Cannondale Front Derailleur Options

I am working on a Cannondale R400 Triple. I believe its a 2001. I'm having trouble with the shifting on the front cogs.

The original deraileur has been replaced with a Microshift R10. I'm thinking I should go back to something like the original shimano. I need a clamp-on for a 28.6 tube that will handle 3 rings in front (30/42/52), 8 in the rear (12-25), and work with the Sora STI Dual Control brifters. Rear derailleur is a Shimano Sora RD-3300 Long Cage.

My choices seem to be the Claris FD-2403, the Sora FD-3403 or the Sora FD-R3030. Any thoughts or suggestions appreciated.

Last edited by kross57; 03-04-21 at 04:31 AM.
kross57 is offline
Old 03-04-21, 05:57 AM
  #2
Soody
Senior Member

Soody's Avatar

Join Date: Mar 2015
Location: New Zealand
Posts: 583

Bikes: Gunnar crosshairs, F Moser, Ken Evans, Pete Tansley, Rocky Mountain Summit, Cinelli mtb

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 92 Post(s)
Liked 83 Times in 48 Posts
Do you have a boss on your frame for a downtube shifter, with a cable adjuster mounted on it? Or is it just a cable stop?
You could do what Lance and Pantani did. Friction downtube shifter for front shifting. And switch your left STI to a plain brake lever.
It's far superior for road triples. Far more flexible too. You might find your current mech would then work well.
This would also let you use a lower granny. 28 or 26. That range might be nice.


Soody is offline
Likes For Soody:
Old 03-04-21, 06:41 AM
  #3
kross57
Senior Member
Thread Starter

Join Date: Aug 2018
Location: north NJ
Posts: 691

Bikes: Miyata 710, Univega Viva Sport, Centurion LeMans, Peugeot U09

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 211 Post(s)
Liked 102 Times in 76 Posts
Just a cable stop. Personally, I would prefer downtube levers, but I need to keep this one as close to stock as possible.
kross57 is offline
Old 03-04-21, 08:04 AM
  #4
kross57
Senior Member
Thread Starter

Join Date: Aug 2018
Location: north NJ
Posts: 691

Bikes: Miyata 710, Univega Viva Sport, Centurion LeMans, Peugeot U09

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 211 Post(s)
Liked 102 Times in 76 Posts
After checking, the Microshift I have now is listed as incompatible with my front chainrings.

I also checked again on the seat tube, which is 31.8 not 28.6.

I have tried every adjustment I can think of, and there is always a problem with the chain rubbing on the inner or outer plate in some (or many) gear combinations. Tightening/loosening the cable or adjusting the limit screws doesn't do it.

As far as replacements, someone pointed out that the specs for the FD3403 say min difference between top and intermediate is 11 teeth. In my case it is 10, correct? So, that would not work.

For the FD-3030, the "max ring teeth" is 50, whereas mine is 52. Again, no good.

Any suggestions on other models? I am now looking at the Shimano FD-5504, FD-5503 and microSHIFT R539. These seem to be compatible.
kross57 is offline
Likes For kross57:
Old 03-04-21, 08:20 AM
  #5
clubman
Youngman Grand

clubman's Avatar

Join Date: Jan 2010
Location: Nova Scotia
Posts: 7,166

Bikes: roadsters, club bikes, fixed and classic

Mentioned: 101 Post(s)
Tagged: 0 Thread(s)
Quoted: 1655 Post(s)
Liked 769 Times in 508 Posts
Yeah, gotta be 31.8. I used to run a Campy Racing Triple front gear on my R500 and it was brilliant.
clubman is offline
Old 03-05-21, 04:15 AM
  #6
kross57
Senior Member
Thread Starter

Join Date: Aug 2018
Location: north NJ
Posts: 691

Bikes: Miyata 710, Univega Viva Sport, Centurion LeMans, Peugeot U09

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 211 Post(s)
Liked 102 Times in 76 Posts
I ordered a FD-5504. I'll let you know how it works out. Thanks to all!
