a 1978-1987 decal for a tretubi Columbus SL or SP frameset. In other words, only the three main tubes are butted SL or SP, with the stays and blades some other material (often, though not always, Aelle). Builders typically transitioned from SL to heavier gauge SP around thge 58-60cm frame size.

The only Columbus decals during this period that did not not have the tubeset designation were SL and SP. Aelle came in a standard, plain gauge version and a butted Aelle R (Rinforzati) version. Cromor was also butted. Columbus' butted tubesets used a single butted seat tube, with the top and down tubes being double butted.
T-Mar is offline
Likes For T-Mar:
Old 08-10-20, 12:40 PM
  #5
bikemig
Senior Member
Thread Starter

bikemig's Avatar

Join Date: Apr 2012
Location: Middle Earth (aka IA)
Posts: 17,319

Bikes: A bunch of old bikes and a few new ones

Mentioned: 140 Post(s)
Tagged: 0 Thread(s)
Quoted: 4620 Post(s)
Liked 994 Times in 681 Posts
Originally Posted by SJX426 View Post
Have you checked the Pinarello catalogs?
Oh yeah, this bike does not show up in the catalogs. This bike is a pretty rare bird and info on it on the interwebs is not that easy to find.
bikemig is offline
Old 08-10-20, 12:42 PM
  #6
bikemig
Senior Member
Thread Starter

bikemig's Avatar

Join Date: Apr 2012
Location: Middle Earth (aka IA)
Posts: 17,319

Bikes: A bunch of old bikes and a few new ones

Mentioned: 140 Post(s)
Tagged: 0 Thread(s)
Quoted: 4620 Post(s)
Liked 994 Times in 681 Posts
Originally Posted by T-Mar View Post
This is a 1978-1987 decal for a tretubi Columbus SL or SP frameset. In other words, only the three main tubes are butted SL or SP, with the stays and blades some other material (often, though not always, Aelle). Builders typically transitioned from SL to heavier gauge SP around thge 58-60cm frame size.

The only Columbus decals during this periods that did not not have the tubeset designation were SL and SP. Aelle came in a standard, plain gauge version and a butted Aelle R (Rinforzati) version. Cromor was also butted. Columbus' butted tubesets used a single butted seat tube, with the top and down tubes being double butted.
That's what I thought as well. But here's the kicker. The bike came to be with the wrong seatpost, a 27.2. A 27.0 didn't want to slide down either but a 26.8 works like a charm. Now I've seen one bike that I am fairly confident was made of columbus SP but it had a 26.8 seatpost. Possible? Or maybe the ears got pinched and this really is a 27.0? That may be the more likely explanation but the 26.8 fits in there pretty snugly once you tighten it down.

Here's the thread on the bike,

Pinarello Treviso cyclo cross

It's not a Treviso, which is a full SL bike. The cross was sold to me as a Treviso and so I thought it was the "cross" version of the Treviso when I purchased it.

Last edited by bikemig; 08-10-20 at 12:50 PM.
bikemig is offline
Old 08-10-20, 12:44 PM
  #7
satbuilder
Senior Member

Join Date: May 2005
Location: Southern Maryland
Posts: 1,284

Bikes: 1969/70 Legnano Roma, 1971 Guerciotti, 1972 Cinelli SC, 1973 Bianchi Team, 173 Colnago Super, 1974 Marnati Corsa, 1974 ish Motobecane CT, 1971 Mercier 300, 1977/78 Colnago Mexico, 1982 Pinarello Italia,Tesch S-22, 1983 Peugeot Mixte

Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 198 Post(s)
Liked 44 Times in 29 Posts
I bought a Pinarello Italia model new in 1982 or 1983, I forget. It had the Tretubi sticker, as others have mentioned it was 3 main tubes butted tubing, This one came with Gipiemme dropouts, and was outfitted with Campagnolo Gran Sport and NR components. Still have the frame and some of the components.

Here's a link to what the sticker should look like: Columbus Tretubi decal years of manufacture?
satbuilder is offline
Likes For satbuilder:
Old 08-10-20, 01:04 PM
  #8
T-Mar
Senior Member

Join Date: Nov 2004
Posts: 20,067
Mentioned: 524 Post(s)
Tagged: 1 Thread(s)
Quoted: 3392 Post(s)
Likes: 0
Liked 788 Times in 613 Posts
Originally Posted by bikemig View Post
That's what I thought as well. But here's the kicker. The bike came to be with the wrong seatpost, a 27.2. A 27.0 didn't want to slide down either but a 26.8 works like a charm. Now I've seen one bike that I am fairly confident was made of columbus SP but it had a 26.8 seatpost. Possible?

Oh, definitely. It's not uncommon for tubes to distort to non-round during the brazing process. Then there's scale and cinch slot burrs, which can result in an apparently undersize tube. Most reputable builders will ream/hone a seat tube after manufacture to bring it back to OEM spec, but a lot of the Italian builders had a poor reputation for frame prep.


However, it's also possible to distort the tube by installing and clamping an undersize post. This typically results in a cinch slot which is narrower at the top than the bottom. In such cases, I pry the cinch slot open with a wide, flat bladed screwdriver, so that it's wider at the top. Then I see what size seat post will install past the bottom of the slot,as that usually represents the true inner diameter of the tube.
T-Mar is offline
Likes For T-Mar:
Old 08-10-20, 01:11 PM
  #9
bikemig
Senior Member
Thread Starter

bikemig's Avatar

Join Date: Apr 2012
Location: Middle Earth (aka IA)
Posts: 17,319

Bikes: A bunch of old bikes and a few new ones

Mentioned: 140 Post(s)
Tagged: 0 Thread(s)
Quoted: 4620 Post(s)
Liked 994 Times in 681 Posts
Originally Posted by T-Mar View Post
Oh, definitely. It's not uncommon for tubes to distort to non-round during the brazing process. Then there's scale and cinch slot burrs, which can result in an apparently undersize tube. Most reputable builders will ream/hone a seat tube after manufacture to bring it back to OEM spec, but a lot of the Italian builders had a poor reputation for frame prep.


However, it's also possible to distort the tube by installing and clamping an undersize post. This typically results in a cinch slot which is narrower at the top than the bottom. In such cases, I pry the cinch slot open with a wide, flat bladed screwdriver, so that it's wider at the top. Then I see what size seat post will install past the bottom of the slot,as that usually represents the true inner diameter of the tube.
This is the most likely explanation for why the 26.8 fits well. It likely is a 27.0 or a 27.2 and it simply needs some work to get the right size seatpost to fit. This is very useful; thank you.
bikemig is offline
Old 08-10-20, 01:13 PM
  #10
T-Mar
Senior Member

Join Date: Nov 2004
Posts: 20,067
Mentioned: 524 Post(s)
Tagged: 1 Thread(s)
Quoted: 3392 Post(s)
Likes: 0
Liked 788 Times in 613 Posts
Originally Posted by bikemig View Post
Oh yeah, this bike does not show up in the catalogs. This bike is a pretty rare bird and info on it on the interwebs is not that easy to find.
In many cases, USA distributors did not import full products lines but only what they thought would sell in sufficiently large quantities. A lot of these "smaller Italian brands" had larger ranges than we realize, because they were not catalogued in the brochures issued by the American distributors.
T-Mar is offline
Old 08-10-20, 02:24 PM
  #11
SJX426
Senior Member

SJX426's Avatar

Join Date: May 2008
Location: Fredericksburg, Va
Posts: 7,122

Bikes: '73 Bottecchia Giro d'Italia, '83 Colnago Superissimo, '84 Trek 610, '84 Trek 760, '88 Pinarello Veneto, '90 De Rosa Professional, '91 Pinarello Montello, '94 Burley Duet, 97 Specialized RockHopper, 2010 Langster, Tern Link D8

Mentioned: 49 Post(s)
Tagged: 0 Thread(s)
Quoted: 742 Post(s)
Liked 300 Times in 197 Posts
I know the factory can be unreliable, got the wrong year from them based on a SN, but this might be different They might actually know!
__________________
Bikes don't stand alone. They are two tired.
SJX426 is offline
