82 Miyata 1000 with stripped pedal threads

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

82 Miyata 1000 with stripped pedal threads

Old 04-30-21, 03:06 PM
  #1
sd5782
Senior Member
Thread Starter

Join Date: Jan 2019
Location: Toledo Ohio
Posts: 1,035

Bikes: 1964 Frejus,1972 Fuji Newest, 1973 Schwinn Super Sport, 1983 Trek 700, 1985 Ironman, 1985 Torpado, 1983 Peugeot UO14, 1989 Miyata 1000LT and others

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 368 Post(s)
Liked 400 Times in 219 Posts
82 Miyata 1000 with stripped pedal threads

I just purchased for cheap a nice 82 Miyata 1000 from my local cp-op. I see now why it was donated, as a cheap pedal was cross threaded into the left crank arm, and the right crankarm was worse as it was JB welded in. Searching, I see insert kits and such, and also reference to my friendly LBS doing such a repair. It is/was a nice looking SR Super Apex 86 bcd half step plus granny. Bike is otherwise all stock with little use and cheap new replacement tires on it. Not sure how I will proceed.

I will post pics when cleaned up on the valuation page and maybe on the sales page, as it is the 63cm size which is a bit big for me. It does have a shorter top tube. Bike had been sitting for 3 years, and the frame is probably worth what I paid. My plan was to take this bike to a swap meet next weekend, so I am somewhat glad I discovered the problem as I donít want to hide something from someone. I just got tired of seeing such a fine bike sitting there waiting for someone to trash it as a beater.
sd5782 is offline
Old 04-30-21, 03:12 PM
  #2
Dylansbob
2k miles from the midwest

Dylansbob's Avatar

Join Date: Feb 2005
Location: Washington
Posts: 1,833

Bikes: ~'75 Colin Laing, '80s Schwinn SuperSport 650b, ex-Backroads ti project...

Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 462 Post(s)
Liked 761 Times in 372 Posts
I'd just slap another crankset on and call it good.
Dylansbob is offline
Old 04-30-21, 03:37 PM
  #3
fettsvenska
Senior Member

fettsvenska's Avatar

Join Date: Dec 2012
Location: Eastern Washington
Posts: 438

Bikes: 1978 Raleigh Competition-1974 Raleigh Folder-1983 Austro Daimler-198? Fuji Monterey-Surly LHT-Surly Karate Monkey-Surly Cross Check

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 43 Post(s)
Liked 94 Times in 53 Posts
Originally Posted by dylansbob View Post
i'd just slap another crankset on and call it good.
^^^^^ this
fettsvenska is offline
Likes For fettsvenska:
Old 04-30-21, 03:45 PM
  #4
merziac
Senior Member

merziac's Avatar

Join Date: Oct 2015
Location: PDX
Posts: 11,049

Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2

Mentioned: 218 Post(s)
Tagged: 0 Thread(s)
Quoted: 3455 Post(s)
Liked 3,548 Times in 2,193 Posts
Originally Posted by sd5782 View Post
I just purchased for cheap a nice 82 Miyata 1000 from my local cp-op. I see now why it was donated, as a cheap pedal was cross threaded into the left crank arm, and the right crankarm was worse as it was JB welded in. Searching, I see insert kits and such, and also reference to my friendly LBS doing such a repair. It is/was a nice looking SR Super Apex 86 bcd half step plus granny. Bike is otherwise all stock with little use and cheap new replacement tires on it. Not sure how I will proceed.

I will post pics when cleaned up on the valuation page and maybe on the sales page, as it is the 63cm size which is a bit big for me. It does have a shorter top tube. Bike had been sitting for 3 years, and the frame is probably worth what I paid. My plan was to take this bike to a swap meet next weekend, so I am somewhat glad I discovered the problem as I donít want to hide something from someone. I just got tired of seeing such a fine bike sitting there waiting for someone to trash it as a beater.
A man walks into a co-op and says "I need a crankset for a frame with stripped/crossthreaded/JBwelded pedal threads", the guy behind the counter looks over at a frame sitting on the floor and says "so do we".
merziac is offline
Old 04-30-21, 04:34 PM
  #5
sd5782
Senior Member
Thread Starter

Join Date: Jan 2019
Location: Toledo Ohio
Posts: 1,035

Bikes: 1964 Frejus,1972 Fuji Newest, 1973 Schwinn Super Sport, 1983 Trek 700, 1985 Ironman, 1985 Torpado, 1983 Peugeot UO14, 1989 Miyata 1000LT and others

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 368 Post(s)
Liked 400 Times in 219 Posts
I know about just slapping on the crankset and that will surely be the cure but it’s a small co-op so none there. Bike swap meet next weekend but mostly catering to vintage balloon tire bikes formerly sponsored by Memory Lane Classics in NW Ohio. The real tragedy is that the bike is ALL STOCK right down to the foam grips, Avocet touring saddle, both racks, and even the owners manual. It would be nice to bite the bullet and see if a repair to those pretty cranks can be done. If not, I might just pirate the front rack for my 89.
sd5782 is offline
Old 04-30-21, 06:37 PM
  #6
clubman
Youngman Grand

clubman's Avatar

Join Date: Jan 2010
Location: Nova Scotia
Posts: 8,309

Bikes: roadsters, club bikes, fixed and classic

Mentioned: 121 Post(s)
Tagged: 0 Thread(s)
Quoted: 2120 Post(s)
Liked 1,516 Times in 971 Posts
Edit. Yes nice cranks and they'll be one along soon enough. Lot's of triples available until you find one.
clubman is offline
Old 04-30-21, 07:02 PM
  #7
Pompiere
Senior Member

Pompiere's Avatar

Join Date: Nov 2005
Location: NW Ohio
Posts: 2,962

Bikes: 1984 Miyata 310, 1986 Schwinn Sierra, 2011 Jamis Quest, 1980 Peugeot TH8 Tandem, 1992 Performance Parabola, 1987 Ross Mt. Hood, 1988 Schwinn LeTour, 1988 Trek 400T, 1981 Fuji S12-S LTD

Mentioned: 20 Post(s)
Tagged: 0 Thread(s)
Quoted: 351 Post(s)
Liked 326 Times in 213 Posts
I'm hoping the Memory Lane swap picks up some of the vendors from Ann Arbor, since they were canceled. I'll be heading over on Thursday morning.
Pompiere is offline
Old 04-30-21, 07:04 PM
  #8
Prostyler
Old school Bmx'r

Prostyler's Avatar

Join Date: Apr 2021
Location: Ohio
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Liked 16 Times in 6 Posts
Originally Posted by sd5782 View Post
I know about just slapping on the crankset and that will surely be the cure but itís a small co-op so none there. Bike swap meet next weekend but mostly catering to vintage balloon tire bikes formerly sponsored by Memory Lane Classics in NW Ohio. The real tragedy is that the bike is ALL STOCK right down to the foam grips, Avocet touring saddle, both racks, and even the owners manual. It would be nice to bite the bullet and see if a repair to those pretty cranks can be done. If not, I might just pirate the front rack for my 89.
where's the swap meet ?
I'm in North Canton
Prostyler is offline
Old 04-30-21, 07:13 PM
  #9
Cougrrcj
Over forty victim of Fate

Cougrrcj's Avatar

Join Date: Jul 2011
Location: NE Ohio
Posts: 3,890

Bikes: A few...

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 620 Post(s)
Liked 368 Times in 255 Posts
Steve, if it doesn't sell this weekend, I have a couple of suitable triple cranksets laying around in my parts bin... I'd have to see what exactly they are though...
__________________
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time

Cougrrcj is offline
Old 04-30-21, 07:39 PM
  #10
sd5782
Senior Member
Thread Starter

Join Date: Jan 2019
Location: Toledo Ohio
Posts: 1,035

Bikes: 1964 Frejus,1972 Fuji Newest, 1973 Schwinn Super Sport, 1983 Trek 700, 1985 Ironman, 1985 Torpado, 1983 Peugeot UO14, 1989 Miyata 1000LT and others

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 368 Post(s)
Liked 400 Times in 219 Posts
Thanks for the replies and some offers. Bike show is in Bowling Green Ohio at the fairgrounds May 6-9th. Toledo Ohio craigslist had a flyer posting a couple days ago. Traditionally the vendors like to pack up Friday but I have read that there is a flea market going on that weekend too, so maybe they will stick around a bit longer. Internet shows a tool with taps and inserts, so maybe the LBS has that. Pics on weekend when cleaned up a bit. Bearings and such have been fine on disassembly so far. Interesting difference between this 82 and my 89.

An interesting aside is about the size. At 5’10” I ride 57-58 cm. My 89 is a 57, but my stem and seat tube adjustments show that I could ride a 60 with that bike. The 63cm has a 34” stand over, but the top tube is closer to 58cm and the seat tube is closer to 62 or less. Interesting how the frame angles can throw some of the sizing rules aside. Fun to work on such a fine machine either way.
sd5782 is offline
Old 05-01-21, 09:00 AM
  #11
sd5782
Senior Member
Thread Starter

Join Date: Jan 2019
Location: Toledo Ohio
Posts: 1,035

Bikes: 1964 Frejus,1972 Fuji Newest, 1973 Schwinn Super Sport, 1983 Trek 700, 1985 Ironman, 1985 Torpado, 1983 Peugeot UO14, 1989 Miyata 1000LT and others

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 368 Post(s)
Liked 400 Times in 219 Posts
Pics on valuation site

As promised, I cleaned the bike up just a bit and posted pics and asked for values. Milo, I may take you up on a crank, unless perhaps I find one at the swap meet, or sell the bike as it is. I am going Saturday morning as I am a working man. The action with that crowd is Thursday and Friday, but I am hoping some stick around for the weekend.
sd5782 is offline
Old 05-01-21, 12:04 PM
  #12
dddd
Ride, Wrench, Swap, Race

dddd's Avatar

Join Date: Jan 2010
Location: Northern California
Posts: 8,488

Bikes: Cheltenham-Pedersen racer, Boulder F/S Paris-Roubaix, Varsity racer, '52 Christophe, '62 Continental, '92 Merckx, '75 Limongi, '76 Presto, '72 Gitane SC, '71 Schwinn SS, etc.

Mentioned: 122 Post(s)
Tagged: 0 Thread(s)
Quoted: 1255 Post(s)
Liked 777 Times in 549 Posts
Can you post a picture or link to the exact crankset?

Re-threading is imo a machine-shop operation, due to the need for keeping the pedal axis perfectly parallel with the bottom bracket axis.

On the other hand, I've used stripped crankarms for long periods of mtb use after using LocTite red to secure the pedal threads and after counter-sinking the crankarm to allow a couple of inner threads to engage. I was shocked how well this worked (found the LX crankset in the trash). The trick was to make it clean and to literally fill the annular space between threaded parts with no air space. I cured it fast using a hair drier then left it for 24hrs.
I subsequently removed the pedal with a wrench to facilitate pedal bearing service, re-did the "glue" job and ride it to this day.
It might also be helpful to first source pedals with slightly longer threading, but I used SPD pedals and simply increased the threaded engagement by countersinking the hole slightly. I didn't need to adjust my cleats at all to give shoe clearance to the arm.

dddd is offline
Old 05-01-21, 04:42 PM
  #13
oneclick
Senior Member

Join Date: Feb 2020
Posts: 2,053
Mentioned: 34 Post(s)
Tagged: 0 Thread(s)
Quoted: 764 Post(s)
Likes: 0
Liked 810 Times in 497 Posts
Originally Posted by dddd View Post
On the other hand, I've used stripped crankarms for long periods of mtb use after using LocTite red...
If the op is going to try this, he should run the pedal in from the back side first, to clean/form the threads on the outer portion somewhat.
oneclick is offline
Old 05-01-21, 05:18 PM
  #14
sd5782
Senior Member
Thread Starter

Join Date: Jan 2019
Location: Toledo Ohio
Posts: 1,035

Bikes: 1964 Frejus,1972 Fuji Newest, 1973 Schwinn Super Sport, 1983 Trek 700, 1985 Ironman, 1985 Torpado, 1983 Peugeot UO14, 1989 Miyata 1000LT and others

Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 368 Post(s)
Liked 400 Times in 219 Posts
Actually the drive side crank arm is beyond stripped as a 9/16 pedal will just go right in and touch no metal. It was held in by JB Weld. The non drive side Is cross threaded on an angle. I saw some videos of a Unior threading kit that the die first opens the whole up to 5/8” and then cuts the threads for an insert that is the proper 9/16” size. It seemed like an acceptable solution for even a hobbyist but isn’t financially practical for one crank unless it was something pretty special. I would think that shops that deal a lot with vintage stuff may even have these. I believe I saw another brand too. I wonder if this service is available with sending cranks out somewhere.
sd5782 is offline
Old 05-01-21, 05:57 PM
  #15
clubman
Youngman Grand

clubman's Avatar

Join Date: Jan 2010
Location: Nova Scotia
Posts: 8,309

Bikes: roadsters, club bikes, fixed and classic

Mentioned: 121 Post(s)
Tagged: 0 Thread(s)
Quoted: 2120 Post(s)
Liked 1,516 Times in 971 Posts
A decent mechanic/machinest can add a helicoil insert that would hold, it you want to keep it original. It shouldn't be fussy and too expensive, relative to replacement.
clubman is offline
Likes For clubman:
Old 05-01-21, 09:36 PM
  #16
Cougrrcj
Over forty victim of Fate

Cougrrcj's Avatar

Join Date: Jul 2011
Location: NE Ohio
Posts: 3,890

Bikes: A few...

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 620 Post(s)
Liked 368 Times in 255 Posts
Originally Posted by sd5782 View Post
As promised, I cleaned the bike up just a bit and posted pics and asked for values. Milo, I may take you up on a crank, unless perhaps I find one at the swap meet, or sell the bike as it is. I am going Saturday morning as I am a working man. The action with that crowd is Thursday and Friday, but I am hoping some stick around for the weekend.
One is a used early 80s- vintage Sakae SX with 52-46-28 chainrings and 170mm arms that is showing some moderate wear on the outer ring, less on the middle, and none at all on the inner ring. Arms look like new, but I haven't looked at the pedal threads! I also haven't looked for a date code if there is one...

I'll have to dig to find the other one - but if I am remembering it right it is modern enough that it has pins. .. I seem to remember that it might have steel chainrings... I probably bought it new ~20 years ago to have a replacement should one of my square-taper triples go bad/ wear out, but it is still unused.
__________________
'75 Fuji S-10S bought new, 52k+ miles and still going!
'84 Univega Gran Tourismo
'84 Univega Viva Sport
'86 Miyata 710
'90 Schwinn Woodlands
Unknown brand MTB of questionable lineage aka 'Mutt Trail Bike'
Plus or minus a few others from time-to-time

Cougrrcj is offline
