Does this look like a Reynolds decal?

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Does this look like a Reynolds decal?

Old 04-03-21, 12:21 PM
  #26
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Originally Posted by 3speedslow View Post
That’s the real deal! Great snag! I continue to look for one of those.
A couple of years ago one was for sale at a Delaware beach town, but the asking price was so dear that I didn't reply to the ad. I wonder how many were sold. The price was around $200 back around 1970 and that was a lot of money; plus Sears was not the go to place for a good bicycle in my mind.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-03-21, 12:45 PM
  #27
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
More photos:
The front hub and notice the spokes as well


The rear hub, notice the spokes

Other stuff

__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-03-21, 01:17 PM
  #28
juvela
Senior Member

juvela's Avatar

Join Date: Feb 2013
Location: Alta California
Posts: 11,260
Mentioned: 312 Post(s)
Tagged: 1 Thread(s)
Quoted: 2675 Post(s)
Liked 1,072 Times in 814 Posts
-----

do rims match?

have not before seen the 40 code marked on the barrel of the Normandy Sport hub

front hub appears to have the Union U in a shield logo marked on the lateral face of the drive side flange

barrel will likely be unmarked

there are three threads showing on the adjustable bottom bracket cup

this may indicate that shell is under width

or it may indicate that assembly performed with a five series spindle intended for 70-71 mm shells

-----

Last edited by juvela; 04-03-21 at 01:21 PM. Reason: spellin'
juvela is offline
Old 04-03-21, 01:46 PM
  #29
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Originally Posted by juvela View Post
-----

do rims match?

have not before seen the 40 code marked on the barrel of the Normandy Sport hub

front hub appears to have the Union U in a shield logo marked on the lateral face of the drive side flange

barrel will likely be unmarked

there are three threads showing on the adjustable bottom bracket cup

this may indicate that shell is under width

or it may indicate that assembly performed with a five series spindle intended for 70-71 mm shells

-----
The rims appear to match to the eye, but when I rub a finger across the profile the front rim profile is more rounded than the rear. The seller had a ladies bike with a similar front wheel. I wonder if the wheels were swapped at some time past.

Oh man, the things you don't notice when buying a bike.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain

Last edited by dweenk; 04-03-21 at 01:56 PM.
dweenk is offline
Old 04-03-21, 02:20 PM
  #30
markk900
Senior Member

markk900's Avatar

Join Date: Jan 2007
Location: Ontario
Posts: 2,230
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 318 Post(s)
Liked 226 Times in 134 Posts
Originally Posted by juvela View Post
would have guessed bicycle very slightly too early for a Crane rear mech

IIRC it's launch was ~1972-----
That is a first generation Crane if that helps at all.....I had one as an upgrade on my AO-8 around 1973.
markk900 is offline
Old 04-03-21, 03:18 PM
  #31
juvela
Senior Member

juvela's Avatar

Join Date: Feb 2013
Location: Alta California
Posts: 11,260
Mentioned: 312 Post(s)
Tagged: 1 Thread(s)
Quoted: 2675 Post(s)
Liked 1,072 Times in 814 Posts
-----

a front hub from Union Frondenberg would fit right in with a cycle manufactured in Oesterreich

symbol am seeing on flange is this one





does rear hub exhibit groove indicating BSC thread?

have you been able to read any markings on rims?

are both Schrader drilled?

due to the good res of the images thought would be able to read the spoke logos but alas they are obscured by rust

on one wheel they look like they may be a crescent which is one of the symbols for Robergel

had expected Union there as well

is drive chain Union?

-----
juvela is offline
Old 04-03-21, 03:55 PM
  #32
Pcampeau
Senior Member

Join Date: Aug 2017
Location: Minneapolis
Posts: 555

Bikes: 1968 Raleigh Super Course. 1972 Raleigh Professional, 1975 Raleigh International, 1978 Raleigh Professional, 1985 Raleigh Prestige, 1972 Schwinn Paramount, 1980 Schwinn Voyageur 11.8, 1978 Schwinn Varsity, 1976 Peugeot PX10, 1972 Motobecane Le Champ

Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 182 Post(s)
Liked 221 Times in 130 Posts
Originally Posted by dweenk View Post
Assuming that the bike is 1970ish, what would the Reynolds decals look like?
I had one of these pass through my hands a couple of years ago. Here is the Reynolds decal.
Pcampeau is offline
Old 04-03-21, 04:46 PM
  #33
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Originally Posted by juvela View Post
-----

a front hub from Union Frondenberg would fit right in with a cycle manufactured in Oesterreich

symbol am seeing on flange is this one





does rear hub exhibit groove indicating BSC thread?

have you been able to read any markings on rims?

are both Schrader drilled?

due to the good res of the images thought would be able to read the spoke logos but alas they are obscured by rust

on one wheel they look like they may be a crescent which is one of the symbols for Robergel

had expected Union there as well

is drive chain Union?

-----
Both rims are drilled for Schraeder valve stems and I can't see any marking opposite the valve hole. It's getting dark now so I will get back to this tomorrow. I was able to remove both drop-out adjusters without damage, and have straightened the bent screw nearly well enough. Another task for tomorrow.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-03-21, 07:20 PM
  #34
mcgeez
Junior Member

mcgeez's Avatar

Join Date: Apr 2021
Location: Orlando, FL
Posts: 10

Bikes: Specialized Expedition

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked 2 Times in 2 Posts
Free Spirit

dweenk, I noticed your post. I still have a vintage Free Spirit model 503.47448.0 purchased new 11/26/1976. I have the owners manual and sales receipt and if I can be of any help in your efforts happy to oblige. It's a great ride, Reynolds 531 weighs in at only 26.5 lbs.
I even did a couple Columbia Triathlons up there in MD some years back. Since I clicked 80 last year I gave up roading, moved to a hybrid and stick to the trails now. The Free Spirit is just hanging in the garage gathering dust.
I tried to attach a photo but not allowed yet since I'm a newbee on the site per the message I got. Anyhow, good luck
mcgeez is offline
Likes For mcgeez:
Old 04-03-21, 07:39 PM
  #35
juvela
Senior Member

juvela's Avatar

Join Date: Feb 2013
Location: Alta California
Posts: 11,260
Mentioned: 312 Post(s)
Tagged: 1 Thread(s)
Quoted: 2675 Post(s)
Liked 1,072 Times in 814 Posts
Originally Posted by mcgeez View Post
dweenk, I noticed your post. I still have a vintage Free Spirit model 503.47448.0 purchased new 11/26/1976. I have the owners manual and sales receipt and if I can be of any help in your efforts happy to oblige. It's a great ride, Reynolds 531 weighs in at only 26.5 lbs.
I even did a couple Columbia Triathlons up there in MD some years back. Since I clicked 80 last year I gave up roading, moved to a hybrid and stick to the trails now. The Free Spirit is just hanging in the garage gathering dust.
I tried to attach a photo but not allowed yet since I'm a newbee on the site per the message I got. Anyhow, good luck
-----

one question he has asked which has not as yet been answered is what the stock stem was

suspect his example several years earlier than yours so kitting may well have differed...

thanks for posting and welcome to the forum!

-----
juvela is offline
Old 04-04-21, 08:25 AM
  #36
3speedslow
Senior Member

3speedslow's Avatar

Join Date: Oct 2010
Location: Jacksonville, NC
Posts: 9,052

Bikes: A few

Mentioned: 114 Post(s)
Tagged: 0 Thread(s)
Quoted: 1860 Post(s)
Liked 777 Times in 496 Posts
The frame is gold, likes it’s colour! Give it some better components!

Any markings on the wingnuts?
3speedslow is offline
Old 04-04-21, 09:25 AM
  #37
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Originally Posted by 3speedslow View Post
The frame is gold, likes it’s colour! Give it some better components!

Any markings on the wingnuts?
No markings on the wingnuts.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-04-21, 09:59 AM
  #38
CO_Hoya
Señor Member

Join Date: Dec 2007
Location: Colorado
Posts: 878

Bikes: Yes

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 222 Post(s)
Liked 163 Times in 92 Posts
Originally Posted by mcgeez View Post
dweenk, I noticed your post. I still have a vintage Free Spirit model 503.47448.0 purchased new 11/26/1976. I have the owners manual and sales receipt and if I can be of any help in your efforts happy to oblige. It's a great ride, Reynolds 531 weighs in at only 26.5 lbs.
I even did a couple Columbia Triathlons up there in MD some years back. Since I clicked 80 last year I gave up roading, moved to a hybrid and stick to the trails now. The Free Spirit is just hanging in the garage gathering dust.
I tried to attach a photo but not allowed yet since I'm a newbee on the site per the message I got. Anyhow, good luck
Pic assist:

CO_Hoya is offline
Likes For CO_Hoya:
Old 04-04-21, 11:37 AM
  #39
juvela
Senior Member

juvela's Avatar

Join Date: Feb 2013
Location: Alta California
Posts: 11,260
Mentioned: 312 Post(s)
Tagged: 1 Thread(s)
Quoted: 2675 Post(s)
Liked 1,072 Times in 814 Posts
Originally Posted by CO_Hoya View Post
Pic assist:

-----

thank you for the pic assist!

front hub of pictured cycle appears to be Normandy Sport - a match for the rear hub of subject bike

interesting that brake arrangement offers no quick release

long nut mounting rear brake caliper suggests that brake bridge may be ESGE plate style

machine certainly appears too early for a 1976 date - perhaps it was old stock when purchased new...

dating -

here is the VB listing for the first edition of the Crane model rear mech; a launch date of 1973 is given:

​​​​​​VeloBase.com - Component: Shimano Crane D-501

this date sounded slightly late to me so checked with disraeligears.co.uk who give a launch date of 1971:

​​​​​​Shimano Crane derailleur (DR-101)

disraeli explains that the same mech was described in manufacturer materials as both the model DR-101 and as the model D-501

the back side of the Sakee Ringyo crank arms should exhibit a date marking:

Date of Manufacture of Bicycle Components can be used to date a bike: component dating

headset:

closely resembles that of the Alatet from Britain, a nicer design and finish than that seen on base model Steyr and Puch badged products:



the Brampton Alatet from Britain:



-----
juvela is offline
Old 04-04-21, 01:19 PM
  #40
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
I had the bike pretty much stripped down until I cut the end of my thumb. So I am workng wirh a paw on the left and a hand on the right for a few days.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-04-21, 01:29 PM
  #41
mcgeez
Junior Member

mcgeez's Avatar

Join Date: Apr 2021
Location: Orlando, FL
Posts: 10

Bikes: Specialized Expedition

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked 2 Times in 2 Posts
Also thanks for the pic assist.
Quite possible it was old stock when purchased in 1976. Sears in Moorestown NJ discounted it $50 off the list $229.99.
The serial number is 4713157 if that is any help.
The seat post diameter measures one inch and uses a sleeve to fit to the seat tube.
mcgeez is offline
Old 04-05-21, 09:21 AM
  #42
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
I checked the date code on the SR crank arms. In the circle there is a 1 at the 2 o'clock position and an 8 at 8 o'clock. Crank arm length is 171.5mm.
I don't see any markings on the drive chain plates.
The drop-outs and fork ends are Shimano.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-05-21, 12:58 PM
  #43
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Originally Posted by mcgeez View Post
dweenk, I noticed your post. I still have a vintage Free Spirit model 503.47448.0 purchased new 11/26/1976. I have the owners manual and sales receipt and if I can be of any help in your efforts happy to oblige. It's a great ride, Reynolds 531 weighs in at only 26.5 lbs.
I even did a couple Columbia Triathlons up there in MD some years back. Since I clicked 80 last year I gave up roading, moved to a hybrid and stick to the trails now. The Free Spirit is just hanging in the garage gathering dust.
I tried to attach a photo but not allowed yet since I'm a newbee on the site per the message I got. Anyhow, good luck
Thanks for your post. I may pick your brain about some of the original components. I still need to de-crud and decode dates on parts. I think my bike is early 70's, and maybe date codes will reveal the truth.
I do have one question. Who manufactured the derailleurs and stem on your bike?
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-05-21, 03:59 PM
  #44
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Minor work on the bike today.
Major work was getting the second Covid Vax for me and my lovely wife. That accomplished, we came home and had a nice egg salad sandwich. My next task is to prep the salmon, potatoes, and aspasagus for dinner.
I'll let my wife handle the knives.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-05-21, 07:21 PM
  #45
mcgeez
Junior Member

mcgeez's Avatar

Join Date: Apr 2021
Location: Orlando, FL
Posts: 10

Bikes: Specialized Expedition

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked 2 Times in 2 Posts
dweenk, Rear derailleur is Shimano Crane.
I'll try to post a pic of the front cage plate, can't quite decipher the logo. Maybe I can get a pic assist again, still short of my 10 post threshold.
Stem is "AVA"
mcgeez is offline
Old 04-05-21, 07:28 PM
  #46
CO_Hoya
Señor Member

Join Date: Dec 2007
Location: Colorado
Posts: 878

Bikes: Yes

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 222 Post(s)
Liked 163 Times in 92 Posts
Originally Posted by mcgeez View Post
Maybe I can get a pic assist again, still short of my 10 post threshold.
Pic assist (it’s what I do):


That appears to be a Shimano Titlist front derailleur (Velobase link).

CO_Hoya is offline
Old 04-06-21, 02:16 PM
  #47
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
I gave the frame its first bath today. WD-40 to soften the crud on the dropouts and chainstays before dishwashing liqiud in water. It's better now and I can handle it without gloves. I still am unable to remove the top tube cable guides even after a good dosing of PB Blaster. I may have to resort to a Dremel cut-off wheel for that, but I had one of them fly apart a couple of years ago. It ruined a perfectly good pair of goggles, and was probably my fault.



Anyone have a recommendation for removing 30 year old electrical tape from seat stays?
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-07-21, 12:32 PM
  #48
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
I haven't really looked closely at the wheels until today. I knew that they didn't match, but now I believe that the rear wheel is origional and the front is not. The rear rim is slightly magnetic - "rims of lightweight steel alloy" - as the catalog said. I am thinking that the rim is stainless steel, though it has a few spots of rust. The spokes are clean, maybe zinc coated? The front rim is aluminum, the hub is steel/alloy, nothing special, and the spokes are rust on a stick.
I have wheels; some are steel, some are alloy, and most are 700C. I am rethinking how to put this back together.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline
Old 04-10-21, 12:04 PM
  #49
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
Originally Posted by juvela View Post
-----

a front hub from Union Frondenberg would fit right in with a cycle manufactured in Oesterreich

symbol am seeing on flange is this one

have you been able to read any markings on rims?
-----
The rear hub is Normandy, stamped 40 below the manufacturer's name, and the rim is Araya. The front hub barrel is too rusty to read a name. After wire brushing it, I still can't see a name. The rim is Weinmann, Belgium.
The freewheel is Shimano.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain

Last edited by dweenk; 04-11-21 at 10:15 AM.
dweenk is offline
Likes For dweenk:
Old 04-15-21, 02:49 PM
  #50
dweenk
Senior Member
Thread Starter

dweenk's Avatar

Join Date: Mar 2013
Location: Maryland
Posts: 3,769

Bikes: 1972 Fuji S-10-S,1970 Raleigh Sports, and more

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 813 Post(s)
Liked 207 Times in 149 Posts
I found a pair of matching rims in my stash today. They're not age appropriate and the spokes are rusty, but they'll do for now. The rear freewheel is a six speed, so I am thinking of a 1 by 6.
The original Maxi crank is swaged so I'll clean it and stash it with the other original parts. Then I propose to use a more modern crank with a small chainring - 46 or so teeth. I will use the original Weinmann brakes, but I am going to change the bars and stem (the stem wasn't original anyhow) so it will have flat or upright bars.
__________________
"The man who does not read has no advantage over the man who cannot read." –Mark Twain
dweenk is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright © 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
