Help IDing old Peugeot road bike

Old 10-14-21, 01:30 PM
  #1
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
Help IDing old Peugeot road bike

Hi, hope I'm in the right place, apologies if not.
I just picked up this old Peugeot road bike to restore, it only cost 50 quid and I like these old bikes so seemed a fun project.
Can anyone ID this model? I've done some searching using the info I have but not getting anything. I haven't even come across one in this colour. It was listed as 1970s and it's was made in France if that helps. It has a simplex rear derailleur (which may or may not need replacing, I need to give it a proper look) Weinmann brakes, and a pretty snazzy red metal Peugeot badge mounted on the front (my other Peugeot just had a sticker) not sure if any of that info helps with ID
It needs a new back brake too so I'd be grateful if someone could point me in the direction of a compatible model.
Cheers!

Patrick


Oh, it seems I'm not allowed to attach a picture...how annoying.

Last edited by Patrick398; 10-14-21 at 01:34 PM.
Patrick398 is offline
Old 10-14-21, 01:34 PM
  #2
cb400bill
Follow Your Arrow

cb400bill's Avatar

Join Date: Jul 2007
Location: Kalamazoo MI
Posts: 19,743

Bikes: Fuji SL2.1 Carbon Di2 Cannondale Synapse Alloy 4 Trek Checkpoint ALR gravel Viscount Aerospace Pro

Mentioned: 46 Post(s)
Tagged: 0 Thread(s)
Quoted: 2530 Post(s)
Liked 3,375 Times in 2,050 Posts
Originally Posted by Patrick398 View Post
Can anyone ID this model?
__________________
How did we get here?





cb400bill is offline
Old 10-14-21, 01:44 PM
  #3
thumpism
Bikes are okay, I guess.

thumpism's Avatar

Join Date: Jan 2015
Location: Richmond, Virginia
Posts: 7,492

Bikes: Waterford Paramount Touring, Giant CFM-2, Raleigh Sports 3-speeds in M23 & L23, Schwinn Cimarron oddball build, Marin Palisades Trail dropbar conversion, Nishiki Cresta GT

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 2143 Post(s)
Liked 1,037 Times in 759 Posts
Welcome! Looks like a UO-8 but with different wheels. I don't think we got them in that color. If you can find a little white sticker taped to the frame it should have the model number and size and serial number on it. Pretty standard Peugeot practice.

Last edited by thumpism; 10-14-21 at 01:47 PM.
thumpism is offline
Old 10-14-21, 01:55 PM
  #4
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
Thank you for posting the picture, some kind of witchcraft that was!

Thanks for the welcome and the replies. Ok that gives me something to go at. I guess I was hoping it was going to turn out to be a gem I'd got at a bargain price but maybe not. The fancy badge on the front got me excited.

On the underside of the top tube there's two hook/lug things, one near the handlebars one near the seat. I can't for the life of me work out what they are. There's also some kind of mounting lug near where the back brakes would sit, I assume that something to do with the rear brake mounting?

Apologies for my ignorance on bike anatomy, I'm learning gradually.
Patrick398 is offline
Old 10-14-21, 02:23 PM
  #5
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
Aha! The lugs on the top tube are pump mounts. Interesting that they would build these directly onto the frame.

Ok that just leaves the lug by the rear brake and another lug I have just noticed on the rear fork...maybe a reflector mounting lug?
Patrick398 is offline
Old 10-14-21, 02:56 PM
  #6
cb400bill
Follow Your Arrow

cb400bill's Avatar

Join Date: Jul 2007
Location: Kalamazoo MI
Posts: 19,743

Bikes: Fuji SL2.1 Carbon Di2 Cannondale Synapse Alloy 4 Trek Checkpoint ALR gravel Viscount Aerospace Pro

Mentioned: 46 Post(s)
Tagged: 0 Thread(s)
Quoted: 2530 Post(s)
Liked 3,375 Times in 2,050 Posts
Those braze ons are probably for a rear rack.
__________________
How did we get here?





cb400bill is offline
Old 10-14-21, 02:56 PM
  #7
T-Mar
Senior Member

Join Date: Nov 2004
Posts: 21,742
Mentioned: 570 Post(s)
Tagged: 1 Thread(s)
Quoted: 4091 Post(s)
Likes: 0
Liked 1,673 Times in 1,183 Posts
There's a generator tab on the non-drive side seat stay, so it should be the UK equivalent of a UE8. Decal scheme suggests late 1970s.
T-Mar is offline
Old 10-14-21, 03:39 PM
  #8
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
Originally Posted by cb400bill View Post
Those braze ons are probably for a rear rack.
I've been looking at some pictures and I think you're right. Although mine only seems to have one. The lower lug I think is a dynamo mount.
Patrick398 is offline
Old 10-14-21, 03:42 PM
  #9
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
Originally Posted by T-Mar View Post
There's a generator tab on the non-drive side seat stay, so it should be the UK equivalent of a UE8. Decal scheme suggests late 1970s.
Yeah I just found a picture of a similar model with the generator fitted. It certainly looks very similar to the UE8 but they all seem to have the pump mount on the down tube, I don't know if that is a significant detail.

There's also some pretty nice patterned engraving on the handlebars. Is that standard for these bikes?
Patrick398 is offline
Old 10-14-21, 04:06 PM
  #10
jdawginsc
Edumacator

Join Date: Jan 2018
Location: Goose Creek, SC
Posts: 2,531

Bikes: '87 Crestdale, '87 Basso Gap, '92 Rossin Performance EL-OS, Faggin Matrix thingy

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 765 Post(s)
Liked 612 Times in 418 Posts
Originally Posted by Patrick398 View Post
Yeah I just found a picture of a similar model with the generator fitted. It certainly looks very similar to the UE8 but they all seem to have the pump mount on the down tube, I don't know if that is a significant detail.

There's also some pretty nice patterned engraving on the handlebars. Is that standard for these bikes?
Pump pegs often were dependent on the frame size. Sometimes they were on the seat-tube, more often on the top tube to open the other two tubes up for water bottle cages.

However, you are right, most pump pegs on Uo8s I have seen on here are on the down tube.
__________________
1987 Crest Cannondale, 1987 Basso Gap, 1992 Rossin Performance EL, 1990ish Van Tuyl, 1980s Vanni Losa Cassani thingy, 1985 Trek 670, 1982 AD SLE, 2003 Pinarello Surprise, 1990ish MBK Atlantique, 1987 Peugeot Competition, 1987 Nishiki Tri-A, Need to do an N -1...


jdawginsc is online now
Likes For jdawginsc:
Old 10-16-21, 10:14 AM
  #11
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
so after about 3 days of searching I can confidently state that I am now one of those chumps trying to work out how to fit a rear brake to these bikes. I've read forum after forum and searched high and low and i don't actually think I've seen this issue properly resolved.
There is one of the adapter things for sale on eBay for 60 or something which just seems ridiculous.
None of the mafac racer calipers I'm seeing have the adapter so I feel like I'm running out of options.
Just use the front brake and lean back?

Edit: I should clarify for those not aware, the rear caliper mounting hole is drilled vertically, in line with the forks. This requires an adapter that the rear caliper attaches to and then the adapter attached vertically into the hole.

Last edited by Patrick398; 10-16-21 at 10:17 AM.
Patrick398 is offline
Old 10-16-21, 11:09 AM
  #12
verktyg
verktyg

verktyg's Avatar

Join Date: Jul 2006
Location: SF Bay Area
Posts: 3,627

Bikes: Current favorites: 1988 Peugeot Birraritz, 1984 Gitane Super Corsa, 1981 Bianchi Campione Del Mondo, 1992 Paramount OS, 1990 Bianchi Mondiale, 1988 Colnago Technos, 1985 RalieghUSA Team Pro, 1973 Holdsworth

Mentioned: 172 Post(s)
Tagged: 0 Thread(s)
Quoted: 849 Post(s)
Liked 626 Times in 392 Posts
Mafac Vertical Rear Caliper Mount Ref 478E

Originally Posted by Patrick398 View Post
so after about 3 days of searching I can confidently state that I am now one of those chumps trying to work out how to fit a rear brake to these bikes. I've read forum after forum and searched high and low and i don't actually think I've seen this issue properly resolved.
There is one of the adapter things for sale on eBay for 60 or something which just seems ridiculous.
None of the mafac racer calipers I'm seeing have the adapter so I feel like I'm running out of options.
Just use the front brake and lean back?

Edit: I should clarify for those not aware, the rear caliper mounting hole is drilled vertically, in line with the forks. This requires an adapter that the rear caliper attaches to and then the adapter attached vertically into the hole.
The part that you are looking for is Ref 478E. They were used with Mafac RAID, RACER and "S" model brakes on bikes with fenders. The ones that I saw were on French Mixte model bikes like Gitanes and Peugeots.




Good luck finding one. They were as rare as.... (quand les poules auront des dents)



I'd check French eBay or other selling websites. Also you might be able to find a cheap "donor bike" that has one of those mounts.

Also, if you are a paid Bike Forum member, you can post a WTB (Want To Buy) or ISO (In Search Of) message in the Classic and Vintage Sales Sub-forum and the ISO and trade Sticky thread section.

verktyg
__________________
Don't believe everything you think! History is written by those who weren't there....

Chas. ;-)


Last edited by verktyg; 10-16-21 at 11:31 AM.
verktyg is offline
Old 10-16-21, 11:35 AM
  #13
Patrick398
Junior Member
Thread Starter

Join Date: Oct 2021
Posts: 21
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 9 Post(s)
Liked 4 Times in 1 Post
Thank you for the information, hopefully I can put it to good use. I did find a caliper on french eBay which at least looks like it could work, it has a very similar looking adapter but I don't recognise the name and searching doesn't yield many results.

I'm not allowed to post URLs yet but this is the title of the listing: Jaws Brake M. D.L.Sylvator. Bike Vintage. New Nos. Mercier Peugeot Expert
Patrick398 is offline
Old 10-16-21, 03:09 PM
  #14
juvela
Senior Member

juvela's Avatar

Join Date: Feb 2013
Location: Alta California
Posts: 11,150
Mentioned: 310 Post(s)
Tagged: 1 Thread(s)
Quoted: 2646 Post(s)
Liked 993 Times in 769 Posts
-----

this livery is termed by the manufacturer "champagne"...and yes we did receive it here in L'Amerique du Nord



-----
