Can This Seatpost Be Saved?

Notices
Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Can This Seatpost Be Saved?

Old 08-27-21, 12:17 PM
  #1
jdave5917
Senior Member
Thread Starter

Join Date: Feb 2010
Posts: 91
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 16 Post(s)
Liked 3 Times in 2 Posts
Can This Seatpost Be Saved?

I realize there is nothing special about the post, but it is original to the bike (1987 Schwinn Tempo - second photo) so I'd prefer to keep them together. Wondering if there is a safe/durable method of reattaching the clamp assembly to the post. Both mating surfaces are clean and smooth so I assume it was just a friction/compression fit, but not sure. I've thought of epoxy but believe the mating surfaces would have to be scuffed first to give that a chance of working. An alternate approach that I've considered is to drill a hole (maybe 1/8") to insert a pin in and then smooth and peen the edges of the pin to prevent it from moving. I think(??) that should be a reliable (if inelegant) approach. I'm thinking that the primary sheer forces would in the vertical direction and counteracted by the saddle mount bottoming out at the opening of the tube, so a failure due to those forces seems unlikely. Just a home mechanic here with my own bike, so not the usual shop liability concerns. Regardless, I will likely let go of it sooner rather than later, so I don't want to knowingly put another rider at risk.
Thoughts/suggestions/methods that have worked for you?

jdave5917 is offline
Old 08-27-21, 12:50 PM
  #2
merziac
Senior Member

merziac's Avatar

Join Date: Oct 2015
Location: PDX
Posts: 8,701

Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci/Ti x3, Gordon, Fuso/Moulton x2, Bornstein, Paisley,1958-74 Paramounts x3, 3rensho, 74 Moto TC, 73-78 Raleigh Pro's x5, Marinoni x2, 1960 Cinelli SC, 1980 Bianchi SC, PX-10 X 2

Mentioned: 167 Post(s)
Tagged: 0 Thread(s)
Quoted: 2660 Post(s)
Liked 1,967 Times in 1,321 Posts
@jdave5917

Most/all here would be a hard NO on this I think.

That being said, imo the pin and peen may work short term but not with out a back stop of epoxy/JB weld and still be very tenuous at best.

AND, do not pass it on, period.
merziac is offline
Likes For merziac:
Old 08-27-21, 12:58 PM
  #3
randyjawa
Senior Member

randyjawa's Avatar

Join Date: Apr 2007
Location: Thunder Bay, Ontario, Canada - burrrrr!
Posts: 10,968

Bikes: 1958 Rabeneick 120D, 1968 Legnano Gran Premio, 196? Torpado Professional, 2000 Marinoni Piuma

Mentioned: 188 Post(s)
Tagged: 0 Thread(s)
Quoted: 1143 Post(s)
Likes: 0
Liked 1,024 Times in 614 Posts
Were the post particularly rare or hard to get, I might be willing to give repair a shot. But, since it is not, then in my mind it is not worth the effort to repair nor is it worth taking a chance with one's safety by riding it. But that is just an old man's opinion and we all know what Mrs. Me thinks of that!-(
__________________
"98% of the bikes I buy are projects".
randyjawa is offline
Likes For randyjawa:
Old 08-27-21, 01:03 PM
  #4
noobinsf
Senior Member

noobinsf's Avatar

Join Date: Sep 2005
Location: Oakland, CA
Posts: 2,708

Bikes: '82 Univega Competizione, '72 Motobecane Grand Record, '83 Mercian KOM Touring, '85 Univega Alpina Uno, '76 Eisentraut Limited

Mentioned: 50 Post(s)
Tagged: 0 Thread(s)
Quoted: 852 Post(s)
Liked 678 Times in 446 Posts
That's a failure mode I would never want to experience. I would replace, and if keeping it original has sentimental value, just keep it and reinstall if it ever becomes a wall hanger. But I'd never ride that post if repaired.
noobinsf is offline
Old 08-27-21, 01:06 PM
  #5
3Roch
Senior Member

Join Date: Jul 2019
Location: far western MD
Posts: 93
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 39 Post(s)
Likes: 0
Liked 32 Times in 21 Posts
If it was the seat post on the E Merckx hour bike yeah maybe. But with all due respect it's just a schwinn seat post that could get someone hurt. Off to the recycle bin.
3Roch is offline
Old 08-27-21, 01:32 PM
  #6
Pcampeau
Senior Member

Join Date: Aug 2017
Location: Minneapolis
Posts: 553

Bikes: 1968 Raleigh Super Course. 1972 Raleigh Professional, 1975 Raleigh International, 1978 Raleigh Professional, 1985 Raleigh Prestige, 1972 Schwinn Paramount, 1980 Schwinn Voyageur 11.8, 1978 Schwinn Varsity, 1976 Peugeot PX10, 1972 Motobecane Le Champ

Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 181 Post(s)
Liked 220 Times in 129 Posts
Itís a Laprade seat post. You can easily find another one and nobody but you will know it wasnít original to the bike. If the bike wasnít yours from new, then perhaps itís already been replaced a time or two.
Pcampeau is offline
Likes For Pcampeau:
Old 08-27-21, 02:18 PM
  #7
Gary12000
Senior Member

Join Date: Apr 2021
Location: South Louisiana
Posts: 108

Bikes: '71 Raleigh Inter, '98 Tommasini, ' 79 Peugeot Super Comp, '82 Trek 714, '95 Trek 520

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 26 Post(s)
Liked 17 Times in 13 Posts
Find an identical seat post and install, make the original a wall hanger..
keep them together in case you ever sell or pass it on.

everyone is satisfied!!!
Gary12000 is offline
Old 08-27-21, 02:31 PM
  #8
SurferRosa
SeŮor Member

SurferRosa's Avatar

Join Date: Dec 2018
Location: Pac NW
Posts: 4,831

Bikes: Old school lightweights

Mentioned: 61 Post(s)
Tagged: 0 Thread(s)
Quoted: 1984 Post(s)
Liked 2,334 Times in 1,270 Posts
.

.
Still looks tall enough for several bikes I've seen here with that coveted "french fit."
SurferRosa is offline
Likes For SurferRosa:
Old 08-27-21, 02:35 PM
  #9
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 8,116

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400, 2013 Novara Randonee, 1990 Trek 970

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 1779 Post(s)
Liked 1,489 Times in 947 Posts
I had a similar seatpost off a same era Super Sport that was pinned at that joint. It had cracked at the pin.
I cut it down and repinned it with a new pin. 2 years so far so good.
dedhed is offline
Old 08-27-21, 02:48 PM
  #10
repechage
Senior Member

Join Date: Jun 2006
Posts: 16,486
Mentioned: 110 Post(s)
Tagged: 0 Thread(s)
Quoted: 2078 Post(s)
Liked 910 Times in 708 Posts
that is like a mtb length post...
I would cut off 3-4 cm, bbrasive clean both parts, then use a metal filled epoxy, then drill and pin it.

Actually, I would just look for an American classic or similar, So Much Lighter... That is a boat anchor.
repechage is offline
Old 08-27-21, 03:10 PM
  #11
verktyg
verktyg

verktyg's Avatar

Join Date: Jul 2006
Location: SF Bay Area
Posts: 3,730

Bikes: Current favorites: 1988 Peugeot Birraritz, 1984 Gitane Super Corsa, 1981 Bianchi Campione Del Mondo, 1992 Paramount OS, 1990 Bianchi Mondiale, 1988 Colnago Technos, 1985 RalieghUSA Team Pro, 1973 Holdsworth

Mentioned: 175 Post(s)
Tagged: 0 Thread(s)
Quoted: 896 Post(s)
Liked 744 Times in 455 Posts
2 Piece Seat Post Failure

NONONONO! UNSAFE AT ANY SPEED!

THINK OF WHAT'S AT RISK DOWN THERE!


The pressed in, swagged or pinned 2 piece style of seatpost construction was, is and always will be a "urine" poor design. Campy made some seatposts that way during their brief MTB misadventure - and they came apart that way too!

Seatposts are one of the most highly stressed parts of a bike! They support most of a rider's weight!

While I don't recall seeing one of those 2 piece alloy seatposts with a split or break at the top of the tube section, what I suspect happens is the constant pounding from road shock expands the top of the tube at the rear enough for the upper part to come loose.

Plastic reinforced carbon fiber seat posts are made that way too and from what I've seen, that's the most common place for failure.

My suggestion: recycle the pieces at separate times or places so that some nimrod doesn't find them and attempt a repair.

You can find 1 piece SR Laprade seatposts on eBay all of the time. Hone or sand the inside of the seat tube to remove any burrs - put something down the tube to keep gunk from getting into the BB.

Lastly, coat the bottom of the seatpost and top of the seat tube with a glob of grease to avoid "HELP! MY SEATPOST IS STUCK!".



dedhed repechage Are you guys looking to compete for the Darwin Award? "HEY! WATCH THIS!"...

verktyg
__________________
Don't believe everything you think! History is written by those who weren't there....

Chas. ;-)


Last edited by verktyg; 08-27-21 at 03:29 PM.
verktyg is offline
Likes For verktyg:
Old 08-27-21, 05:16 PM
  #12
jdave5917
Senior Member
Thread Starter

Join Date: Feb 2010
Posts: 91
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 16 Post(s)
Liked 3 Times in 2 Posts
Originally Posted by SurferRosa View Post
.

.
Still looks tall enough for several bikes I've seen here with that coveted "french fit."
Best reply so far!. Funny...But thought provoking.. Looking for the hacksaw.
jdave5917 is offline
Likes For jdave5917:
Old 08-27-21, 05:23 PM
  #13
sdn40
Senior Member

Join Date: Sep 2016
Location: Green Bay, WI
Posts: 629

Bikes: 88 Cannondale Criterium

Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 281 Post(s)
Liked 132 Times in 82 Posts
I'd be much more worried about keeping my seatpost original to my body than the Schwinn's
sdn40 is offline
Old 08-27-21, 06:34 PM
  #14
smontanaro
Senior Member

Join Date: Aug 2007
Location: Evanston, IL
Posts: 4,692

Bikes: many

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 959 Post(s)
Liked 491 Times in 310 Posts
I'll offer an alternate perspective. My Griffon has an interesting seatpost, a Campy Record with a titanium shaft:



Bob Freeman takes trashed Campy seatposts, chops off the shaft at a certain point, turns the remainder down and epoxies a new titanium shaft to the stub. I don't know how long the stub is or how tight the fit is without the glue, but I trust Bob to do the right thing. (He's made quite a few of these, with — as far as I know — no problems.) Strava tells me I have about 1500 miles on the bike, and thus the seatpost. I am out of town for the weekend, but can make some measurements next week. If your shaft was an interference fit, I rather suspect that it can be epoxied back together.
__________________
Slowest Common Denominator
I prefer you contact me by email (skip.montanaro@gmail.com).

smontanaro is offline
Old 08-27-21, 07:21 PM
  #15
jdave5917
Senior Member
Thread Starter

Join Date: Feb 2010
Posts: 91
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 16 Post(s)
Liked 3 Times in 2 Posts
Originally Posted by smontanaro View Post
I'll offer an alternate perspective. My Griffon has an interesting seatpost, a Campy Record with a titanium shaft:



Bob Freeman takes trashed Campy seatposts, chops off the shaft at a certain point, turns the remainder down and epoxies a new titanium shaft to the stub. I don't know how long the stub is or how tight the fit is without the glue, but I trust Bob to do the right thing. (He's made quite a few of these, with ó as far as I know ó no problems.) Strava tells me I have about 1500 miles on the bike, and thus the seatpost. I am out of town for the weekend, but can make some measurements next week. If your shaft was an interference fit, I rather suspect that it can be epoxied back together.
Some impressive handiwork right there!
jdave5917 is offline
Old 08-27-21, 08:02 PM
  #16
scarlson
Senior Member

scarlson's Avatar

Join Date: Jun 2010
Location: Medford MA
Posts: 1,491

Bikes: Ron Cooper touring, 1959 Jack Taylor 650b ladyback touring tandem, Vitus 979, Joe Bell painted Claud Butler Dalesman, Colin Laing curved tube tandem, heavily-Dilberted 1982 Trek 6xx, Renť Herse tandem

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 685 Post(s)
Liked 830 Times in 465 Posts
Originally Posted by smontanaro View Post
I'll offer an alternate perspective. My Griffon has an interesting seatpost, a Campy Record with a titanium shaft:



Bob Freeman takes trashed Campy seatposts, chops off the shaft at a certain point, turns the remainder down and epoxies a new titanium shaft to the stub. I don't know how long the stub is or how tight the fit is without the glue, but I trust Bob to do the right thing. (He's made quite a few of these, with ó as far as I know ó no problems.) Strava tells me I have about 1500 miles on the bike, and thus the seatpost. I am out of town for the weekend, but can make some measurements next week. If your shaft was an interference fit, I rather suspect that it can be epoxied back together.
Yeah, wow, I want to make one now!
__________________
Owner & co-founder, Cycles Renť Hubris. Unfortunately attaching questionable braze-ons to perfectly good frames since about 2015. With style.
scarlson is offline
Old 08-27-21, 09:09 PM
  #17
repechage
Senior Member

Join Date: Jun 2006
Posts: 16,486
Mentioned: 110 Post(s)
Tagged: 0 Thread(s)
Quoted: 2078 Post(s)
Liked 910 Times in 708 Posts
Originally Posted by verktyg View Post
NONONONO! UNSAFE AT ANY SPEED!

THINK OF WHAT'S AT RISK DOWN THERE!


The pressed in, swagged or pinned 2 piece style of seatpost construction was, is and always will be a "urine" poor design. Campy made some seatposts that way during their brief MTB misadventure - and they came apart that way too!

Seatposts are one of the most highly stressed parts of a bike! They support most of a rider's weight!

While I don't recall seeing one of those 2 piece alloy seatposts with a split or break at the top of the tube section, what I suspect happens is the constant pounding from road shock expands the top of the tube at the rear enough for the upper part to come loose.

Plastic reinforced carbon fiber seat posts are made that way too and from what I've seen, that's the most common place for failure.

My suggestion: recycle the pieces at separate times or places so that some nimrod doesn't find them and attempt a repair.

You can find 1 piece SR Laprade seatposts on eBay all of the time. Hone or sand the inside of the seat tube to remove any burrs - put something down the tube to keep gunk from getting into the BB.

Lastly, coat the bottom of the seatpost and top of the seat tube with a glob of grease to avoid "HELP! MY SEATPOST IS STUCK!".



dedhed repechage Are you guys looking to compete for the Darwin Award? "HEY! WATCH THIS!"...

verktyg
I did recí buy an alternative.
it is an interesting failure, I have seen the Campagnolo / titanium hybrids before, a reasonably sound approach with the correct adhesive.
repechage is offline
Old 08-27-21, 09:56 PM
  #18
polymorphself
Senior Member

Join Date: Oct 2017
Posts: 1,486
Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 595 Post(s)
Liked 597 Times in 304 Posts
Iíve seen this seat post more than any other. They are a dime a dozen (seems like they are on every mid range Japanese bike from the 80s) and very cheaply had. I couldnít imagine bothering to attempt a repair and riding it, especially if Iím sure Iíll be moving the bike along to someone else soon enough.
polymorphself is offline
Old 08-27-21, 09:57 PM
  #19
canopus
Senior Member

canopus's Avatar

Join Date: Mar 2009
Location: Kingwood, TX
Posts: 1,540

Bikes: Road, Touring, BMX, Cruisers...

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 116 Post(s)
Liked 142 Times in 89 Posts
Know anyone that TIG welds aluminum? Easy fix.
__________________
1984 Cannondale ST
1985 Cannondale SR300
1980 Gary Littlejohn Cruiser
1984 Trek 760
1981 Trek 710
Pics
canopus is offline
Old 08-27-21, 10:34 PM
  #20
thook
(rhymes with spook)

thook's Avatar

Join Date: Aug 2009
Location: Winslow, AR
Posts: 2,523

Bikes: '83 univega gran turismo x2, '85 schwinn super le tour,'89 miyata triple cross, '91 GT tequesta, '90 yokota grizzly peak, '94 GT backwoods, '95'ish scott tampico, '98 bonty privateer, '93 mongoose crossway 625, '98 parkpre ariel, 2k'ish giant fcr3

Mentioned: 23 Post(s)
Tagged: 0 Thread(s)
Quoted: 784 Post(s)
Liked 590 Times in 439 Posts
there's a lot of criticism....or was...that a steer tube for a fork that is/was either too short or busted couldn't safely be repaired/spliced. it can. the seat post could be too in much the same manner. and, it'd be safe. thing is you'll see the repair on the post whereas with the fork (that i've seen) you can't. not only is the repair hidden by submersion in the frame, but it's steel. in the video i've seen, it's shown how that was done. i doubt it could be done so nicely with aluminum, though. moreover, the fork i refer to is rare. that post is not....sentiment or not.
thook is offline
Old 08-28-21, 07:40 PM
  #21
73StellaSX76
Senior Member

Join Date: Mar 2015
Location: Redwood City, CA
Posts: 245

Bikes: 2016 SOMA DCD, 2014 Niner RLT9, 2008 Ibis Silk SL, 1998 Ibis Spanky, 1973 Stella SX76

Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 60 Post(s)
Liked 70 Times in 42 Posts
If you really want to save it, instead of pinning it consider drill and tapping and installing a couple 5mm button head screws fore and aft, epoxy the joint and the threads too, that should hold it.

Here is a titanium replacement sleeve I press-fit and bonded to a Dura Ace seat post 15-20 years ago. it's held, although this is no longer my prime ride.
73StellaSX76 is offline
Old 08-29-21, 01:48 AM
  #22
verktyg
verktyg

verktyg's Avatar

Join Date: Jul 2006
Location: SF Bay Area
Posts: 3,730

Bikes: Current favorites: 1988 Peugeot Birraritz, 1984 Gitane Super Corsa, 1981 Bianchi Campione Del Mondo, 1992 Paramount OS, 1990 Bianchi Mondiale, 1988 Colnago Technos, 1985 RalieghUSA Team Pro, 1973 Holdsworth

Mentioned: 175 Post(s)
Tagged: 0 Thread(s)
Quoted: 896 Post(s)
Liked 744 Times in 455 Posts
Welding Cast luminum To Wrought Aluminum

Originally Posted by canopus View Post
Know anyone that TIG welds aluminum? Easy fix.
It can be done, but....

Wrought aluminum alloy 6061 is the metal most commonly used on non-cast bicycle parts. It's produced to have a very low amount of impurities thus providing uniform strength and a quality finish.

Cast aluminum alloy 356 and A356 is the most common alloy for cast parts. Large pieces like automotive castings are frequently produced using sand casting processes. Smaller or more precise parts are made with pressure casting equipment. Those parts are cast to reduce or eliminate most machining thus reducing manufacturing costs. The cast alloys were never formulated to be welded.

The Japanese euphemistically called this "melt forging" !!!

6061 and 356/A356 alloys have similar properties and chemical make up but wrought 6061 is generally about 10%-15% stronger.

Cast aluminum products can be made of high quality "virgin" metal but they can also contain lots of impurities which cause what could be described as microscopic bubbles in the metal. These impurities are what can make cast aluminum difficult to weld.

At 400į most aluminum looses it's heat treated strength. The metal on both sides of the weld in the HAZ (Heat Affected Zone) loose it's original heat treated strength.

Link to a 12+ minute video demonstrating welding cast aluminum. Worth watching if you are interested in learning the why's - skip to 1:27:


verktyg

"HEY! WATCH THIS!" The cry of aspiring Darwin Award Candidates!
__________________
Don't believe everything you think! History is written by those who weren't there....

Chas. ;-)


Last edited by verktyg; 08-29-21 at 01:55 AM.
verktyg is offline
Old 08-29-21, 04:32 AM
  #23
smontanaro
Senior Member

Join Date: Aug 2007
Location: Evanston, IL
Posts: 4,692

Bikes: many

Mentioned: 51 Post(s)
Tagged: 0 Thread(s)
Quoted: 959 Post(s)
Liked 491 Times in 310 Posts
Originally Posted by verktyg View Post
Link to a 12+ minute video demonstrating welding cast aluminum. Worth watching if you are interested in learning the why's - skip to 1:27:

https://www.youtube.com/watch?v=zvHq2YCfMp4

verktyg

"HEY! WATCH THIS!" The cry of aspiring Darwin Award Candidates!
Thanks for the video link. Will definitely watch.

As for Darwin Award candidate lingo, I believe the current term of art is, "Hold my beer..."
__________________
Slowest Common Denominator
I prefer you contact me by email (skip.montanaro@gmail.com).

smontanaro is offline
Old 08-29-21, 10:58 AM
  #24
Vintage_Cyclist
Senior Member

Vintage_Cyclist's Avatar

Join Date: Nov 2013
Location: Big Apple
Posts: 1,476

Bikes: yes

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 439 Post(s)
Likes: 0
Liked 171 Times in 85 Posts
Why even consider risking a grotesque, medieval-style impalement over an easily replaced bicycle part?

Chinese boy impaled on his seat tube after freak accident

BMX rider impaled by bike airlifted to safety in California

Although, if you google 'impaled by bicycle', it's far more common for handlebars and brake levers to be catastrophically inserted into humans.

Teen Gets 'Inverted' Scrotum and 'Degloved' Penis After Being Impaled on Bike Handlebars
Vintage_Cyclist is offline
Old 08-29-21, 06:40 PM
  #25
verktyg
verktyg

verktyg's Avatar

Join Date: Jul 2006
Location: SF Bay Area
Posts: 3,730

Bikes: Current favorites: 1988 Peugeot Birraritz, 1984 Gitane Super Corsa, 1981 Bianchi Campione Del Mondo, 1992 Paramount OS, 1990 Bianchi Mondiale, 1988 Colnago Technos, 1985 RalieghUSA Team Pro, 1973 Holdsworth

Mentioned: 175 Post(s)
Tagged: 0 Thread(s)
Quoted: 896 Post(s)
Liked 744 Times in 455 Posts
Vlad

Originally Posted by Vintage_Cyclist View Post
Why even considaer risking a grotesque, medieval-style impalement over an easily replaced bicycle part?

Chinese boy impaled on his seat tube after freak accident

BMX rider impaled by bike airlifted to safety in California


Vlad "The Impaler"




PROTECT THE JUNK! You only get one set!

verktyg
__________________
Don't believe everything you think! History is written by those who weren't there....

Chas. ;-)

verktyg is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright © 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
